Bryston BR20 Firmware Update Instructions

Hide thumbs Also See for BR20:

Download this manual

BR20 Firmware Update Instructions:

1. Download the appropriate .bin file and save it to a local computer.

You can find the latest .bin file at this link:

2. Attach an Ethernet cable to the Ethernet SERVICE port on the back of the BR20 (the one closest to the

power line cord) – You can borrow the Streamer's Ethernet cable for this process if you need to.

3. Open any browser on your computer (preferably chrome) and type in

window.

4. You should see a device listed as BR20BCN (with your serial #) click on that box.

5. This will take you to the main GUI of the firmware. From here, click on the MENU button in the top

right corner and then FIRMWARE UPDATE

6. On the next screen you want to click on UPDATE FIRMWARE near the bottom.

Then on the following screen, click CHOOSE FILE (point it to where you saved the previous .bin file)

then click the UPDATE FIRMWARE button and wait for the progress bar to complete.

http://support.bryston.com/downloads/BR-20/firmware/

www.mybryston.com

in the URL

Page 1 2. Attach an Ethernet cable to the Ethernet SERVICE port on the back of the BR20 (the one closest to the power line cord) – You can borrow the Streamer’s Ethernet cable for this process if you need to.
Page 2 7. The BR20’s front panel will go through a series of flashing and solid LED displays. PLEASE do not interrupt this process. When the upload is complete the unit will reboot itself. At this point you can refresh the BCON GUI and verify that the update completed by looking at the Firmware version # at the bottom of the screen.
