Power Blower
Operator's Manual
MODEL
Read rules for safe operation and all instructions carefully. ECHO provides this Operator's
Manual which must be read and understood for proper and safe operation.
X7501138700
PB-231LN
Serial Number 002001001 - 02999999
WARNING
DANGER
X750001120
08/00

Advertisement

Table of Contents
loading

Summary of Contents for Echo PB-231LN

  • Page 1 Power Blower Operator's Manual MODEL PB-231LN Serial Number 002001001 - 02999999 WARNING DANGER Read rules for safe operation and all instructions carefully. ECHO provides this Operator's Manual which must be read and understood for proper and safe operation. X750001120 X7501138700 08/00...
  • Page 2: Table Of Contents

    NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual. You will find it easy to use and full of helpful operating tips and SAFETY messages.
  • Page 3: Manual Safety Symbols And Important Information

    Make sure the decals are legible and that you understand and follow the instructions on them. If a decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information.
  • Page 4: International Symbols

    ATTACHMENTS • Do not use blower if any part is missing or damaged. • Have repairs done only by an authorized ECHO Service dealer. • Do not use any attachment, accessory or replacement part unless it is recommended in this Operator's Manual.
  • Page 5: Fuel

    IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. Contact your ECHO dealer for ordering information. After Refueling; • Wipe any spilled fuel from the unit.
  • Page 6 Breathing Protection -- Wear a face mask to protect against dust. Hearing Protection -- ECHO recommends wearing hearing protection whenever unit is used. Proper Clothing -- Wear snug fitting, durable clothing; • Pants should have long legs, shirts with long sleeves.
  • Page 7: Safe Operation

    OWER LOWER PERATOR ANUAL SAFE OPERATION Determine Operation Area -- • Do not operate this product indoors or in inadequately ventilated areas. • Review area to be cleared. Look for potential hazards such as stones or metal objects. • Spectators and fellow workers must be warned, and children and animals prevented from coming nearer than 15m (50 ft.) while the blower is in use.
  • Page 8: Extended Operation/Extreme Conditions

    EXTENDED OPERATION EXTREME CONDITIONS Vibration and Cold -- It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals may be brought about by exposure to vibration and cold. Exposure to vibration and cold may cause tingling and burning sensations followed by loss of color and numbness in the fingers.
  • Page 9: Description

    Maintenance Section of this manual. CONTENTS 1 - Power Head 1 - Blower Pipe Assembly 1 - Operator's Manual 1 - Warranty Registration Card 1 - ECHO Emissions and Warranty Statement 1 - Bottle ECHO 2-Stroke Oil Mix...
  • Page 10 1. STOP SWITCH - "SLIDE SWITCH" mounted on top of handle. Push forward to start and run. Slide back to stop. 2. THROTTLE TRIGGER - Spring loaded to return to idle when released. During acceleration, press trigger gradually for best operating technique. 3.
  • Page 11: Specifications

    Spark Arrestor Muffler w / Catalyst Fuel Mixed (Gasoline and Two-stroke Oil) Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil Gasoline 89 Octane unleaded. DO NOT use fuel containing methyl alcohol, more than 10% ethyl alcohol or 15% MTBE.
  • Page 12: Assembly

    50:1 oil meets this standard. Engine problems due to inadequate lubrication caused by failure to use an ISO-L-EGD and J.A.S.O. FC certified oil, such as Echo Premium 50:1 Two-stroke Oil, will void the two-stroke engine warranty. (Emission related parts only are covered for two years, regardless of two-stroke oil used, per the statement listed in the California Emission Defect Warranty Explanation.)
  • Page 13 IMPORTANT Spilled fuel is a leading cause of hydrocarbon emissions. Some states may require the use of automatic fuel shut-off containers to reduce fuel spillage. Contact your ECHO dealer for ordering information. After Refueling - •...
  • Page 14: Operation

    PERATION • Provide all operators of this equipment with the Operator's Manual and instructions for safe operation. • Before starting the unit, equip yourself and any other person working (50 ft.) within the 15m (50 ft.) Safety Zone with the required Protective Equipment and clothing.
  • Page 15: Starting Warm Engine

    2. Move stop switch (A) to "STOP" position. WARNING DANGER If engine does not stop when stop switch is moved to STOP position, close choke - COLD START position - to stall engine. Have your ECHO dealer repair stop switch before using blower again.
  • Page 16: Operating Blower

    OPERATING BLOWER WARNING DANGER Always wear safety glasses, hearing protection and a face filter mask or serious personal injury may result. . Do not point the blower pipe in the direction of people or pets. Read the Safety Section carefully. IMPORTANT To avoid engine damage due to over revving, do not block blower pipe.
  • Page 17: Maintenance

    ECHO para el mantenimiento. Se ha clasificado cada tarea de mantenimiento para que decida si desea hacer el mantenimiento USTED o el distribuidor de ECHO. Si la tarea no está...
  • Page 18: Air Filter

    AIR FILTER Level 1. Tools required: 25-50 mm (1-2 in.) medium bristle paint brush. Parts required: 90030 REPOWER Air and Filter Kit NOTE Clean daily. 1. Close choke (Cold Start Position). This prevents dirt from entering the carburetor throat when the air filter is removed. Brush accumulated dirt from the air cleaner area.
  • Page 19: Spark Plug

    OWER LOWER PERATOR ANUAL WARNING DANGER Muffler and catalytic mufflers operate at extremely high tempera- tures. Muffler area must be kept clean. Do not perform maintenance on the engine or muffler until engine and muffler are completely cool, otherwise serious personal injury may occur. SPARK PLUG Level 2.
  • Page 20: Exhaust System

    Cleaning Grill 1. Brush accumulated debris from crankcase intake grill above the fuel tank. Cleaning Cylinder Fins 1. Remove two upper 3 mm hex screws at recoil starter. 2. Remove four engine cover screws and remove cover from engine. Clean cylinder fins to allow cooling air to pass freely. 3.
  • Page 21: Carburetor Adjustment

    The cylinder exhaust port must be inspected and cleaned of excess carbon every 3 months or 90 hours of operation in order to maintain this engine within the emissions durability period. ECHO strongly recommends that you return your unit to your ECHO dealer for this important maintenance service. CARBURETOR ADJUSTMENT...
  • Page 22: Troubleshooting

    No fuel at Fuel strainer clogged Clean Cranks carburetor carburetor Fuel line clogged Clean Carburetor See your ECHO dealer Fuel at No fuel at Carburetor See your ECHO dealer cylinder cylinder Fuel Mixture is too rich Muffler wet Open choke...
  • Page 23: Storage

    7. Remove the spark plug and pour 7cc (1/4 oz., 1/2 tablespoon) of fresh, clean ECHO 2-stroke engine oil into the cylinder through the spark plug hole. A. Place a clean cloth over the spark plug hole.
  • Page 24: Servicing Information

    Operator's Manual made payable to ECHO, INCORPORATED. State on a sheet of paper model number and serial number of the ECHO unit you have, part number of the manual (if known), your name and address and mail to address above: Available Parts Lists PB-231LN S/N 002001001 &...
