Page 1 300 SRT8 2 0 0 8 O W N E R ’ S M A N U A L...
Page 2 VEHICLES SOLD IN CANADA With respect to any Vehicles Sold in Canada, the name Chrysler LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution therefor. DRIVING AND ALCOHOL Drunken driving is one of the most frequent causes of accidents.
Page 3: Introduction
TABLE OF CONTENTS SECTION ............. 3 INTRODUCTION THINGS TO KNOW BEFORE STARTING YOUR VEHICLE UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 5: Table Of Contents
CONTENTS Introduction ......4 How To Use This Manual ....4 Warnings And Cautions .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION This manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your new vehicle. It is supplemented by a Warranty Information Booklet and various customer-oriented documents. You are urged to read these publications carefully.
Page 7 INTRODUCTION 5...
Page 8: Vehicle Identification Number
The Vehicle Identification Number (VIN) is on the left front corner of the instrument panel. The VIN is visible from outside of the vehicle through the windshield. This number also appears on the Automobile Information VIN Location Disclosure Label affixed to a window on your vehicle, the NOTE: It is illegal to remove the VIN.
Page 9: Vehicle Modifications / Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS / ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to an accident resulting in serious injury or death.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS A Word About Your Keys ....12 Wireless Ignition Node (WIN) ... . .12 FOB With Integrated Key .
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Unlatch The Trunk ....22 Using The Panic Alarm ....22 Programming Additional Transmitters .
Page 13 Driver And Front Passenger Supplemental Restraint System (SRS) - Airbag ... .49 Event Data Recorder (EDR) ....62 Child Restraint .
Page 14: Things To Know Before Starting Your Vehicle 9
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Your vehicle uses a keyless ignition system. This system consists of a Fob with Integrated Key and a Wireless Ignition Node (WIN) with integral ignition switch. You can insert the double-sided integrated key into the igni- tion switch with either side up.
Page 15: Fob With Integrated Key
Fob with Integrated Key The Fob with Integrated Key operates the ignition switch. It also contains the Remote Keyless Entry (RKE) trans- mitter and a valet key, which stores in the rear of the Fob. The valet key allows for entry into the vehicle should the battery in the vehicle or the Fob go dead.
Page 16: Tip Start Feature
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Tip Start Feature Do not press the accelerator. Use the Fob with Integrated Key to briefly turn the ignition switch to the START position and release it as soon as the starter engages. The starter motor will continue to run, and it will disengage automatically when the engine is running.
Page 17: Key-In-Ignition Reminder
Key-In-Ignition Reminder If you open the driver’s door and the key is in the ignition, a chime will sound to remind you to remove the key. NOTE: The Key-In-Ignition reminder only sounds when the ignition key is placed in the LOCK or ACC position.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • The Sentry Key Immobilizer System is not compat- ible with aftermarket remote starting systems. Use of these systems may result in vehicle starting problems and loss of security protection. • Exxon/Mobil SpeedPass™, additional fobs, or any other transponder-equipped components on the same key chain will not cause a fault unless the additional part is physically held against the fob being used to...
Page 19: Customer Sentry Key (Fob) Programming
procedure. This procedure consists of programming a blank fob to the vehicle electronics. A blank fob is one that has never been programmed. NOTE: When having the Sentry Key System serviced, bring all vehicle fobs with you to the authorized dealer. Customer Sentry Key (Fob) Programming If you have two valid Sentry Keys , you can program new Sentry Keys...
Page 20: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: If a programmed key is lost, see your authorized dealer to have all remaining keys erased from the sys- tem’s memory. This will prevent the lost key from starting your vehicle. The remaining keys must then be reprogrammed.
Page 21: To Arm The System
To Arm the System Remove the key from the ignition switch and either press a power door LOCK switch while the driver or passenger door is open or press the LOCK button on the Remote Keyless Entry (RKE) transmitter. After the last door is closed, or if all doors are closed, the system will arm itself in about 16 seconds.
Page 22: Illuminated Entry System
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the alarm system is armed and the battery becomes disconnected the system will remain armed when the battery is reconnected. The exterior lights will flash, the horn will sound, and the ignition will not start the vehicle.
Page 23: To Unlock The Doors
Remote Keyless Entry (RKE) Transmitter To unlock the doors: Press and release the UNLOCK button on the transmitter once to unlock the driver’s door, or twice within five seconds to unlock all doors. The turn signal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on.
Page 24: To Lock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Turn Headlights On with Remote Key Unlock This feature activates the headlights for up to 90 seconds when the doors are unlocked with the transmitter. The time for this feature is programmable. For details, refer to “Turn Headlights On with Remote Key Unlock,”...
Page 25: Programming Additional Transmitters
NOTE: • The interior lights will turn off if you turn the ignition switch to the ACC or ON position while the Panic Alarm is activated. However, the exterior lights and horn will remain on. • You may need to be less than 35 ft (11 m) from the vehicle when using the transmitter to turn off the Panic Alarm due to the radio frequency noises emitted by the system.
Page 26: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Battery Replacement 2. Remove and replace the batteries. Avoid touching the new batteries with your fingers. Skin oils may cause battery deterioration. If you touch a battery, clean it with rubbing alcohol. 3.
Page 27: Remote Starting System - If Equipped
2. Closeness to a radio transmitter such as a radio station tower, airport transmitter, and some mobile or CB radios. REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry (RKE) trans- mitter to start the engine conveniently from outside the vehicle while still maintaining security.
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For security, power window and power sunroof op- eration (if so equipped) are disabled when the vehicle is in the REMOTE START mode. • The engine can be started two consecutive times (two 15 minute cycles) with the RKE transmitter.
Page 29: Door Locks
To Turn Off the Engine While in REMOTE START Mode Press and release the REMOTE START button one time. NOTE: To avoid inadvertent shut downs, the system will disable the one time press of the REMOTE START button for two seconds after receiving a valid REMOTE START request.
Page 30: Power Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • For personal security and safety in the event of an accident, lock the vehicle doors before you drive as well as when you park and leave the vehicle. • When leaving the vehicle, always remove the key from the ignition and lock your vehicle.
Page 31 If you press the power door LOCK switch while the key is in the ignition, and any front door is open, the power locks will not operate. This prevents you from acciden- tally locking the key in the vehicle. Removing the key or closing the door will allow the locks to operate.
Page 32: Child Protection Door Lock
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Unlock Doors on Exit The doors will unlock automatically on vehicles with power door locks if: 1. The Automatic Unlock Doors On Exit feature is en- abled 2. The transmission was in gear and the vehicle speed returned to 0 mph (0 km/h) 3.
Page 33 To Engage the Child Protection Door Lock System 1. Open the rear door. 2. Insert the tip of the valet key (or alike) into the child lock control and pull it upward. Child Lock Control 3. Repeat Steps 1 and 2 for the opposite rear door. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 NOTE: When the Child Protection Door Lock system is engaged, the door can be opened only by using the...
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For emergency exit with the system engaged, move the door LOCK switch to the UNLOCK position, roll down the window and open the door with the outside door handle. To Disengage the Child Protection Door Lock System 1.
Page 35: Windows
WINDOWS Power Windows The window controls on the driver’s door control all the door windows. Power WINDOW Switches THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 There are single window controls on each passenger door trim panel, which operate the passenger door windows. The window controls will operate only when the ignition switch is in the ON or ACC position.
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE AUTO-Down Feature The driver door power WINDOW switch and some model passenger door power WINDOW switches have an AUTO-down feature. Press the WINDOW switch to the second detent, release, and the window will go down automatically.
Page 37 The power WINDOW switches will remain active for up to 60 minutes after the ignition switch is turned off. Opening either front door will cancel this feature. The time for this feature is programmable. Refer to “Delay Power Off to Accessories Until Exit,” under “Personal Settings (Customer Programmable Features),”...
Page 38: Wind Buffeting
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Window LOCKOUT Switch Reset Anytime the vehicle battery is disconnected or goes dead, the AUTO-up function will be disabled. To reactivate the auto-up feature, perform the following steps after vehicle power is restored: 1.
Page 39: Trunk Lock And Release
TRUNK LOCK AND RELEASE The trunk lid can be released from inside the vehicle by pressing the TRUNK RELEASE Button located on the instrument panel to the left of the steering wheel. NOTE: The transmission must be in PARK before the switch will operate.
Page 40: Trunk Safety Warning
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE TRUNK SAFETY WARNING WARNING! Do not allow children to have access to the trunk, either by climbing into the trunk from outside, or through the inside of the vehicle. Always close the trunk lid when your vehicle is unattended.
Page 41: Occupant Restraints
OCCUPANT RESTRAINTS Some of the most important safety features in your vehicle are the restraint systems. These include the front and rear seat belts for the driver and all passengers, the front airbags for both the driver and front passenger, the optional supplemental side curtain airbags for the driver and passengers seated next to a window, and the optional supplemental front seat mounted side airbags.
Page 42: Lap/Shoulder Belts
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Research has shown that seat belts save lives, and they can reduce the seriousness of injuries in a collision. Some of the worst injuries happen when people are thrown from the vehicle. Seat belts reduce the possibility of ejection and the risk of injury caused by striking the inside of the vehicle.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 Lap/Shoulder Belt Operating Instructions 1. Enter the vehicle and close the door. Sit back and adjust the front seat. 2. The seat belt latch plate is above the back of your seat. Grasp the latch plate and pull out the belt.
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch plate into the buckle until you hear a “click.” Connecting Latch Plate To Buckle WARNING! • A belt that is buckled into the wrong buckle will not protect you properly.
Page 45 4. Position the lap belt across your thighs, below your abdomen. To remove slack in the lap belt portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. The belt will automatically retract to its stowed position. If necessary, slide the latch plate down the webbing to allow the belt to retract fully. WARNING! A frayed or torn belt could rip apart in a collision and leave you with no protection.
Page 47: Lap/Shoulder Belt Untwisting Procedure
Adjusting Upper Shoulder Belt As a guide, if you are shorter than average you will prefer a lower position, and if you are taller than average you will prefer a higher position. When you release the anchorage try to move it up and down to make sure that it is locked in position.
Page 48: Seat Belt Pretensioners
46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioners The seat belts for both front seating positions are equipped with pretensioning devices that are designed to remove any slack from the seat belts in the event of a collision.
Page 49: Automatic Locking Mode - If Equipped
1. With all doors closed, and the ignition switch in any position except ON or START, buckle the driver’s seat belt. 2. Turn the ignition switch to the ON position, but do not start the engine. Wait for the Seat Belt Reminder Light to turn off and then proceed to the next step.
Page 50: Seat Belts And Pregnant Women
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE How To Engage The Automatic Locking Mode 1. Buckle the combination lap and shoulder belt. 2. Grasp the shoulder portion and pull downward until the entire belt is extracted. 3. Allow the belt to retract. As the belt retracts, you will here a clicking sound.
Page 51: Driver And Front Passenger Supplemental Restraint System (Srs) - Airbag
WARNING! Using a seat belt extender when not needed can increase the risk of injury in a collision. Only use when the seat belt is not long enough when it is worn low and snug and in the recommended seating posi- tions.
Page 52 50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The front airbags have a multistage inflator design. This may allow the airbag to have different rates of inflation that are based on collision severity. WARNING! • Do not put anything on or around the front airbag covers or attempt to open them.
Page 53 Window Airbag NOTE: Airbag covers may not be obvious in the interior trim, but they will open to allow airbag deployment. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 If the vehicle is equipped with supplemental front seat mounted side airbags, they are marked with an SRS label sewn into the outboard side of the seat.
Page 54 52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • If your vehicle is equipped with supplemental front seat mounted side airbags, do not use accessory seat covers or place objects between you and the seat airbags; the perfor- mance could be adversely affected and/or objects could be pushed into you, causing serious injury.
Page 55 Here are some simple steps you can take to minimize the risk of harm from a deploying airbag. 1. Children 12 years old and younger should ride buck- led up in the rear seat. WARNING! Infants in rear-facing child restraints should NEVER ride in the front seat of a vehicle with a passenger front airbag.
Page 56 54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 8. If your vehicle has supplemental side curtain airbags and/or supplemental front seat mounted side airbags, do not lean against the door, as the airbags will inflate forcefully into the space between you and the door. 9.
Page 57 Airbag System Components The airbag system consists of the following: • Occupant Restraint Controller (ORC) • Side Remote Acceleration Sensors (if equipped) • Airbag Warning Light • Driver Airbag • Front Passenger Airbag • Supplemental Side Curtain Airbags above side win- dows (if equipped) •...
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The ORC also monitors the readiness of the electronic parts of the system whenever the ignition switch is in the START or ON positions. These include all of the items listed above except the knee bolster, the instru- ment panel, and the steering wheel and column.
Page 59 separate and fold out of the way as the bags inflate to their full size. The bags fully inflate in about 50 to 70 ms. This is about half of the time that it takes to blink your eyes. The bags then quickly deflate while helping to restrain the driver and front passenger.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE seam in the seat’s trim cover and opens into the space between the occupant and the door. The airbag inflates at a very high speed and with enough force to injure you if you are not belted and seated properly, or if items are positioned in the area where the front seat mounted side airbag inflates.
Page 61 WARNING! Unapproved modifications or service procedures to the front seat assembly, its related components, or seat cover may inadvertently change the airbag de- ployment in case of a frontal crash. This could result in death or serious injury to the driver or front seat passenger if the vehicle is involved in an accident.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • As the airbags deflate, you may see some smoke-like particles. The particles are a normal by-product of the process that generates the nontoxic gas used for airbag inflation. These airborne particles may irritate the skin, eyes, nose, or throat.
Page 63 Maintaining Your Airbag System WARNING! • Modifications to any part of the airbag system could cause it to fail when you need it. You could be injured because the airbags are not there to protect you. Do not modify the components or wiring, including adding any kind of badges or stickers to the steering wheel hub trim cover or the upper passenger side of the instrument...
Page 64: Event Data Recorder (Edr)
62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Event Data Recorder (EDR) In the event of an accident, your vehicle is designed to record up to five seconds of specific vehicle data param- eters (see the following list) in an event data recorder prior to the moment of airbag deployment, or near deployment, and up to a quarter second of high-speed deceleration data during and/or after airbag deploy-...
Page 65 may be released for incorporation in aggregate crash databases, such as those maintained by the US govern- ment and various states. Data of a potentially sensitive nature, such as would identify a particular driver, ve- hicle, or crash, will be treated confidentially. Confidential data will not be disclosed by DaimlerChrysler Corporation to any third party except when: 1.
Page 66: Child Restraint
64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Traction/stability control status • Tire Pressure Monitoring System status (if equipped) Child Restraint Everyone in your vehicle needs to be buckled up all the time, including babies and children. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
Page 67 Infants and Child Restraints • Safety experts recommend that rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg). Two types of child restraints can be used rearward-facing, infant carriers and convertible child seats. •...
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The belt-positioning booster seat is for children weighing more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit with knees bent over the vehicle’s seat cushion while the child’s back is against the seatback, they should use a belt-positioning booster seat.
Page 69 WARNING! • Improper installation can lead to failure of an infant or child restraint. It could come loose in a collision. The child could be badly injured or killed. Follow the manufacturer’s directions ex- actly when installing an infant or child restraint. •...
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE LATCH — Child Seat Anchorage System (Lower Anchors and Tether for CHildren) Your vehicle’s rear seat is equipped with the child restraint anchorage system called LATCH. The LATCH system provides for the installation of the child restraint without using the vehicle’s seat belts, instead securing the child restraint using lower anchorages and upper tether straps from the child restraint to the vehicle...
Page 71 LATCH Anchorages Installing the LATCH-Compatible Child Restraint System We urge you to follow the manufacturer’s directions carefully when installing your child restraint. Not all child restraint systems will be installed as described here. THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 Again, carefully follow the installation instructions that are provided with the child restraint system.
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE means of adjusting the tension in the strap. Forward- facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a hook for attachment to the tether strap anchorage and a means of adjusting the tension of the strap.
Page 73 WARNING! Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be badly injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint. Installing Child Restraints Using the Vehicle Seat Belt The passenger seat belts are equipped with either cinch-...
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE In the rear seat, you may have trouble tightening the lap/shoulder belt on the child restraint because the buckle or latch plate is too close to the belt path opening on the restraint. Disconnect the latch plate from the buckle and twist the short buckle end belt several times to shorten it.
Page 75: Break-In Recommendations
NOTE: Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap. WARNING! An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.
Page 76: Safety Tips
74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The engine oil, transmission fluid, and axle lubricant installed at the factory is high-quality and energy- conserving. Oil, fluid, and lubricant changes should be consistent with anticipated climate and conditions under which vehicle operations will occur. The recommended viscosity and quality grades is shown in Section 7.
Page 77: Lock Your Vehicle
Lock Your Vehicle Always remove the key from the ignition and lock all doors when leaving the vehicle unattended, even in your own driveway or garage. Try to park your vehicle in a well-lit area and never invite theft by leaving articles of value exposed.
Page 78: Safety Checks You Should Make Inside The Vehicle
76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! • Exhaust gases can injure or kill. They contain carbon monoxide (CO) which is colorless and odorless. Breathing it can make you unconscious and can eventually poison you. To avoid breathing (CO), follow the safety tips below.
Page 79: Periodic Safety Checks You Should Make Outside The Vehicle
Defroster Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to feel the air directed against the windshield. See your authorized dealer for service if your defroster is inoper- able. Periodic Safety Checks You Should Make Outside The Vehicle Tires...
Page 81 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS Mirrors .......84 Automatic Dimming Inside Mirror ..84 Outside Mirrors .
Page 82 80 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Recognition System (VR) — If Equipped . . 115 Voice Recognition System (VR) Operation ..115 Commands ......116 Voice Training .
Page 83 Lights-On Reminder ....136 Fog Lights ......137 Multifunction Lever .
Page 84 82 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adaptive Cruise Control (ACC) — If Equipped ......153 Adaptive Cruise Control (ACC) Operation .
Page 85 Troubleshooting Tips ....183 General Information ....183 Power Sunroof —...
Page 86: Mirrors
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS Automatic Dimming Inside Mirror This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn the feature on or off by pressing the button at the base of the mirror. A light next to the button will illuminate to indicate when the dimming feature is activated.
Page 87: Outside Mirrors
CAUTION! To avoid damage to the mirror during cleaning, never spray any cleaning solution directly onto the mirror. Apply the solution onto a clean cloth and wipe the mirror clean. Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic and a slight overlap of the view obtained from the inside mirror.
Page 88: Driver's-Side Outside Mirror Auto Dimmer
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Driver’s-Side Outside Mirror Auto Dimmer This mirror automatically adjusts for annoying headlight glare from vehicles behind you. You can turn this feature on or off by pressing the button at the base of the inside rearview mirror.
Page 89: Heated Remote Control Mirrors
After selecting a mirror, move the knob in the same direction you want the mirror to move. Use the center off position to guard against accidentally moving a mirror position. Power Mirror Control UNDERSTANDING THE FEATURES OF YOUR VEHICLE 87 NOTE: For vehicles equipped with Driver Memory Seat, you can use your Remote Keyless Entry (RKE) Transmitter or the MEMORY switch on the driver’s door...
Page 90: Illuminated Vanity Mirrors
88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Illuminated Vanity Mirrors An illuminated vanity mirror is on the sun visor. To use the mirror, rotate the sun visor downward and swing the mirror cover upward. The light turns on automatically. Closing the mirror cover turns off the light. Illuminated Vanity Mirror HANDS-FREE COMMUNICATION (UConnect ) —...
Page 91 NOTE: For UConnect customer support, visit the following websites: • www.chrysler.com/uconnect • www.dodge.com/uconnect • www.jeep.com/uconnect • or call 1–877–855–8400 UConnect allows you to transfer calls between the system and your cellular phone as you enter or exit your vehicle and enables you to mute the system’s microphone for private conversation.
Page 92: Operation
90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Recognition Button Actual button location may vary with radio. The individual buttons are described in the “Operation” section. The UConnect system can be used with any Hands-Free Profile certified Bluetooth cellular phone. See the UConnect website for supported phones.
Page 93 • For each feature explanation in this section, only the combined form of the voice command is given. You can also break the commands into parts and say each part of the command when you are asked for it. For example, you can use the combined form voice com- mand Phonebook New Entry, or you can break the combined form command into two voice commands:...
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The following are general phone to UConnect system pairing instructions: • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Setup Phone Pairing. • When prompted, after the beep, say Pair a Phone and follow the audible prompts.
Page 95 Dial by Saying a Number • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Dial. • The system will prompt you to say the number you want to call. • For example, you can say 234-567-8901. The phone number that you enter must be of valid length and combination.
Page 96 94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Add Names to Your UConnect Phonebook NOTE: Adding names to the phonebook is recom- mended when the vehicle is not in motion. • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Phonebook New Entry.
Page 97 Object Exchange Profile (OBEX). Please see your phone Owner’s Manual for specific instructions on how to send these entries from your phone. NOTE: • The phone handset must support Bluetooth OBEX transfers of phonebook entries to use this feature. • Some phones cannot send phonebook entries if they are already connected to any system via Bluetooth , and you may see a message on the phone display that the Bluetooth link is busy.
Page 98 96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Phonebook Edit can be used to add another phone number to a name entry that already exists in the phonebook. For example, the entry John Doe may have a mobile and a home number, but you can add ”John Doe’s”...
Page 99: Phone Call Features
• After confirmation, the phonebook entries will be deleted. • Note that only the phonebook in the current language is deleted. List All Names in the UConnect Phonebook • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Phonebook List Names.
Page 100 98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the call, press and hold the PHONE button until you hear a single beep, indicating that the incoming call was rejected. Answer or Reject an Incoming Call - Call Currently in Progress If a call is currently in progress and you have another incoming call, you will hear the same network tones for call waiting that you normally hear when using your cell phone.
Page 101 Conference Call When two calls are in progress (one active and one on hold), press and hold the PHONE button until you hear a double beep indicating that the two calls have been joined into one conference call. Three-Way Calling To initiate three-way calling, press the “Voice Recogni- tion”...
Page 102: Uconnect System Features
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Continuation Call continuation is the progression of a phone call on the UConnect system after the vehicle ignition key has been switched to OFF. Call continuation functionality avail- able on the vehicle can be any one of three types: •...
Page 103 Emergency Assistance If you are in an emergency and the mobile phone is reachable: • Pick up the phone and manually dial the emergency number for your area. If the phone is not reachable and the UConnect system is operational, you may reach the emergency number as follows: •...
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: The Towing Assistance number dialed is based on the country where the vehicle is purchased (1-800-528- 2069 for the U.S., 1-877-213-4525 for Canada, 55-14-3454 for Mexico City and 1-800-712-3040 for outside Mexico City in Mexico).
Page 105 sequence of numbers, followed by Send, is also to be used for navigating through an automated customer service center menu structure, and to leave a number on a pager. You can also send stored UConnect phonebook entries as tones for fast and easy access to voice mail and pager entries.
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • After the Ready prompt and the following beep, say Setup Confirmations. The UConnect system will play the current confirmation prompt status and you will be given the choice to change it. Phone and Network Status Indicators If available on the radio and/or on a premium display such as the instrument panel cluster, and supported by your cell phone, the UConnect...
Page 107: Advanced Phone Connectivity
In order to un-mute the UConnect system: • Press the “Voice Recognition” button. • Following the beep, say Mute off. Advanced Phone Connectivity Transfer Call to and from Cellular Phone The UConnect system allows ongoing calls to be trans- ferred from your cellular phone to the UConnect system without terminating the call.
Page 108: Things You Should Know About Your Uconnect System
106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Select Another Cellular Phone This feature allows you to select and start using another phone paired with the UConnect system. • Press the PHONE button to begin. • After the Ready prompt and the following beep, say Setup Select Phone and follow the prompts.
Page 109 system Voice Training feature may be used. To enter this training mode, follow one of the two following proce- dures: From outside the UConnect mode (e.g., from radio mode): • Press and hold the “Voice Recognition” button for five seconds until the session begins, or, •...
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • low-to-medium vehicle speed, • low road noise, • smooth road surface, • fully closed windows, • dry weather condition. • Even though the system is designed for users speaking in North American English, French, and Spanish ac- cents, the system may not always work for some.
Page 111 • smooth road surface, • fully closed windows, • dry weather conditions, and • operation from the drivers seat. • Performance, such as audio clarity, echo, and loudness to a large degree rely on the phone and network, and not the UConnect system. •...
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111...
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE...
Page 115 Voice Commands Primary Alternate(s) zero three four five seven eight nine star (*) plus (+) pound (#) add location UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 Voice Commands Primary Alternate(s) call cancel confirmation prompts continue delete dial download edit emergency English erase all Espanol...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Voice Commands Primary Alternate(s) language list names list phones mobile mute mute off new entry pager pair a phone phone pairing pairing phonebook phone book previous record again redial Voice Commands Primary Alternate(s) return to main menu return or main menu select phone...
Page 117: General Information
General Information This device complies with part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration.
Page 118: Commands
116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you ever wish to interrupt the system while it lists options, press the VR hard-key, listen for the beep, and say your command. Pressing the VR hard-key while the system is speaking is known as “barging in.”...
Page 119 3. Use the ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the voice recognition system is speaking. Please note the volume setting for VR is different then the audio system. Main Menu Start a dialogue by pressing the VR hard-key. You may say MAIN MENU to switch to the main menu.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Satellite Radio To switch to satellite radio mode say SAT or SATELLITE RADIO. In this mode, you may say the following com- mands: • CHANNEL NUMBER (to change the channel by its spoken number) •...
Page 121: Voice Training
− CONTINUE (to continue recording) − DELETE (to delete the recording) • PLAY MEMOS (to play previously recorded memos) — During the playback you may press the VR hard- key to stop playing memos. You continue by saying one of the following commands: −...
Page 122: Seats
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SEATS Power Seats The power SEAT switch is on the outboard side of the seat near the floor. Use this switch to move the driver’s seat up or down, forward or rearward, or to tilt the seat. The passenger’s seat will move up or down, forward or rearward.
Page 123: Power Reclining Seats
WARNING! Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted and you could be injured. Adjust the seat only while the vehicle is parked. CAUTION! Do not place any article under a power seat as it may cause damage to the seat controls.
Page 124: Lumbar Support
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt and be seriously or even fatally injured. Use the recliner only when the vehicle is parked.
Page 125: Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 Head Restraints Head restraints can reduce the risk of whiplash injury in the event of impact from the rear. Adjust the restraint so that the upper edge is as high as practical. To raise it, pull upward on the head restraint.
Page 126: Heated Seats
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats Heated seats provide comfort and warmth on cold days and can help soothe sore muscles and backs. The heaters provide the same heat level for both cushion and back. The driver seat and front passenger seat are heated. The controls for each heater are located near the bottom center of the instrument panel.
Page 127: Folding Rear Seat
LEDs changes from two to one, indicating the change. Operation on the low setting also turns off automatically after 30 minutes. NOTE: Once a heat setting is selected, heat will be felt within two to five minutes. WARNING! Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion, or other physical conditions must exercise care...
Page 128: Driver Memory Seat - If Equipped
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap. WARNING! • Be certain that the seatback is securely locked into position.
Page 129: Programming The Memory Feature
Memory Switch Programming The Memory Feature To create a new memory profile, perform the following: NOTE: Saving a new memory profile will erase an existing profile from memory. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 1. Adjust all memory profile settings to desired prefer- ences (i.e., seat, side mirror, adjustable pedals, power tilt and telescopic steering column, and radio station pre- sets).
Page 130: Linking And Unlinking The Remote Keyless Entry (Rke) Transmitter To The Memory Feature
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Press and release the SET (S) button on the MEMORY switch, then press the side of the rocker switch labeled (2) within five seconds. The EVIC will display which memory position is being set. NOTE: Memory profiles can be set without the vehicle in PARK, but the vehicle must be in PARK to recall a memory profile.
Page 131: Memory Position Recall
NOTE: Your transmitters can be unlinked to your memory settings by pressing the SET (S) button followed by the UNLOCK button on the transmitter in Step 4 above. Memory Position Recall NOTE: The vehicle must be in PARK to recall memory positions.
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When you remove the key from the ignition switch, the driver seat will move about 2.4 in (60 mm) rearward if the driver seat position is greater than or equal to 2.7 in (67.7 mm) forward of the rear stop. The seat will return to its previously set position when you insert the key into the ignition switch and turn it out of the LOCK position.
Page 133: To Open And Close The Hood
TO OPEN AND CLOSE THE HOOD Two latches must be released to open the hood. First, pull the hood release lever located under the left side of the instrument panel. Hood Release Lever UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Next, move to the outside of the vehicle and push the safety catch to the left.
Page 134: Lights
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Use the hood prop rod (if equipped) to secure the hood in the open position. To prevent possible damage, do not slam the hood to close it. Lower the hood, until it is open approximately 6 in (15 cm), and then drop it.
Page 135: Automatic Headlights
HEADLIGHT Switch Rotate the HEADLIGHT switch clockwise to the first detent for parking light and instrument panel light operation. Turn it to the second detent for headlight, parking light, and instrument panel light operation. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Automatic Headlights This system automatically turns the headlights ON or OFF according to ambient light levels.
Page 136: Headlights On With Wipers
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE HEADLIGHT Switch NOTE: The engine must be running before the head- lights will come on in the automatic mode. Headlights On with Wipers When this feature is active, the headlights will turn on approximately 10 seconds after the wipers are turned ON if the HEADLIGHT switch is placed in the AUTO posi- tion.
Page 137 and automatically switches from high beams to low beams until the approaching vehicle is out of view. To Activate 1. Select “Automatic High Beams — ON” through the Electronic Vehicle Information Center (EVIC). Refer to “Automatic High Beams,” under “Personal Settings (Customer Programmable Features),”...
Page 138: Headlight Time Delay
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlight Time Delay This feature provides the safety of headlight illumination for up to 90 seconds (programmable) when leaving your vehicle in an unlit area. To activate the delay feature, turn OFF the ignition switch while the headlights are still on.
Page 139: Fog Lights
Fog Lights The front FOG LIGHT switch is on the HEAD- LIGHT switch below the dimmer control. To acti- vate the front fog lights, turn ON the parking lights or the low beam headlights and press the FOG LIGHT switch. An indicator light in the instrument cluster illuminates when the fog lights are turned ON.
Page 140: Overhead Console Map/Reading Lights
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Turn Signals Move the multifunction lever up or down and the corresponding turn signal indicator in the instrument cluster flashes to show proper operation of the front and rear turn signal lights. You can also signal a lane change by moving the lever partially up or down without moving beyond the detent.
Page 141: Interior Lights
Overhead Console Interior Lights The interior lights come on when a door is opened. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position. This will occur if the interior lights were switched ON manually or are on UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 because a door is open.
Page 142: Windshield Wipers And Washers
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Dome Light Position Rotate the dimmer control completely upward to the second detent to turn on the interior lights. The interior lights will remain on when the dimmer control is in this position. Interior Light Defeat (OFF) Rotate the dimmer control to the extreme bottom OFF position.
Page 143: Intermittent Wiper System
Rotate the end of the multifunction lever to the first detent past the intermittent settings for low speed wiper operation, or to the second detent past the intermittent settings for high speed wiper operation. CAUTION! Turn the windshield wipers off when driving through an automatic car wash.
Page 144: Windshield Washers
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Windshield Washers To use the washer, push the multifunction lever inward (toward the steering column) to the second detent and hold it for as long as washer spray is desired. If you activate the washer while the windshield wiper control is in the delay range, the wipers will operate for two wipe cycles after releasing the lever and then resume the intermittent interval previously selected.
Page 145 setting 5 or 6 if you desire more sensitivity. Place the lever in the OFF position when not using the system. NOTE: • The rain sensing feature will not operate when the wiper speed is in the LOW or HIGH position. •...
Page 146: Adding Washer Fluid
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adding Washer Fluid The windshield washer fluid reservoir is located in the front of the engine compartment. Be sure to check the fluid level in the reservoir at regular intervals. Fill the reservoir with windshield washer solvent (not radiator antifreeze) and operate the system for a few seconds to flush out the residual water.
Page 147: Headlight Washers - If Equipped
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. HEADLIGHT WASHERS — IF EQUIPPED The multifunction lever operates the headlight washers when the ignition switch is in the ON position and the headlights are ON.
Page 148: Adding Washer Fluid
146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adding Washer Fluid The headlight washer and windshield washer share the same fluid reservoir. The reservoir is located in the front of the engine compartment. Be sure to check the fluid level in the reservoir at regular intervals. Fill the reservoir with windshield washer solvent (not radiator antifreeze) and operate the system for a few seconds to flush out the residual water.
Page 149: Power Tilt/Telescoping Steering Column
WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution. POWER TILT/TELESCOPING STEERING COLUMN This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column.
Page 150: Adjustable Pedals
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: For vehicles equipped with Driver Memory Seat, you can use your Remote Keyless Entry (RKE) transmitter or the MEMORY switch on the driver’s door trim panel to return the tilt/telescopic steering column to pre-programmed positions.
Page 151 ADJUSTABLE PEDALS Switch Press the switch forward to move the pedals forward (toward the front of the vehicle). Press the switch rearward to move the pedals rearward (toward the driver). • The pedals can be adjusted with the ignition OFF. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 •...
Page 152: Electronic Speed Control
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls. Pedal travel may become lim- ited if movement is stopped by an obstruction in the adjustable pedal’s path.
Page 153: To Activate
To Activate Push and release the ON/OFF button located on the end of the speed control lever. The indicator light in the instrument cluster will illuminate to show that the speed control sys- tem is ON. To turn the system OFF, push and release the ON/OFF button again.
Page 154: To Deactivate
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Deactivate The system will disable electronic speed control without erasing the memory if you: • Softly tap the brake pedal, • Depress the brake pedal, or • Pull the speed control lever toward you to CANCEL. Pushing and releasing the ON/OFF button or turning off the ignition erases the set speed from memory.
Page 155: To Accelerate For Passing
To Accelerate For Passing Depress the accelerator as you would normally. When the pedal is released, the vehicle will return to the set speed. Using Speed Control on Hills NOTE: The speed control system maintains speed up and down hills. A slight speed change on moderate hills is normal.
Page 156 154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ACC will allow you to keep cruise control engaged in light to moderate traffic conditions without the constant need to reset your cruise control. ACC utilizes an infrared sensor designed to detect a vehicle directly ahead in your path.
Page 157: Adaptive Cruise Control (Acc) Operation
WARNING! You should switch off the ACC system: • When driving in fog; heavy rain; heavy snow; sleet; heavy traffic; and complex driving situations (i.e., in highway construction zones). • When entering a turn lane or highway off ramp; when driving on roads that are winding, icy, snow-covered, slippery, or have steep uphill or downhill slopes;...
Page 158: Activating Adaptive Cruise Control (Acc)
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Activating Adaptive Cruise Control (ACC) You can only activate ACC if the vehicle speed is above 25 mph (40 km/h). When the system is turned on and in the READY state, the Electronic Vehicle Information Center (EVIC) dis- plays “ACC READY.”...
Page 159: To Set A Desired Speed
To turn the system OFF, push and release the ON/OFF button again. At this time, the system will turn off and the EVIC will display “ACC OFF.” WARNING! Leaving the Adaptive Cruise Control (ACC) system on when not in use is dangerous. You could acciden- tally set the system or cause it to go faster than you want.
Page 160: To Cancel
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The system will not be controlling the distance be- tween your vehicle and the vehicle ahead. The vehicle speed will only be determined by the position of the accelerator pedal. To Cancel The system will disable ACC without erasing the memory if: •...
Page 161: To Turn Off
To Turn Off The system will turn off and erase the set speed in memory if: • You push and release the ON/OFF button. • You turn off the ignition. • You switch off ESP. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 To Resume Speed Push the lever up to RESUME ACCEL and release.
Page 162: To Vary The Speed Setting
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To Vary the Speed Setting While ACC is set, you can increase the set speed by lifting and holding the lever in RESUME ACCEL. If the lever is continually held, the set speed will continue to increase in 5 mph (Canada 10 km/h) increments until the lever is released.
Page 163: Setting The Following Distance In Acc
Setting the Following Distance in ACC The specified following distance for ACC can be set by varying the distance setting between long, medium, and short. Using this distance setting and the vehicle speed, ACC calculates and sets the distance to the vehicle ahead. This distance setting displays in the EVIC.
Page 164: Adaptive Cruise Control (Acc) Menu
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The distance setting is changed. • The system disengages. (Refer to the information on ACC Activation). The maximum braking applied by ACC is limited; how- ever, the driver can always apply the brakes manually, if necessary.
Page 165 Press the MENU button (located on the steer- ing wheel) repeatedly until one of the follow- ing displays in the EVIC: Menu Button ACC OFF − When ACC is deactivated, the display will read “ACC OFF.” UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163...
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ACC READY − When ACC is activated, the display will read “ACC READY.” ACC SET − When ACC is set, the set speed will display. 1 — Sensed Vehicle Indicator 2 — Set Speed 3 —...
Page 167: Display Warnings And Maintenance
The ACC SET screen will display once again if any ACC activity occurs, which may include any of the following: • Set speed change • Distance setting change • System cancel UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 • Acquisition/loss of Target •...
Page 168 166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If weather conditions are not a factor, the driver should examine the sensor. It may require cleaning or removal of an obstruction. The sensor is located behind the grille, slightly offset from the center of the grille. ACC Sensor Location To keep the ACC System operating properly, it is impor- tant to note the following maintenance items:...
Page 169 • Do not remove any screws from the sensor or the sensor mount. Doing so could cause an ACC system malfunction or failure and require a sensor re- alignment. • If the sensor is damaged due to an accident, see your authorized dealer for service.
Page 170: Precautions While Driving With Acc
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Service ACC Warning If the system turns off, and the EVIC displays “SERVICE ACC,” it indicates there is an internal system fault that requires service from an authorized dealer. Precautions While Driving with ACC In certain driving situations, ACC may have detection issues.
Page 171 Turns and Bends In turns or bends, ACC may detect a vehicle ahead too late or too early. This may cause your vehicle to brake late or unexpectedly. Give extra attention in curves and be ready to apply the brakes if necessary. Be sure to select an appropriate speed while driving in curves.
Page 172 170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lane Changing ACC will not detect a vehicle until it is completely in the lane in which you are traveling. In the illustration shown, ACC has not yet detected the vehicle changing lanes and it will not until it may be too late to take action.
Page 173 Narrow Vehicles Some narrow vehicles traveling near the outer edges of the lane or edging into the lane are not detected until they have moved fully into the lane. There will not be suffi- cient distance to the vehicle ahead. UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Stationary Objects and Vehicles ACC does not react to stationary objects and stationary...
Page 174: General Information
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE General Information CLASS 1 LASER PRODUCT Classification Specifications: 21 C.F.R part 1040.10 & 1040.11 DIN EN 60825-1:2003 IEC 60825-1:2001 REAR PARK ASSIST SYSTEM The Rear Park Assist System is a driver aid that senses for obstacles behind the vehicle.
Page 175 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 The warning display contains two sets of yellow and red LEDs, one set to warn of obstacles behind the left rear of the vehicle and the other set to warn of obstacles behind the right rear of the vehicle.
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING DISPLAY DISTANCES DISPLAY LED OBSTACLE DISTANCE FROM: REAR CORNERS 1st LED 2nd LED 3rd LED 4th LED 31.5 in (80 cm) 5th LED 25.5 in (65 cm) 6th LED 20 in (50 cm) 7th LED 16 in (40 cm) 8th LED...
Page 177 WARNING! • Drivers must be careful when backing up even when using the Rear Park Assist System. Always check carefully behind your vehicle, look behind you, and be sure to check for pedestrians, animals, other vehicles, obstructions, and blind spots before backing up.
Page 178: Overhead Console
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • Ensure that the rear bumper is free of dirt and debris to keep the system operating properly. • Jackhammers, large trucks, and other vibrations could affect the performance of the system. If “Service Park Assist System”...
Page 179: Sunglasses Storage
These lights also turn on when a door is opened, or when the UNLOCK button on the Remote Keyless Entry (RKE) transmitter is pressed, or when the dimmer control is turned fully upward, past the second detent. Sunglasses Storage At the rear of the console, a compartment is provided for the storage of a pair of sunglasses.
Page 180: Programming Homelink
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people or pets are in the path of the door or gate. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 181 It is recommended that a new battery be placed in the hand-held transmitter of the device being programmed to HomeLink for more efficient training and accurate transmission of the radio-frequency signal. Your vehicle should be parked outside of the garage while training.
Page 182 180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: After training a HomeLink garage door does not operate with HomeLink and the garage door opener was manufactured after 1995, the garage door opener may have rolling code. If so, proceed to the heading “Programming A Rolling Code System.” 5.
Page 183: Gate Operator/Canadian Programming
7. Return to the vehicle and press the programmed HomeLink button twice (holding the button for two seconds each time). If the device is plugged in and activates, programming is complete. If the device does not activate, press the button a third time (for two seconds) to complete the training.
Page 184: Using Homelink
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Then proceed with Step 4 under “Programming HomeLink ” earlier in this section. Using HomeLink To operate, simply press and release the programmed HomeLink button. Activation will now occur for the trained device (i.e., garage door opener, gate operator, security system, entry door lock, home/office lighting, etc.) The hand-held transmitter of the device may also be used at any time.
Page 185: Troubleshooting Tips
Troubleshooting Tips If you are having trouble programming HomeLink , here are some of the most common solutions: • Replace the battery in the original transmitter. • Press the learn button on the garage door opener to complete the training for rolling code. •...
Page 186: Power Sunroof - If Equipped
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED The power SUNROOF switch is located between the sun visors on the overhead console. Power Sunroof Controls WARNING! • Never leave children in a vehicle with the key in the ignition switch.
Page 187: Opening Sunroof - Express
Opening Sunroof - Express Press the switch rearward and release, and the sunroof will open automatically from any position. The sunroof will open fully and then stop automatically. This is called Express Open. During Express Open operation, any movement of the SUNROOF switch will stop the sunroof. Closing Sunroof - Express Press the switch forward and release, and the sunroof will close automatically from any position.
Page 188: Sunshade Operation
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunshade Operation The sunshade can be opened manually. However, the sunshade will open automatically as the sunroof opens. NOTE: The sunshade cannot be closed if the sunroof is open. Wind Buffeting Wind buffeting can be described as the perception of pressure on the ears or a helicopter-type sound in the ears.
Page 189: Electrical Power Outlets
ELECTRICAL POWER OUTLETS There are two 12-volt electrical outlets on this vehicle. Both of the outlets are protected by a fuse. The 12-volt power outlet next to the ash receiver tray (if equipped with an optional Smoker’s Package) has power available only when the ignition is ON.
Page 190: Electrical Outlet Use With Engine Off
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The center console outlet is powered directly from the battery (power available at all times). Items plugged into this outlet may discharge the battery and/or prevent engine starting. Center Console Power Outlet Electrical Outlet Use With Engine Off CAUTION! •...
Page 191: Cupholders
CUPHOLDERS Front Seat Cupholders The cupholders are located in the forward edge of the center console. Front Seat Cupholders UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 Rear Seat Cupholders The rear seat cupholders are located in the center armrest between the rear seats. The cupholders are positioned forward in the armrest and side-by-side to provide conve- nient access to beverage cans or bottles while maintaining a resting place for the rear occupants’...
Page 192: Storage
190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Console Features The center console contains two shift bezel cubby bins with rubber mats for holding small items. For vehicles not equipped with navigation radio, the console also contains an extra storage bin located below the climate control, which holds up to four CD jewel cases.
Page 193: Cargo Area
The top compartment holds small items, such as a pen and note pad, while the larger bottom compartment will hold CDs and alike. The bottom compartment also con- tains a 12-volt power outlet and a molded-in coin holder (designed to hold various size coins). A slot in the left and right side of the top compartment provides clearance for power cords to pass conveniently out of the bin with the lid closed.
Page 194 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! • Be certain that the seatback is securely locked into position. If the seatback in not securely locked into position, the seat will not provide the proper stability for child seats and/or pas- sengers.
Page 195 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS Instrument Panel And Controls ... . . 197 Premium Instrument Cluster ....198 Instrument Cluster Descriptions .
Page 196 194 UNDERSTANDING YOUR INSTRUMENT PANEL Radio Broadcast Signals ....231 Two Types Of Signals ....231 Electrical Disturbances .
Page 197 Operating Instructions — Hands-Free Communication (UConnect ) (If Equipped) . . . 253 Clock Setting Procedure ....253 Sales Code RES — AM/FM Stereo Radio With CD Player (MP3 AUX Jack) .
Page 198 196 UNDERSTANDING YOUR INSTRUMENT PANEL Kicker 13-Speaker High Performance Sound System With Driver-Selectable Surround (DSS) – If Equipped ....276 Kicker Mobile Surround (KMS1) – If Equipped .
Page 199: Instrument Panel And Controls
INSTRUMENT PANEL AND CONTROLS 1 — Air Outlet 2 — Instrument Cluster 3 — HAZARD Switch 4 — Analog Clock 5 — Electronic Stability Program OFF Button* 6 — Glove Box UNDERSTANDING YOUR INSTRUMENT PANEL 197 7 — Radio 8 — Climate Control 9 —...
Page 200: Premium Instrument Cluster
198 UNDERSTANDING YOUR INSTRUMENT PANEL PREMIUM INSTRUMENT CLUSTER...
Page 201: Instrument Cluster Descriptions
INSTRUMENT CLUSTER DESCRIPTIONS 1. Electronic Speed Control/Adaptive Cruise Control Indicator Light — If Equipped This light will turn on when the electronic speed control or ACC is ON. (See page 150 for more information.) (See page 153 for more information.) 2.
Page 202 200 UNDERSTANDING YOUR INSTRUMENT PANEL Loose Fuel Filler Cap If the vehicle diagnostic system determines that the fuel filler cap is loose, improperly installed, or damaged, a “Check Gascap” message will display in the EVIC. Tighten the fuel filler cap properly and press the TRIP ODOMETER button to turn off the message.
Page 203 If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock brakes. If the ABS light does not turn on when the Ignition switch is turned to the ON position, have the light inspected by an authorized dealer.
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL The dual brake system provides a reserve braking capac- ity to a portion of the hydraulic system in the event of a failure. Failure of either half of the dual brake system is indicated by the Brake Warning Light, which will turn on when the brake fluid level in the master cylinder drops below a specified level.
Page 205 the light remains on, or if the light does not turn on, have the light inspected by an authorized dealer. NOTE: The light will turn on when the ignition switch is in the ON position and the parking brake is applied. This light shows only that the parking brake is applied.
Page 206 204 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! Driving with a hot cooling system could damage your vehicle. If the temperature gauge reads 240°F (116°C) or greater, pull over and stop the vehicle. Idle the vehicle with the air conditioner turned off until the pointer drops back into the normal range 200–...
Page 207 16. High Beam Light This light will turn on when the high beam headlights are ON. Push the multifunction lever away from the steering wheel to switch the headlights to high beam. (See page 137 for more information.) 17. Transmission Range Indicator This display indicator shows the automatic transmission gear selection.
Page 208 206 UNDERSTANDING YOUR INSTRUMENT PANEL engine running, your vehicle will usually be drivable. However, see your authorized dealer for service as soon as possible. If the light is flashing when the engine is running, immediate service is required. In this case, you may experience reduced performance, an elevated/rough idle or engine stall, and your vehicle may require towing.
Page 209 Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the system is not operating properly. The TPMS malfunction indicator is combined with the low tire pressure telltale. When the system detects a malfunction, the telltale will flash for approximately one minute and then remain continuously illuminated.
Page 210 208 UNDERSTANDING YOUR INSTRUMENT PANEL 23. Charging System Light This light shows the status of the electrical charg- ing system. The light should turn on when the ignition switch is first turned ON and remain on briefly as a bulb check. If the light stays on, or turns on while driving, turn off some of the vehicle’s non-essential electrical devices (i.e., radio) or slightly increase engine speed (if at idle).
Page 211: Electronic Vehicle Information Center (Evic)
Do not operate the vehicle until the cause is corrected. This light does not show how much oil is in the engine. The engine oil level must be checked using the procedure shown in Section 7. (See page 391 for more information.) ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) Electronic Vehicle Information Center...
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL • UConnect hands-free communication system dis- plays (if equipped), • Navigation system screens (if equipped), • Audio mode display, • Surround Sound modes (if equipped with Driver- Selectable Surround [DSS]), and • Performance Pages (if equipped). The system allows the driver to select information by pressing the following buttons mounted on the steering wheel.
Page 213: Electronic Vehicle Information Center (Evic) Displays
Press the AUDIO MODE button to select the Compass/Temp/Audio screen. Along with compass reading and outside temperature, this screen will display radio and media mode AUDIO information depending on which radio is in the MODE vehicle. Refer to “Remote Sound System Con- Button trols”...
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL • Door(s) Ajar (with a single chime if vehicle is in motion) • Trunk Ajar (with a single chime) • Low Washer Fluid (with a single chime) • Oil Pressure • ACC Off — When the Adaptive Cruise Control (ACC) system is turned off.
Page 215 • ACC Blinded — If the Adaptive Cruise Control (ACC) system deactivates due to performance limiting con- ditions. Refer to “Adaptive Cruise Control (ACC)” in Section 3 (if so equipped). • ACC Unavailable — If the Adaptive Cruise Control (ACC) system turns off due to a temporary malfunc- tion that limits functionality.
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL • Right Front Low Pressure (with a single chime). Refer to information on “Tire Pressure” and “Tire Pressure Monitor” under “Starting And Operating.” • Right Rear Low Pressure (with a single chime). Refer to information on “Tire Pressure” and “Tire Pressure Monitor”...
Page 217: Trip Functions
Trip Functions Press and release the MENU button until one of the following Trip Functions displays in the EVIC: • Average Fuel Economy • Distance To Empty • Trip A • Trip B • Elapsed Time • Display Units of Measure in Press the SCROLL button to cycle through all the Trip Computer functions.
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL • When the DTE value is less than 30 mi (48 km) estimated driving distance, the DTE display will change to a text display of LOW FUEL. This display will continue until the vehicle runs out of fuel. Adding a significant amount of fuel to the vehicle will turn off the LOW FUEL text and a new DTE value will display.
Page 219: Performance Pages - If Equipped
Performance Pages — If Equipped WARNING! Measurement of vehicle statistics with the Perfor- mance Pages is intended for off-highway or off-road use only and should not be done on any public roadways. It is recommended that these features be used in a controlled environment and within the limits of the law.
Page 220 218 UNDERSTANDING YOUR INSTRUMENT PANEL • The feature will “ready” when the vehicle speed is at 0 mph (0 km/h). The word “READY” will flash when conditions are met for the event to begin. • Dashes will display if the vehicle fails to reach 60 mph (100 km/h) in less then 10 seconds.
Page 221 1/8 Mile, 1/4 Mile When selected, this screen displays the time it takes the vehicle to travel 1/8 mile (1/4 mile) within 30 seconds and the vehicle’s speed when it reaches 1/8 mile (1/4 mile). • The feature will “ready” when the vehicle is at 0 mph (0 km/h).
Page 222: Compass Display
220 UNDERSTANDING YOUR INSTRUMENT PANEL • Press and hold the FUNCTION SELECT button for three seconds to toggle between current speed and top speed. • To reset top speed, quickly press and release the FUNCTION SELECT button when top speed is dis- played.
Page 223 UNDERSTANDING YOUR INSTRUMENT PANEL 221 5. Complete one or more 360 degree turns (in an area free from large metal or metallic objects) until the “CAL” message turns off. The compass will now function nor- mally. Compass Variance Compass Variance is the difference between magnetic North and geographic North.
Page 224: Telephone - If Equipped
222 UNDERSTANDING YOUR INSTRUMENT PANEL 1. Turn the ignition switch ON. 2. Press and hold the COMPASS button for approxi- mately two seconds. 3. Press the SCROLL button until “Compass Variance” message and the last variance zone number displays in the EVIC.
Page 225 The EVIC displays this symbol to indicate an incoming call. Incom- ing Call The EVIC displays this symbol to indicate that the UConnect phone is currently in analog mode. Analog The EVIC displays this symbol to indicate that the UConnect phone is currently roaming. Roam- UNDERSTANDING YOUR INSTRUMENT PANEL 223 The EVIC displays this symbol to indicate that...
Page 226: Navigation - If Equipped
224 UNDERSTANDING YOUR INSTRUMENT PANEL The EVIC displays this symbol to indicate that a phone connection has been made. Call in Progress The EVIC displays this symbol to indicate that the UConnect phone is currently not avail- able. Phone Avail- able Navigation —...
Page 227: Driver-Selectable Surround Sound (Dss) - If Equipped
Driver-Selectable Surround Sound (DSS) – If Equipped Press and release the MENU button until “Surround Sound” displays in the EVIC. The EVIC provides infor- mation on the current surround mode. • Stereo • Video Surround • Audio Surround While in the Surround Sound menu, press the FUNC- TION SELECT button to change surround modes.
Page 228: Personal Settings (Customer Programmable Features)
226 UNDERSTANDING YOUR INSTRUMENT PANEL Personal Settings (Customer Programmable Features) Personal Settings allows the driver to set and recall features when the transmission is in PARK. Press and release the MENU button until Personal Set- tings displays in the EVIC. Use the SCROLL button to display one of the following choices: “Language”...
Page 229 Press is selected, you must press the RKE UNLOCK button twice to unlock the passenger’s doors. When All Doors 1st Press is selected, all of the doors will unlock on the first press of the RKE UNLOCK button. To make your selection, press and release the FUNCTION SELECT button until “Driver Door 1st Press”...
Page 230 228 UNDERSTANDING YOUR INSTRUMENT PANEL “Automatically Move Seat Back on Exit” — If Equipped This feature provides automatic driver seat positioning to enhance driver mobility when entering and exiting the vehicle. To make your selection, press and release the FUNCTION SELECT button until “ON” or “OFF” ap- pears.
Page 231 when exiting the vehicle. To make your selection, press and release the FUNCTION SELECT button until “0,” “30,” “60,” or “90” appears. “Tilt Mirrors Down in Reverse” When ON is selected, the outside rearview mirrors will tilt downward when the ignition switch is in the ON position and the transmission is in the REVERSE posi- tion.
Page 232 230 UNDERSTANDING YOUR INSTRUMENT PANEL “Park Assist System” When ON is selected, the system will scan for objects behind the vehicle when the transmission is in the REVERSE or NEUTRAL position. To make your selec- tion, press and release the FUNCTION SELECT button until “ON”...
Page 233: Setting The Analog Clock
SETTING THE ANALOG CLOCK To set the analog clock at the top center of the instrument panel, press and hold the button until the setting is correct. Analog Clock UNDERSTANDING YOUR INSTRUMENT PANEL 231 RADIO GENERAL INFORMATION Radio Broadcast Signals Your new radio will provide excellent reception under most operating conditions.
Page 234: Electrical Disturbances
232 UNDERSTANDING YOUR INSTRUMENT PANEL Electrical Disturbances Radio waves may pick up electrical disturbances during transmission. They mainly affect the wave amplitude, and thus remain a part of the AM reception. They interfere very little with the frequency variations that carry the FM signal.
Page 235: Operating Instructions - Satellite Radio (If Equipped)
An auxiliary input jack permits passengers to listen to a portable MP3 player through the vehicle’s speakers. For vehicles equipped with the Vehicle Entertainment System (VES) , separate audio outputs allow passengers to listen to the vehicle speakers while different audio tracks play through the system’s wireless headphones.
Page 236: Clock Setting Procedure
234 UNDERSTANDING YOUR INSTRUMENT PANEL Clock Setting Procedure Setting the Clock 1. Turn on the multimedia system. 2. Touch the screen where the time is displayed. The clock setting menu will appear on the screen. 3. To move the hour forward, touch the screen where the word “Hour”...
Page 237 Show Time if Radio is Off When selected, this feature will display the time of day on the touch screen when the multimedia system is turned off. Proceed as follows to change the current setting: 1. Turn on the multimedia system. 2.
Page 238: Sales Code Req - Am/Fm Stereo Radio And 6-Disc Cd/Dvd Changer (Mp3/Wma Aux Jack)
236 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE REQ — AM/FM STEREO RADIO AND 6–DISC CD/DVD CHANGER (MP3/WMA AUX JACK) NOTE: The radio sales code is located on the lower right side of your radio faceplate. REQ Radio Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC position to operate the radio.
Page 239 to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection. Holding either button will bypass stations without stopping until you release it. SCAN Button Pressing the SCAN button causes the tuner to search for the next listenable station, in AM, FM or Satellite (if equipped) frequencies, pausing for five seconds at each listenable station before continuing to the next.
Page 240 238 UNDERSTANDING YOUR INSTRUMENT PANEL 3. After adjusting the hours, press the right side TUNE/ SCROLL control knob to set the minutes. The minutes will begin to blink. 4. Adjust the minutes using the right side TUNE/ SCROLL control knob. Press the TUNE/SCROLL control knob to save the time change.
Page 241 Push the rotary TUNE/SCROLL control knob a third time and TREBLE will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the treble tones. Push the rotary TUNE/SCROLL control knob a fourth time and BALANCE will display. Turn the TUNE/ SCROLL control knob to the right or left to adjust the sound level from the right or left side speakers.
Page 242 240 UNDERSTANDING YOUR INSTRUMENT PANEL Program Type Jazz News Nostalgia Oldies Personality Public Rhythm and Blues Religious Music Religious Talk Rock Soft Soft Rock Soft Rhythm and Blues Sports Talk 16-Digit Character Display Jazz News Nostalga By pressing the SEEK button when the Music Type icon Oldies is displayed, the radio will be tuned to the next frequency Persnlty...
Page 243 NOTE: Turn the TUNE/SCROLL control knob to scroll through the entries. Push the AUDIO/SELECT button to select an entry and make changes. • DVD Enter - When the disc is in DVD Menu mode, selecting DVD Enter will allow you to play the current highlighted selection.
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL • VES™ CH1/CH2 - Allows the user to change the mode of either the IR1 or IR2, wireless headphones by pressing the AUDIO/SELECT button (if equipped). • Set Home Clock - Pressing the SELECT button allows you to set the clock.
Page 245 Subtitles — If Equipped Selecting this item allows you to choose between subtitle Off or On. Audio DRC — If Equipped Selecting this item allows you to limit maximum audio dynamic range. The default is set to High, and under this setting, dialogues will play at 11 db higher than if the setting is Normal.
Page 246: Operation Instructions - (Disc Mode For Cd And Mp3/Wma Audio Play, Dvd-Video)
244 UNDERSTANDING YOUR INSTRUMENT PANEL You may add a second station to each pushbutton by repeating the above procedure with this exception: Press the SET button twice and SET 2 will show in the display window. Each button can be set for SET 1 and SET 2 in both AM and FM.
Page 247 NOTE: The ignition switch must be in the ON or ACC position to operate the radio. LOAD Button — Loading Compact Disc(s) Press the LOAD button and the pushbutton with the corresponding number (1-6) where the CD is being loaded. The radio will display PLEASE WAIT and prompt when to INSERT DISC.
Page 248: Notes On Playing Mp3/Wma Files
246 UNDERSTANDING YOUR INSTRUMENT PANEL SCAN Button (CD MODE) Press the SCAN button to scan through each track on the CD currently playing. TIME Button (CD MODE) Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF (CD MODE) Press and hold FF (Fast Forward) and the CD player will begin to fast forward until FF is released, or RW or...
Page 249 The radio uses the following limits for file systems: • Maximum number of directory levels: 8 • Maximum number of files: 255 • Maximum number of folders: 100 • Maximum number of characters in file/folder names: • Level 1: 12 (including a separator . and a three- character extension) •...
Page 250 248 UNDERSTANDING YOUR INSTRUMENT PANEL MPEG Sampling Specification Frequency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16 Layer 3 Sampling Specification Frequency (kHz) 44.1 and 48 ID3 Tag information for artist, song title, and album title are supported for ID3 version 1 tags.
Page 251: List Button (Disc Mode For Mp3/Wma Play)
To increase the speed of disc loading, it is recommended to use CD-R media and single-session discs. To create a single-session disc, enable the “Disc at Once” option before writing to the disc. LIST Button (DISC Mode for MP3/WMA Play) Pressing the LIST button will bring up a list of all folders on the disc.
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL Pressing the AUX button will change the mode to auxil- iary device if the AUX jack is connected. NOTE: The AUX device must be turned on and the device’s volume set to the proper level. If the AUX audio is not loud enough, turn the device’s volume up.
Page 253: Sales Code Rer - Multimedia System - If Equipped
Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions - Satellite Radio Mode (If Equipped) Refer to “Satellite Radio” in this section. Operating Instructions - Video Entertainment System (VES™) (If Equipped) Refer to separate “Video Entertainment System (VES™) Guide.”...
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL The RER Multimedia system contains a radio, Sirius Satellite Radio player, navigation system, CD/DVD player, USB port, 20-gigabyte hard drive (HDD), and the UConnect Hands-Free Bluetooth cellular system. NOTE: If your vehicle is not equipped with UConnect , the unit will respond with a “Feature Not Available”...
Page 255: Operating Instructions - Satellite Radio
Other special features include direct tune, music type selections, traffic messaging (optional), easy store presets, parental lockout for VES™ (if equipped), backup camera display for vehicles equipped with a backup camera, and on some models, a dual display screen operation. Refer to your “Navigation User’s Manual”...
Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL 4. Touch the screen where the words “Set Time Zone” are displayed. The time zone selection menu will appear on the screen. 5. Select a time zone by touching the screen where your selection appears. If you do not see a time zone that you want to select, touch the screen where the word “Page”...
Page 257 3. If the words “Time: GPS Time” are displayed at the top of the screen, touch the bottom of the screen where the words “GPS Time” are displayed. The user clock time setting menu will appear on the screen. 4. To move the hour forward, touch the screen where the word “Hour”...
Page 258: Sales Code Res - Am/Fm Stereo Radio With Cd Player (Mp3 Aux Jack)
256 UNDERSTANDING YOUR INSTRUMENT PANEL SALES CODE RES — AM/FM STEREO RADIO WITH CD PLAYER (MP3 AUX JACK) NOTE: The radio sales code is located on the lower right side of your radio faceplate. RES Radio (Non-Satellite Model Shown - With Satellite Similar) Operating Instructions - Radio Mode NOTE: The ignition switch must be in the ON or ACC...
Page 259 SEEK Buttons Press and release the SEEK buttons to search for the next listenable station in AM/FM mode. Press the right switch to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make another selection.
Page 260 258 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button Press the TIME button and the time of day will display. In AM or FM mode, pressing the TIME button will switch between the time and frequency displays. Clock Setting Procedure 1. Press and hold the TIME button, until the hours blink. 2.
Page 261 TUNE Control Turn the rotary TUNE/SCROLL control knob clockwise to increase or counterclockwise to decrease the frequency. Setting the Tone, Balance, and Fade Push the rotary TUNE/SCROLL control knob and BASS will display. Turn the TUNE/SCROLL control knob to the right or left to increase or decrease the bass tones. Push the rotary TUNE/SCROLL control knob a second time and MID will display.
Page 262 260 UNDERSTANDING YOUR INSTRUMENT PANEL Toggle the MUSIC TYPE button to select the following format types: Program Type No program type or un- defined Adult Hits Classical Classic Rock College Country Foreign Language Information Jazz News Nostalgia Oldies 16-Digit Character Display Rhythm and Blues None...
Page 263 By pressing the SEEK button when the Music Type icon is displayed, the radio will be tuned to the next frequency station with the same selected Music Type name. The Music Type function only operates when in the FM mode. If a preset button is activated while in the Music Type (Program Type) mode, the Music Type mode will be exited and the radio will tune to the preset station.
Page 264: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
262 UNDERSTANDING YOUR INSTRUMENT PANEL stations to be stored into pushbutton memory. The sta- tions stored in SET 2 memory can be selected by pressing the pushbutton twice. Every time a preset button is used, a corresponding button number will display. Buttons 1 - 6 These buttons tune the radio to the stations that you commit to pushbutton memory (12 AM and 12 FM...
Page 265 CAUTION! • This CD player will accept 4–3/4 in (12 cm) discs only. The use of other sized discs may damage the CD player mechanism. • Do not use adhesive labels. These labels can peel away and jam the player mechanism. •...
Page 266: Notes On Playing Mp3 Files
264 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button Press this button to change the display from a large CD playing time display to a small CD playing time display. RW/FF Press the RW button to stop the CD at the beginning of the current CD track/title.
Page 267 files properly and may be unable to play the file nor- mally. UDF and Apple HFS formats are not supported. The radio uses the following limits for file systems: • Maximum number of folder levels: 8 • Maximum number of files: 255 •...
Page 268 266 UNDERSTANDING YOUR INSTRUMENT PANEL rates (VBR) are also supported. The majority of MP3 files use a 44.1 kHz sampling rate and a 192, 160, 128, 96 or VBR bit rates. MPEG Sampling Specification Frequency (kHz) MPEG-1 Audio 48, 44.1, 32 Layer 3 MPEG-2 Audio 24, 22.05, 16...
Page 269: List Button (Cd Mode For Mp3 Play)
LIST Button (CD Mode for MP3 Play) Pressing the LIST button will bring up a list of all folders on the disc. Scrolling up or down the list is done by turning the TUNE/SCROLL control knob. Selecting a folder by pressing the TUNE/SCROLL control knob will begin playing the files contained in that folder (or the next folder in sequence if the selection does not contain playable files).
Page 270: Satellite Radio (Rsc) - If Equipped (Rer/Req/Ren Radios Only)
268 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) Press this button to change the display to time of day. The time of day will display for five seconds (when ignition is OFF). Operating Instructions - Hands-Free Phone (UConnect ) (If Equipped) Refer to “Hands-Free Communication (UConnect )”...
Page 271: Electronic Serial Number/Sirius Identification Number (Ens/Sid)
call the toll-free number 888-539-7474, or visit the Sirius web site at www.sirius.com, or at www.siriuscanada.ca for Canadian residents. Please have the following infor- mation available when calling: 1. The Electronic Serial Number/Sirius Identification Number (ESN/SID). 2. Your Vehicle Identification Number. Electronic Serial Number/Sirius Identification Number (ENS/SID) The Electronic Serial Number/Sirius Identification Num-...
Page 272: Satellite Antenna
270 UNDERSTANDING YOUR INSTRUMENT PANEL Satellite Antenna To ensure optimum reception, do not place items on the roof around the rooftop antenna location or strap items to the trunk lid around the trunk lid antenna (if equipped). Metal objects placed within the line of sight of the antenna will cause decreased performance.
Page 273 SCAN Button Pressing the SCAN button causes the tuner to search for the next channel, pausing for eight seconds before con- tinuing to the next. To stop the search, press the SCAN button a second time. INFO Button Pressing the INFO button will cycle between Artist, Song Title, and Composer (if available) information.
Page 274 272 UNDERSTANDING YOUR INSTRUMENT PANEL SETUP Button Pressing the SETUP button allows you to select the following items: • Display Sirius ID number — Press the AUDIO/ SELECT button to display the Sirius ID number. This number is used to activate, deactivate, or change the Sirius subscription.
Page 275: Operating Instructions - Hands-Free Phone (If Equipped)
Operating Instructions - Hands-Free Phone (If Equipped) Refer to “Hands-Free Communication (UConnect )” in Section 3. Operating Instructions - Video Entertainment System (VES™) (If Equipped) Refer to separate “Video Entertainment System (VES™) Guide.” SIRIUS BACKSEAT TV™ — IF EQUIPPED Satellite video uses direct satellite receiver broadcasting technology to provide streaming video coast to coast.
Page 276 274 UNDERSTANDING YOUR INSTRUMENT PANEL Opening the Rear Seat VES • The LCD Screen swings up from the rear of the armrest to allow the rear seat passenger(s) to view the display. VES Video Screen NOTE: Close the armrest after the LCD screen has been raised to its viewing position.
Page 277 • A battery-powered infrared remote control snaps into a molded compartment in the center console armrest upper storage bin. VES Remote Control • Two wireless infrared headsets allow rear seat passen- gers to listen to the same or individual audio sources. UNDERSTANDING YOUR INSTRUMENT PANEL 275 Audio/Video RCA Jacks (AUX Jacks) on the rear of the center console enable...
Page 278: Kicker 13-Speaker High Performance Sound System With Driver-Selectable Surround (Dss) - If Equipped
276 UNDERSTANDING YOUR INSTRUMENT PANEL Kicker 13-speaker High Performance Sound System with Driver-Selectable Surround (DSS) – If Equipped Your vehicle is equipped with a state of the art audio amplifier that provides 5.1-channel surround sound from any stereo audio source. A new feature of the Kicker audio system offers the ability to choose surround sound for any audio source or video source.
Page 279: Universal Consumer Interface (Uci) - If Equipped
The KMS1 Video Surround mode activates whenever a video source is selected, unless the system is already in “Audio Surround” mode. DSS modes for video sources are “Stereo,” “Audio Surround,” and “Video Surround.” When in Video Surround mode, balance and fade are set automatically by the KMS1 system to provide the ultimate surround sound experience.
Page 280: Controlling The Ipod Using Radio Buttons
278 UNDERSTANDING YOUR INSTRUMENT PANEL Controlling The iPod Using Radio Buttons To get into the UCI (iPod ) mode and access a connected iPod , press the AUX button on the radio faceplate. Once in the UCI (iPod ) mode, the iPod available from iPod ) will start playing over the vehicle audio system.
Page 281 Pressing and releasing the FF button will go forward five seconds of the current track. SEEK Buttons Use the SEEK buttons to move to the previous or the next track. If the left (down) button is pressed during the first two seconds of the current track, it will go back to the previous track in the list;...
Page 282: List Or Browse Mode
280 UNDERSTANDING YOUR INSTRUMENT PANEL List or Browse Mode During Play mode, pressing any of the following buttons will take you to List mode. List mode enables you to scroll through the list of menus and tracks on the iPod device.
Page 283: Remote Sound System Controls - If Equipped
After pressing a preset button, you will see the list you are in on the top line and the first item in that list on the second line. To exit the List mode without selecting a track, press the same preset button again to go back to Play mode. LIST Button Pressing the LIST button will take to the top level menu of the iPod .
Page 284 282 UNDERSTANDING YOUR INSTRUMENT PANEL Vehicles equipped with steering wheel-mounted buttons are also equipped with the Electronic Vehicle Information Center (EVIC). The EVIC features a driver-interactive display. This is located in the upper part of the instru- ment cluster between the speedometer and tachometer. The VOLUME button controls the sound level of the sound system.
Page 285: Cd/Dvd Disc Maintenance
CD/DVD DISC MAINTENANCE To keep the CD/DVD discs in good condition, take the following precautions: 1. Handle the disc by its edge; avoid touching the surface. 2. If the disc is stained, clean the surface with a soft cloth, wiping from center to edge. 3.
Page 286: Automatic Temperature Control
284 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Temperature Control Automatic Temperature Controls Automatic Operation The Infrared Dual-Zone Climate Control System auto- matically maintains the climate in the cabin of the vehicle at the comfort levels desired by the driver and passenger. To accomplish this, the system gathers information from the controls on the climate control, from a dual sun- sensor located in the top of the instrument panel, from an...
Page 287 or HI AUTO. The LO AUTO position should be used for front seat occupants only. The HI AUTO position should be used when more airflow is desired, or when rear seat occupants are present. Then, dial in the temperature you would like the system to maintain by rotating the driver or passenger Temperature Control knob.
Page 288 286 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • The surface of the climate control panel and the top center of the instrument panel should be kept free of debris due to the location of the climate control sensors. Mud on the windshield may also cause poor operation of this system.
Page 289 UNDERSTANDING YOUR INSTRUMENT PANEL 287...
Page 290 288 UNDERSTANDING YOUR INSTRUMENT PANEL The operator can override the AUTO mode setting to change airflow distribution by rotating the Mode Control knob (on the right) to one of the following positions. • Defrost Air is directed to the windshield through the outlets at the base of the windshield.
Page 291: Operating Tips
turn off the air conditioning. An LED in the button illuminates when manual compressor operation is selected. NOTE: To control the air conditioning manually, the mode selector must be moved out of the AUTO position. • Recirculation Control This button can be used to block out smoke, odors, dust, high humidity, or if rapid cooling is desired.
Page 292 290 UNDERSTANDING YOUR INSTRUMENT PANEL Winter Operation Use of the air Recirculation mode during winter months is not recommended because it may cause window fogging. Vacation Storage Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air and high blower setting.
Page 293 UNDERSTANDING YOUR INSTRUMENT PANEL 291 Control Setting Suggestions for Various Weather Conditions...
Page 294: Rear Window Features
292 UNDERSTANDING YOUR INSTRUMENT PANEL REAR WINDOW FEATURES Electric Rear Window Defroster The Electric Rear Window Defroster control is located on the climate control. Press this button to turn ON the rear window defroster and the heated outside rearview mirrors (if equipped). An LED in the button will illuminate when the rear window defroster is ON.
Page 295: Starting And Operating
STARTING AND OPERATING CONTENTS Starting Procedures ..... 297 Automatic Transmission ....298 Normal Starting (Tip Start) .
Page 296 294 STARTING AND OPERATING Traction ......312 Driving Through Water ....313 Flowing/Rising Water .
Page 297 Life Of Tire ......341 Replacement Tires ..... 342 Alignment And Balance .
Page 298 296 STARTING AND OPERATING Gross Vehicle Weight Rating (GVWR) ..364 Gross Axle Weight Rating (GAWR) ..364 Overloading ......365 Loading .
Page 299: Starting Procedures
STARTING PROCEDURES Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if present, instruct all other occupants to buckle their seat belts. STARTING AND OPERATING 297 WARNING! • Never leave children alone in a vehicle. Leaving unattended children in a vehicle is dangerous for a number of reasons.
Page 300: Automatic Transmission
298 STARTING AND OPERATING Automatic Transmission The shift lever must be in the NEUTRAL or PARK position before you can start the engine. Apply the brakes before shifting into any driving gear. CAUTION! Damage to the transmission may occur if the follow- ing precautions are not observed: •...
Page 301: Normal Starting (Tip Start)
Normal Starting (Tip Start) NOTE: Normal Starting of either a cold or a warm engine is obtained without pumping or depressing the accelerator pedal. Do not press the accelerator. Use the Fob with Integrated Key to briefly turn the ignition switch to the START position and release it as soon as the starter engages.
Page 302: If Engine Fails To Start
300 STARTING AND OPERATING If Engine Fails To Start WARNING! • Never pour fuel or other flammable liquids into the throttle body air inlet opening in an attempt to start the vehicle. This could result in a flash fire causing serious personal injury. •...
Page 303: After Starting
After Starting The idle speed is controlled automatically and it will decrease as the engine warms up. ENGINE BLOCK HEATER — IF EQUIPPED The engine block heater warms engine coolant and permits quicker starts in cold weather. Connect the cord to a standard 110-115 Volt AC electrical outlet with a grounded, three-wire extension cord.
Page 304: Automatic Transmission - General Information
302 STARTING AND OPERATING WARNING! It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle speed. If your foot is not firmly on the brake pedal, the vehicle could accelerate quickly forward or in reverse.
Page 305 • The electronically-controlled transmission provides a precise shift schedule. The transmission electronics are self-calibrating. Therefore, the first few shifts on a new vehicle may be somewhat abrupt or soft until after the break-in period. This is a normal condition, and pre- cision shifts will develop within a few shift cycles.
Page 306: Brake/Transmission Shift Interlock System
304 STARTING AND OPERATING Over-Temperature Mode The transmission electronics constantly monitor the trans- mission oil temperature. If the transmission exceeds nor- mal operating temperature, the transmission will change the way it shifts to help control the condition. This may result in a slightly different feeling or response during normal operation in DRIVE position.
Page 307: 5-Speed Automatic Transmission
To activate the override, first insert the key into the ignition switch and turn it to the ACC or ON position. Then, press the pink-colored tab trough the access pot with a small flat blade screwdriver or alike. While pressing the override, move the shift lever out of the PARK position.
Page 308 306 STARTING AND OPERATING When parking on a flat surface, place the shift lever in the PARK position first, and then apply the parking brake. When parking on a hill, it is important to set the parking brake before placing the shift lever in PARK, otherwise the load on the transmission locking mechanism may make it difficult to move the shift lever out of PARK.
Page 309 REVERSE Shift into REVERSE gear only when the vehicle is com- pletely stopped. NEUTRAL In NEUTRAL, no power is transmitted from the engine to the drive axle. When the brakes are released, the vehicle can be moved freely (pushed or towed). Do not engage NEUTRAL position while driving except to coast when the vehicle is in danger of skidding (e.g., on icy roads).
Page 310 308 STARTING AND OPERATING When frequent transmission shifting occurs when using the Overdrive range, such as when operating the vehicle under heavy loading conditions (in hilly terrain, travel- ing into strong head winds, or while towing heavy trailers, use the AutoStick mode and select the “3”...
Page 311 Delayed Shifts in Cold Temperatures During cold temperature operation, you may notice delayed upshifts depending on engine and transmission temperature as well as vehicle speed. This feature im- proves warm up time of the engine and transmission to achieve maximum efficiency. Temporary Transmission Limp Home Mode The transmission is monitored for abnormal conditions.
Page 312: Autostick
310 STARTING AND OPERATING Have the transmission checked at your authorized dealer as soon as possible. If the problem has been momentary, the transmission can be reset to regain all forward gears. Permanent Transmission Limp Home Mode Permanent Limp Home Mode will be activated if the transmission enters temporary Limp Home Mode three times.
Page 313: Autostick General Information
NOTE: • In Autostick mode, the transmission will only shift up and down when the driver manually moves the shift lever Right (D+) or Left (D-). • An UPSHIFT message will appear in the Electronic Vehicle Information Center (EVIC) portion of the in- strument cluster when using Autostick .
Page 314: Driving On Slippery Surfaces
312 STARTING AND OPERATING • Transmission shifting will be more noticeable when Autostick is engaged. DRIVING ON SLIPPERY SURFACES Acceleration Rapid acceleration on snow covered, wet, or other slip- pery surfaces may cause the rear wheels to pull errati- cally to the right or left. This phenomenon occurs when there is a difference in the surface traction under the rear (driving) wheels.
Page 315: Driving Through Water
DRIVING THROUGH WATER Driving through water more than a few inches/ millimeters deep will require extra caution to ensure safety and prevent damage to your vehicle. Flowing/Rising Water WARNING! Do not drive on, or cross, a road or a path where water is flowing and/or rising (as in storm run-off).
Page 316 314 STARTING AND OPERATING CAUTION! • Driving through standing water may cause dam- age to your vehicle’s drivetrain components. Al- ways inspect your vehicle’s fluids (i.e., engine oil, transmission, axle, etc.) for signs of contamination (i.e., fluid that is milky or foamy in appearance) after driving through standing water.
Page 317: Parking Brake
PARKING BRAKE The parking brake should always be applied when the driver is not in the vehicle. WARNING! Never use PARK position on an automatic transmis- sion as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.
Page 318 316 STARTING AND OPERATING Parking Brake The brake light in the instrument cluster will turn on when the parking brake is applied and the ignition switch is ON. NOTE: This light only shows that the parking brake is applied. It does not show the degree of brake application. WARNING! •...
Page 319: Brake System
BRAKE SYSTEM Your vehicle is equipped with dual hydraulic brake systems. If either of the two hydraulic systems loses normal capability, the remaining system will still function. There will be some loss of overall braking effectiveness. This may be evident by increased pedal travel during application, greater pedal force required to slow or stop, and potential activation of the Brake Warning Light.
Page 320 318 STARTING AND OPERATING ABS is activated during braking under certain road or stopping conditions. ABS-inducing conditions can in- clude ice, snow, gravel, bumps, railroad tracks, loose debris, or panic stops. You also may experience the following when the brake system goes into Anti-lock: •...
Page 321: Power Steering
All vehicle wheels and tires must be the same size and type and tires must be properly inflated to produce accurate signals for the computer. Anti-Lock Brake Light The ABS light monitors the Anti-Lock Brake Sys- tem. The light will come on when the ignition switch is turned to the ON position and may stay on for as long as four seconds.
Page 322: Electronic Brake Control System
320 STARTING AND OPERATING Upon initial start-up in cold weather, the power steering pump may make noise for a short amount of time. This is due to the cold, thick fluid in the steering system. This noise should be considered normal, and it does not in any way damage the steering system.
Page 323: Abs (Anti-Lock Brake System)
ABS (Anti-Lock Brake System) This system aids the driver in maintaining vehicle control under adverse braking conditions by controlling hydrau- lic brake pressure. This prevents wheel lock-up to help avoid skidding on slippery surfaces during braking. For more information about ABS, refer to “Anti-Lock Brake System”...
Page 324: Tcs (Traction Control System)
322 STARTING AND OPERATING TCS (Traction Control System) This system monitors the amount of wheel spin of each driven wheel. If wheel spin is detected, brake pressure is applied to the slipping wheel(s) and engine power is reduced to provide enhanced acceleration and stability. BAS (Brake Assist System) This system complements the Anti-Lock Brake System (ABS) by optimizing the vehicle braking capability dur-...
Page 325: Esp (Electronic Stability Program)
ESP (Electronic Stability Program) This system enhances directional control and stability of the vehicle under various driving conditions. The ESP corrects for oversteering and understeering the vehicle by applying the brake of the appropriate wheel. Engine power may also be reduced to assist in counteracting the condition of oversteer or understeer and help the vehicle maintain the desired path.
Page 326 324 STARTING AND OPERATING WARNING! The ESP (Electronic Stability Program) cannot pre- vent the natural laws of physics from acting on the vehicle, nor can it increase the traction afforded by prevailing road conditions. The ESP cannot prevent accidents, including those resulting from excessive speed in turns, driving on very slippery surfaces, or hydroplaning.
Page 327 NOTE: To improve the vehicle’s traction when driving with snow chains, or when starting-off in deep snow, sand, or gravel, it may be desirable to switch to the “Partial Off” mode by momentarily depressing the “ESP OFF” button. Once the situation requiring “Partial Off” mode is overcome, turn the ESP ON again by momen- tarily depressing the “ESP OFF”...
Page 328: Synchronizing Esp
326 STARTING AND OPERATING NOTE: When the ESP is switched off a feature of the system remains active. This feature controls wheel spin across an axle quite similarly to a limited slip differential. If one wheel on an axle is spinning faster than the other, the system will apply the brake of the spinning wheel and allow more engine torque to be applied to the wheel that is not spinning.
Page 329: Esp/Bas Malfunction Indicator Light And Esp/Tcs Indicator Light
Indicator Light should go out. However, if the light remains on, have the ESP and BAS checked at your authorized dealer as soon as possible. ESP/BAS Malfunction Indicator Light and ESP/TCS Indicator Light The Malfunction Indicator Light for the ESP is combined with the BAS indicator.
Page 330: Tire Safety Information
328 STARTING AND OPERATING TIRE SAFETY INFORMATION Tire Markings NOTE: • P (Passenger)-Metric tire sizing is based on U.S. design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designation. Ex- ample: P215/65R15 95H. • European Metric tire sizing is based on European design standards.
Page 331 Tire Sizing Chart Size Designation: P = Passenger car tire size based on U.S. design standards ...blank... = Passenger car tire based on European design standards LT = Light truck tire based on U.S. design standards T = Temporary spare tire 31 = Overall diameter in inches (in) 215 = Section width in millimeters (mm) 65 = Aspect ratio in percent (%).
Page 332 330 STARTING AND OPERATING Service Description: 95 = Load Index —A numerical code associated with the maximum load a tire can carry H = Speed Symbol —A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —The maximum speed corresponding to the speed symbol should only be achieved un- der specified operating conditions (i.e., tire pressure, vehicle loading, road conditions,...
Page 333: Tire Identification Number (Tin)
Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire, however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, DOT = Department of Transportation —This symbol certifies that the tire is in compliance with the U.S.
Page 334: Tire Loading And Tire Pressure
332 STARTING AND OPERATING Tire Loading and Tire Pressure Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on either the face of the driver’s door or the driver’s side B-pillar. Tire Placard Location Tire and Loading Information Placard Tire And Loading Information Placard This placard tells you important information about: 1) number of people that can be carried in the vehicle...
Page 335 Loading The vehicle maximum load on the tire must not exceed the load carrying capacity of the tire on your vehicle. You will not exceed the tire’s load carrying capacity if you adhere to the loading conditions, tire size, and cold tire inflation pressures specified on the Tire and Loading Information placard and in the “Vehicle Loading”...
Page 336 334 STARTING AND OPERATING 4. The resulting figure equals the available amount of cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five 150 lb (68 kg) passengers in your vehicle, the amount of available cargo and luggage load capacity is 650 lbs (295 kg) {(since 5 x 150 = 750, and 1400 –...
Page 337 STARTING AND OPERATING 335...
Page 338: Tires - General Information
336 STARTING AND OPERATING WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and increase your stopping distance. Use tires of the recommended load capacity for your vehicle. Never overload them. TIRES — GENERAL INFORMATION Tire Pressure Proper tire inflation pressure is essential to the safe and satisfactory operation of your vehicle.
Page 339: Tire Inflation Pressures
2. Economy— Improper inflation pressures can cause uneven wear patterns to develop across the tire tread. These abnormal wear patterns will reduce tread life resulting in a need for earlier tire replacement. Under-inflation, also increases tire rolling resistance and results in higher fuel consump- tion.
Page 340 338 STARTING AND OPERATING check tire pressure. Do not make a visual judgement when determining proper inflation. Radial tires may look properly inflated even when they are under-inflated. CAUTION! After inspecting or adjusting the tire pressure, al- ways reinstall the valve stem cap (if equipped). This will prevent moisture and dirt from entering the valve stem, which could damage the valve stem.
Page 341: Radial-Ply Tires
Tire Pressures for High Speed Operation The manufacturer advocates driving at safe speeds within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high speeds, maintaining correct tire inflation pressure is very important.
Page 342: Tire Spinning
340 STARTING AND OPERATING Tire Spinning When stuck in mud, sand, snow, or ice conditions, do not spin your vehicle’s wheels above 35 mph (55 km/h). Refer to the paragraph on “Freeing A Stuck Vehicle” in Section 6. WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure.
Page 343: Life Of Tire
These indicators are molded into the bottom of the tread grooves. They will appear as bands when the tread depth becomes 1/16 in (2 mm). When the tread is worn to the tread wear indicators, the tire should be replaced. Many states have laws requiring tire replacement at this point.
Page 344: Replacement Tires
342 STARTING AND OPERATING Replacement Tires The tires on your new vehicle provide a balance of many characteristics. They should be inspected regularly for wear and correct cold tire inflation pressure. The manu- facturer strongly recommends that you use tires equiva- lent to the originals in size, quality and performance when replacement is needed.
Page 345: Alignment And Balance
CAUTION! Replacing original tires with tires of a different size may result in false speedometer and odometer readings. Alignment And Balance Poor suspension alignment may result in: • Fast tire wear. • Uneven tire wear, such as feathering and one-sided wear.
Page 346: Snow Tires
344 STARTING AND OPERATING CAUTION! To avoid damage to your vehicle or tires, observe the following precautions: • Because of restricted chain clearance between tires and other suspension components, it is important that only chains in good condition are used. Broken chains can cause serious damage.
Page 347: Tire Rotation Recommendations
If you need snow tires, select tires equivalent in size and type to the original equipment tires. Use snow tires only in sets of four. Failure to do so may adversely affect the safety and handling of your vehicle. Snow tires generally have lower speed ratings than what was originally equipped with your vehicle and should not be operated at sustained speeds over 75 mph (120 km/h).
Page 348: Tire Rotation - All Season Tires
346 STARTING AND OPERATING Tire Rotation — All Season Tires The suggested rotation method for vehicles equipped with all season tires is the “forward-cross” as shown in the following diagram.
Page 349: Tire Pressure Monitor System (Tpms) - If Equipped
TIRE PRESSURE MONITOR SYSTEM (TPMS) — IF EQUIPPED • The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recommended cold placard pressure. • The tire pressure will vary with temperature by about 1 psi (6.9 kPa) for every 12°F (6.5°C).
Page 350 348 STARTING AND OPERATING vehicle may need to be driven for up to 10 minutes above 15 mph (25 km/h) in order for the TPMS to receive this information. − For example, your vehicle may have a recom- mended cold (parked for more than three hours) placard pressure of 30 psi (207 kPa).
Page 351: Base System - If Equipped
NOTE: • The TPMS is not intended to replace normal tire care and maintenance or to provide warning of a tire failure or condition. • The TPMS should not be used as a tire pressure gauge while adjusting your tire pressure. •...
Page 352 350 STARTING AND OPERATING The matching full size spare wheel and tire assembly (if equipped) has a tire pressure monitoring sensor. The matching full size spare can be used in place of any of the four road tires. The TPMS will only monitor the pressure in the full size spare when it is used in place of a road tire.
Page 353 3. Accumulation of snow or ice around the wheels or wheel housings. 4. Using tire chains on the vehicle. 5. Using wheels/tires not equipped with TPM sensors. NOTE: Vehicles with Full Size Spare 1. The matching full size spare wheel and tire assembly has a tire pressure monitoring sensor that can be moni- tored by the TPMS.
Page 354: Premium System - If Equipped
352 STARTING AND OPERATING 5. Once you repair or replace the original road tire, and reinstall it on the vehicle in place of the compact spare, the TPMS will update automatically and the TPM Telltale Light will turn OFF, as long as no tire pressure is below the low-pressure warning limit in any of the four active road tires.
Page 355 Tire Pressure Monitoring Low Pressure Warnings The Tire Pressure Monitoring Telltale Light will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires. In addition, the EVIC will display one or more low pressure messages (Left Front, Left Rear, Right Front, Right Rear) for three seconds and a graphic showing the pressure values of...
Page 356 354 STARTING AND OPERATING Should this occur, you should stop as soon as possible and inflate the tires with low pressure (those flashing in the EVIC graphic) to the vehicle’s recommended cold placard pressure value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flash- ing, and the Tire Pressure Monitoring Telltale Light will...
Page 357 If the ignition key is cycled, this sequence will repeat, providing the system fault still exists. If the system fault no longer exists, the Tire Pressure Monitoring Telltale Light will no longer flash, and the CHECK TPM SYS- TEM message will no longer display, and a pressure value will display in place of the dashes.
Page 358 356 STARTING AND OPERATING NOTE: Vehicles with Compact Spare 1. The compact spare tire does not have a tire pressure monitoring sensor. Therefore, the TPMS will not monitor the pressure in the compact spare tire. 2. If you install the compact spare tire in place of a road tire that has a pressure below the low-pressure warning limit, upon the next ignition key cycle, the TPM Telltale Light will remain ON and a chime will sound.
Page 359: General Information
General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Operation is subject to the following conditions: • This device may not cause harmful interference. • This device must accept any interference received, including interference that may cause undesired op- eration.
Page 360: Reformulated Gasoline
358 STARTING AND OPERATING necessary to deliver enhanced emissions, performance, and durability for your vehicle. The manufacturer recom- mends the use of gasolines that meet the WWFC speci- fications, if they are available. Reformulated Gasoline Many areas of the country require the use of cleaner burning gasoline referred to as reformulated gasoline.
Page 361: Mmt In Gasoline
Problems that result from using methanol/gasoline or E85 ethanol blends are not the responsibility of the manufacturer. While MTBE is an oxygenate made from methanol, it does not have the negative effects of metha- nol. MMT In Gasoline MMT is a manganese-containing metallic additive that is blended into some gasoline to increase octane.
Page 362: Carbon Monoxide Warnings
360 STARTING AND OPERATING • The use of leaded gas is prohibited by Federal law. Using leaded gasoline can impair engine performance and damage the emissions control system. • An out-of-tune engine or certain fuel or ignition mal- functions can cause the catalytic converter to overheat. If you notice a pungent burning odor or some light smoke, your engine may be out of tune or malfunc- tioning and may require immediate service.
Page 363: Adding Fuel
• Guard against carbon monoxide with proper mainte- nance. Have the exhaust system inspected every time the vehicle is raised. Have any abnormal conditions repaired promptly. Until repaired, drive with all side windows fully open. • Keep the trunk/liftgate closed when driving your vehicle to prevent carbon monoxide and other poison- ous exhaust gases from entering the vehicle.
Page 364 362 STARTING AND OPERATING NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler cap door reinforcement. Gas Cap Tether Hook CAUTION! • Damage to the fuel system or emissions control system could result from using an improper fuel tank filler tube cap (gas cap).
Page 365: Loose Fuel Filler Cap Message
WARNING! • Never have any smoking materials lit in or near the vehicle when the gas cap is removed or the tank filled. • Never add fuel to the vehicle when the engine is running. • A fire may result if gasoline is pumped into a portable container that is inside of a vehicle.
Page 366: Vehicle Loading
364 STARTING AND OPERATING VEHICLE LOADING The load carrying capacity of your vehicle is shown on the “Vehicle Certification Label.” This information should be used for passenger and luggage loading as indicated. Do not exceed the specified Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight Rating (GAWR).
Page 367: Overloading
WARNING! Because the front wheels steer the vehicle, it is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. Overloading The load carrying components (axle, springs, tires, wheels, etc.) of your vehicle will provide satisfactory...
Page 368 366 STARTING AND OPERATING A loaded vehicle is shown in the illustration. Note that neither the GVWR nor the GAWR capacities have been exceeded. EXAMPLE ONLY Empty Weight Load (including driver, pas- sengers, and cargo) Total GAWR NOTE: Refer to the “Vehicle Certification Label” affixed to the rear of the driver’s door for your vehicle’s GVWR and GAWRs.
Page 369: Trailer Towing
TRAILER TOWING Trailer towing with this vehicle is not recommended. RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) TOWING THIS VEHICLE BEHIND ANOTHER VEHICLE (Flat Towing With All Four Wheels On The Ground) Recreational towing for this vehicle is not recommended. NOTE: If the vehicle requires towing, make sure all four wheels are off the ground.
Page 371: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flasher ....370 If Your Engine Overheats ....371 TIREFIT Tire Repair .
Page 372: Hazard Warning Flasher
370 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHER The HAZARD switch is located in the center of the instrument panel between the center air outlets. Hazard Flasher Switch Depress the switch to activate the flashers. When acti- vated, all directional turn signals will flash on and off to warn oncoming traffic of an emergency.
Page 373: If Your Engine Overheats
IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate ac- tion. • On the highways — Slow down. • In city traffic — While stopped, put transmission in NEUTRAL, but do not increase engine idle speed.
Page 374: Tirefit Tire Repair
372 WHAT TO DO IN EMERGENCIES WARNING! A hot engine cooling system is dangerous. You or others could be badly burned by steam or boiling coolant. You may want to call a service center if your vehicle overheats. If you decide to look under the hood yourself, refer to Section 7 and follow the warnings under the Cooling System Pressure Cap paragraph.
Page 375 TIREFIT contents 1. Air pump hose 2. Power plug and cable 3. AIR PUMP switch 4. Pressure gauge 5. TIREFIT sealant bottle 6. TIREFIT sealant hose WHAT TO DO IN EMERGENCIES 373 WARNING! • Do not attempt to repair a tire on the side of the vehicle close to traffic.
Page 376 374 WHAT TO DO IN EMERGENCIES Sealing tire with TIREFIT Turn on the hazard warning flashers. 1. Move the shift lever to the PARK position, turn off the engine, and set the parking brake. 2. Remove the TIREFIT kit from the trunk. 3.
Page 377 14. Disconnect the air pump hose (1) from the underside of the sealant bottle (5) by flipping the hose valve open. 15. Connect the air pump hose valve to the tire valve and flip the hose valve closed. 16. Leave the parking brake set and the shift lever in PARK and start the engine.
Page 378 376 WHAT TO DO IN EMERGENCIES 25. Leave the parking brake set and the shift lever in PARK and start the engine. 26. Inflate the tire to the pressure indicated on the tire pressure label on the driver-side latch pillar by pressing the switch (3) on the air pump to I (ON) and watching the pressure gauge.
Page 379: Jump-Starting Procedures
JUMP-STARTING PROCEDURES WARNING! • Take care to avoid the radiator cooling fan whenever the hood is raised. It can start anytime the ignition switch is ON. You can be hurt by the fan. • Do not attempt to push or tow your vehicle to get it started. Vehicles equipped with an automatic transmission cannot be started this way.
Page 380 378 WHAT TO DO IN EMERGENCIES 3. Set the parking brake, place the automatic transmis- sion in PARK, and turn the ignition switch to the LOCK position on both vehicles. 4. Turn off the heater, radio, and all unnecessary electri- cal loads.
Page 381 WARNING! • You should not try to start your vehicle by pushing or towing. • Do not connect the cable to the negative post of the discharged battery. The resulting electrical spark could cause the battery to explode. • During cold weather when temperatures are be- low the freezing point, electrolyte in a discharged battery may freeze.
Page 382: Freeing A Stuck Vehicle
380 WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels.
Page 383: Towing A Disabled Vehicle
WARNING! Fast spinning tires can be dangerous. Forces gener- ated by excessive wheel speeds may cause tire dam- age or failure. A tire could explode and injure some- one. Do not spin your vehicle’s wheels faster than 35 mph (55 km/h) when you are stuck, and don’t let anyone near a spinning wheel, no matter what the speed.
Page 384: Towing This Vehicle Behind Another Vehicle With A Tow Dolly
382 WHAT TO DO IN EMERGENCIES CAUTION! • Do not attempt to tow this vehicle from the front with sling type towing equipment. Damage to the front fascia will result. • If the transmission is not operative or if the vehicle is to be towed more than 30 mi (48 km), then the only approved method of towing is with a flat-bed truck.
Page 385: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS 6.1L Engine Compartment ....386 Onboard Diagnostic System — OBD II ..387 Loose Fuel Filler Cap ....387 Emissions Inspection And Maintenance Programs .
Page 386 384 MAINTAINING YOUR VEHICLE Power Steering — Fluid Check ... . 400 Front And Rear Suspension Ball Joints ..401 Steering Linkage ..... . 401 Body Lubrication .
Page 387 Fluids And Capacities ....435 Fluids, Lubricants, And Genuine Parts ..436 MAINTAINING YOUR VEHICLE 385 Engine .
Page 388: 6.1L Engine Compartment
386 MAINTAINING YOUR VEHICLE 6.1L ENGINE COMPARTMENT 1 — Remote Jump-Start Positive Battery Post 2 — Fuses (Front Power Distribution Center) 3 — Coolant Pressure Cap 4 — Brake Fluid Reservoir Access Cover 5 — Coolant Bottle 6 — Power Steering Fluid 7 —...
Page 389: Onboard Diagnostic System - Obd Ii
ONBOARD DIAGNOSTIC SYSTEM — OBD II Your vehicle is equipped with a sophisticated onboard diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic transmission control systems. When these systems are operating properly, your vehicle will provide excellent performance and fuel economy, as well as engine emis- sions well within current government regulations.
Page 390: Emissions Inspection And Maintenance Programs
388 MAINTAINING YOUR VEHICLE TRIP ODOMETER button to turn off the message. If the problem continues, the message will appear the next time the vehicle is started. A loose, improperly installed, or damaged fuel filler cap may also turn on the MIL. EMISSIONS INSPECTION AND MAINTENANCE PROGRAMS In some localities, it may be a legal requirement to pass...
Page 391: Replacement Parts
5. Approximately 15 seconds later, one of two things will happen: a. The MIL will flash for about 10 seconds and then return to being fully illuminated until you turn OFF the ignition key or start the engine. This means that your vehicle’s OBD II system is not ready and you should not proceed to the I/M station.
Page 392: Authorized Dealer Service
390 MAINTAINING YOUR VEHICLE AUTHORIZED DEALER SERVICE Your authorized dealer has the qualified service person- nel, special tools, and equipment to perform all service operations in an expert manner. Service manuals are available which include detailed service information for your vehicle. Refer to these manuals before attempting any procedure yourself.
Page 393: Engine Oil
Engine Oil Checking Oil Level To assure proper engine lubrication, the engine oil must be maintained at the correct level. Check the oil level at regular intervals, such as every fuel stop. The best time to check the engine oil level is about five minutes after a fully warmed engine is shut off or before starting the engine after it has sat overnight.
Page 394 392 MAINTAINING YOUR VEHICLE Change Engine Oil Refer to the Maintenance Schedule in Section 8. NOTE: Under no circumstances should oil change intervals exceed 6,000 mi (10 000 km) or six months, whichever occurs first. Engine Oil Selection For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or...
Page 395: Engine Oil Filter
The engine oil filler cap also shows the recommended engine oil viscosity for your engine. For information on engine oil filler cap location, refer to the “Engine Com- partment” illustration in this section. Materials Added to Engine Oil The manufacturer strongly recommends against the ad- dition of any additives (other than leak detection dyes) to the engine oil.
Page 396: Spark Plugs
394 MAINTAINING YOUR VEHICLE Inspect belts for evidence of cuts, cracks, glazing, or frayed cords and replace if there is indication of damage that could result in belt failure. Also, check belt routing to make sure there is no interference between the belts and other engine components.
Page 397: Fuel Filter
Fuel Filter A plugged fuel filter can cause stalling, limit the speed at which a vehicle can be driven or cause hard starting. Should an excessive amount of dirt accumulate in the fuel tank, filter replacement may be necessary. See your authorized dealer for service.
Page 398 396 MAINTAINING YOUR VEHICLE WARNING! A hot exhaust system can start a fire if you park over materials that can burn. Such materials might be grass or leaves coming into contact with your exhaust system. Do not park or operate your vehicle in areas where your exhaust system can contact anything that can burn.
Page 399: Maintenance-Free Battery
MAINTAINING YOUR VEHICLE 397 Maintenance-Free Battery The top of the maintenance-free battery is permanently sealed. You will never have to add water, nor is periodic maintenance required. NOTE: The battery is stored under an access cover in the trunk. Remote battery terminals are located in the engine compartment for jump-starting.
Page 400 398 MAINTAINING YOUR VEHICLE WARNING! • Battery fluid is a corrosive acid solution and can burn or even blind you. Don’t allow battery fluid to contact your eyes, skin, or clothing. Don’t lean over a battery when attaching clamps. If acid splashes in eyes or on skin, flush the area imme- diately with large amounts of water.
Page 401: Air Conditioner Maintenance
Air Conditioner Maintenance For best possible performance, your air conditioner should be checked and serviced by an authorized dealer at the start of each warm season. This service should include cleaning of the condenser fins and a performance test. Drive belt tension should also be checked at this time.
Page 402: A/C Air Filter - If Equipped
400 MAINTAINING YOUR VEHICLE Refrigerant Recovery and Recycling R-134a Air Conditioning Refrigerant is a hydrofluorocar- bon (HFC) that is endorsed by the Environmental Pro- tection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.
Page 403: Front And Rear Suspension Ball Joints
WARNING! Fluid level should be checked on a level surface and with the engine OFF to prevent injury from moving parts and to ensure accurate fluid level reading. Do not overfill. Use only manufacturer’s recommended power steering fluid. If necessary, add fluid to restore to the proper indicated level.
Page 404: Windshield Wiper Blades
402 MAINTAINING YOUR VEHICLE The external lock cylinders should be lubricated twice a year, preferably in the Fall and Spring. Apply a small amount of a high quality lubricant such as Mopar Lock Cylinder Lubricant or equivalent directly into the lock cylinder.
Page 405: Exhaust System
The fluid reservoir will hold nearly 1 gal (4 l) of washer fluid when the message “Low Washer Fluid” appears in the Electronic Vehicle Information Center (EVIC). WARNING! Commercially available windshield washer solvents are flammable. They could ignite and burn you. Care must be exercised when filling or working around the washer solution.
Page 406: Cooling System
404 MAINTAINING YOUR VEHICLE Cooling System WARNING! • When working near the radiator cooling fan, dis- connect the fan motor lead or turn the ignition switch to the LOCK position. The fan is tempera- ture controlled and can start at any time the ignition switch is in the ON position.
Page 407 drain from the coolant recovery bottle. DO NOT RE- MOVE THE COOLANT PRESSURE CAP WHEN THE COOLING SYSTEM IS HOT. Cooling System — Drain, Flush, and Refill The system should be drained, flushed, and refilled at the intervals shown in the “Maintenance Schedule” in Sec- tion 8.
Page 408 406 MAINTAINING YOUR VEHICLE Adding Coolant Your vehicle has been built with an improved engine coolant that allows extended maintenance intervals. This coolant can be used up to five years or 100,000 mi (160 000 km) before replacement. To prevent reducing this extended maintenance period, it is important that you use the same coolant throughout the life of your vehicle.
Page 409 The cap should be inspected and cleaned if there is any accumulation of foreign material on the sealing surfaces. WARNING! • The warning words “DO NOT OPEN HOT” on the cooling system pressure cap are a safety pre- caution. Never add coolant when the engine is overheated.
Page 410 408 MAINTAINING YOUR VEHICLE The radiator normally remains completely full, so there is no need to remove the radiator cap unless checking for coolant freeze point or replacing coolant. Advise your service attendant of this. As long as the engine operating temperature is satisfactory, the coolant bottle need only be checked once a month.
Page 411: Hoses And Vacuum/Vapor Harnesses
• Make sure that the radiator and coolant recovery bottle overflow hoses are not kinked or obstructed. • Keep the front of the radiator clean. If your vehicle is equipped with air conditioning, keep the front of the condenser clean, also. •...
Page 412: Brake System
410 MAINTAINING YOUR VEHICLE You are urged to use only the manufacturer’s specified hoses with quick connect fittings, or their equivalent in material and specification, in any fuel system servicing. It is mandatory to replace any damaged hoses or quick connect fittings that have been removed during service.
Page 413 Ensure nylon tubing in these areas has not melted or collapsed. Inspect all hose connections such as clamps and cou- plings to make sure they are secure and no leaks are present. NOTE: • Often, fluid such as oil, power steering fluid, and brake fluid are used during assembly plant operations to facilitate the assembly of hoses to couplings.
Page 414 412 MAINTAINING YOUR VEHICLE Clean the top of the master cylinder area before removing the cap. Add fluid to bring the level up to the top of the “FULL” mark on the side of the master cylinder reservoir. Overfilling of fluid is not recommended because it may cause leaking in the system.
Page 415: Automatic Transmission
CAUTION! Do not allow petroleum-based fluid to contaminate the brake fluid. Seal damage may result. Automatic Transmission Fluid Level Check Regular automatic transmission fluid level checks are not required. For this reason, the dipstick is omitted. If you notice fluid loss or gear shift malfunction, have your authorized dealer check the transmission fluid level.
Page 416: Front And Rear Wheel Bearings
414 MAINTAINING YOUR VEHICLE Fluid and Filter Changes Refer to the Maintenance Schedule in Section 8 for the recommended transmission fluid and filter change inter- vals. If the transmission is disassembled for any reason, the fluid and filter should be changed. Selection of Lubricant It is important that the proper lubricant is used in the transmission to assure optimum transmission perfor-...
Page 417 highly corrosive to the metal in your vehicle. Outside parking, which exposes your vehicle to airborne contami- nants, road surfaces on which the vehicle is operated, extreme hot or cold weather and other extreme condi- tions will have an adverse effect on paint, metal trim, and underbody protection.
Page 418 416 MAINTAINING YOUR VEHICLE CAUTION! Do not use abrasive or strong cleaning materials such as steel wool or scouring powder that will scratch metal and painted surfaces. Special Care • If you drive on salted or dusty roads or if you drive near the ocean, hose off the undercarriage at least once a month.
Page 419 heavy soil and/or excessive brake dust, use Mopar Wheel Cleaner (05066247AB) or equivalent or select a nonabrasive, non-acidic cleaner. Do not use scouring pads, steel wool, a bristle brush, or metal polishes. Only Mopar or equivalent is recommended. Do not use oven cleaner.
Page 420 418 MAINTAINING YOUR VEHICLE Cleaning Headlights Your vehicle has plastic headlights that are lighter and less susceptible to stone breakage than glass headlights. Plastic is not as scratch resistant as glass and therefore different lens cleaning procedures must be followed. To minimize the possibility of scratching the lenses and reducing light output, avoid wiping with a dry cloth.
Page 421: Cleaning The Center Console Cupholders
Seat Belt Maintenance Do not bleach, dye, or clean the belts with chemical solvents or abrasive cleaners. This will weaken the fabric. Sun damage can also weaken the fabric. If the belts need cleaning, use Mopar Total Clean, a mild soap solution, or lukewarm water.
Page 422 420 MAINTAINING YOUR VEHICLE CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
Page 423 Cavity Car- Mini- Description tridge Fuse Fuse 30 Amp — Windshield Wiper Pink 30 Amp — Anti-lock Brake System Pink (ABS) Valves 40 Amp — Radiator Fan Green 50 Amp — Anti-lock Brake System (ABS) Pump Motor — — — 50 Amp —...
Page 424: Fuses (Rear Power Distribution Center)
422 MAINTAINING YOUR VEHICLE Fuses (Rear Power Distribution Center) There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays. Rear Power Distribution Center Opening The Access Panel...
Page 425 CAUTION! • When installing the power distribution center cover, it is important to ensure the cover is prop- erly positioned and fully latched. Failure to do so may allow water to get into the power distribution center and possibly result in an electrical system failure.
Page 426 424 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse — 15 Amp Diagnostic Link Connec- Blue tor (DLC)/Wireless Con- trol Module (WCM)/ Wireless Ignition Node (WIN) — 20 Amp Power Outlet Yellow — — — 11 * — —...
Page 427 Cavity Car- Mini- Description tridge Fuse Fuse — 10 Amp Ignition Run — 5 Amp Adaptive Cruise Control Orange (ACC) - if equipped/ Cluster/Electronic Sta- bility Program (ESP)/ Powertrain Control Module (PCM)/STOP LIGHT Switch — 10 Amp Door Modules/Power Mirrors/Steering Con- trol Module (SCM) —...
Page 428 426 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description tridge Fuse Fuse — 10 Amp Heated Mirrors - if equipped — 5 Amp Auto Inside Rearview Orange Mirror/Heated Seats - if equipped/Switch Bank — 10 Amp AC Heater Control/ Headlights/Park Assist - if equipped/Tire Pres- sure Monitoring - if equipped/Occupant Re-...
Page 429: Vehicle Storage
VEHICLE STORAGE If you are leaving your vehicle dormant for more than 21 days, you may want to take these steps to protect your battery. • Disconnect the negative cable from the battery. • Anytime you store your vehicle, or keep it out of service (i.e., vacation) for two weeks or more, run the air conditioning system at idle for about five minutes in the fresh air and high blower setting.
Page 430: Bulb Replacement
428 MAINTAINING YOUR VEHICLE LIGHT BULBS — Exterior Low Beam Headlight – High Intensity Discharge (HID) ..D1S (Serviced at Authorized Dealer) High Beam Headlight..... 9005 Front Park/Turn Light .
Page 431 NOTE: When HID headlights are turned on, there is a blue hue to the lights. This diminishes and becomes more white after approximately 10 seconds, as the system charges. 1. Open the hood. NOTE: Removal of the air cleaner filter housing may be necessary prior to replacing bulbs in the headlight assem- bly on the driver side of the vehicle.
Page 432 430 MAINTAINING YOUR VEHICLE CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. 3 — Park/Turn Light Bulb...
Page 433: Tail/Stop, Tail, Turn Signal Light, And Backup Light
Tail/Stop, Tail, Turn Signal Light, and Backup Light 1. Open the Trunk. 2. Remove two fasteners from the back of the tail light assembly. 3. Pull back the trunk liner. MAINTAINING YOUR VEHICLE 431 4. Remove the remaining fastener from the back of the tail light assembly.
Page 434 432 MAINTAINING YOUR VEHICLE 7. Pull the tail light assembly clear from the vehicle to access the bulbs. Turn bulb sockets counterclockwise to remove. 8. Turn the appropriate bulb and socket assembly coun- terclockwise to remove it from the tail light assembly. 2 —...
Page 435 MAINTAINING YOUR VEHICLE 433 3 — Turn Signal Light Bulb 4 — Backup Light Bulb 9. Disconnect the bulb from the socket assembly and install the replacement bulb. 10. Reinstall the bulb and socket assembly into the tail light assembly, and then turn it clockwise.
Page 436: License Light
434 MAINTAINING YOUR VEHICLE 11. Reinstall the tail light assembly, fasteners, electrical connector, and trunk liner. 12. Close the trunk. License Light 1. Remove the screws securing the light to the rear fascia. 2. Remove the bulb and socket assembly. 3.
Page 437: Fluids And Capacities
FLUIDS AND CAPACITIES Fuel (approximate) 6.1 Liter Engine Engine Oil with Filter 6.1 Liter Engine (SAE 0W-40) Cooling System * 6.1 Liter Engine (Mopar Antifreeze/Coolant 5 Year/ 100,000 Mile Formula) or equivalent * Includes heater and coolant recovery bottle filled to MAX level.
Page 438: Engine
436 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS, AND GENUINE PARTS Engine Component Engine Coolant Engine Oil (6.1L) Oil Filter (6.1L) Spark Plugs (6.1L) Fuel Selection (6.1L) Fluids, Lubricants, and Genuine Parts Mopar Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Or- ganic Additive Technology) or equivalent For best performance and maximum protection under all types of operating conditions, the manufacturer only recommends full synthetic engine oils that meet the American Petroleum Institute (API) categories of SM or SM/CF, and...
Page 439: Chassis
Chassis Component Automatic Transmission Brake Master Cylinder Power Steering Reservoir Rear Axle Fluids, Lubricants, and Genuine Parts Mopar ATF+4 Automatic Transmission Fluid Mopar DOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids.
Page 441 MAINTENANCE SCHEDULES CONTENTS Emissions Control System Maintenance ..440 Maintenance Schedule ....440 Severe Duty ......442 Required Maintenance Intervals .
Page 442: Emissions Control System Maintenance
Chrysler recommends that these maintenance intervals be performed at your selling dealer. The technicians at your dealership know your vehicle best, and have access...
Page 443 At Each Stop for Fuel • Check the engine oil level. Refer to “Engine Oil” under “Maintenance Procedures” in Section 7. • Check the windshield washer solvent and add if required. Once a Month • Check tire pressure and look for unusual wear or damage.
Page 444: Severe Duty
442 MAINTENANCE SCHEDULES Severe Duty If your vehicle is operated under the Severe Duty condi- tions listed below change your engine oil and filter every 3,000 mi (5 000 km) or three months as indicated in the Maintenance Schedule. • Stop and go driving. •...
Page 445: Required Maintenance Intervals
Required Maintenance Intervals Maintenance Items Change the engine oil and engine oil filter if using your vehicle under any of these severe duty condi- tions: Short trips, stop and go driving, dusty or off- road conditions, police, taxi, fleet, or frequent trailer towing.
Page 446 444 MAINTENANCE SCHEDULES Maintenance Items Replace the air conditioning filter (if equipped). Inspect the rear axle fluid. Inspect the CV joints. Perform the first inspection at 12,000 mi (20 000 km) or 12 months. Inspect the exhaust system. Perform the first inspec- tion at 12,000 mi (20 000 km) or 12 months.
Page 447 Maintenance Items Inspect and replace PCV valve if necessary. Flush and replace the engine coolant. Replace the spark plugs. Change the automatic transmission fluid and filter. WARNING! You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment.
Page 449: If You Need Consumer Assistance
IF YOU NEED CONSUMER ASSISTANCE CONTENTS Suggestions For Obtaining Service For Your Vehicle ......449 Prepare For The Appointment .
Page 450 448 IF YOU NEED CONSUMER ASSISTANCE Publication Order Forms ....454 Department Of Transportation Uniform Tire Quality Grades ......455 Treadwear .
Page 451: Suggestions For Obtaining Service For Your Vehicle
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR VEHICLE Prepare For The Appointment If you’re having warranty work done, be sure to have the right papers with you. Take your warranty folder. All work to be performed may not be covered by the warranty.
Page 452: If You Need Assistance
450 IF YOU NEED CONSUMER ASSISTANCE IF YOU NEED ASSISTANCE The manufacturer and its authorized dealers are vitally interested in your satisfaction. We want you to be happy with our products and services. Warranty service must be done by an authorized dealer. We strongly recommend that you take your vehicle to your authorized selling dealer.
Page 453: Daimlerchrysler Canada Inc
DaimlerChrysler Canada Inc. Customer Center P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: (800) 465–2001 In Mexico contact: Av. Prolongacion Paseo de la Reforma, 1240 Sante Fe C.P. 05109 Mexico, D. F. In Mexico: (915) 729–1248 or 729–1240 Outside Mexico: (525) 729–1248 or 729–1240 Customer Assistance for the Hearing or Speech Impaired (TDD/TTY) To assist customers who have hearing difficulties, the...
Page 454: Warranty Information (U.s. Vehicles Only)
452 IF YOU NEED CONSUMER ASSISTANCE The manufacturer will not stand behind any service contract that is not the manufacturer’s Service Contract. It is not responsible for any service contract other than the manufacturer’s Service Contract. If you purchased a service contract that is not a manufacturer’s Service Contract, and you require service after your manufactur- er’s New Vehicle Limited Warranty expires, please refer...
Page 455: Mopar Parts
MOPAR PARTS MOPAR fluids, lubricants, parts, and accessories are available from your authorized dealer. They will help you keep your vehicle operating at its best. REPORTING SAFETY DEFECTS In the 50 United States and Washington, D.C. If you believe that your vehicle has a defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the...
Page 456 454 IF YOU NEED CONSUMER ASSISTANCE PUBLICATION ORDER FORMS To order the following manuals, you may use either the website or the phone numbers listed below. Visa, Mas- tercard, American Express, and Discover orders are ac- cepted. If you prefer mailing your payment, please call for an order form.
Page 457 Call toll free at: • 1–800–890–4038 (U.S.) • 1–800–387–1143 (Canada) Visit us on the Worldwide Web at: • www.techauthority.daimlerchrysler.com • www.daimlerchrysler.ca/manuals DEPARTMENT OF TRANSPORTATION UNIFORM TIRE QUALITY GRADES The following tire grading categories were established by the National Highway Traffic Safety Administration. The specific grade rating assigned by the tire’s manufacturer in each category is shown on the sidewall of the tires on your vehicle.
Page 458 456 IF YOU NEED CONSUMER ASSISTANCE Traction Grades The traction grades, from highest to lowest, are AA, A, B, and C. These grades represent the tire’s ability to stop on wet pavement, as measured under controlled conditions on specified government test surfaces of asphalt and concrete. A tire marked C may have poor traction performance.
Page 459 INDEX...
Page 460 458 INDEX About Your Brakes ....315,317 ABS (Anti-Lock Brake System) ... . 317,321 Adaptive Cruise Control (ACC) (Cruise Control) .
Page 461 Auto Unlock, Doors ..... . . 30 Auto Up Power Windows ....34 Automatic Dimming Mirror .
Page 462 460 INDEX Anti-Lock (ABS) ....317,321 Fluid Check ..... . . 411,437 Hoses .
Page 463 Climate Control ......283 Clock ..... 231,234,237,253,258 Coin Holder .
Page 464 462 INDEX Dealer Service ......390 Deck Lid, Emergency Release ....38 Deck Lid, Power Release .
Page 465 Jump Starting ......377 Overheating ......371 Towing .
Page 466 464 INDEX Filters Air Cleaner ......394 Air Conditioning ....290,400 Engine Fuel .
Page 467 Materials Added ..... . . 359 Methanol ......358 Octane Rating .
Page 468 466 INDEX Bulb Replacement ..... . 428 Cleaning ......418 Delay .
Page 469 Jump Starting ......377 Key, Programming ......17 Key, Replacement .
Page 470 468 INDEX Headlight Switch ..... . 132 Headlights ......132,428 Headlights On Reminder .
Page 471 Power Door ......28 Low Tire Pressure System ....347 Lower Anchors and Tether for CHildren (LATCH) .
Page 472 470 INDEX New Vehicle Break-In Period ....73 Occupant Restraints ..... . . 39 Octane Rating, Gasoline (Fuel) .
Page 473 Placard, Tire and Loading Information ..332 Port Universal Serial Bus (USB) ... . . 232,251 USB ......232,251 Power Brakes .
Page 474 472 INDEX Rear Window Defroster ....292 Rear Window Features ....292 Reception, Radio .
Page 475 Seat Belt Reminder ..... . . 46 Seat Belts ......39,40,76 Adjustable Upper Shoulder Anchorage .
Page 476 474 INDEX Settings, Personal ......226 Shifting ....... 301 Automatic Transmission .
Page 477 Storing Your Vehicle ..... . 427 Stuck, Freeing ......380 Sun Roof .
Page 478 476 INDEX Rotation ......345 Safety ......328,336 Sizes .
Page 479 Universal Serial Bus (USB) Port ... 232,251 Universal Transmitter ..... 177 Unleaded Gasoline .
Page 480 478 INDEX Power ....... 33 Windshield Defroster ....77,288 Windshield Washers .
Page 481 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this vehicle’s electronic system to provide immunity to radio frequency signals. Mobile two-way radios and telephone equipment must be installed properly by trained person- nel. The following must be observed during installation. The positive power connection should be made directly to the battery and fused as close to the battery as possible.
Page 482 81-026-0848 First Edition Printed in U.S.A.
