Cleaning the Front Caster Wheel
1 Pull firmly on the front wheel module to remove it
from the robot.
2 Pull firmly on the wheel to remove it from its
housing (see illustration below).
3
Remove any debris from inside the wheel cavity.
4 Reinstall all parts when finished.
Make sure the wheel clicks back into place.
Housing
Important:
A front wheel clogged with hair and debris
could result in damage to your floor. If the wheel is not
spinning freely after you have cleaned it, please contact
Customer Care.
Axle Wheel
Cleaning the Multi-Surface Brushes
1 Pinch the brush frame release
tab, lift the tab, and remove any
obstructions.
Remove the brushes from the
2
robot. Remove the brush caps
from the ends of the brushes.
Remove any hair or debris that
has collected beneath the
caps. Reinstall the brush caps.
Remove any hair or debris
3
from the square and
hexagonal pegs on the
opposite side of the brushes.
Remove the bin from the
4
robot and clear any debris
from the vacuum path.
5 Reinstall the brushes in the robot.
Match the shape of the brush pegs
with the shape of the brush icons in
the cleaning head module.
