Step 3: Connect External Devices
Connect the monitor, mouse, keyboard, and network cables.
NOTE:
model.
1
2
3
4
5
6
NOTE:
system board may be used at the same time. Some settings may need to be
changed in Computer Setup to use both connectors. For information about Boot
Order, refer to the Computer Setup (F10) Utility Guide on the Documentation and
Diagnostics CD.
CAUTION:
the computer until the operating system is successfully installed.
Doing so may cause errors and may prevent the operating system
from installing properly.
ENWW
Arrangement and number of connectors may vary by
Power Cord Connector
Voltage Select Switch
PS/2 Mouse Connector (green)
PS/2 Keyboard Connector
(purple)
Universal Serial Bus (USB)
Serial Connector
If a PCI graphics card is installed, the connectors on the card and the
Do not add optional hardware or third-party devices to
7 Parallel Connector
8 Monitor Connector
9 Microphone Connector (pink)
10 Line-Out Connector for
powered audio devices (green)
11 Line-In Audio Connector (blue)
12 RJ-45 Network Connector
