Linking Parent Unit And Baby Unit - Philips Avent SCD734 User Manual

Linking parent unit and baby unit

Dry materials
Wood, plaster, cardboard, glass
(without metal, wires or lead)
Brick, plywood
Reinforced concrete
Metal grilles or bars
Metal or aluminium sheets
1 Press and hold the
power-on light goes on
2 Press and hold the
display lights up. The ‚link' light on the parent unit starts flashing red
and the message ‚I AM LINKING' appears on the display.
When the parent unit and baby unit are linked, the ‚link' light turns
solid green The signal strength indicator and the message ‚LINKED'
appear on the display
If no connection is established, the message ‚NOT LINKED' is displayed
and the parent unit starts and the parent unit starts to beep
What to do if no link is established
- If the parent unit is out of range, place it closer to the baby unit, but
not closer than 1 metre/3.5 feet.
- If the baby or parent unit is too close, <2 m/6.5 ft away from another
DECT appliance (e.g. a cordless phone), switch off this appliance or
move the unit away from this appliance
- If the baby unit is switched off, switch it on.
Operating range
- The operating range is 330 metres/1000 feet outdoors and up to
50 metres/150 feet indoors.
- The operating range of the baby monitor varies depending on the
surroundings and factors that cause interference Wet and moist
materials cause so much interference that the range loss is up to
100% For interference from dry materials, see the table below
Material thickness
< 30 cm (12 in)
< 30 cm (12 in)
< 30 cm (12 in)
< 1 cm (0.4 in)
< 1 cm (0.4 in)
button on the baby unit for 2 seconds until the
button on the parent unit for 2 seconds until the
- 5 -
Loss of range
0-10 %
5-35 %
30-100 %
90-100 %
100 %
