Conettix Cellular Communicators
1
1
2
3
1.
2.
Bosch Security Systems B.V.
2
B444-V/B444-A cellular module
Primary antenna connection port
B40-P/MB25/MB50 external antenna
Connect antenna wire to the B40-P/MB25/MB50 antenna port (callout #3).
Connect other end of B40-P/MB25/MB50 antenna wire to primary antenna port on B444-
V/B444-A cellular module (callout #2).
3
Installation Manual
Component overview | en
2020.02 | 04 | F.01U.345.070
