Refrigerator
user manual
English
imagine
the possibilities
Thank you for purchasing a Samsung product.
To receive a more complete service,
please register your product at
www.samsung.com/register
DA99-01584A(HM-P)-EN(0.4).indd
1
2009.9.30
4:31:14 PM

Advertisement

Table of Contents
loading

Related Manuals for Samsung SRS583HDP

Summary of Contents for Samsung SRS583HDP

  • Page 1 Refrigerator user manual English imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/register DA99-01584A(HM-P)-EN(0.4).indd 2009.9.30 4:31:14 PM...
  • Page 2 KEy fEaturEs of your nEw rEfrigErator Your Samsung Side-By-Side Refrigerator comes equipped with many space-saving, innovative storage and energy-efficient features. HiDDEn HingEs & Door s/w • Slick-covered hidden hinges & door s/w helps Neat & Stylish square frontal view.
  • Page 3 safety information safEty inforMation • Before operating the appliance, please read this manual thoroughly and retain it for your WARNING reference. • Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those described in this manual. WARNING CAUTION/WARNING SYMBOLS USED Indicates that a danger of death or serious injury exists.
  • Page 4 safety information • In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited depends on the amount of WARNING refrigerant used.
  • Page 5 - You run risk of causing a fire, malfunction and/or personal injury. • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung electronics service center. • Keep ventilation opening in the appliance enclosure or mounting structure clear of obstruction.
  • Page 6 safety information Caution signs for CLEaning • Do not insert your hands into the bottom area under the appliance. - Any sharp edges may cause personal injury. • Never put fingers or other objects into the dispenser hole and ice chute. - It may cause personal injury or material damage.
  • Page 7 safety information aDDitionaL tiPs for ProPEr usagE • Allow the appliance to stand for 2hours after installation. • To get best performance of product, - Do not place foods too closely in front of the vents at the rear of the appliance as it can obstruct free air circulation in the freezer compartment.

  • Page 8: Table Of Contents

    17 Making minor adjustments to the doors 18 Checking the water dispenser line(optional) rEfrigErator 19 Installing the water dispenser line oPErating tHE saMsung 23 Setting up the refrigerator siDE-By-siDE rEfrigErator 24 Operating the refrigerator 25 Using the digital display...

  • Page 9: Getting Ready To Install The Refrigerator

    Congratulations on the purchase of your Samsung Side-By-Side Refrigerator. We hope you will enjoy the many state-of-the-art features and efficiencies that this new appliance has to offer. Selecting the best location for the refrigerator •...

  • Page 10: Removing The Refrigerator Doors

    rEMoVing tHE rEfrigErator Doors If your entrance won’t allow the refrigerator to pass easily through it, you can remove the doors. 1. Removing the Front Leg Cover First, open both the freezer and refrigerator doors, and then take off the front leg cover by turning the three screws counter-clockwise.
  • Page 11 setting up your side-by-side refrigerator 2. Removing the freezer door A few things to mention first. • Make sure that you lift the door straight up so the hinges are not bent or broken. • Be careful not to pinch the water tubing and wire harness on the door. •...
  • Page 12 Removing the Fridge Door 1. With the door closed, remove the upper hinge cover using a screwdriver. 2. Remove hinge screws and the ground screw by turning counter-clockwise, and take off the upper hinge . Be careful that the door does not fall on you as you are removing it 3.

  • Page 13: Reattaching The Refrigerator Doors

    setting up your side-by-side refrigerator rEattaCHing tHE rEfrigErator Doors Once you have safely placed your refrigerator where you plan for it to stay, it is time to put the doors back on. Reattaching the Freezer Door 1. Replace the freezer door by inserting the water line back into the lower corner of the door and then into the hole on the lower hinge Gently pull the water line back down so that it runs straight, with no kinks...
  • Page 14 Reattaching the Fridge Door 1. Insert the lower hinge back into the lower hinge bracket 2. Fit the hole in the corner of the fridge door over the lower hinge 3. Insert the upper hinge shaft into the hole on the hinge .
  • Page 15 setting up your side-by-side refrigerator Reattaching the Water Supply Line 1. Insert the water line into the coupler Reattaching the Front Leg Cover Before attaching the cover, check water connector for leakage. Replace the front leg cover by turning the three screws clockwise, as shown in the figure. front Leg Cover screw setting up...

  • Page 16: Leveling The Refrigerator

    LEVELing tHE rEfrigErator Now that the doors are back on the refrigerator, you will want to make sure the refrigerator is level so you can then make final adjustments. If the refrigerator is not level, it will not be possible to get the doors perfectly even. The front of the refrigerator is also adjustable.

  • Page 17: Making Minor Adjustments To The Doors

    setting up your side-by-side refrigerator MaKing Minor aDJustMEnts to tHE Doors Remember, a leveling refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on leveling the refrigerator. When the door of the freezer is higher than the fridge adjustment part...

  • Page 18: Checking The Water Dispenser Line(Optional)

    CHECKing tHE watEr DisPEnsEr LinE (oPtionaL) A water dispenser is just one of the helpful features on your new Samsung refrigerator. To help promote better health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms.
  • Page 19 Before being used, the leakage in these places should be examined CAUTION • Samsung Warranty does not cover WATER LINE INSTALLATION. • It’ll be done at customer’s charge except the retail price includes installation cost.
  • Page 20 instaLLing tHE watEr DisPEnsEr LinE For Exterior model Parts for water line Installation Water line fixer and pipe Water line purifier lock-clip screws connector purifier Connecting to the water supply line CAUTION Connect the water pipe with coupler and tap. The water line must be connected to the cold water pipe.
  • Page 21 setting up your side-by-side refrigerator Remove any residual matter inside the purifier. (Model with the purifier) - Open the main water tap to check whether water OUTLET SIDE is running through the water tube on the water inlet OF PURIFIER PURIFIER side of the purifier.
  • Page 22 Removing any residual matter inside the water supply line after installing filter. 1. Turn ON the main water supply & turn OFF the valve to the water supply line. 2. Run water through the dispenser until the water runs clear (approx.

  • Page 23: Setting Up The Refrigerator

    If you have any further questions, contact your Samsung Electronics service center. 1. Place the refrigerator in an appropriate location with reasonable clearance between the wall and the refrigerator.

  • Page 24: Operating The Refrigerator

    oPErating tHE rEfrigErator USINg THE CONTROL PANEL rsH1K/J, rsH3K rsH1f/D, rsH3f/D rsH1n/B, rsH3n Speeds up the time needed to freeze products in the freezer. This can be helpful if poWER FREEZE you need to quickly freeze items that spoil easily or if the temperature in the freezer BUTTON has warmed dramatically (For example, if the door was left open).

  • Page 25: Using The Digital Display

    SAMSUNG side-by-side refrigerator using tHE DigitaL DisPLay “88” segment on Freezer part indicates the current Freezer temperature. “88” segment on Fridge part indicates the current Fridge temperature. “Quick Cool”, “thaw”, “soft freeze” and “0 Zone” indicates the status of the CoolSelect Zone™ Drawer.

  • Page 26: Controlling The Temperature

    Filter Indicator When the filter indicator light is on, it is time to change the filter. Typically this happens about every 6 months. After removing the old water filter and installing a new one (see page 38 for instructions on how to do this), reset the indicator status light by pressing the Ice Type button for about 3 seconds.

  • Page 27: Using The Ice And Cold Water Dispenser

    SAMSUNG side-by-side refrigerator using tHE iCE anD CoLD watEr DisPEnsEr Press the Ice Type button to select the type of ice you want No Ice Select this if you want to turn off the icemaker Ice is made in cubes. When you select “Crushed”, the icemaker grinds the ice cubes into crushed ice.

  • Page 28: Shelves And Bins

    sHELVEs anD Bins Freezer Ice Maker Bucket (Optional) Lamp Cover Ice Chute Glass Shelves Plastic Shelf Door Bins Drawers Front Leg Cover Fridge Water Filter (Optional) Lamp Cover Dairy Bin Glass Shelf Wine Shelf(Optional) Egg Tray Z Shelf(Optional) Beverage Station (Optional) Moving Shelf(Optional) Door Bins...

  • Page 29: Storing Food

    Storing Food in the Freezer The Samsung Side-By-Side Refrigerator has been designed to provide you with maximum spacesaving features and functions. Here are some of the customized compartments we have created to keep your food fresher, longer. Remember, in order to prevent odor penetration to the ice, stored food should be wrapped securely and as airtight as possible.
  • Page 30 Storing Food in the Freezer Do not put your fingers, hands or any other objects in the ice ICE CHUTE chute or the ice maker bucket. This may result in personal injury WARNING or material damage. SHELVES Can be used to store all types of frozen food. Can be used for small packages of frozen DooR BINS food.

  • Page 31: Using The Coolselect Zone™ Drawer (Optional)

    SAMSUNG side-by-side refrigerator using tHE CooLsELECt ZonE™ DrawEr (oPtionaL) The CoolSelect Zone™ Drawer is designed to make your busy life just a little bit easier. Quick Cool Button You can use the “Quick Cool” operation with the CoolSelect Zone™ Drawer to quickly cool 1~3 canned beverages in about an hour.
  • Page 32 Select Button 1. When “soft freeze” is selected on the CoolSelect Zone™ Drawer, the temperature on the drawer digital panel displays 23°F(- 5°C), regardless of the overall temperature setting of the refrigerator. This feature helps keep meat and fish fresh for longer. 2.

  • Page 33: Removing The Freezer Accessories

    SAMSUNG side-by-side refrigerator rEMoVing tHE frEEZEr aCCEssoriEs Cleaning and rearranging the interior of the freezer is a snap. 1. Remove the glass shelf by pulling the shelf out as far as it will go. Then, gently lift it up and remove it.
  • Page 34 rEMoVing tHE friDgE aCCEssoriEs 1. Remove the spill Proof Glass Shelf by pulling the shelf out as far as it will go. Then, gently lift it up and gently remove it. 2. Remove the Vegetable & Fruit Drawer by pressing on the indentations found on the inside left and right sides of the Veggie Box/Dry Box cover and remove by pulling forward.

  • Page 35: Cleaning The Refrigerator

    SAMSUNG side-by-side refrigerator CLEaning tHE rEfrigErator Caring for your Samsung Side-By-Side Refrigerator prolongs the life of your appliance and helps keep it odor and germ-free. Cleaning the Interior Clean the inside walls and accessories with a mild detergent and then wipe dry with a soft cloth.
  • Page 36 Cleaning the Twin Deodorizer (Optional) To clean the twin deodorizer, remove the cover with a flat blade screwdriver. Remove the deodorizer cartridge from the cover and soak it in clean, warm water for at least 4 hours. Then, allow the cartridge to dry completely before replacing it in the holder. This can take up to 8 hours in a well-ventilated area.

  • Page 37: Changing The Interior Lights

    SAMSUNG side-by-side refrigerator CHanging tHE intErior LigHts Pull the power plug out of the socket before changing the interior light of the refrigerator. - Otherwise, there is a risk of electric shock. If you experience difficulty when changing the WARNING light, contact your service center.

  • Page 38: Changing The Water Filter

    Changing the Interior Lights in the Freezer The freezer light is located in the bottom of the auger motor case. 1. Lift the lamp cover up and pull out with 2 hands in the direction of arrows. 2. Replace the bulb with a new one. 3.

  • Page 39: Using The Doors

    This is due to air getting into the line. It should pose no problem to operation. Ordering replacement filters To order more water filter cartridges, contact your authorized Samsung dealer. using tHE Doors The refrigerator doors are equipped with a door opening and closing feature that ensures that the doors close all the way and are securely sealed.
  • Page 40 troubleshooting pRoBLEM SoLUTIoN the refrigerator does not • Check that the power plug is properly connected. work at all or it does not • Is the temperature control on the display panel set to the correct temperature? Try chill sufficiently. setting it to a lower temperature.
  • Page 41 circuit diagram RSH*K,J RSH*F,D DA99-01584A(HM-P)-EN(0.4).indd 2009.9.30 4:34:13 PM...
  • Page 42 circuit diagram RSH*B,N RSH1Z* DA99-01584A(HM-P)-EN(0.4).indd 2009.9.30 4:34:44 PM...
  • Page 43 circuit diagram RSH1V,S RSH1P,U DA99-01584A(HM-P)-EN(0.4).indd 2009.9.30 4:35:21 PM...
  • Page 44 This product should not be mixed with other commercial wastes for disposal. Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. In an effort to promote recycling this user manual is printed on recycled paper.
