Pioneer Elite VSX-LX105 Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Instruction Manual
AV RECEIVER
VSX-LX105
En

Advertisement

loading

Related Manuals for Pioneer Elite VSX-LX105

Summary of Contents for Pioneer Elite VSX-LX105

  • Page 1 Instruction Manual AV RECEIVER VSX-LX105...

  • Page 2: Table Of Contents

    Table of contents Firmware Update Speaker Layout Troubleshooting Main Room Main Room Room Supplementary Information Zone 2 Zone 2 Zone 2 Zone 2 Speaker Connections Reducing the Power Consumption in Standby State When the following functions are enabled, the power consumption in standby state increases.

  • Page 3: Speaker Layout

    Connections Before starting the procedure Firmware Update Connecting the TV Update Information of the firmware To ARC/eARC TV Firmware Update Procedure To Non-ARC TV Part Names Connecting the SUB Monitor Front Panel SUB Monitor Display Connecting Playback Devices Rear Panel Connecting an AV Component with HDMI Jack Remote Controller Mounted...
  • Page 4 Operating this unit Adding Play Queue Information Amazon Music Sort and Delete Registering This Unit with Amazon Music Playing Back Playing Amazon Music using the Pioneer Remote Connecting a transmitter for playback Connections Playing Amazon Music using the remote controller...
  • Page 5 Setting Up Operations Playing Back Pioneer Remote App Setup Main features Initial Setup System Setup Troubleshooting Menu list Input/Output Assign When the unit is operating erratically Speaker Troubleshooting Appendix Audio Adjust Source Speaker Layouts and Selectable Listening Modes Hardware Input Formats and Selectable Listening Modes...
  • Page 6 Before starting the procedure „ What's in the box „ Note • Connect speakers with an impedance of 4 Ω to 16 Ω. • The power cord must be connected only after all other connections are completed. • We will not accept any responsibility for damage arising from the connection with equipment manufactured by other companies.
  • Page 7 Firmware Update Updating the Firmware via Network This unit is equipped with a function to update the firmware via network or USB port when the firmware update is announced after purchase. This enables • While updating the firmware, do not do the following: various functions to be added and operations to be improved.
  • Page 8 Updating via USB If an Error Message is Displayed If an error occurs, "- Error!" is displayed on the display of the unit. ("" • While updating the firmware, do not do the following: represents an alphanumeric character.) Refer to the following descriptions and –...
  • Page 9 4. Connect the USB storage device to the USB port of this unit. • Others: • If an AC adapter is supplied with the USB storage device, connect the AC After removing the power plug once, insert it to the outlet, and then start the adapter, and use it with a household outlet.
  • Page 10 Part Names Front Panel is selected with the input selector and the unit is connected to the network. Lights up when any of the following functions is working or enabled in standby state of this unit. When this indicator is lighting, the power consumption in standby state increases, however, the increase in power consumption is minimized by entering the HYBRID STANDBY mode where only the...
  • Page 11 Front Panel (ø1/8″/3.5 mm). STANDBY/ON button the current setting conditions such as input 15. PHONES jack: Headphones with a standard selector, listening mode, etc. or call the plug (ø1/4"/6.3 mm) are connected. registered settings. ( →p85) 16. SETUP MIC jack: Connect the supplied speaker 19.
  • Page 12 Display Display input is selected. 3. Lights according to the type of input digital audio signal and the listening mode. 4. Lights in the following conditions. TUNED: Receiving AM/FM radio. STEREO: Receiving FM stereo. SLEEP: Sleep timer is set. ( →p114) AUTO STBY: Auto Standby is set.
  • Page 13 Rear Panel Rear Panel 6. NETWORK port: Connect to the network with an Ethernet cable. 7. USB port: Connect a USB storage device to play music files ( →p87). You can also supply power (5 V/1 A) to USB devices with a USB cable.
  • Page 14 Rear Panel 14. SUBWOOFER PRE OUT jacks: Connect a powered subwoofer with a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each of the SUBWOOFER PRE OUT jacks. 15. 12V TRIGGER OUT jack: Connect a device equipped with a 12V trigger input jack to enable power link operation between the device and this unit.
  • Page 15 Remote Controller Remote Controller STANDBY/ON button 10. INPUT SELECT button: Switches the input to be 2. PERSONAL PRESET 1/2/3 buttons: Registers played. the current setting conditions such as input (STATUS) button: Switches the information on selector, listening mode, etc. or call the the display.
  • Page 16 Remote Controller 14. TONE/DIALOG/SW buttons: Adjusts the sound 17. ZONE 2 SHIFT button: Used to control the quality of the speakers and volume level of the multi-zone function ( →p82). (The ZONE 3 subwoofer. SHIFT button cannot be used with this unit.) TONE button: You can adjust the sound quality 18.
  • Page 17 Inputting Characters You can input characters or symbols on the keyboard displayed on the TV • Select "A/a" to switch between upper and lower cases. (Can also be switched screen such as when inputting a password for Wi-Fi Setup ( →p126) or naming with the MODE button on the remote controller.) a preset radio station ( →p111).
  • Page 18 Speaker Layout This unit can be used in different ways, depending on the layout of the speakers you are installing. Select the speaker layout that suits the installation environment, then confirm the methods for installation and connection. Speaker Layout 3.1ch 5.1ch 7.1ch ‰...
  • Page 19 Speaker Layout The listening room and the speaker layout 1. ZONE A Speakers The speaker system set up in the main room (where this unit is located). 2. ZONE 2 Speakers The 2 ch speaker system set up in a separate room (ZONE 2). This enables you to play the same source in the main room and the separate at the same time, or to play separate sources.
  • Page 20 Speaker Layout 3.1 Channel System A 3.1 Channel System that combines front speakers with a center speaker and a subwoofer. Basic system ( →p26) 3.1 ch + ZONE 2 ( →p26) 3.1 ch (Bi-Amping (Front)) ( →p26) Main Room Zone 2 Zone 2 3.1ch 5.1ch...
  • Page 21 Speaker Layout 5.1 Channel System This is a basic 5.1 Channel System. Basic system ( →p26) 5.1 ch + ZONE 2 ( →p26) 5.1 ch (Bi-Amping (Front)) ( →p26) Main Room Zone 2 Zone 2 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 22 Speaker Layout 7.1 Channel System This is a 7.1 Channel System that consists of the basic 5.1 Channel System and added surround back speakers. Basic system ( →p27) 7.1 ch + ZONE 2 ( →p27) Main Room Zone 2 Zone 2 3.1ch 5.1ch 7.1ch...
  • Page 23 Speaker Layout 3.1.2 Channel System A Speaker System that is a 3.1 Channel System with one set of height speakers added. 3.1.2 ch (Front High or Rear High) ( →p28) 3.1.2 ch (Top Front or Top Middle or Top Rear) 3.1.2 ch (Dolby Enabled Speakers (Front)) ( →p28) ( →p28)
  • Page 24 Speaker Layout 5.1.2 Channel System A Speaker System that is a 5.1 Channel System with one set of height speakers added. 5.1.2 ch (Front High or Rear High) ( →p29) 5.1.2 ch (Top Front or Top Middle or Top Rear) 5.1.2 ch (Dolby Enabled Speakers (Front or ( →p29) Surround)) ( →p29)
  • Page 25 Speaker Installation How the speakers are set up depends on the size and shape of the room, so here we introduce just a basic layout example. The alphabetic symbols used in this chapter represent the following speakers: Front speaker Left Front speaker Right Center speaker Surround speaker Left...
  • Page 26 Speaker Installation „ 3.1 Channel System „ 5.1 Channel System a: 22° to 30° a: 22° to 30°, b: 120° FL, FR Place the Left and Right Front Speakers to match ear height. FL, FR Place the Left and Right Front Speakers to match ear height. The center speaker should be set up facing the listening position at The center speaker should be set up facing the listening position an angle.
  • Page 27 Speaker Installation „ 7.1 Channel System a: 22° to 30°, b: 90° to 110°, c: 135° to 150° FL, FR Place the Left and Right Front Speakers to match ear height. The center speaker should be set up facing the listening position at an angle.
  • Page 28 Speaker Installation „ 3.1.2 Channel System Top Speakers High Speakers a: 22° to 30° a: 30° to 55° 3´ (0.9 m) b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position.
  • Page 29 Speaker Installation „ 5.1.2 Channel System Top Speakers High Speakers a: 22° to 30° b: 120° a: 30° to 55° 3´ (0.9 m) b: 65° to 100° or more c: 125° to 150° 3´ (0.9 m) or more TFL, TFR Fit top front speakers on the ceiling in front of the listening position. TML, TMR Fit top middle speakers on the ceiling directly above the listening position.
  • Page 30 Speaker Connections (Before starting the procedure) Speaker Connections and "Speaker Impedance" Settings 4-16 Speaker Connections 3.1 Channel System 33, 34, 35 5.1 Channel System 36, 37, 38 7.1 Channel System 39, 40 3.1.2 Channel System 41, 42, 43 5.1.2 Channel System 44, 45 3.1ch 5.1ch...
  • Page 31 Speaker Connections Speaker Connections and "Speaker Impedance" Settings Connections „ (Note) Speaker Impedance Connect speakers with an impedance of 4 Ω to 16 Ω. If any of the speakers to be connected has an impedance of 4 Ω or more and less than 6 Ω, set "Speaker Impedance"...
  • Page 32 Speaker Connections „ Connect the Subwoofer a Subwoofer cable Connect a powered subwoofer with this unit using a subwoofer cable. Up to two powered subwoofers can be connected. The same signal is output from each SUBWOOFER PRE OUT jack. 3.1ch 5.1ch 7.1ch 3.1.2ch...
  • Page 33 Speaker Connections „ 3.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 34 Speaker Connections „ 3.1 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 35 Speaker Connections „ 3.1 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 36 Speaker Connections „ 5.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 37 Speaker Connections „ 5.1 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 38 Speaker Connections „ 5.1 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of your speakers as well.
  • Page 39 Speaker Connections „ 7.1 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 40 Speaker Connections „ 7.1 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch While ZONE 2 playback is being performed, surround back speakers installed in the main room cannot play audio. 7.1ch 3.1.2ch 5.1.2ch...
  • Page 41 Speaker Connections „ 3.1.2 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 42 Speaker Connections „ 3.1.2 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 43 Speaker Connections „ 3.1.2 Channel System (Bi-Amping the Speakers) For high- frequency 3.1ch For low- frequency 5.1ch 7.1ch Be sure to remove the jumper bar connecting between the woofer jacks and tweeter jacks of the Bi-Amping supported speakers. Refer to the instruction manual of 3.1.2ch your speakers as well.
  • Page 44 Speaker Connections „ 5.1.2 Channel System 3.1ch 5.1ch 7.1ch 3.1.2ch 5.1.2ch...
  • Page 45 Speaker Connections „ 5.1.2 Channel System + ZONE SPEAKER MAIN ROOM ZONE 2 FL(Z2) FR(Z2) 3.1ch FR(Z2) FL(Z2) 5.1ch 7.1ch While ZONE 2 playback is being performed, height speakers installed in the main room cannot play audio. 3.1.2ch 5.1.2ch...
  • Page 46 Connections Connecting the TV Connecting the SUB Monitor Connecting Playback Devices Connecting an AV Component in a Separate Room (Multi-zone Connection) Connecting Antennas Network Connection Connections Connecting External Control Devices Connecting the Power Cord...
  • Page 47 Connections Connecting the TV By connecting a TV to this unit, you can show the video from AV devices connected to this unit on the TV and also play the sound from the TV through this unit. To ARC/eARC TV IN(ARC) If the TV supports the ARC (Audio Return Channel) function(*), use only the HDMI cable to connect with the TV.
  • Page 48 Connections Connecting the SUB Monitor SUB Monitor This unit has multiple HDMI OUT jacks, and another TV or projector can be connected to the HDMI OUT SUB jack. • Switch between MAIN and SUB using the HDMI MAIN/SUB button on the remote controller ( →p15) or "AV Adjust"...
  • Page 49 Connections Connecting Playback Devices Connecting an AV Component with HDMI Jack Mounted This is a connection example of an AV component equipped with an HDMI jack. When connecting with an AV component that conforms to the CEC (Consumer Electronics Control) standard, you can use the HDMI CEC function (*) that enables linking with input selectors, etc.
  • Page 50 Connections Connecting an Audio Component This is a connection example of an audio component. Connect a CD player using a digital coaxial cable or analog audio cable. You can also connect a turntable that has an MM-type cartridge to the PHONO jack. •...
  • Page 51 Connections Connecting an AV Component in a Separate Room (Multi-zone Connection) Connecting a TV (ZONE 2) While a disc is played on a Blu-ray Disc player in the main room (where this unit is located), you can play the video and audio of the same Blu-ray Disc player or another AV component on the TV equipped with an HDMI IN jack in a separate room (ZONE 2).
  • Page 52 Connections Connecting an Integrated Amplifier (ZONE 2) You can enjoy 2 ch audio in the separate room (ZONE 2) while performing playback in the main room (where this unit is located). Use an analog audio cable to connect the ZONE 2 PRE/LINE OUT terminal on this unit to the input jack on an integrated amplifier in the separate room.
  • Page 53 Connections Connecting Antennas Connect the antenna to this unit, and set up the antenna at the best position for listening while receiving radio signals. Attach the indoor FM antenna to the wall using push pins or adhesive tape. a AM loop antenna, b Indoor FM antenna...
  • Page 54 Connections Network Connection This unit can be connected to the network using a wired LAN or Wi-Fi (wireless LAN). You can enjoy network functions such as Internet radio by network connection. If connection is made by the wired LAN, connect the router and the NETWORK jack with the Ethernet cable as shown in the illustration.
  • Page 55 Connections Connecting External Control Devices IR IN port When connecting a remote control receiver unit consisting of an IR Receiver, etc. to this unit, operation using the remote controller is possible even if the remote control signal is difficult to reach (due to installation in the cabinet, etc.).
  • Page 56 Connections 12V TRIGGER OUT jack When connecting a device equipped with a TRIGGER IN jack such as a BD/ DVD player to this unit, the device can be turned on or set to standby by interlocking the operation on this unit. When any input is selected, this unit outputs a maximum of 12 V/100 mA control signal from the 12V TRIGGER OUT jack, and controls the power link operation of the external device.
  • Page 57 Connections Connecting the Power Cord Connect the power cord after all the connections are completed. • This model includes a removable power cord. Be sure to connect the power cord to the AC IN of the unit first, and then connect it to the outlet. Always disconnect the outlet side first when disconnecting the power cord.
  • Page 58 Playback Basic Operations AV Component Playback BLUETOOTH Playback ® Listening To the Radio Listening Mode AV Adjust Network Services Playback Spotify AirPlay ® DTS Play-Fi ® Amazon Alexa Amazon Music Connecting the Sonos System for Playback Internet Radio Convenience functions Multi-zone Using PERSONAL PRESET USB Storage Device...
  • Page 59 Playback AV Component Playback You can play the audio from AV components, such as Blu-ray disc players through this unit. • When a TV is connected to the HDMI OUT SUB jack, use the HDMI MAIN/SUB button or "AV Adjust" ( →p68) to switch between MAIN and SUB. Basic Operations Perform the following procedure when this unit is on.
  • Page 60 If a password is requested, enter "0000". • This unit is displayed as "Pioneer VSX-LX105 XXXXXX". This display can The illustration shows an image. be changed with the Friendly Name function ( →p127) or the Pioneer Remote App ( →p135) (can be used with the iOS or Android™).
  • Page 61 Playback Transmitting audio from this unit to BLUETOOTH wireless technology enabled devices Pairing 1. Press the input selector you want to play. • Select a source other than "BLUETOOTH". This function does not work if you select "BLUETOOTH". • This function can be used in one location, either the main room (where this unit is located) or a separate room (ZONE 2).
  • Page 62 Playback Playing Back 1. Do the play operations on the AV component connected to this unit. Do the play operations on this unit when the input is TUNER or NET. You cannot adjust the volume of the BLUETOOTH wireless technology enabled device on this unit.
  • Page 63 Playback Listening To the Radio You can receive AM and FM radio stations on this unit with the built-in tuner. Listening To the AM/FM Radio Tuning into a Radio Station Perform the following procedure when this unit is on. „ Tuning Automatically 1.
  • Page 64 Playback „ Tuning Manually Note that if you tune manually, the reception for FM broadcasts will be monaural rather than stereo, irrespective of the sensitivity of the reception. 1. Press TUNER repeatedly to select either "AM" or "FM". 2. Press MODE repeatedly to display "TunMode: Manual" on the display. 3.
  • Page 65 Playback Presetting a Radio Station „ Registration Procedure „ Selecting a Preset Radio Station You can preset up to 40 of your favorite radio stations. 1. Press TUNER. 2. Press the cursors to select a preset number. After tuning in to the radio station you want to register, perform the following procedure.
  • Page 66 Playback Listening Mode You can change the listening mode during play by pressing repeatedly "AUTO/DIRECT", "SURR", or "STEREO". • For details of the effects of each listening mode, refer to "Listening Mode Effects" ( →p155). • For listening modes selectable for each audio format of input signals, refer to "Input Formats and Selectable Listening Modes" ( →p151). „...
  • Page 67 Playback „ SURR button Checking the input format and listening mode By pressing repeatedly you can select the audio format of the signals being input Repeatedly pressing the button on the remote controller switches the display and switch between a variety of listening modes. Select the mode that suits your of the main unit in the following order.
  • Page 68 Playback AV Adjust Menu operations You can quickly adjust the settings you frequently use, such as tone adjustments, etc. You can make the settings on the TV screen while playing something. Press on the remote controller to display the AV Adjust menu. Note that there is no display on the TV screen when the input selector is "CD", "TV", "PHONO", "FM", or "AM", so follow the main unit’s display while doing the operations.
  • Page 69 Playback „ HDMI „ Room EQ HDMI Out: Select the HDMI OUT jack to output video signals from "MAIN", MCACC EQ: Enable or disable the equalizer function that corrects for distortion "SUB", and "MAIN+SUB". caused by the acoustic environment of the room. •...
  • Page 70 Playback Spotify Use your phone, tablet or computer as a remote control for Spotify. Go to spotify.com/connect to learn how.
  • Page 71 Confirm that this unit and the PC are connected to the same network beforehand. Then, press NET on the remote controller. Next, click the AirPlay icon in iTunes, select this unit from the displayed devices, and start play of a music file. iPhone Pioneer VSX-LX105 XXXXXX e.g., iOS 10...
  • Page 72 AirPlay-enabled iPhone device. XXXXXX Pioneer VSX-LX105 You can also play the music files on a PC with iTunes (Ver. 12.8 or later) XXXXXXXX Pioneer equipped. Confirm that this unit and the PC are connected to the same network...
  • Page 73 "Group playback" that plays the same music in https://intl.pioneer-audiovisual.com/playfi/info_p.html separate rooms at home. To enjoy this function, download Pioneer Music Control • To use a music streaming distribution service, user registration may be App (available on iOS or Android ™...
  • Page 74 Refer to "Pioneer Remote App" ( →p135) for information about the app. 2. Start Pioneer Remote App and tap the unit when displayed. 3. Tap "NET" or "NETWORK" at the top of the Pioneer Remote App screen, and after switching to the network menu, tap the "amazon alexa" icon.
  • Page 75 Playback Operating this unit 7. When registration is finished, the screen returns to the one for Pioneer Remote App. Follow the on screen instructions and talk to the terminal with Amazon Alexa (an Amazon Echo, etc.), and confirm that you can use voice You can use voice commands to adjust the volume on this unit, start and stop commands.
  • Page 76 Refer to "Pioneer Remote App" ( →p135) for information about the app. 2. Start Pioneer Remote App and tap the unit when displayed. 3. Tap "NET" or "NETWORK" at the top of the Pioneer Remote App screen, and after switching to the network screen, tap the "Amazon Music" icon to display You can use the music distribution service provided by Amazon by registering the Amazon Music login screen.
  • Page 77 Playing Amazon Music using the Pioneer Remote App 1. Start the Pioneer Remote App. This unit is displayed automatically when the app is started, so tap the unit when displayed to select it. 2. Tap "NET" or "NETWORK" at the top of the screen, and after switching to the network screen, tap the "Amazon Music"...
  • Page 78 Playback Connecting the Sonos System for Playback How to Connect This Unit and Sonos Connect 1. Connect the Sonos Connect to the AUDIO IN jack of this unit with the RCA audio cable supplied with the Sonos Connect. Any input can be used other than the PHONO jack.
  • Page 79 Playback Sonos Connect. • Up to 32 devices can be displayed on the Sonos product list screen. If you cannot find the Sonos Connect to be interlocked, return to the previous screen, turn off the product you do not want to interlock, and try again. Output Zone: With the cursors / , select the ZONE where you want to listen to the music.
  • Page 80 Playback Internet Radio By connecting this unit to an Internet-connected network, you can enjoy Internet radio services such as TuneIn Radio. • To play Internet radio services, the network needs to be connected to the Internet. • Depending on the Internet radio service, a user registration may be required on your PC beforehand. For details of each service, visit the website of each service.
  • Page 81 Playback Internet Radio Service Menu You can bookmark specific stations, or delete stations that have been bookmarked. The displayed menu varies according to the service being selected. The menu icon is displayed while a station is being played. When only this icon is displayed, pressing ENTER will display the menu on the screen.
  • Page 82 "BLUETOOTH". You cannot select different stations of AM/FM broadcasts for the main room and separate room. Pioneer Remote App ( →p135) is useful for the multi-zone playback operation. Download Pioneer Remote App (available on iOS or Android™) to a mobile device, such as a smartphone and tablet to use it.
  • Page 83 Playback Playing Back In the remote controller operation, while pressing and holding the ZONE 2 SHIFT button on the remote controller, operate with each button. 1. Point the remote controller at the unit, and while pressing and holding the ZONE 2 SHIFT button on the remote controller, press . •...
  • Page 84 Playback output. • When video and audio via HDMI input are output to ZONE 2, set "Input/ Output Assign" - "TV Out / OSD" - "Zone 2 HDMI" ( →p101) to "Use" on the System Setup menu. • DSD audio signals cannot be output to ZONE 2 when selected with the "NET" or "USB"...
  • Page 85 Playback Using PERSONAL PRESET Registration You can register settings ( →p86) such as the current input selector and listening mode with the three PERSONAL PRESET buttons, and call a registered setting in a single operation. e.g.) Pressing the PERSONAL PRESET button will automatically switch the input selector to "TUNER"...
  • Page 86 Playback Settings that can be registered The following settings can be registered with PERSONAL PRESET. – Input selector (Network service or AM/FM radio stations can also be registered.) – Output destination (HDMI) – Listening mode – Volume level (Upper limit "0.0 dB") (When ZONE 2 is on, the volume level of ZONE 2 is also registered.) –...
  • Page 87 Playback USB Storage Device You can play music files stored on a USB storage device. Supported Audio Formats USB Storage Device Requirements MP3 (.mp3) • This unit can use USB storage devices that comply with the USB mass • MPEG-1/MPEG-2 Audio Layer 3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, storage class standard.
  • Page 88 Playback Playing music files saved on a USB storage device Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. 2. Plug your USB storage device with the music files into the USB port either on the front panel or rear panel of this unit.
  • Page 89 Playback may not be displayed correctly. • This unit supports the gapless playback of the USB storage device in the following conditions. When continuously playing WAV, FLAC and Apple Lossless files with the same format, sampling frequency, the number of channels and quantization bit rate.
  • Page 90 Playback Music Server Streaming play of music files stored on PCs or NAS devices connected to the same network as this unit is supported. • The network servers this unit is compatible with are those PCs with players installed that have the server functionality of Windows Media Player 12, or NAS that ®...
  • Page 91 Playback Playing Back Perform the following procedure when this unit is on. 1. Switch the input on the TV to the input connected to the unit. TV’s REMOTE 2. Start the server (Windows Media Player 12, or NAS device) containing the ®...
  • Page 92 Playback Controlling Remote Playback from a PC 6. Select the target server with the cursors, and press ENTER to display the items list screen. You can use this unit to play music files stored on your PC by operating the PC •...
  • Page 93 The Play Queue information is effective until the power cord of this unit is removed from the outlet. Refer to "Pioneer Remote App" ( →p135) for information about the app.
  • Page 94 Playback 2. Tap the " " icon of the track to sort, and drag the icon to the destination. 3. To delete a track, slide the track to the left until the trash icon changes to " ". If the device is on iOS, slide the " "...
  • Page 95 Playback Connecting a transmitter for playback When you connect wireless headphones or a wireless speaker transmitter to the ZONE B LINE OUT terminal of this unit, you can play back the same source through the wireless headphones or wireless speakers as in the main room. Connections Setting Up 1.
  • Page 96 Playback When using a speaker layout of 3.1 ch or more, you can select only the "Ext. Stereo" listening mode.
  • Page 97 Setup Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, then select System Setup with the cursors on the remote controller and press ENTER. Select the item with the cursor buttons of the remote controller and Setup press ENTER to confirm your selection.
  • Page 98 Setup System Setup Menu list Input/Output Assign TV Out / OSD Make settings for TV output and On-Screen Displays (OSD) that appear on the TV. p100 HDMI Input Change input assignment between the input selectors and HDMI IN jacks. p102 Digital Audio Input Change input assignment between the input selectors and DIGITAL AUDIO IN COAXIAL/ p102...

  • Page 99: Firmware Update

    Setup Hardware HDMI Change the settings of the HDMI function. p113 Power Management Change the settings for the power-save function. p114 12V Trigger Set the 12V trigger output setting to each input. p116 Works with SONOS Change the settings to connect with the Sonos Connect. p116 Multi Zone Zone 2...
  • Page 100 Setup Input/Output Assign Input/Output Assign „ TV Out / OSD ‰ 1080p -> 4K Upscaling (Default Value: Off) When using a TV that supports 4K, video signals input at 1080p can be Make settings for TV output and On-Screen Displays (OSD) that appear on the automatically upscaled to 4K for output.
  • Page 101 Setup Input/Output Assign ‰ HDMI 4K/8K Signal Format (Default Value: 4K Standard) ‰ OSD Language (Default Value: English) Set the 4K/8K signal format input and output by this unit. Set to suit the TV or Select the on-screen display language from the following. player connected.
  • Page 102 Setup Input/Output Assign „ HDMI Input „ Digital Audio Input Change input assignment between the input selectors and HDMI IN jacks. Change input assignment between the input selectors and DIGITAL AUDIO IN COAXIAL/OPTICAL jacks. If you do not assign a jack, select "---". ‰...
  • Page 103 Setup Input/Output Assign „ Analog Audio Input „ Input Skip Change input assignment between the input selectors and AUDIO IN jacks. If You can skip inputs to which nothing is connected when selecting them with the you do not assign a jack, select "---". INPUT SELECTOR dial on the main unit or with the INPUT SELECT button on the remote controller.
  • Page 104 Setup Input/Output Assign „ PERSONAL PRESET Information (Zone 2) Confirm the registered contents of 1 to 3 buttons of PERSONAL PRESET. Setting Item Default Value Setting Details The registered settings are displayed in the list. Input Selector Displays the input selector that has been set. ‰...
  • Page 105 Setup Speaker Speaker „ Configuration ‰ Zone 2 Preout (Default Value: Zone 2) Set an output destination of the audio output from ZONE 2 PRE/LINE OUT/ Change the settings of connection environment of the speakers. ZONE B LINE OUT jack. ‰...
  • Page 106 Setup Speaker „ Crossover Surround Back: Set according to the speakers to be used. Change the settings of crossover frequencies. "Small": When speaker where the speaker diameter is 16 cm or less are to be ‰ Front (Default Value: Small) used.
  • Page 107 Setup Speaker „ Distance „ Channel Level Set the distance from each speaker to the listening position. Adjust the volume level of each speaker. ‰ Front Left (Default Value: 10.0 ft/3.00 m) ‰ Front Left (Default Value: 0.0 dB) Center (Default Value: 10.0 ft/3.00 m) Center (Default Value: 0.0 dB)
  • Page 108 Setup Speaker „ Dolby Enabled Speaker Change the settings of Dolby Enabled Speakers. • This setting can be selected when "Configuration" - "Height Speaker" is set to "Dolby Speaker". ‰ Distance from the ceiling (Default Value: 6.0 ft/1.80 m) Set the distance between the Dolby Enabled Speaker and the ceiling. Select between "0.1 ft"/"0.03 m"...
  • Page 109 Setup Audio Adjust Audio Adjust „ Dual Mono/Mono „ Dolby Change the settings of multiplex audio playback. Change the setting of when Dolby signals are input. ‰ Dual Mono (Default Value: Main) ‰ Loudness Management (Default Value: On) Set the audio channel or language to be output when playing multiplex audio or When playing Dolby TrueHD, enable the dialog normalization function which multilingual broadcasts, etc.
  • Page 110 Setup Audio Adjust „ Volume Change the Volume settings. ‰ Mute Level (Default Value: -∞ dB) Set the volume lowered from the listening volume when muting is on. Select a value from "-∞ dB", "-40 dB" and "-20 dB". ‰ Volume Limit (Default Value: Off) Set the maximum value to prevent the volume from becoming too loud.
  • Page 111 Setup Source Source „ Input Volume Absorber „ Audio Select Adjust the volume level when there are differences in volume level among Select the priority for input selection when multiple audio sources are connected multiple devices connected to this unit. Select the input selector to make the to one input selector, such as connections to both the "BD/DVD"...
  • Page 112 Setup Source Analog When giving priority to the input signal from AUDIO IN jacks • This item can be selected only when the input to be set is assigned to the AUDIO IN jack in the "Input/Output Assign" - "Analog Audio Input" setting. ‰...
  • Page 113 Setup Hardware Hardware „ HDMI ‰ HDMI Standby Through (Default Value: Auto (Eco)) When this is set to anything other than "Off", you can play the video and audio of Change the settings of the HDMI function. an HDMI-connected player on the TV even if the unit is in standby mode. Also, ‰...
  • Page 114 Setup Hardware „ Power Management ‰ Audio TV Out (Default Value: Auto) You can enjoy audio through the speakers of the TV while this unit is on. Change the settings for the power-save function. • The setting is fixed to "Auto" if "HDMI CEC" is set to "On". If you change this ‰...
  • Page 115 Pioneer Remote App that can control this unit. • When this function is set to "On", the power consumption in standby state...
  • Page 116 Setup Hardware „ 12V Trigger „ Works with SONOS Set when outputting the control signal (maximum 12 V/100 mA) through the 12V Change the settings to connect with the Sonos Connect. TRIGGER OUT jack. Different settings can be set for each input selector. You (SONOS-1/SONOS-2) can enable power link operation when you connect the unit and the external ‰...
  • Page 117 Setup Hardware ‰ Output Zone (Default Value: Main) Select the zone where you want to listen to the music. • To use this function, set "Input Selector" beforehand. Main Outputs audio only to the main room (where this unit is located).
  • Page 118 Setup Multi Zone Multi Zone „ Zone 2 „ Remote Play Zone Change the settings for Zone 2. Change the settings for remote play. ‰ Output Level (Default Value: Fixed) ‰ Remote Play Zone (Default Value: Auto) Select whether to adjust the volume on the integrated amplifier in the separate When playing with AirPlay or Spotify Connect, or when using the Music Server room or on this unit when outputting to Zone 2.
  • Page 119 Select an ID for the unit's remote controller from "1", "2", and "3" to prevent Press ENTER to select when updating the firmware via network. interference between the unit and other Pioneer components that are installed • This setting cannot be selected if you do not have Internet access or there is in the same room.
  • Page 120 Setup Miscellaneous „ Initial Setup Make the initial setup from the setup menu. • Wait for a while if "Initial Setup" cannot be selected. It can be selected when the network function is activated. „ Lock Lock the Setup menu so that the settings cannot be changed. ‰...
  • Page 121 Setup MCACC Menu operations Setup the speakers automatically or make desired changes to the equalizer. You can also check the values set currently for each speaker setting. Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, then select MCACC with the cursors on the remote controller and press ENTER.
  • Page 122 Setup Full Auto MCACC 2. Place the supplied speaker setup microphone at the listening position, and connect it to the SETUP MIC jack on the main unit. Place the supplied speaker setup microphone in the listening position, measure the test tones emitted by the speakers, then the unit automatically sets the optimum volume level for each speaker, the crossover frequencies, and the distance from the listening position.
  • Page 123 Setup Manual MCACC „ EQ Adjust Center, Surround Right, Surround Left: After selecting the speaker frequency from between "63 Hz" and "16 kHz" with If you perform Full Auto MCACC then settings are automatic, but you can also the cursors / , adjust the volume of that frequency between "-12.0 dB"...
  • Page 124 Setup MCACC Data Check You can check the number of speaker channels connected and the content and values you have set for each of the speaker settings. „ Speaker Setting You can check the number of speaker channels connected and the large and small settings you have set for the low range reproduction capabilities for each of the speakers.
  • Page 125 Setup Network/Bluetooth Menu operations Make settings related to network connections and BLUETOOTH. Use the on-screen displays (OSD) that appear on the TV to make the settings. Press on the remote controller to display the Home screen, select "Network/ Bluetooth" with the cursors on the remote controller, then press ENTER. Select the item with the cursor buttons of the remote controller and press ENTER to confirm your selection.
  • Page 126 Setup Network • When LAN is configured with a DHCP, set "DHCP" to "Enable" to configure ‰ MAC Address (Default Value: -) the setting automatically. ("Enable" is set by default) To assign fixed IP addresses to each components, you must set "DHCP" to "Disable" and Check the MAC address of this unit.
  • Page 127 When this function is not used Displays/Sets the proxy server port number when you input "Proxy URL". ‰ AirPlay Device Name (Default Value: Pioneer VSX-LX105 XXXXXX) ‰ Friendly Name (Default Value: Pioneer VSX-LX105 XXXXXX) Change the model name of this unit which is displayed on the AirPlay- connected device to an easily recognized name.
  • Page 128 Setup Network ‰ AirPlay Password (Default Value: -) ‰ Network Check (Default Value: -) You can set a password of up to 31 characters so that only registered users You can check the network connection. can use AirPlay. Press ENTER when "Start" is displayed. 1.
  • Page 129 Setup Bluetooth Bluetooth Change the settings for the BLUETOOTH function. ‰ Pairing Information (Default Value: -) • Wait for a while if "Bluetooth" cannot be selected. It will appear when the You can initialize the pairing information stored on this unit. If you are no longer BLUETOOTH function is started up.
  • Page 130 Setup Bluetooth „ Bluetooth Transmitter ‰ Pairing Information (Default Value: -) You can initialize the pairing information stored on this unit. If you are no longer ‰ Bluetooth Transmitter (Default Value: Off) able to connect with a device you have paired, try doing this. ( →p143) Select whether or not to use the function that transmits audio from this unit to Pressing ENTER when "Clear"...
  • Page 131 Setup Web Setup Menu operations Device Information You can make the settings for the network function of this unit using an Internet browser on a PC, smartphone, etc. You can change the Friendly Name or AirPlay Device Name, set an AirPlay Password, etc.
  • Page 132 Setup Initial Setup with Auto Start-up Wizard Operations When you turn the unit on for the first time after purchase, the Initial Setup screen is automatically displayed on the TV to allow you to make settings TV’s REMOTE required for startup using simple operations following on-screen guidance. Inputs 1.
  • Page 133 Setup „ Network Connection Keyboard Input 1. A confirmation screen asking you whether to agree to the privacy statement To switch between upper and lower cases, select "A/a" on the screen, and press is displayed during network setting. If you agree, select "Accept" and press ENTER on the remote controller.
  • Page 134 Setup „ 2. Multi Zone Sound Check 1. Place the supplied speaker setup microphone at the listening position, and connect it to the SETUP MIC jack on the main unit. Output test tones to ZONE 2 to enjoy audio in a separate room (ZONE 2) in addition to the main room.
  • Page 135 (internet radio or play of a music file) without looking at the TV. • To use Pioneer Remote App, this unit needs to be connected to the same network as the mobile device.
  • Page 136 Troubleshooting Troubleshooting „ Listening Modes „ Video Before starting the procedure „ Linked operation Problems may be solved by simply turning the power on/off or disconnecting/ „ Tuner connecting the power cord, which is easier than working on the connection, setting and operating procedure.
  • Page 137 Troubleshooting When the unit is operating erratically ‰ Try restarting the unit ‰ Resetting the unit (this resets the unit settings to the default) Restarting this unit may solve the problem. Set the main unit to standby, then after waiting for 5 seconds or more, press and hold the STANDBY/ON button If the restart of the unit does not solve the problem, reset the unit, and restore of the main unit for at least 5 seconds, and then restart the unit.

  • Page 138: Troubleshooting

    Troubleshooting Troubleshooting „ Power ‰ When the power is turned on, "AMP Diag Mode" appears on the display of the main unit • The protection circuit function may have operated. If the unit suddenly enters the standby state and "AMP Diag Mode" appears on the display of the main unit when the power is turned on again, this function is diagnosing whether or not the main unit is malfunctioning or there is an abnormality with the speaker cable connection.
  • Page 139 Troubleshooting ‰ No sound from the TV • Change the input selector on this unit to the position of the terminal to which the TV is connected. • If the TV doesn't support the ARC function, along with connection by HDMI, connect the TV and this unit using a digital optical cable. ( →p47) ‰...
  • Page 140 Troubleshooting ‰ Noise can be heard • Using cable ties to bundle audio pin cables, power cords, speaker cables, etc. may degrade the audio performance. Do not bundle the cords. • An audio cable may be picking up interference. Change the position of the cables. ‰...
  • Page 141 Troubleshooting ‰ About DTS signals • With media that switches suddenly from DTS to PCM, PCM playback may not start immediately. In such a case, stop playback on the player side for approx. 3 seconds or more. Then, resume playback. The playback will be performed normally. •...
  • Page 142 Troubleshooting ‰ Images flicker • The output resolution of the player may not be compatible with the resolution of the TV. If the player is connected to this unit with an HDMI cable, change the output resolution on the player. Also this may be solved by changing the screen mode on the TV. ‰...
  • Page 143 Troubleshooting „ BLUETOOTH function • Unplug and plug the power cord of the unit, or turn off and on the BLUETOOTH enabled device. Restart of the BLUETOOTH enabled device may be effective. • BLUETOOTH enabled devices must support the A2DP profile. •...
  • Page 144 Troubleshooting ‰ Sound is interrupted • There maybe a problem with the BLUETOOTH enabled device. Check the information on a web page. ‰ The audio quality is poor after connection with a BLUETOOTH enabled device • The BLUETOOTH reception is poor. Move the BLUETOOTH enabled device closer to the unit, or remove any obstacle between the BLUETOOTH enabled device and this unit.
  • Page 145 Troubleshooting „ USB storage device ‰ USB storage device is not displayed • Check if the USB storage device or USB cable is securely inserted to the USB port of the unit. ( →p87) • Disconnect the USB storage device once from the unit, and then reconnect it. •...
  • Page 146 Troubleshooting „ ZONE B function ‰ Cannot output audio to ZONE B • To output audio to ZONE B, set the audio output destination for "Audio" - "Zone B" on AV Adjust to "On (A+B)" or "On (B)" and also set "Speaker" ( →p95) - "Configuration"...
  • Page 147 • The volume level correction of the subwoofer may not have been completed. Lower the volume of the subwoofer before Full Auto MCACC measurement. ‰ Cannot operate the Full Auto MCACC screen with the Pioneer Remote App (available on iOS and Android™)
  • Page 148 Appendix Speaker Layouts and Selectable Listening Modes See the following table for selectable listening modes for each speaker layout. Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 (*1) (*1) (*1) (*2) (*2) (*2) (*2) (*2) DD (Dolby Audio - DD) (*1) (*1) (*1)
  • Page 149 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 (*3) (*3) (*3) ES Discrete (DTS-ES Discrete) ES Matrix (DTS-ES Matrix) DTS 96/24 (*3) (*3) (*3) DTS-HD HR (DTS-HD High Resolution) DTS-HD Master (DTS-HD Master Audio) DTS Express DTS:X DTS Neural:X DTS Virtual:X...
  • Page 150 Appendix Speaker layout (ch) Listening mode 2.1.2 3.1.2 4.1.2 5.1.2 (*1) (*1) (*1) (*1) (*1) (*3) (*3) (*3) (*3) (*1) (*1) (*1) (*2) (*2) (*2) (*2) (*2) Stereo (*4) (*4) (*4) (*4) (*4) (*4) (*4) (*4) (*4) Mono (*4) (*4) (*4) (*4) (*4)
  • Page 151 Appendix Input Formats and Selectable Listening Modes You can select a variety of listening modes Listening mode DTHD according to the audio format of the signal to be Pure Direct DSur (Dolby Audio (Dolby Atmos input. Direct (Dolby Audio (Dolby Audio - DD+) Audio - (*13)
  • Page 152 Appendix Listening mode DTS-HD HR DTS-HD ES Discrete ES Matrix DTS 96/24 (DTS-HD High Master (DTS- (DTS-ES DTS (*2) Express (DTS-ES DTS:X Neural:X Virtual:X (*2) Resolution) HD Master Discrete) (*2) Matrix) (*5) (*6) (*9) (*10) Input format (*2) Audio) (*2) (*5) 2-channel signal input Analog / PCM...
  • Page 153 Appendix Listening mode Classical / Unplugged / F.S.Surround Ent.Show (Entertainment Ext.Stereo / (Front Stage (Multich Mono Show) / Drama / Mono Music (*2)(*12) Surround) PCM) (*2) AdvancedGame / Action (*8) Input format (*9) / Rock/Pop / Sports (*7) 2-channel signal input Analog / PCM Music files / DSD (*1) DD / DD+ / DTHD...
  • Page 154 Appendix (*1) You cannot select any mode other than Pure Direct, Stereo, Ext.Stereo and Mono Music if the sampling rate is 5.6/11.2 MHz. (*2) A center speaker or surround speakers need to be installed. (*3) If the input source is Blu-ray Disc and the speaker layout is 5.1 ch or less, DD+ cannot be selected. Instead, the listening mode for DD can be selected. (*4) This can only be selected when no surround back speaker is connected.
  • Page 155 Appendix Listening Mode Effects In alphabetical order – Atmos 3.0/3.1: When front speakers and center speaker are installed – Atmos 4.0/4.1: When front speakers and surround speakers are „ Action installed – Atmos 5.0/5.1: When front speakers, center speaker and surround Mode suitable for movies with a lot of action scenes.
  • Page 156 Appendix DD+ (Dolby Audio - DD+) DTHD (Dolby Audio - TrueHD) „ „ This mode faithfully reproduces the sound design recorded in the Dolby Digital This mode faithfully reproduces the sound design recorded in the Dolby TrueHD Plus audio format. audio format.
  • Page 157 Appendix „ DTS channels such as the surround back channel at a sampling rate of 96 kHz and at a resolution of 24 bits. This mode faithfully reproduces the sound design recorded in the DTS audio • To enable transfer of this audio format, connect via an HDMI cable and set format.
  • Page 158 Appendix „ DTS:X „ F.S.Surround (Front Stage Surround) This mode faithfully reproduces the sound design recorded in the DTS:X audio In this mode, you can enjoy a virtual playback of multichannel surround sound format. even with only two or three speakers. This works by controlling how sounds The DTS:X audio format is a combination of the mixing method based on reach the listener's left and right ears.
  • Page 159 Appendix Speaker combinations • Up to two powered subwoofers can be connected in either combination. SURROUND ZONE 2 Speaker Channels FRONT CENTER SURROUND HEIGHT Bi-AMP BACK (ZONE SPEAKER) 2.1 ch (*1) (*1) 3.1 ch (*1) (*1) 4.1 ch (*1) (*1) 5.1 ch (*1) (*1)
  • Page 160 Appendix General Specifications Amplifier Section North American models With 8 ohm loads, both channels driven, from 20-20,000 Hz; rated 100 watts per channel minimum RMS power, Rated Output Power with no more than 0.08% total harmonic distortion from 250 milliwatts to rated output. (FTC) Maximum Effective Output Power 210 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD Dynamic Power (IEC60268-Short-term...
  • Page 161 Appendix DAB Tuning Frequency Range DAB Sensitivity Preset Channel BLUETOOTH Section North American models Communication system BLUETOOTH Specification version 4.2 Frequency band 2.4 GHz band Modulation method FHSS (Frequency Hopping Spread Spectrum) Compatible BLUETOOTH profiles A2DP 1.2, AVRCP 1.3 Receiving: SBC, AAC Supported Codecs Transmitting: SBC, aptX, aptX HD Transmission range (A2DP)
  • Page 162 Appendix 2 ch linear PCM: 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 16/20/24 bit Multi-channel linear PCM: Audio Format Maximum 7.1 channels, 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 16/20/24 bit Bitstream: Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS, DTS-ES, DTS 96/24, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Express, DTS:X, DSD(2.8 MHz), PCM...
  • Page 163 Appendix Corresponding Frame rate Color space Color depth HDMI IN 1 - 3 HDMI IN 4 - 6 input resolutions 24/25/30 Hz YCbCr4:2:2 12 bit (3840x2160p) YCbCr4:4:4/RGB 8 bit 10/12 bit 4K SMPTE 48/50/60 Hz YCbCr4:2:0 8 bit (4096x2160p) 10/12 bit YCbCr4:2:2 12 bit YCbCr4:4:4/RGB...
  • Page 164 Appendix Network Section North American models Ethernet LAN 1 (10BASE-T/100BASE-TX) Wireless LAN IEEE 802.11 a/b/g/n/ac standard (Wi-Fi standard) 5 GHz/2.4 GHz band ® MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR WMA (.wma) •...

  • Page 165: Hdmi Cec ( →P113)

    Appendix MP3 (.mp3) • MPEG-1/MPEG-2 Audio Layer-3/44.1 kHz, 48 kHz/Between 8 kbps and 320 kbps, and VBR WMA (.wma) • 44.1 kHz, 48 kHz/Between 5 kbps and 320 kbps, and VBR • WMA Pro/Voice/WMA Lossless formats are not supported. WAV (.wav) WAV files contain uncompressed PCM digital audio.
  • Page 166 Appendix 2.7 W Equipment with HiNA functionality Standby This equipment complies with European Commission Regulation (EC) No 1275/2008 as equipment with HiNA mode, Network disconnect and Network functionality. If you do not to use the Network function, please set Network Standby setting to OFF. you can Standby ON reduce power consumption under standby mode.
  • Page 167 Appendix Others North American models Setup Mic 1 (Front) RS-232 12V TRIGGER OUT 1 (IN) Specifications and features are subject to change without notice. License and Trademark ‰...
  • Page 168 SN 29403937A_EN © 2020 Onkyo & Pioneer Corporation. All rights reserved. https://pioneer-audiovisual.com/privacy/ "Pioneer", "ELITE" and "MCACC logo" are trademarks of Pioneer Corporation, and are used under license. F2006-1...
