Owner’s Guide 400-108-015-B Table of contents Overview About your new thermostat ................... 1 Controls and display....................2 Installation Installation guidelines .................... 3 Mounting the thermostat ..................4 Wiring ........................5 Configuration switches ..................6 Operation Temperature display and setting ................7 Setup menu......................
TH108PLUS About your new thermostat This thermostat is designed to control an electric heating system such as a baseboard heater, a convector or a fan-forced heater. The thermostat CANNOT be used with: • a resistive load under 2 A • a resistive load over 12.5 A •...
Owner’s Guide 400-108-015-B Controls and display Backlit Screen Up button Down button Appears when the setpoint is displayed Temperature Appears when the thermostat is configured Heating intensity for a fan-forced heater indicator (the image (see page 6) disappears when heating is off) The settings are locked (see page 6)
TH108PLUS Installation guidelines TURN OFF POWER TO THE HEATING SYSTEM AT THE MAIN POWER PANEL TO AVOID ELECTRICAL SHOCK. The installation must be performed by a qualified electrician and must com- ply with electrical codes of your region. Do NOT install the thermostat in an area where it can be exposed to water or rain.
Owner’s Guide 400-108-015-B Mounting the thermostat Loosen the screw underneath the thermostat and separate the faceplate from the wallplate. NOTE: The screw remains captive and cannot be completely removed. Wire the thermostat (see page 5). Mount the wallplate to the electrical box using the provided screws.
Owner’s Guide 400-108-015-B Configuration switches Configuration switches are on the back of the faceplate. Factory settings are inside gray cells. Parameter Down Lock Unlock Settings lock Fan Yes Fan-forced heater Unit °F °C The thermostat buttons are disabled and appears on the screen (see page 2) when the settings are locked.
TH108PLUS Temperature display and setting The thermostat generally displays the room temperature. • To display the set temperature (setpoint), press the Up or Down button once. The setpoint temperature will remain on the screen for 5 seconds. • To change the setpoint temperature, press the Up or Down button repeatedly until the desired temperature is displayed.
Owner’s Guide 400-108-015-B Setup menu Press the Up and Down buttons simultaneously for three seconds to enter the setup menu. Press the Up or Down button to change the option. Press the Up and Down buttons simultaneously and briefly to advance to the next parameter.
TH108PLUS In case of difficulty PROBLEM SOLUTIONS This is normal unless the thermostat is too hot Thermostat is hot. to touch. Ensure that the heater capacity does not exceed the thermostat’s maximum load. Avoid any of the following conditions: Wrong temperature is •...
TH108PLUS 3-year limited warranty Honeywell warrants this product, excluding battery, to be free from defects in the workmanship or materials, under normal use and service, for a period of three (3) years from the date of pur- chase by the consumer. If at any time during the warranty period the product is determined to be defective or malfunctions, Honeywell shall repair or replace it (at Honeywell's option).
Owner’s Guide 400-108-015-B Customer Assistance If you have any questions about the product installation or use, contact us at: 705 Montrichard Avenue Saint-Jean-sur-Richelieu, Quebec J2X 5K8 Canada 1-800-831-2823 Email: aube.service@honeywell.com For more information on our products, go to www.aubetech.com...
Page 15
Guide du propriétaire TH108PLUS Thermostat non programmable 400-108-015-B 2009-11-30...
Page 16
Guide du propriétaire 400-108-015-B Table des matières Aperçu À propos du thermostat ..................1 Commandes et affichage ..................2 Installation Consignes d'installation..................3 Installation du thermostat ..................4 Branchement ......................5 Sélecteurs de configuration................... 6 Fonctionnement Affichage et réglage de la température ..............7 Menu de configuration...................
Page 17
TH108PLUS À propos de votre nouveau thermostat Ce thermostat est conçu pour commander un système de chauffage électrique comme une plinthe électrique, un convecteur ou un ventiloconvecteur. Ce thermostat NE peut être utilisé avec : • une charge résistive inférieure à 2 A •...
Guide du propriétaire 400-108-015-B Commandes et affichage Écran rétroéclairé Bouton Haut Bouton Bas Apparaît lorsque la température de Température consigne est affichée Apparaît si le thermostat Indicateur d'intensité est configuré pour un du chauffage (l’image ventiloconvecteur (voir disparaît lorsque le la page 6) chauffage est Les réglages sont verrouillés...
TH108PLUS Consignes d'installation METTRE LE SYSTÈME DE CHAUFFAGE HORS TENSION AU PANNEAU ÉLECTRIQUE AFIN D'ÉVITER TOUT RISQUE DE CHOC ÉLECTRIQUE. L’installation doit être effectuée par un électricien qualifié et doit être con- forme aux codes de l'électricité en vigueur dans votre région. Ne PAS installer le thermostat à...
Guide du propriétaire 400-108-015-B Installation du thermostat Desserrer la vis sous le thermostat et séparer la façade du thermostat de sa base. NOTA : La vis ne peut être complètement retirée et reste captive sur la base. Brancher le thermostat (voir la page 5). Installer la base sur la boite électrique à...
TH108PLUS Branchement Relier les fils du thermostat à l'alimentation et au système de chauffage (charge). Installation à deux fils Installation à quatre fils...
Guide du propriétaire 400-108-015-B Sélecteurs de configuration Les sélecteurs de configuration sont à l’arrière de la façade. Les configurations par défaut sont dans les cases grises. Paramètre Haut Verrouillé (Lock) Déverrouillé (Unlock) Verrouillage des réglages Oui (Fan Yes) Non (No) Ventiloconvecteur Unité...
TH108PLUS Affichage et réglage de la température Le thermostat affiche généralement la température de la pièce . • Pour afficher la température de consigne (réglée), appuyer une fois sur le bouton Haut ou Bas. Celle-ci apparaîtra à l’écran pendant 5 secondes. •...
Page 24
Guide du propriétaire 400-108-015-B Réglages avancés Appuyer simultanément sur les boutons Haut et Bas pendant trois secondes. Appuyer sur le bouton Haut ou Bas pour changer d’option. Appuyer simultanément et brièvement sur les boutons Haut et Bas pour avancer au paramètre suivant. Appuyer simultanément sur les boutons Haut et Bas pendant trois secondes pour enregistrer tout changement et sortir du menu.
TH108PLUS En cas de difficulté PROBLÈME SOLUTIONS Cette situation est normale, à moins que le thermostat Le thermostat est ne soit trop chaud pour pouvoir y toucher. S’assurer chaud. que le système de chauffage n’excède pas la charge maximale du thermostat. Éviter les situations suivantes : Le thermostat •...
Guide du propriétaire 400-108-015-B Fiche technique Alimentation : 240 VCA, 60 Hz Charge minimale : 2 A (résistive seulement) 500 W @ 240 VCA Charge maximale : 12,5 A (résistive seulement) 3 000 W @ 240 VCA Plage d'affichage : 0 °C à 50,0 °C (32 °F à 122 °F) Plage de température de consigne : 5,0 °C à...
TH108PLUS Garantie limitée de 3 ans Honeywell garantit ce produit, à l'exception des piles, contre tout vice de fabrication ou de matière dans la mesure où il en est fait une utilisation et un entretien convenables, et ce, pour trois (3) ans à partir de la date d'achat par le consommateur.
Guide du propriétaire 400-108-015-B Service à la clientèle Pour toute question concernant l’installation ou l’utilisation de du produit, prière de nous joindre à : 705, avenue Montrichard Saint-Jean-sur-Richelieu (Québec) J2X 5K8 Canada 1 800 831-2823 Courriel : aube.service@honeywell.com Pour de plus amples informations sur nos produits, visiter www.aubetech.com...
