1/2" D-HANDLE VSR DRILL
SET UP AND OPERATING INSTRUCTIONS
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright
2002 by Harbor Freight Tools
©
contained herein may be reproduced in any shape or form without the express written consent of
Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein. Tools required for
assembly and service may not be included.
For technical questions or replacement parts, please call 1-800-444-3353.
Revised Manual 07d, 09j, 11a
Model
47991
. All rights reserved. No portion of this manual or any artwork
®
Advertisement
Table of Contents
Related Manuals for Chicago Electric 47991
Summary of Contents for Chicago Electric 47991
- Page 1 Tools required for assembly and service may not be included. For technical questions or replacement parts, please call 1-800-444-3353. Revised Manual 07d, 09j, 11a Model 47991 . All rights reserved. No portion of this manual or any artwork ®...
-
Page 2: Specifications
Keep children away. Children must never be allowed in the work area. Do not let them handle machines, tools, or extension cords. SKU 47991 For technical questions, please call 1-800-444-3353. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit rust. - Page 3 Code § 25249.5, et seq.) 16. People with pacemakers should consult their physician(s) before use. Electromagnetic fields in close SKU 47991 For technical questions, please call 1-800-444-3353. proximity to heart pacemaker could cause pacemaker interference or pacemaker failure. In addition, people with pacemakers should: •...
-
Page 4: Operation
Figure 1 Chuck Side Handle SKU 47991 For technical questions, please call 1-800-444-3353. UNPACKING When unpacking, check to make sure the parts listed on page 6 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible. -
Page 5: Maintenance
With steel, tin, and sheet metal use a light machine oil, with aluminum, use paraffin. Do not SKU 47991 For technical questions, please call 1-800-444-3353. use lubricants with brass, copper, and cast iron. Grasp the handles firmly with both hands and slowly squeeze the Trigger (34). -
Page 6: Parts List
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Note: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 47991 For technical questions, please call 1-800-444-3353. PARTS LIST Q’ty... -
Page 7: Assembly Drawing
SKU 47991 For technical questions, please call 1-800-444-3353. ASSEMBLY DRAWING 28 29 30 Page 7... -
Page 8: Limited 90-Day Warranty
This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 47991 For technical questions, please call 1-800-444-3353. Page 8...
