Grizzly G5349 Instruction Sheet

Always wear safety glasses
during
serious personal injury!
Always disconnect tool from
air to prevent unexpected
operation during service!
Introduction
Just a squeeze of the trigger provides 50 ft/lbs.
of torque! Ergonomically designed for maximum
comfort, these professional quality ratchets deliv-
er up to 160 RPM to your sockets, making them
the perfect choice for home or high volume com-
mercial work. Weighs 3 lbs.
Inventory
A. Air Ratchet .................................................. 1
Operation
Tool requires 90 PSI to operate correctly.
To improve tool lifespan, use a filter/lubricator/
regulator as shown in Figure 2. Otherwise, lubri-
cate daily with a couple drops of pneumatic tool oil
directly into the air fitting as shown in Figure 3.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
EYE INJURY HAZARD!
use to prevent
INJURY HAZARD!
EXPLOSION HAZARD!
Never exceed 120 PSI!
COPYRIGHT © FEBRUARY, 2006 BY GRIZZLY INDUSTRIAL, INC.
#PC8044 PRINTED IN TAIWAN
MODEL G5349
⁄ " AIR RATCHET
3
8
INSTRUCTION SHEET
Figure 1. Model G5349.
Quick
Quick
Connector
Connector
Your
Tool
Quick
Coupler
Air Hose
Figure 2. Installing your tool.
Figure 3. Lubricating directly into air fitting.
If you need help with your new pneumatic tool,
call our Tech Support at: (570) 546-9663.
Lubricator
Regulator
Air
Compressor
Quick
Filter
Coupler
