- Page 1 INSTRUCTION MANUAL PG1 Tester Read and understand all of the instructions and safety information in this manual before operating of servicing this tool. 52026635 © 2007 Greenlee Textron Inc. 5/07...
-
Page 2: Table Of Contents
Operation ... 6 Troubleshooting ... 7 Greenlee / A Textron Company Description The Greenlee PG1 Tester is a hand-held testing device intended for reading-out, replacing, and programming the programmable controller memory of Greenlee’s electro-hydraulic battery-powered tools. The PG1 consists of a shock-proof aluminum case with a four-line display and five operation keys. -
Page 3: Important Safety Information
Failure to observe this warning could result in severe injury or death. Greenlee / A Textron Company Electric shock hazard: Contact with live circuits could result in severe injury or death. - Page 4 Do not expose the unit to extremes in temperature or high humidity. Failure to observe these precautions may result in injury and may damage the unit. Greenlee / A Textron Company Do not use another manufacturer’s charger. Other manufacturers’ chargers may overcharge and damage the battery.
-
Page 5: Identification
Dimensions (approximate) Length ...235 mm (9-1/4 in) Width (min.) ...80 mm (3-1/8 in) Width (max.) ...105 mm (4-1/8 in) Depth ...32 mm (1-1/4 in) Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070 PG1 Tester... -
Page 6: Setup
LED of the tool to be tested. 3. Briefly touch the power trigger of the tool. 4. The PG1 will display the serial number of the tool and, if available, the date code, the type designa- tion, and special features of the tool. -
Page 7: Troubleshooting
Possible Remedy Replace batteries. Adjust contrast; refer to the “Setup” section. Clean LED with a dry cloth. Exchange cable or return tool to an authorized Greenlee service center. Return tool to an authorized Greenlee service center. Charge or replace battery. - Page 8 800-435-0786 Fax: 815-397-7070 Fax: Canada 800-435-0786 Fax: International +1-815-397-7070 Fax: +1-815-397-9247 4455 Boeing Drive • Rockford, IL 61109-2988 • USA • 815-397-7070 • An ISO 9001 Company Greenlee Textron Inc. is a subsidiary of Textron Inc. www.greenlee.com 800-451-2632 815-397-1865 800-524-2853...
