Ryobi RC-2050NV Owner's Operating Manual

Oil-free
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Voltage................................................................................................... 230V~50Hz
R
ated power........................................................................................ 1.5kW/2.0HP
Intermittent duty........................................................................................... S3 25%
Receiver capacity................................................................................................. 50l
Type.............................................................................................................. Oil-free
Free air delivery (FAD)................................................................................ 222l/min
CFM..................................................................................................................... 7.8
Working pressure................................................................................. 10bar/145psi
No load speed........................................................................................... 3400min
Sound pressure level.......................................................... L
Sound power level.............................................................L
Net weight...................................................................................................... 22.2kg
THANK YOU FOR BUYING A RYOBI
Your new compressor has been engineered and manufactured to Ryobi's high
standard of dependability, ease of operation and operator safety. Properly cared
for, it will give you years of rugged, trouble free performance. If you use your
compressor properly and only for what it is intended, you will enjoy years of
safe, reliable service.
CAUTION: Carefully read through this entire owner's
KEEP THIS MANUAL FOR FUTURE REFERENCE
OWNER'S OPERATING MANUAL
OIL-FREE COMPRESSOR
MODEL RC-2050NV
SPECIFICATIONS
OIL-FREE COMPRESSOR
manual, paying close attention to the general
safety rules and rules for safe operation,
before using.
1
75.5dB(A),k=3dB(A)
pA
95.5 dB(A),k=3dB(A)
WA
-1

Advertisement

Table of Contents
loading

Related Manuals for Ryobi RC-2050NV

Summary of Contents for Ryobi RC-2050NV

  • Page 1 THANK YOU FOR BUYING A RYOBI OIL-FREE COMPRESSOR Your new compressor has been engineered and manufactured to Ryobi’s high standard of dependability, ease of operation and operator safety. Properly cared for, it will give you years of rugged, trouble free performance. If you use your compressor properly and only for what it is intended, you will enjoy years of safe, reliable service.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The purpose of safety rules is to attract your The warnings and safety instructions must be attention to possible dangers. The safety symbols followed to ensure reasonable safety and efficiency and the explanations with them, require your in using this product.

  • Page 3: Work Area

    IMPORTANT SAFETY INSTRUCTIONS This compressor is designed for tyre inflation, the Avoid kinking or trapping the air hose. Always operation of pneumatic tools, spray painting and replace faulty hoses - never attempt a repair if a spraying non-corrosive cleaning agents. Do not use leak is detected.

  • Page 4: Electrical Safety

    IMPORTANT SAFETY INSTRUCTIONS c) Keep bystanders, children, and visitors level which can lead to hearing damage. The away while operating an air compressor. employer and user must ensure that any Distractions can cause you to lose control. necessary hearing protection is provided and used by the operator and others in the work d) Operate air compressor in an open area at area.

  • Page 5: Specific Safety Rules

    SPECIFIC SAFETY RULES d) Release all pressures within the system products, or any strong solvents to clean the slowly. Dust and debris may be harmful. unit. Following this rule will reduce the risk of deterioration of the enclosure plastic. e) Store idle air compressors out of the reach of children and other untrained persons.
  • Page 6 DESCRIPTION 1. Transportation handle 6. Air receiver tank 2. On/Off switch 7. Shroud 3. Wheels 8. Air outlet pressure gauge 4. Condensation drain tap 9. Air outlet quick release connector (regulated) 5. Rubber foot 10. Pressure regulator...

  • Page 7: Packing Contents

    UNPACKING CAUTION. This packaging contains the packaging away, keep it safe throughout the sharp objects. Take care when guarantee period, then recycle if possible, unpacking. Remove the machine, otherwise dispose of it by the proper means. Do together with the accessories supplied, from the not let children play with empty plastic bags due to packaging.

  • Page 8: Operation

    OPERATION DANGER. Do not disassemble any part • Always use the handle of the compressor with air in tank - • Do not lift by (or put strain on) air taps, valves bleed the tank. Failure to depressurize or hoses. tank could result in explosion and/or serious personal injury.

  • Page 9: Overload Protection

    OPERATION The compressor continues to operate according to this automatic cycle until the On/Off (I/O) switch is pressed. Always wait at least 10 seconds from when the compressor has been switched off before restarting this. OVERLOAD PROTECTION This compressor is fitted with an overload protection device, In the event that the motor becomes too hot a thermal protection device will cut the mains supply to the motor.

  • Page 10: Using The Air Compressor

    OPERATION Check that the drain valve tap is closed (Fig.6). Connect the compressor to a suitable 16A mains supply. Switch on the compressor by pressing the On/Off switch to the ON (depressed) position (Fig.7). The compressor will now start. When the air receiver tank is pressurised to its working capacity the compressor will automatically switch off.

  • Page 11: Draining The Reservoir

    OPERATION Fine adjustments to the air pressure can be made DRAINING THE RESERVOIR CAUTION. It is important to drain the until the accessory is working at its optimum performance. reservoir before storage to help prevent tank corrosion. Do not exceed the maximum rated air pressure for the accessory.

  • Page 12: Troubleshooting

    Now that you have purchased your tool, should a need ever exist of repair or service, simply contact your nearest Ryobi Authorised Service Centre or other qualified service organistion. Be sure to provide all pertinent facts when you call or visit.
  • Page 13 SYMBOLS Indicates danger, warning or caution. It means attention!!! Safety Alert Symbol Your safety is involved. Read Your Operator's Your manual contains special messages to bring attention Manual to potential safety concerns as well as operating and servicing information. Please read all the information carefully to ensure satisfaction and safe use.
  • Page 14 NOTES...
  • Page 15 NOTES...
