Gigabyte GA-7ZMMC User Manual
Gigabyte GA-7ZMMC User Manual

Gigabyte GA-7ZMMC User Manual

Amd athlon/duron socket a processor motherboard
Table of Contents

Advertisement

Quick Links

DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-7ZMMC
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Signature:
Date:
Jan. 15, 2001
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including interference
that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection
against
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause interference to radio or
television equipment reception, which can be
harmful
interference
This
equipment
and
can
radiate
in
radio

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GA-7ZMMC

  • Page 1 Phone/Fax No: (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Mother Board Model Number: GA-7ZMMC Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), Class B Digital Device Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Page 2: Declaration Of Conformity

    Safety of household and similar electrical appliances (Stamp) Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH declare that the product Mother Board GA-7ZMMC is in conformity with EN 61000-3-2* EN60555-2 EN61000-3-3* EN60555-3 EN 50081-1 EN 50082-1 EN 55081-2...
  • Page 3 7ZMMC AMD Athlon /Duron Socket A Processor Motherboard USER'S MANUAL AMD Athlon /Duron Socket A Processor Motherboard REV. 2.01 Third Edition R-201-03-010627...
  • Page 5 How This Manual Is Organized This manual is divided into the following sections: 1) Revision History 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM 7) Four Speaker & SPDIF 8) @BIOS &...
  • Page 7: Table Of Contents

    Revision History Item Checklist Feature Summary 7ZMMC Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List Block Diagram Suspend to RAM Installation Four Speaker & SPDIF Introduction (Optional) @BIOS Introduction EasyTuneIII Introduction Memory Installation Page Index for BIOS Setup Appendix...
  • Page 8: Revision History

    7ZMMC Motherboard Revision History Revision Revision Note 2.01 Initial release of the 7ZMMC motherboard user’s manual. 2.01 Second release of the 7ZMMC motherboard user’s manual. 2.01 Third release of the 7ZMMC motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein.
  • Page 9: Item Checklist

    Item Checklist Item Checklist The 7ZMMC motherboard Cable for IDE / floppy device Diskettes or CD (GA-7ZMM CD) for motherboard driver & utility 7ZMMC user’s manual...
  • Page 10: Feature Summary

    7ZMMC Motherboard Feature Summary Form Factor 24.4 cm x 22.2 cm Micro ATX size form factor, 4 layers PCB. AMD Athlon 256K/64K L2 cache on die Supports 600MHz ~ 1GHz and above Chipset Pro Savage KM133, consisting of: VT8365 Memory/AGP/PCI Controller (PAC) VT82C686B PCI Super-I/O Integrated Peripheral Controller (PSIPC) Clock Generator...
  • Page 11 PS/2 Connector On-Board VGA On-Board Sound BIOS Additional Features PS/2 Keyboard interface and PS/2 Mouse interface Build S3 Savage4 (86C370) in VT8365 Support shared memory architecture Creative CT5880 sound (Optional) AC’97 CODEC Line In / Line Out / Mic In / AUX In / CD In / TEL / SPDIF (Optional) / Game Port / Four Speaker (Optional) Licensed AMI BIOS, 2M bit flash ROM...
  • Page 12: 7Zmmc Motherboard Layout

    7ZMMC Motherboard 7ZMMC Motherboard Layout PS/2 Socket A CPU Creative CT5880 AGP 1 PCI1 PCI2 JP11 PCI3 VT8365 7ZMMC VT82C 686B USB2 LED1 BAT1 BIOS...
  • Page 13: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors ATX Power COM A / VGA / LPT Port Floppy Connector Game & Audio Port IDE 1(Primary) / IDE 2(Secondary) Connector J2 (System Fan) J3 (CPU Fan) J7 (AUX_IN) J8 (TEL) J9 (CD Audio Line In)
  • Page 14: Cpu Speed Setup

    7ZMMC Motherboard CPU Speed Setup The system bus speed is selectable at 100MHz. The user can select the system bus speed by DIP switch SW1 . SW1: CPU Speed Setup SW1: *102 *103 *107 *110 *113 *115 *133 * These speed settings are not guaranteed. AMD CPU Heat Sink Installation: Beware: Please check that the heat sink is in good contact with the CPU before you turn on your system.
  • Page 15: Connectors

    Connectors ATX Power COM A / VGA / LPT Port Pin No. Definition 3,5,7,13, 15-17 1,2,11 4,6,19,20 Power Good 5V SB stand by+5V PS-ON(Soft On/Off) LPT Port COM A Connectors 3.3V +12V -12V...
  • Page 16: Floppy Connector

    7ZMMC Motherboard Floppy Connector Game & Audio Port FDD1 Red Line Line Out 1 Line In/Line Out 2 Line Out 1: Line Out or SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder).
  • Page 17: Ide1 (Primary), Ide2 (Secondary) Connector

    IDE1 (Primary), IDE2 (Secondary) Connector J2: Sysem Fan IDE 2 IDE 1 Red Line Pin No. Definition Control +12V SENSE Connectors...
  • Page 18: Definition

    7ZMMC Motherboard J3: CPU Fan J7: AUX_IN Pin No. Definition Control +12V SENSE Pin No. Definition AUX-L AUX-R...
  • Page 19: J8 (Tel)

    J8 TEL: The connector is for Modem with internal voice connector J9: CD Audio Line In Pin No. Definition Signal-In Signal-Out Pin No. Definition CD-L CD-R Connectors...
  • Page 20: J12: Wake On Lan

    7ZMMC Motherboard J12: Wake On LAN J13: Ring Power On (Internal Modem Card Wake Up) Pin No. Definition +5V SB Signal Pin No. Definition Signal...
  • Page 21: Jp2: Front Audio

    JP2: Front Audio JP6: Power Fan Pin No. 3,4,5,6, 10,15 8,16 Pin No. Definition Control +12V Connectors Definition Incase speaker (R) Incase speaker (L) +12V Front Audio (R) Front Audio (L) Rear Audio (R) Rear Audio (L)
  • Page 22: Ps/2 Keyboard & Ps/2 Mouse Port

    7ZMMC Motherboard JP8 / LED1: STR LED Connector & DIMM LED PS/2 Keyboard & PS/2 Mouse Port STR LED Connector External. DIMM LED PS/2 Mouse Mouse/Keyboard Pin No. Definition PS/2 Keyboard PS/2 Data VCC(+5V) Clock...
  • Page 23: Usb1 (Rear Usb Port)

    USB 1: Rear USB Port USB 2: Front USB Connector Pin No. Definition USB V0 USB D0- USB D0+ USB V1 1 2 3 4 USB D1- USB D1+ Pin No. Connectors Definition USB D2- USB D2+ USB D3+ USB D3-...
  • Page 24: Panel And Jumper Definition

    7ZMMC Motherboard Panel And Jumper Definition BAT1: Battery J11: 2x11 Pins Front Panel CAUTION Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.
  • Page 25 GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPK (Speaker Connector) RE (Reset Switch) P+P P (Power LED) PW (Soft Power Connector) J16 /J17/J18: CNR (Primary or Secondary) Select [Optional] (CNR Open: Normal Operation Close: Entering Green Mode Pin 1: LED anode(+) Pin 2: LED cathode( ) Pin 1: LED anode(+)
  • Page 26: Jp1: Front Mic Function

    7ZMMC Motherboard JP1: Front MIC Function JP3: Clear CMOS Function (Optional) Pin No. Definition 1-2 close Enable Front MIC Function 2-3 close Disable Front MIC Function Pin No. Definition 1-2 close Normal (Default) 2-3 close Clear CMOS...
  • Page 27: Jp4: Usb Device Wake Up Selection

    JP4: USB Device Wake up Selection JP7: STR Function Enable Panel and Jumper Definition Pin No. Definition 1-2 close Normal (Default) 2-3 close USB Device Wake up (If you want to use “ USB Dev Wakeup from S3~S5 ” function, you have to set the BIOS setting “USB Dev Wakeup from S3~S5”...
  • Page 28: Jp9: Bios Write Protect Function

    7ZMMC Motherboard JP9: BIOS Write Protect Function JP10: CPU Clock Frequency (Optional) Pin No. Definition 1-2 close Write Protect Enable 2-3 close Write Protect Disable (Default) Please set Jumper JP9 to “2-3 close” to enabled BIOS write function when you update new BIOS or new device. Pin No.
  • Page 29: Jp11: Onboard Sound Function Selection

    Panel and Jumper Definition JP11: Onboard Sound Function Selection Pin No. Definition 1-2 close Onboard Sound Enable (Default) 2-3 close Onboard Sound Disable...
  • Page 30: Performance List

    AMD K7 Athlon (128x2) MB SDRAM (MICRON MT48LC8M8A2-8E B) DRAM 384KB included in CPU CACHE SIZE Gigabyte GF2000 DISPLAY Onboard IDE (IBM DTLA-307045) STORAGE Windows NT O.S. Display Driver at 1024 x 768 x 16bit colors x 75Hz.
  • Page 31 AMD K7 Athlon (128x2) MB SDRAM (KINGMAX KSV884T4A1A) DRAM 384KB included in CPU CACHE SIZE VIA OnChip Display DISPLAY Onboard IDE (IBM DTLA-307045) STORAGE Windows NT O.S. Display Driver at 1024 x 768 x 16bit colors x 75Hz. DRIVER Processor Winbench99 FPU Winmark 99 Business Disk Winmark 99...
  • Page 32: Block Diagram

    7ZMMC Motherboard Block Diagram 2X/4X AGPCLK (66MHz) On Chip PCI Bus 33MHz CT5880 AC97 3 PCI CODEC PCI (33MHz) AGPCLK (66MHz) PCI (33MHz) 48MHz 14.318MHz CPUCLK (100MHz) AMD-K7 System Bus 100MHz VT8365 100/133MHz AGPCLK (66MHz) 33MHz 14.318MHz 48MHz VT82C 686B Floppy LPT Port PS/2...
  • Page 33: Suspend To Ram Installation

    Suspend To RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 34 7ZMMC Motherboard Step 2: (If you want to use STR Function, please set jumper JP7 Closed.) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ Standby State : S3 / STR”...
  • Page 35 A.3 How to put your system into STR mode? There are two ways to accomplish this: Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B. Choose the “Stand by” item and press “OK” Suspend to RAM Installation...
  • Page 36 7ZMMC Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 37 Suspend to RAM Installation C. Select the “Advanced” tab and “Standby” mode in Power Buttons. D. Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button. A.4 How to recover from the STR sleep mode? There are five ways to “wake up”...
  • Page 38 7ZMMC Motherboard A.5 Notices: In order for STR to function properly, several hardware and software requirements must be satisfied: Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). Your SDRAM must be PC-100 compliant. Jumper JP8 is provided to connect to the STR LED in your system chassis.
  • Page 39: Four Speaker & Spdif Introduction (Optional)

    Four Speaker & SPDIF Introduction (Optional) Four Speaker Introduction What is Four Speaker? The Creative CT5880 audio chip can support up to 4 speaker output. If you select “Four speaker out”, Line In will be reconfigured as another line out to support a second pair of speakers.
  • Page 40 7ZMMC Motherboard c. Select “Four speaker” item. Microsoft Windows Me setup procedure: a. Go to “Control Panel” Double click “Sounds and Multimedia”.
  • Page 41 b. Select “Audio” Page, and click “Advanced” button. c. Select “Quadraphonic Speakers” and click ok. Four Speaker Application The four speaker function will only be supported in application softwares that use Microsoft DirectX and Creative EAX, for example, the game titles, software DVD player and MP3 player. Four Speaker and SPDIF Introduction Click ”Advanced”.
  • Page 42: Spdif Introduction

    7ZMMC Motherboard SPDIF Introduction What is SPDIF? The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder. How to use SPDIF? a. Click your mouse right button in “My Computer” and select the “Properties” item. b.
  • Page 43 Four Speaker and SPDIF Introduction c. Click “Sound, video and game controllers” item and select the “Creative Sound Blaster PCI128” item. d. Click “Settings” item and select the “Output Mode” item.
  • Page 44 7ZMMC Motherboard e. Click “Digital” item, Line Out will be reconfigure to SPDIF Out. f. Recommend you to select “Autosense”, It will automatically detect the type (mono or stereo) of the audio connector that you plug into Line Out audio jack, then configure Line Out to either SPDIF or Speaker accordingly.
  • Page 45: @Bios™ Introduction

    Or you may want to keep a backup for your current BIOS, just choose “Save Current BIOS” to save it first. You make a wise choice to use Gigabyte, and @BIOS your BIOS smartly. You are now worry free from updating wrong BIOS, and capable to maintain and manage your BIOS easily.
  • Page 46: Easytuneiii Introduction

    Click “Advanced Mode” to enjoy “sport drive” class overclocking. In “Advanced Mode”, one can change the system bus speed in small increments to get ultimate system performance. And no matter which mainboard is used, if it’s a Gigabyte’s ™ product*, EasyTuneIII helps to perform the best of system.
  • Page 47: Easytuneiii Tm Introduction

    This wonderful software is now free bundled in Gigabyte motherboard attached driver CD. Users may make a test drive of “EasyTuneIII features by themselves. For further technical information, please link to: Note: If your CD version is 1.6 or below, please visit our website and...
  • Page 48: Memory Installation

    7ZMMC Motherboard Memory Installation The motherboard has 2 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch. Memory size can vary between sockets.
  • Page 49: Page Index For Bios Setup

    Page Index for BIOS Setup The Main Menu Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor Supervisor Password / User Password IDE HDD Auto Detection Save &...
  • Page 50: Entering Setup

    7ZMMC Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power ON the computer and press <Del>...
  • Page 51: Getting Help

    GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 52 7ZMMC Motherboard Power Management Setup This setup page includes all the items of Green function features. PnP/PCI Configurations This setup page includes all the configurations of PCI & PnP ISA resources. Load BIOS Defaults Bios Defaults indicates the value of the system parameter which the system would be in the safe configuration.
  • Page 53: Standard Cmos Setup

    Standard CMOS Setup The items in Standard CMOS Features Menu (Figure 2) are divided into 9 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 54 7ZMMC Motherboard Time The times format in <hour> <minute> <second>. The time is calculated base on the 24-hour military-time clock. For example, 1 p.m. is 13:00:00. Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer.
  • Page 55: Extended Memory

    Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 56: Bios Features Setup

    7ZMMC Motherboard BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved 1st Boot Device 2nd Boot Device 3rd Boot Device S.M.A.R.T. for Hard Disks BootUp Num-Lock Floppy Drive Seek Password Check 1st / 2nd / 3rd Boot Device Floppy Boot Device by Floppy.
  • Page 57: Password Check

    Boot Up Num-Lock Keypad is number keys. (Default Value) Keypad is arrow keys. Floppy Drive Seek During POST, BIOS will determine if the floppy disk drive installed is 40 or 80 tracks. 360 type is 40 tracks while 720 , 1.2 and 1.44 are all 80 tracks. Enabled BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks.
  • Page 58: Chipset Features Setup

    7ZMMC Motherboard Chipset Features Setup AMIBIOS SETUP – CHIPSET FEATURES SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Configure Timing by SPD DRAM Frequency SDRAM CAS# Latency AGP Mode AGP Comp. Driving Manual AGP Comp. Driving AGP Fast Write AGP Aperture Size ClkGen Spread Spectrum USB Controller...
  • Page 59: Usb Controller

    AGP Comp. Driving Set AGP Comp. Driving to Auto. (Default Value) Auto Manual Set AGP Comp. Driving to Manual. If AGP Comp. Driving is Manual. Manual AGP Comp. Driving: AGP Fast Write Enabled Enable AGP Fast Write function. Disable this function. (Default Value) Disabled AGP Aperture Size Set AGP Aperture Size to 4MB.
  • Page 60: Power Management Setup

    7ZMMC Motherboard Power Management Setup AMIBIOS SETUP – POWER MANAGEMENT SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved ACPI Standby State USB Dev Wakeup From S3~S5 Suspend Time Out (Minute) Display Activity IRQ3 IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ11 IRQ13...
  • Page 61 Enable Suspend Time Out after 40min. Enable Suspend Time Out after 50min. Enable Suspend Time Out after 60min. Display Activity Ignore Display Activity. (Default Value) Ignore Monitor Monitor Display Activity. IRQ 3~IRQ15 Ignore Ignore IRQ3 ~IRQ15. Monitor Monitor IRQ3~IRQ15. Soft-off by Power Button Soft switch ON/OFF for POWER ON/OFF.
  • Page 62 7ZMMC Motherboard Resume On RTC Alarm You can set “Resume On RTC Alarm” item to enabled and key in Data/time to power on system. Disable this function. (Default Value) Disabled Enabled Enable alarm function to POWER ON system. If the default value is Enabled. RTC Alarm Date: RTC Alarm Hour: RTC Alarm Minute:...
  • Page 63 PNP/PCI Configurations AMIBIOS SETUP – PNP / PCI CONFIGURATION ( C ) 1999 American Megatrends, Inc. All Rights Reserved VGA Frame Buffer Size VGA Boot from IRQ 3 IRQ 4 IRQ 5 IRQ 7 IRQ 9 IRQ 10 IRQ 11 IRQ 14 IRQ 15 VGA Frame Buffer Size...
  • Page 64: Pnp/Pci Configuration

    7ZMMC Motherboard Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item F6 : Load BIOS Defaults...
  • Page 65: Load Setup Defaults

    Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP Load SETUP Defaults (Y/N)? N PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 66: Integrated Peripherals

    7ZMMC Motherboard Integrated Peripherals AMIBIOS SETUP – INTEGRATED PERIPHERALS ( C ) 1999 American Megatrends, Inc. All Rights Reserved OnBoard FDC OnBoard Serial Port 1 OnBoard Parallel Port Parallel Port Mode Parallel Port DMA Parallel Port IRQ OnBoard IDE OnBoard AC’97 Audio OnBoard MC’97 Modem OnBoard Legacy Audio Sound Blaster...
  • Page 67 Enable On Board LPT port and address to 3BC. Set On Board LPT port to Auto. (Default Value) Auto Disabled Disable On Board LPT port. Parallel Port Mode Using Parallel port as Enhanced Parallel Port. Using Parallel port as Extended Capabilities Port. (Default Value) Normal Normal Operation.
  • Page 68 7ZMMC Motherboard OnBoard Legacy Audio Enable OnBoard Legacy Audio. (Default Value) Enabled Disabled Disable OnBoard Legacy Audio. Sound Blaster Enabled Enable Sound Blaster. Disable Sound Blaster. (Default Value) Disabled SB I/O Base Address SB I/O Base Address 220h-22Fh SB I/O Base Address 240h-24Fh SB I/O Base Address 260h-26Fh...
  • Page 69: Hardware Monitor

    Hardware Monitor AMIBIOS SETUP – HARDWARE MONITOR SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved CPU Temperature System Temperature CPU Fan Speed System Fan Speed Vcore Vcc3 +5.000V +12.000V CPU Temperature. ( C / F) Detect CPU Temperature automatically. System Temperature.
  • Page 70: Set Supervisor / User Password

    7ZMMC Motherboard Set Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 71: Ide Hdd Auto Detection

    IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1999 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Tue Jan 25, 2000 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Not Installed Pri Slave : Not Installed Sec Master : Not Installed...
  • Page 72: Save & Exit Setup

    7ZMMC Motherboard Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION SAVE to CMOS and EXIT(Y/N)? Y LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit...
  • Page 73: Exit Without Saving

    Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.24a ( C ) 1999 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Quit without saving (Y/N) ? N LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item...
  • Page 74: Appendix

    7ZMMC Motherboard Appendix Appendix A: VIA VT8365/VT8364 Chipsets Driver Installation A.VIA 4 in 1 Service Pack Utility: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VIA 4in 1 Service Pack Driver”...
  • Page 75 Appendix 8.Click “Next”. 7.Click “Next”. 9.Click “Finish” to restart computer. (10)
  • Page 76 7ZMMC Motherboard B.VT8365/VT8364 VGA Driver: Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. 1.Click “VT8365/VT8364 VGA Driver” item. 3.Click “Next”. 4.Click “Finish”...
  • Page 77 Appendix B: Creative Sound Driver Installation (Optional) Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “Audio” icon. 1. Click “Creative CT5880 Sound Driver”...
  • Page 78 7ZMMC Motherboard 7.Click here. 8.Click”Next”. 9.Click “Finish” to restart computer. (10)
  • Page 79 Appendix C: VIA AC’97 Audio Driver Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “Audio” icon. 1.Click “VIA AC’97 Audio Driver” item.
  • Page 80 7ZMMC Motherboard Appendix D: EasyTune III Setup Insert the support CD that came with your motherboard into your CD-ROM driver or double –click the CD driver icon in My Computer to bring up the screen. Press “tool” icon. 1.Click “EasyTune III Setup” item.
  • Page 81 Appendix 6.Click “Finish” to restart computer.
  • Page 82 7ZMMC Motherboard Appendix E: BIOS Flash Procedure BIOS update procedure: If your OS is Win9X, we recommend that you used Gigabyte @BIOS Click “Tool”. Click “@BIOS Writer v1.06”. Click “ ”. Methods and steps: I. Update BIOS through Internet a. Click "Internet Update" icon b.
  • Page 83 In method I, if the BIOS file you need cannot be found in @BIOS onto Gigabyte's web site for downloading and updating it according to method II. d. Please note that any intercorruption during updating will cause system unbooted...
  • Page 84 Format a bootable system floppy diskette by the command “ format a:/s ” in command mode. Visit the Gigabyte website at http:// need and download it to your bootable floppy diskette. Insert the bootable diskette containing the BIOS file into the floppy diskette driver.
  • Page 85 Appendix Appendix F: Issues To Beware Of When Installing CNR Please use standard CNR card like the one in order to avoid mechanical problem. (See Figure A) PCI Slot Figure A: Standard CNR Card...
  • Page 86 7ZMMC Motherboard Appendix G: Acronyms Acronyms Meaning ACPI Advanced Configuration and Power Interface Advanced Power Management Accelerated Graphics Port Audio Modem Riser Advanced Communications Riser BIOS Basic Input / Output System Central Processing Unit CMOS Complementary Metal Oxide Semiconductor CRIMM Continuity RIMM Communication and Networking Riser Direct Memory Access...
  • Page 87 Acronyms Meaning Original Equipment Manufacturer PCI A.G.P. Controller POST Power-On Self Test Peripheral Component Interconnect RIMM Rambus in-line Memory Module Special Circumstance Instructions SECC Single Edge Contact Cartridge SRAM Static Random Access Memory Symmetric Multi-Processing System Management Interrupt Universal Serial Bus Voltage ID Appendix...
