Supero SUPERSERVER 1018R-WC0R User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
UPER
®
S
S
UPER
ERVER
®
1018R-WC0R
USER'S MANUAL
1.0

Advertisement

Table of Contents
loading

Related Manuals for Supero SUPERSERVER 1018R-WC0R

Summary of Contents for Supero SUPERSERVER 1018R-WC0R

  • Page 1 UPER ® UPER ERVER ® 1018R-WC0R USER’S MANUAL...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.
  • Page 3 About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 1018R-WC0R. Installation and maintainance should be performed by experienced technicians only. The SuperServer 1018R-WC0R is a high-end server based on the SC116AC2- R706WB 1U rackmount chassis and the X10SRW-F motherboard.
  • Page 4 UPER ERVER 1018R-WC0R User's Manual Chapter 5: Advanced Motherboard Setup Chapter 5 provides detailed information on the X10SRW-F motherboard, including the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfig- uring the motherboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 1018R-WC0R User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Motherboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 PCIe Expansion Slots ..................1-2 Serial ATA ......................1-2 Rear I/O Ports ....................1-2 Server Chassis Features ................1-3 System Power ....................
  • Page 7 Table of Contents Power ......................3-1 UID ........................3-2 Control Panel LEDs ..................3-2 Universal Information LED ................3-2 NIC1 ........................ 3-3 NIC2 ........................ 3-3 HDD ......................... 3-3 Power ......................3-3 Hard Drive Carrier LEDs ................. 3-4 Hard Drives ..................... 3-4 Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements ............
  • Page 8 UPER ERVER 1018R-WC0R User's Manual DIMM Installation .................... 5-8 Memory Population Guidelines ............... 5-9 Adding PCIe Add-On Cards ................5-11 Serverboard Details ..................5-12 X10SRW-F Quick Reference ................ 5-12 Connector Definitions ................... 5-14 Jumper Settings .................... 5-20 5-10 Onboard Indicators ..................5-22 5-11 SATA Ports ....................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 1018R-WC0R is comprised of two main subsystems: the SC116AC2-R706WB 1U chassis and the X10SRW-F motherboard. Please refer to our web site for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 10: Motherboard Features

    UPER ERVER 1018R-WC0R User's Manual Motherboard Features The SuperServer 1018R-WC0R is built around the X10SRW-F, a single processor motherboard based on the Intel C612 Express chipset. Below are the main features ® of the X10SRW-F. (See Figure 1-1 for a block diagram of the chipset.)

  • Page 11: Server Chassis Features

    Chapter 1: Introduction Server Chassis Features The SC116AC2-R706WB is Supermicro's third-generation 1U chassis. The follow- ing is a general outline of the main features of the SC116AC2-R706WB chassis. System Power The SC116AC2-R706WB features a 750W power supply composed of two separate power modules to provide power redundancy.
  • Page 12 UPER ERVER 1018R-WC0R User's Manual Figure 1-1. Intel C612 Express Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. VR12.5 5 PHASE 145W CHA,B SNB CORE DDR-IV CHC,D DMI2 PCI-E X16 G3 PCI-E X16G3 DMI2 PCI-E X8 G3...

  • Page 13: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 14 UPER ERVER 1018R-WC0R User's Manual Notes...

  • Page 15: Chapter 2 Server Installation

    Unpacking the System You should inspect the box the SuperServer 1018R-WC0R was shipped in and note if it was damaged in any way. If the server itself shows damage you should file a damage claim with the carrier who delivered it.

  • Page 16: Warnings And Precautions

    UPER ERVER 1018R-WC0R User's Manual • This product is for installation only in a Restricted Access Location (dedicated equipment rooms, service closets and the like). • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units. Warnings and Precautions Rack Precautions •...

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 18: Rack Mounting Instructions

    UPER ERVER 1018R-WC0R User's Manual Rack Mounting Instructions This section provides information on installing the SC116 chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 19: Inner Rail Extension

    Chapter 2: Server Installation Figure 2-2. Identifying the Sections of the Rack Rails (right side rail shown) Inner Rail Extension The SC116 chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack.

  • Page 20: Outer Rails

    UPER ERVER 1018R-WC0R User's Manual Secure to the Front of the Rack Secure to the Rear of the Rack Attach Outer Rails together Figure 2-3. Assembling the Outer Rails Outer Rails Installing the Outer Rails to the Rack 1. Attach the shorter outer rail to the outside of the longer outer rail. You must align the pins with the slides.
  • Page 21 Chapter 2: Server Installation Figure 2-4. Installing the Outer Rails to the Server Rack Note: figures are for illustrative purposes only. Always install servers to the bottom of a rack first.

  • Page 22: Installing The Chassis Into A Rack

    UPER ERVER 1018R-WC0R User's Manual Figure 2-5. Installing the Rack Rails Installing the Chassis into a Rack 1. Confirm that chassis includes the inner rails and inner rail extensions. Also- confirm that the outer rails are installed on the rack. 2.

  • Page 23: Installing The Chassis Into A Telco Rack

    Chapter 2: Server Installation Installing the Chassis into a Telco rack To install the chassis into a Telco or post-style rack, use two L-shaped brackets on either side of the chassis (four total). 1. First, determine how far follow the server will extend out the front of the rack. Larger chassis should be positioned to balance the weight between front and back.
  • Page 24 UPER ERVER 1018R-WC0R User's Manual Figure 2-6. Installing the Chassis into a Telco Rack Note: figures are for illustrative purposes only. Always install servers to the bottom of a rack first. 2-10...

  • Page 25: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel and on the drive carriers that provide system and component status for the server. This chapter explains the meanings of all LED indicators and the appropriate responses that need to be taken. Control Panel Buttons There are two buttons located on the front of the chassis: a power on/off button and a UID button.

  • Page 26: Uid

    UPER ERVER 1018R-WC0R User's Manual Depressing the UID (Unit Identifier) button illuminates an LED on both the front and rear of the chassis for easy system location in large stack configurations. The LED will remain on until the button is pushed a second time. Another UID button on the rear of the chassis serves the same function.

  • Page 27: Nic1

    Chapter 3: System Interface Universal Information LED States State Indication Fast Blinking Red (1x/sec) Fan Fail Solid Red CPU Overheat Slow Blinking Red (1x/4 sec) Power Fail Solid Blue Local UID Button Depressed Blinking Blue IPMI-Activated UID NIC1 Indicates network activity on GLAN1 when flashing. NIC2 Indicates network activity on GLAN2 when flashing.

  • Page 28: Hard Drive Carrier Leds

    UPER ERVER 1018R-WC0R User's Manual Hard Drive Carrier LEDs The SC116AC chassis supports the use of 10 SAS/SATA/NVMe PCI SSD drives. Hard Drives Each hard drive carrier has two LEDs. • Blue: When illuminated, this blue LED (on the front of the hard drive carrier) indicates drive activity.

  • Page 29: About Standardized Warning Statements

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 30 UPER ERVER 1018R-WC0R User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 31 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 32: Installation Instructions

    UPER ERVER 1018R-WC0R User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 33: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 34: Power Disconnection Warning

    UPER ERVER 1018R-WC0R User's Manual 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록 해야 합니다. Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A.
  • Page 35 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 36: Equipment Installation

    UPER ERVER 1018R-WC0R User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 37: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 38: Battery Handling

    UPER ERVER 1018R-WC0R User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬...
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 40: Redundant Power Supplies

    UPER ERVER 1018R-WC0R User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 41: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 42: Comply With Local And National Electrical Codes

    UPER ERVER 1018R-WC0R User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫اللىحة‬ ‫أوالطاقة المىجىدة على‬ ‫التيار الكهزبائي‬ ‫مه‬ ‫خطز‬ ‫هناك‬ ‫هذا الجهاس‬ ‫خدمة‬ ‫كه حذرا عند‬ ‫يعمل‬ ‫النظام‬ ‫عندما يكىن‬ 경고! 시스템이...

  • Page 43: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫المتعلقة‬ ‫المحلية والىطىية‬ ‫قىاويه‬ ‫يجب أن يمتثل لل‬ ‫الكهربائية‬...

  • Page 44: Hot Swap Fan Warning

    UPER ERVER 1018R-WC0R User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 45 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 46: Power Cable And Ac Adapter

    UPER ERVER 1018R-WC0R User's Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fire. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only.
  • Page 47 Chapter 4: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué...
  • Page 48 UPER ERVER 1018R-WC0R User's Manual Notes 4-20...

  • Page 49: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to connect the data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference. Remember to completely close the chassis when you have finished working with the serverboard to better cool and protect the system.

  • Page 50: Connecting Cables

    UPER ERVER 1018R-WC0R User's Manual Connecting Cables Now that the serverboard is installed, the next step is to connect the cables to the board. These include the data cables for the peripherals and control panel and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed to prevent them from blocking the flow of cooling air that moves through the system from front to back.

  • Page 51: Rear I/O Ports

    Chapter 5: Advanced Serverboard Setup Figure 5-1. Control Panel Header Pins Ground Power LED HDD LED NIC1 LED NIC2 LED OH/Fan Fail LED PWR Fail LED Reset Reset Button Ground Power Button Ground Rear I/O Ports See Figure 5-2 below for the descriptions of the various rear I/O ports. Figure 5-2.

  • Page 52: Installing The Processor And Heatsink

    UPER ERVER 1018R-WC0R User's Manual Installing the Processor and Heatsink Caution: When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: • Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components.
  • Page 53 Chapter 5: Advanced Serverboard Setup 3. With the lever labeled 'Close 1st' fully retracted, gently push down on the 'Open 1st' lever to open the load plate. Lift the load plate to open it completely. Gently push 4. Using your thumb and the index down to pop the load plate finger, remove the 'WARNING'...

  • Page 54: Installing And Removing A Passive Cpu Heatsink

    UPER ERVER 1018R-WC0R User's Manual 7. With the CPU in the socket, in- Gently close spect the four corners of the CPU the load plate. to make sure that they are flush with the socket. 8. Close the load plate. Use your thumb to gently push the lever labeled 'Close 1st' then the lever labeled 'Open 1st' down until they...
  • Page 55 Chapter 5: Advanced Serverboard Setup Removing the Heatsink Caution: Removing the CPU or the heatsink is not recommended. However, if necessary, please follow the instructions below. 1. Unscrew the heatsink screws from the serverboard in the sequence shown. 2. Gently wriggle the heatsink to loosen it from the CPU (do not use excessive force).

  • Page 56: Installing Memory

    UPER ERVER 1018R-WC0R User's Manual Installing Memory Caution! Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X10SRW-F supports up to 512 GB of ECC/non-ECC Load-Reduced (LRDIMM), up to 256 GB of ECC Registered (RDIMM) or up to 64 GB of unbuffered (UDIMM) DDR4-2133/1600/1333 memory in eight DIMM sockets.

  • Page 57: Memory Population Guidelines

    Chapter 5: Advanced Serverboard Setup DIMM Module Population Table Follow the tables below when installing memory. Memory Population Guidelines Please follow the tables below when populating the X10SRW-F. DDR4 Unbuffered ECC (UDIMM) Memory DIMM Slots per DIMMs Populat- Ranks per DIMM (any DIMM Type POR Speeds Channel...
  • Page 58 UPER ERVER 1018R-WC0R User's Manual Notes: Using DDR4 DIMMs with different operating frequencies is not allowed. Be sure to use memory modules of the same type, same speed, same frequency on the same motherboard. All channels in a system will run at the lowest common frequency. Due to memory allocation to system devices, the amount of memory that remains available for operational use will be reduced when 4 GB of RAM is used.

  • Page 59: Adding Pcie Add-On Cards

    Chapter 5: Advanced Serverboard Setup Adding PCIe Add-On Cards The 1018R-WC0R can accommodate two full-height, full-length PCIe 3.0 x16 and one low-profile, half-length PCIe 3.0 x8 add-on (expansion) cards installed to the riser cards included in the system. Installing an Add-on Card 1.

  • Page 60: Serverboard Details

    UPER ERVER 1018R-WC0R User's Manual Serverboard Details Figure 5-6. X10SRW-F Layout JUIDB1 COM1 USB0/1(3.0) BIOS COM2 LICENSE LAN2 LAN1 USB2/3 IPMI_LAN JPL1/LAN JPL1 1-2:ENABLE 2-3:DISABLE LEDM1 JPG1 JPF1 JPG1:VGA ON:POWER FORCE ON 1-2:ENABLE 2-3:DISABLE JBT1 USB8(3.0) JPB1 JL1: CHASSIS INTRUSION T-SGPIO3 (SATA SGPIO2) T-SGPIO2...
  • Page 61 Chapter 5: Advanced Serverboard Setup Connector Description COM1/COM2 COM1 (Port)/COM2 (Header) FAN1-2, FAN4-7 System/CPU Fan Headers 24-pin Main ATX Power Connector Speaker/Buzzer Front Panel Control Header JIPMB1 System Management Bus Header for the IPMI Slot Chassis Intrusion Header JOH1 Overheat LED/Fan Fail Power SMB (System Management Bus) JPWR1 8-pin CPU Power Connector...

  • Page 62: Connector Definitions

    UPER ERVER 1018R-WC0R User's Manual Connector Definitions Power Connectors ATX Power 24-pin Connector Pin Definitions A 24-pin main power supply connector Pin# Definition Pin # Definition (J24) and an 8-pin CPU power con- +3.3V +3.3V nector (JPWR1) must be connected to the power supply.
  • Page 63 Chapter 5: Advanced Serverboard Setup PWR Fail LED Power Fail LED Pin Definitions (JF1) The Power Fail LED connection is lo- Pin# Definition cated on pins 5 and 6 of JF1. See the 3.3V table on the right for pin definitions. Signal OH/Fan Fail/ PWR Fail/Blue_UID LED Pin Definitions (JF1)
  • Page 64 UPER ERVER 1018R-WC0R User's Manual Power LED The Power LED connector is located Power LED Pin Definitions (JF1) on pins 15 and 16 of JF1. This con- Pin# Definition nection is used to provide LED indica- 3.3V tion of power being supplied to the Power LED system.
  • Page 65 Chapter 5: Advanced Serverboard Setup LAN Ports Pin Definition Pin# Definition Pin# Definition P2V5SB SGND Ethernet Ports TD0+ Act LED Two Ethernet ports (LAN1/LAN2) are TD0- P3V3SB located on the rear I/O backpanel. TD1+ Link 100 LED (Yel- In addition, an dedicated IPMI LAN, low, +3V3SB) located above USB 0/1 ports, provides TD1-...
  • Page 66 UPER ERVER 1018R-WC0R User's Manual Serial Port Pin Definitions (COM1/COM2) Serial Ports Pin # Definition Pin # Definition One serial port (COM1) is located next to USB 0/1 VGA port. COM2 is located behind COM1 on the mother- board. See the table on the right for pin definitions.
  • Page 67 Chapter 5: Advanced Serverboard Setup TPM/Port 80 Header Pin Definitions Pin # Definition Pin # Definition TPM Header/Port 80 LCLK A Trusted Platform Module/Port 80 LFRAME# <(KEY)> header is located at JTPM1 to provide LRESET# +5V (X) TPM support and a Port 80 connec- LAD 3 LAD 2 tion.

  • Page 68: Jumper Settings

    UPER ERVER 1018R-WC0R User's Manual Standby Power Header Standby PWR Pin Definitions The +5V Standby Power header is lo- Pin# Definition cated at JSTBY1. See the table on the +5V Standby right for pin definitions. (You must also Ground have a card with a Standby Power con- No Connection nector and a cable to use this feature.) Jumper Settings...
  • Page 69 Chapter 5: Advanced Serverboard Setup LAN Enable/Disable LAN1/2 Enable Jumper Settings Use JPL1 and JPL2 to enable/disable Jumper Setting Definition LAN ports 1/2. See the table on the Pins 1-2 Enabled right for jumper settings. The default Pins 2-3 Disabled setting is Enabled.

  • Page 70: 5-10 Onboard Indicators

    UPER ERVER 1018R-WC0R User's Manual Watch Dog Enable/Disable Jumper JWD controls the Watch Dog function. Watch Dog is a system moni- tor that can reboot the system when a Watch Dog Jumper Settings software application hangs. Jumping Jumper Setting Definition pins 1-2 will cause WD to reset the sys- Pins 1-2 Reset...
  • Page 71 Chapter 5: Advanced Serverboard Setup Unit Identification LED (LE1) A rear UID LED indicator (LE1) is lo- cated next to the I/O backplane. This UID Indicator provides easy identifica- UID LED tion of a system unit that may be in Status need of service.

  • Page 72: 5-11 Sata Ports

    UPER ERVER 1018R-WC0R User's Manual 5-11 SATA Ports SATA Port SATA Ports Pin Definitions Pin# Definition Definition There are ten Serial ATA por ts Ground provided on the ser verboard (I- Ground SATA0-9). See the table on the right for pin definitions. Ground 5-24...

  • Page 73: 5-12 Installing Software

    Chapter 5: Advanced Serverboard Setup 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO file for your serverboard.

  • Page 74: Superdoctor® 5

    UPER ERVER 1018R-WC0R User's Manual SuperDoctor® 5 The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface in Windows and Linux operating systems. The program moni- tors system health information such as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 75: 5-13 Onboard Battery

    Chapter 5: Advanced Serverboard Setup 5-13 Onboard Battery Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.
  • Page 76 UPER ERVER 1018R-WC0R User's Manual Notes 5-28...

  • Page 77: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform mainte- nance on the SC116AC2-R706WB chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 78: Control Panel

    UPER ERVER 1018R-WC0R User's Manual Figure 6-1. Front and Rear Chassis Views Control Panel Hot-Swap Drive Bays (10) USB Ports PCIe Expansion Slots (w/ Riser Card) Power Supplies Rear I/O Ports (see Section 5-3) Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the motherboard to provide you with system status indications.

  • Page 79: System Fans

    Chapter 6: Advanced Chassis Setup Figure 6-2. Removing the Chassis Cover Warning: Except for short periods of time, do NOT operate the server without the cover in place. The chassis cover must be in place to allow proper airflow and prevent overheating.
  • Page 80 UPER ERVER 1018R-WC0R User's Manual Replacing a System Fan 1. Open the chassis while the system is running to determine which fan has failed. Never run the server for an extended period of time with the chassis open. 2. Turn off the power to the system and unplug the power cord from the power supply.

  • Page 81: Checking The Airflow

    Chapter 6: Advanced Chassis Setup Checking the Airflow Check the Airflow 1. Make sure there are no objects obstructing the airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.

  • Page 82: Hard Drive Installation

    UPER ERVER 1018R-WC0R User's Manual Hard Drive Installation The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow for the drive bays. For this reason, even empty carriers without drives installed must remain in the chassis.
  • Page 83 Chapter 6: Advanced Chassis Setup Removing a Hard Drive 1. To remove a carrier, push the release button located beside the drive LEDs. 2. Swing the handle fully out and use it to pull the unit straight out. Note: Your operating system must have RAID support to enable the hot-plug ca- pability of the hard drives.

  • Page 84: Power Supply

    UPER ERVER 1018R-WC0R User's Manual Power Supply The SC116 chassis comes equipped with two redundant 750W power supplies. These power supplies are auto-switching capable and automatically sense and operate at a 100v to 240v input voltage. An amber light will be illuminated on the power supply when the power is off.

  • Page 85: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS setup utility for the X10SRW-F. The ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS setup utility screens. Note: For AMI BIOS recovery, please refer to the UEFI BIOS Recovery Instructions in Appendix C.

  • Page 86: Main Setup

    UPER ERVER 1018R-WC0R User's Manual How to Start the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS setup utility. From the main menu, you can access the other setup screens.
  • Page 87 Chapter 7: BIOS System Date/System Time Use this option to change the system date and time. Highlight System Date or System Time using the arrow keys. Enter new values using the keyboard. Press the <Tab> key or the arrow keys to move between fields. The date must be entered in Day MM/DD/YYYY format.

  • Page 88: Advanced Setup Configurations

    UPER ERVER 1018R-WC0R User's Manual Advanced Setup Configurations Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.
  • Page 89 Chapter 7: BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...
  • Page 90 UPER ERVER 1018R-WC0R User's Manual Restore on AC Power Loss Use this feature to set the power state after a power outage. Select Power-Off for the system power to remain off after a power loss. Select Power-On for the system power to be turned on after a power loss.
  • Page 91 Chapter 7: BIOS Hyper-Threading Select Enable to use Intel Hyper-Threading Technology to enhance CPU perfor- mance. The options are Enable and Disable. Performance/Watt Select Power Optimized to use Intel Turbo Boost Technology to maximize system performance (with maximum cooling) when performance state P0 lasts more than two seconds.
  • Page 92 UPER ERVER 1018R-WC0R User's Manual DCU IP Prefetcher If this item is set to Enable, the IP prefetcher in the DCU (Data Cache Unit) will prefetch IP addresses to improve network connectivity and system performance. The options are Enable and Disable. DCU (Data Cache Unit) Mode Use this item to set the DCU data-prefecting mode.
  • Page 93 Chapter 7: BIOS Advanced Power Management Configuration Power Technology Select Energy Efficient to support power-saving mode. Select Custom to custom- ize system power settings. Select Disabled to disable power-saving settings. The options are Disable, Energy Efficient, and Custom. Config TDP Select Enable to allow the user to configure the Thermal Design Power (TDP) settings for the system.
  • Page 94 UPER ERVER 1018R-WC0R User's Manual CPU C6 Report (Available when Power Technology is set to Custom) Select Enable to allow the BIOS to report the CPU C6 state (ACPI C3) to the operating system. During the CPU C6 state, power to all caches is turned off. The options are Enable and Disable.
  • Page 95 Chapter 7: BIOS Short Duration Power Limit Enable Select Enable to support Short Duration Power Limit (Power Limit 2). The options are Enable and Disable. Short Duration Power Limit This item displays the time period during which short duration power is main- tained.
  • Page 96 UPER ERVER 1018R-WC0R User's Manual PORT 2A Link Speed Use this item to configure the link speed of a PCI-E port specified by the user. The options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) (5 GT/s) and Gen 3 (Generation 3) (8 GT/s).
  • Page 97 Chapter 7: BIOS  Intel VT for Directed I/O (VT-d) Intel VT for Direct I/O (VT-d) Intel VT for Directed I/O (VT-d) ® Select Enable to use Intel Virtualization Technology support for Direct I/O VT-d support by reporting the I/O device assignments to the VMM (Virtual Machine Monitor) through the DMAR ACPI Tables.
  • Page 98 UPER ERVER 1018R-WC0R User's Manual Link Speed Mode Use this item to select the data transfer speed for QPI Link connections. The options are Fast and Slow. Link Frequency Select Use this item to select the desired frequency for QPI Link connections. The op- tions are 6.4GB/s, 8.0GB/s, 9.6GB/s, Auto, and Auto Limited.
  • Page 99 Chapter 7: BIOS DRAM RAPL (Running Average Power Limit) Baseline Use this feature to set the run-time power-limit baseline for DRAM modules. The options are Disable, DRAM RAPL Mode 0, and DRAM RAPL Mode 1. Set Throttling Mode Throttling improves reliability and reduces power consumption in the proces- sor via automatic voltage control during processor idle states.
  • Page 100 UPER ERVER 1018R-WC0R User's Manual Memory RAS (Reliability_Availability_Serviceability) Configuration Use this submenu to configure the following Memory RAS settings. RAS Mode Select Enable to enable RAS support to enhance reliability, availability and ser- viceability of onboard memory modules. The options are Enable and Disable. Lockstep x4 DIMMs Select Enable to enable Lockstep Technology support for x4 DIMM modules.
  • Page 101 Chapter 7: BIOS South Bridge  The following South Bridge information will display:\ • USB Configuration • USB Module Version • USB Devices Legacy USB Support Select Enabled to support onboard legacy USB devices. Select Auto to disable legacy support if there are no legacy USB devices present. Select Disable to have all USB devices available for EFI applications only.
  • Page 102 UPER ERVER 1018R-WC0R User's Manual EHCI2 Select Enabled to enable EHCI (Enhanced Host Controller Interface) support on USB 2.0 connector #2 (-at least one USB 2.0 connector should be enabled for EHCI support.) The options are Disabled and Enabled. XHCI Pre-Boot Drive Select Enabled to enable XHCI (Extensible Host Controller Interface) support on a pre-boot drive specified by the user.
  • Page 103 Chapter 7: BIOS SATA Port 0~ Port 5 This item displays the information detected on the installed SATA drive on the particular SATA port. • Model number of drive and capacity • Software Preserve Support Port 0~ Port 5 Select Enabled to enable a SATA port specified by the user. The options are Disabled and Enabled.
  • Page 104 UPER ERVER 1018R-WC0R User's Manual *If the item above "Configure SATA as" is set to RAID, the following items will display: Support Aggressive Link Power Management When this item is set to Enabled, the SATA AHCI controller manages the power usage of the SATA link.
  • Page 105 Chapter 7: BIOS sSATA Configuration  When this submenu is selected, the AMI BIOS automatically detects the presence of the SATA devices that are supported by the SCU controller and displays the following items: sSATA Controller This item enables or disables the onboard SATA controller supported by the Intel SCU chip.
  • Page 106 UPER ERVER 1018R-WC0R User's Manual sSATA Port 0 ~ Port 3 Spin Up Device On an edge detect from 0 to 1, set this item to allow the PCH to start a COMRE- SET initialization to the device. The options are Enabled and Disabled. Port 0 ~ Port 3 sSATA Device Type Use this item to specify if the sSATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive.
  • Page 107 Chapter 7: BIOS sSATA Port 0~ Port 3 Select Enabled to enable an sSATA port specified by the user. The options are Disabled and Enabled. sSATA Port 0 ~ Port 3 Hot Plug This feature designates this port for hot plugging. Set this item to Enabled for hot-plugging support, which will allow the user to replace an sSATA drive without shutting down the system.
  • Page 108 UPER ERVER 1018R-WC0R User's Manual • PCI Latency Timer PCI AER (Advanced Error-Reporting) Support Use this item to configure the PCI-X latency timer for a device installed on a PCI-X bus. Select 64 to set the PCI-X latency timer to 64 PCI clock cycles. The options are 32, 64, 96, 128, 160, 192, 224 and 248 (PCI Bus Clocks).
  • Page 109 Chapter 7: BIOS on the system configuration. Select Disabled to disable ASPM support. The options are Disabled and Auto. Warning: Enabling ASPM support may cause some PCI-E devices to fail! MMIOHBase Use this item to select the base memory size according to memory-address map- ping for the IO hub.
  • Page 110 UPER ERVER 1018R-WC0R User's Manual Super IO Configuration  Super IO Chip AST2400  Serial Port 1 Configuration/Serial Port 2 Configuration Serial Port 1/Serial Port 2 Select Enabled to enable the onboard serial port specified by the user. The options are Enabled and Disabled.
  • Page 111 Chapter 7: BIOS COM1 Console Redirection Terminal Type This feature allows the user to select the target terminal emulation type for Con- sole Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Char- acter Set.
  • Page 112 UPER ERVER 1018R-WC0R User's Manual Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Dis- abled and Enabled.
  • Page 113 Chapter 7: BIOS Bits Per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 114 UPER ERVER 1018R-WC0R User's Manual Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 115 Chapter 7: BIOS Bits Per Second This item sets the transmission speed for a serial port used in Console Redirec- tion. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines. The options are 9600, 19200, 57600, and 115200 (bits per second).
  • Page 116 UPER ERVER 1018R-WC0R User's Manual ACPI Settings  WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) plat- form and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.

  • Page 117: Event Logs

    Chapter 7: BIOS Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 118 UPER ERVER 1018R-WC0R User's Manual Erasing Settings Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log before an event logging is initialized at bootup. The options are No and Yes. When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full.

  • Page 119: Ipmi

    Chapter 7: BIOS IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. IPMI Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system. System Event Log ...
  • Page 120 UPER ERVER 1018R-WC0R User's Manual When SEL is Full This feature allows the user to determine what the BIOS should do when the sys- tem event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
  • Page 121 Chapter 7: BIOS Gateway IP Address This item displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 192.168.10.253). 7-37...

  • Page 122: Security Settings

    UPER ERVER 1018R-WC0R User's Manual Security Settings This menu allows the user to configure the following security settings for the system. Password Check Select Setup for the system to check for a password at Setup. Select Always for the system to check for a password at bootup or upon entering the BIOS Setup utility. The options are Setup and Always.

  • Page 123: Boot Settings

    Chapter 7: BIOS Boot Settings Use this feature to configure Boot Settings: Setup Prompt Timeout Use this item to indicate the length of time (the number of seconds) for the BIOS to wait before rebooting the system when the setup activation key is pressed. Enter the value of 65535 (0xFFFF) for the BIOS to wait indefinitely.
  • Page 124 UPER ERVER 1018R-WC0R User's Manual • Dual Boot Order #8 • Dual Boot Order #9 • Dual Boot Order #10 • Dual Boot Order #11 • Dual Boot Order #12 • Dual Boot Order #13 • Dual Boot Order #14 •...

  • Page 125: Save & Exit

    Chapter 7: BIOS Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 126 UPER ERVER 1018R-WC0R User's Manual Save As User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <En- ter>. This enables the user to save any changes to the BIOS setup for future use. Restore User Defaults To set this feature, select Restore User Defaults from the Exit menu and press <En- ter>.

  • Page 127: Appendix A Bios Error Beep Codes

    Appendix A: BIOS POST Error Codes Appendix A BIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed at each system boot, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue to boot.
  • Page 128 UPER ERVER 1018R-WC0R User's Manual Notes...

  • Page 129: Appendix B System Specifications

    Appendix B: System Specifications Appendix B System Specifications Processors Single Intel E5-2600/E5-1600 v3 Series processor in an LGA2011 socket (Socket Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C612 Express chipset BIOS 128 Mb AMI®...
  • Page 130 UPER ERVER 1018R-WC0R User's Manual System Cooling Six 4-cm counter-rotating fans System Input Requirements AC Input Voltage: 100V - 240V AC auto-range Rated Input Current: 700W: 8A - 6A max, 750W: 4.5A - 3.8A max Rated Input Frequency: 50 to 60 Hz Power Supply Rated Output Power: Part# PWS-706P-1R, 700W (100-140VAC), 750W (200- 240VAC)
  • Page 131 Appendix B: System Specifications Notes...
  • Page 132 UPER ERVER 1018R-WC0R User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com- munication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
