9
SET MODE
■ Set mode items (Continued)
D SQL Key Action "
The function temporarily opens the squelch.
• Pu (Push): The Monitor function is activated by holding
down [SQL] for more than 1 second.
The squelch opens while holding down the key.
• Ho (Hold): The Monitor function is activated by holding
down [SQL] for more than 1 second.
The squelch stays open until the user pushes
any key.
D Backlight "
Turns the Automatic Backlight function ON or OFF.
• OFF: The function is OFF.
• ON: The backlight turns ON for 5 seconds when the user
pushes any key except [PTT].
D Contrast "
Selects the transceiver's display contrast.
• Hi:
The transceiver's display contrast is set to High.
• Lo:
The transceiver's display contrast is set to Low.
D Power Save "
Turns the Power Save function ON or OFF.
• OFF: The function is OFF.
• ON: The Power Save function reduces current drain by
deactivating the receiver circuit of the transceiver at
specific intervals.
21
"
"
"
"
D CH Display "
"/"
Selects the number of digits to display the channel number.
You can select settings for each channel group.
• 3d:
The channel number is displayed in 3 digits.
(Example: 78A)
• 4d:
The channel number is displayed in 4 digits.
(Example: 1078)
D Scrambler Code "
Set the voice scrambler code to between 1 and 32.
D VOX Level "
"
Sets the VOX gain level to between 1 (The lowest
sensitivity) to 10 (The highest sensitivity).
Higher values make the VOX function more sensitive to your
voice.
D VOX Delay "
"
Sets the VOX Delay to between 1 (The shortest) to 6 (The
longest) in 0.5 second steps.*
*Example: If the VOX delay is set to 2, transmitter stays ON for 1
second.
The VOX Delay is the amount of time the transmitter stays
ON after you stop speaking before the VOX switches to
receive.
"/"
"/"
"
"
