- Page 1 OWNER’S MANUAL REAL 5.1 CH DVD SOUND BAR Please read this manual carefully before operating your set and retain it for future reference. MODEL HLT55W (HLT55W, SHT55-S/D) P/NO : MFL65899781 HLT55W-F2_DSGPLL_ENG_9781.indd 1 2010-10-13 5:57:06...
- Page 2 To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation when open. DO NOT STARE INTO BEAM. HLT55W-F2_DSGPLL_ENG_9781.indd 2 2010-10-13 5:57:06...
- Page 3 AND 625p UNIT, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER. You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players.
-
Page 4: Table Of Contents
To display the DVD Menu Setting up To display the DVD title Connections to Your TV 1.5 times speed playback HDMI Out Connection Screen Saver Video Connection Starting play from selected Resolution Setting time Resume playback Video Output Resolution HLT55W-F2_DSGPLL_ENG_9781.indd 4 2010-10-13 5:57:06... - Page 5 Presetting the Radio Stations Deleting all the saved stations Deleting a saved station Improving poor FM reception Sound adjustment Setting the surround mode Advanced Operations Recording to USB Maintenance Notes on Discs Handling the Unit Troubleshooting Troubleshooting HLT55W-F2_DSGPLL_ENG_9781.indd 5 2010-10-13 5:57:06...
-
Page 6: Unique Features
Listens to sound from TV, DVD and Digital device with vivid 5.1 (2.1 or 2.0) ch mode. Accessories Unit brackets (2) Screws (4) Please check and identify the supplied accessories. Video cable (1) HDMI cable (1) HLT55W-F2_DSGPLL_ENG_9781.indd 6 2010-10-13 5:57:07... -
Page 7: Introduction
• If you try to play a DVD with a different available on that disc. regional code from your unit, the message “Check Regional Code” appears on the TV screen. HLT55W-F2_DSGPLL_ENG_9781.indd 7 2010-10-13 5:57:08... -
Page 8: Playable File Requirement
• File extensions: “.jpg” DivX file, subtitle may not be display. • CD-ROM file format : ISO9660/ JOLIET • If you play a DivX file different from DivXspec, it may not operate normally. HLT55W-F2_DSGPLL_ENG_9781.indd 8 2010-10-13 5:57:08... -
Page 9: Remote Control
• • • • • • • • • • a • • • • • • • • • 1 (POWER) : Switches the unit ON or OFF. Z OPEN/CLOSE : Opens and closes the disc Drawer. HLT55W-F2_DSGPLL_ENG_9781.indd 9 2010-10-13 5:57:08... - Page 10 • • • • • • • • • • g • • • • • • • • • TITLE RETURN DISC MENU MIC VOL ECHO VOL TV Control buttons : Controls the TV. (LG TV MARKER SLEEP only) VOCAL FADER PR/CH Controlling the TV...
-
Page 11: Front Panel
• Be careful not to have any conductive material such as metallic object on the touch buttons. It can cause malfunctions. • Be careful not to have any conductive material such as metallic object on the touch buttons. It can cause malfunctions. HLT55W-F2_DSGPLL_ENG_9781.indd 11 2010-10-13 5:57:09... -
Page 12: Rear Panel
Preparation Rear panel D HDMI OUT A Antenna Connector B AUX IN (L/R) E OPTICAL IN C VIDEO OUT HLT55W-F2_DSGPLL_ENG_9781.indd 12 2010-10-13 5:57:09... -
Page 13: Installation
BRACKET INSTALL GUIDE with the bottom Screws and Wall Plugs are not supplied for of TV and attach to the position. mounting the unit. We recommend the Hilti (HUD- Step 1 1 6 x 30) for the mounting. Please purchase it. HLT55W-F2_DSGPLL_ENG_9781.indd 13 2010-10-13 5:57:09... - Page 14 If the unit falls off, it may result in an injury or damage to the product. • When the unit is installed on a wall, please make sure that a child does not pull any of connecting cables, as it may cause it to fall. HLT55W-F2_DSGPLL_ENG_9781.indd 14 2010-10-13 5:57:10...
-
Page 15: Attaching The Speakers
Initial setting an ID of wireless subwoofer 1. Connect the power cord of the Wireless subwoofer to the outlet. 2. Turn on the main unit : The main unit and wireless subwoofer will be automatically connected. HLT55W-F2_DSGPLL_ENG_9781.indd 15 2010-10-13 5:57:10... - Page 16 5. Press PAIRING button on the subwoofer. - If you see the blue LED indicator light, pairing was successful. 6. Use U / u to select the [5.1 Speaker Setup] and press ENTER ( ) for wireless speaker connection test. HLT55W-F2_DSGPLL_ENG_9781.indd 16 2010-10-13 5:57:10...
-
Page 17: Connections To Your Tv
• You can fully enjoy digital audio and video signals together with this HDMI connection. • When you use HDMI connection, you can change the resolution for the HDMI output. (Refer to “Resolution Setting” on page 19.) HLT55W-F2_DSGPLL_ENG_9781.indd 17 2010-10-13 5:57:10... -
Page 18: Video Connection
• When the HDMI connection with HDCP is not verified, TV screen is changed to black or green screen or the snow noise may occur on the screen. In this case, check the the HDMI connection, or disconnect the HDMI cable. HLT55W-F2_DSGPLL_ENG_9781.indd 18 2010-10-13 5:57:10... -
Page 19: Resolution Setting
ENTER to confirm your selection. NOTE If your TV does not accept the resolution you have set on the player, you can set resolution to 576p (or 480p) as follows: Press x (STOP) for more than 5 seconds. HLT55W-F2_DSGPLL_ENG_9781.indd 19 2010-10-13 5:57:10... -
Page 20: Optional Equipment Connection
RADIO&INPUT. If your TV has only one output for audio (mono), 4. Turn on the portable player or external connect it to the left (white) audio jack on the unit. device and start playing it. HLT55W-F2_DSGPLL_ENG_9781.indd 20 2010-10-13 5:57:11... -
Page 21: Usb Connection
STOP (x) twice in a row. • USB port of the unit cannot be connected 2. Remove the USB device from the unit. to PC. The unit can not be used as a storage device. HLT55W-F2_DSGPLL_ENG_9781.indd 21 2010-10-13 5:57:11... -
Page 22: Optical In Connection
2. Select the AUX OPT by using the OPTICAL. To select the AUX OPT directly 3. Listen to sound with 5.1 (2.1 or 2.0) ch speaker. 4. To escape from AUX OPT by using the OPTICAL. Function is retuned to previous one. HLT55W-F2_DSGPLL_ENG_9781.indd 22 2010-10-13 5:57:11... -
Page 23: Adjust The Setup Settings
2. Use U u I i to select a language then press ENTER. The confirm menu will appear. 3. Use I i to select the [Enter] then press ENTER to finish the language setup. HLT55W-F2_DSGPLL_ENG_9781.indd 23 2010-10-13 5:57:11... -
Page 24: Language
Outputs 576 (or 480) lines of progressive Select when a standard 4:3 TV is connected. video. [16:9] [576i (or 480i)] Select when a 16:9 wide TV is connected. Outputs 576 (or 480) lines of interlaced video. HLT55W-F2_DSGPLL_ENG_9781.indd 24 2010-10-13 5:57:11... -
Page 25: Audio
Make the sound clear when the volume is turned down (Dolby Digital only). Set to [On] for this effect. Vocal Select [On] to mix karaoke channels into normal stereo. This function is effective for multi-channel karaoke DVDs only. HLT55W-F2_DSGPLL_ENG_9781.indd 25 2010-10-13 5:57:11... -
Page 26: Lock (Parental Control)
If you select unlock, parental control is not You can set up wireless connection manually, active and the disc plays in full. when your connection is not completed. Refer to page 16. 4. Press ENTER to confirm your rating selection. HLT55W-F2_DSGPLL_ENG_9781.indd 26 2010-10-13 5:57:12... -
Page 27: Others
2. Input a password and press ENTER. 3. Select the first character using U u buttons. 4. Press ENTER and select the second character using U u buttons. 5. Press ENTER to confirm your Area code selection. HLT55W-F2_DSGPLL_ENG_9781.indd 27 2010-10-13 5:57:12... -
Page 28: Operation
4. Press ENTER then selected option menu. NOTE • For the most Audio CD and DVD-ROM discs, playback starts automatically. • The unit plays only music file contained in the USB storage device or disc automatically. HLT55W-F2_DSGPLL_ENG_9781.indd 28 2010-10-13 5:57:12... -
Page 29: Other Operations
- Audio CD/ MP3/ WMA : Track/ All/ Random/ Off In the pause mode, press SLOW (bb or BB) to Slowing down select the required speed. the playing (DVD, DivX only) The DivX speed file cannot be slow down reverse playback. HLT55W-F2_DSGPLL_ENG_9781.indd 29 2010-10-13 5:57:12... -
Page 30: To Display The Dvd Menu
The resume point may be cleared when a button Screen Saver is pressed (for example; 1 (POWER), Z OPEN/ CLOSE, etc). The screen saver appears when you leave the unit in Stop mode for about five minutes. HLT55W-F2_DSGPLL_ENG_9781.indd 30 2010-10-13 5:57:12... -
Page 31: Marked Playback
3. Use I i to select desired code option. 4. Select the play mode by using the U u and 4. Press O RETURN to exit the On-Screen press ENTER. display. [Mark Play] Marked playback. [Current Play] Normal playback HLT55W-F2_DSGPLL_ENG_9781.indd 31 2010-10-13 5:57:12... -
Page 32: Viewing A Photo File
Rotate – Press ENTER to rotate the Returning to photo. the [Home] O Close RETURN menu. e Go to list – Press ENTER to return [Photo] menu. HLT55W-F2_DSGPLL_ENG_9781.indd 32 2010-10-13 5:57:12... -
Page 33: Sleep Timer Setting
NOTE • This function is available to use only when a microphone is connected. • It is not available on the MONO source. HLT55W-F2_DSGPLL_ENG_9781.indd 33 2010-10-13 5:57:12... -
Page 34: Radio Operations
3. Press ENTER a preset number will flash in the display window. 4. Press PRESET (-/+) to select the preset number you want. 5. Press ENTER. The station is stored. 6. Repeat the steps 2 to 5 to store other stations. HLT55W-F2_DSGPLL_ENG_9781.indd 34 2010-10-13 5:57:12... -
Page 35: Sound Adjustment
The BASS is Bass Blast. During • This function is not operated when the BASS playback, reinforce the treble, microphone is connected to the unit. bass and surround sound effect. HLT55W-F2_DSGPLL_ENG_9781.indd 35 2010-10-13 5:57:12... -
Page 36: Advanced Operations
The making of unauthorized copies of copy- protected material, including computer programs, files, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offense. This equipment should not be used for such purposes. Be responsible Respect copyrights. HLT55W-F2_DSGPLL_ENG_9781.indd 36 2010-10-13 5:57:13... -
Page 37: Maintenance
For details, please contact your nearest authorized service center. HLT55W-F2_DSGPLL_ENG_9781.indd 37 2010-10-13 5:57:13... -
Page 38: Troubleshooting
There is an obstacle in the path between work well / at all Remove the obstacle. the remote control and the unit. The batteries in the remote control are flat. Replace the batteries with new ones. HLT55W-F2_DSGPLL_ENG_9781.indd 38 2010-10-13 5:57:13... - Page 39 Kurdish 7585 Scots Gaelic 7168 Yiddish 7473 Estonian 6984 Laothian 7679 Serbian 8382 Yoruba 8979 Faroese 7079 Latin 7665 Serbo-Croatian 8372 Zulu 9085 Fiji 7074 Latvian, Lettish 7686 Shona 8378 Finnish 7073 Lingala 7678 Sindhi 8368 HLT55W-F2_DSGPLL_ENG_9781.indd 39 2010-10-13 5:57:13...
- Page 40 Mongolia Taiwan Ecuador Morocco Thailand Egypt Nepal Turkey El Salvador Netherlands Uganda Ethiopia Netherlands Antilles Ukraine Fiji New Zealand United States Finland Nigeria Uruguay France Norway Uzbekistan Germany Oman Vietnam Great Britain Pakistan Zimbabwe Greece Panama HLT55W-F2_DSGPLL_ENG_9781.indd 40 2010-10-13 5:57:13...
- Page 41 • Refer to the TV owner’s manual for the Laboratories. Dolby and the double-D symbol are details of SIMPLINK function. trademarks of Dolby Laboratories. • LG TV with SIMPLINK function has the logo as shown above. • Use a higher version cable than 1.2 A HDMI cable.
- Page 42 (W x H x D): 0.5 Vrms (3.5 mm stereo jack) Net Weight: 7.1 kg Tuner Designs and specifications are subject to change without prior notice. • FM Tuning Range: 87.5 to 108.0 MHz or 87.50 to 108.00 MHz HLT55W-F2_DSGPLL_ENG_9781.indd 42 2010-10-13 5:57:13...
- Page 43 HLT55W-F2_DSGPLL_ENG_9781.indd 43 2010-10-13 5:57:13...
