- Page 1 OWNER’S MANUAL Speaker Sound Bar Please read this manual carefully before operating your set and retain it for future reference. HLS26W www.lg.com P/NO : MFL67164760 HLS26W-NB_DCANLLK_ENG_4760.indd 1 2011-03-03 5:32:32...
-
Page 2: Safety Information
Safety way to remove the battery or the battery from the equipment: Remove the WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK old battery or battery pack, follow the steps HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN in reverse order than the assembly. To prevent OR MOISTURE. contamination of the environment and bring on WARNING: Do not install this equipment in a possible threat to human and animal health, the confined space such as a book case or similar unit. old battery or the battery put it in the appropriate CAUTION: Do not block any ventilation openings. container at designated collection points. Do Install in accordance with the manufacturer’s not dispose of batteries or battery together with instructions. other waste. It is recommended that you use Slots and openings in the cabinet are provided for local, free reimbursement systems batteries and ventilation and to ensure reliable operation of the accumulators. The battery shall not be exposed to product and to protect it from over heating. The excessive heat such as sunshine, fire or the like. openings shall be never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product shall not be placed in a built- in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to. HLS26W-NB_DCANLLK_ENG_4760.indd 2 2011-03-03 5:32:32... - Page 3 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11. Only use attachments/accessories specified by the manufacturer. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. HLS26W-NB_DCANLLK_ENG_4760.indd 3 2011-03-03 5:32:32...
-
Page 4: Table Of Contents
Optional Equipment Connection – Setting up the remote to control your – AUDIO (PORT. IN) In Connection – Listening to music from your portable player – OPTICAL In connection – Speaker ez (easy) setup – USB Playback HLS26W-NB_DCANLLK_ENG_4760.indd 4 2011-03-03 5:32:32... - Page 5 Table of Contents Troubleshooting Troubleshooting Appendix Maintenance – Handling the Unit Trademarks and Licenses Specifications HLS26W-NB_DCANLLK_ENG_4760.indd 5 2011-03-03 5:32:32...
-
Page 6: Unique Features
Getting Started Unique Features Accessories Please check and identify the supplied accessories. Portable In Listen to music from your portable device. (MP3, Notebook, etc) Speaker ez (easy) Setup Remote control (1) Batteries (2) Listen to sounds from TV, DVD or Digital device with vivid 2.0 ch mode. WALL BRACKET Wall bracket (1) INSTALL GUIDE (1) Optical cable (1) HLS26W-NB_DCANLLK_ENG_4760.indd 6 2011-03-03 5:32:33... -
Page 7: Introduction
Getting Started Introduction Playable file Symbols Used in this Manual MP3/ WMA music file requirement Note MP3/ WMA file compatibility with this unit is limited Indicates special notes and operating features. as follows : y Sampling frequency : within 32 to 48 kHz (MP3), within 32 to 48 kHz (WMA) Indicates tip and hints for making the task easier. > y Bit rate : within 32 to 320 kbps (MP3), Caution 40 to 192 kbps (WMA) Indicates cautions for preventing possible damages y Maximum files : Under 999 from abuse. y File extensions : “.mp3”/ “.wma” HLS26W-NB_DCANLLK_ENG_4760.indd 7 2011-03-03 5:32:33... -
Page 8: Remote Control
• • • • • • • • • • d • • • • • • • • • TV Control buttons: See page 20 BLUETOOTH: Pairing, connecting and disconnecting your unit and Bluetooth device in function other than the Bluetooth. 0 to 9 numerical buttons: Selects numbered Battery Installation numbered files. Enters the PIN code. Remove the battery cover on the rear of the Remote Control, and insert two (size AAA) battery with and matched correctly. HLS26W-NB_DCANLLK_ENG_4760.indd 8 2011-03-03 5:32:33... -
Page 9: Front Panel
Getting Started Front panel A Display D I STOP B USB Port E T PLAY / PAUSE C F FUNCTION F – VOL + Press it repeatedly to select other function. Adjusts speaker volume. G 1 STANDBY/ON Rear panel A PORT. (Portable) IN B OPTICAL IN 1/ 2 HLS26W-NB_DCANLLK_ENG_4760.indd 9 2011-03-03 5:32:33... -
Page 10: Connecting
Connecting Mounting the main 2. When you mount it on a wall (concrete), use the wall plugs (Not supplied). You should drill some unit on a wall holes. A guide sheet (WALL BRACKET INSTALL GUIDE) is supplied to drill. Use the sheet to check the point to drill. You can mount the main unit on a wall. Prepare screws and brackets. Step 2 Preperation Unit Wall bracket WALL BRACKET INSTALL GUIDE Note 1. Match the TV’s BOTTOM EDGE of WALL BRACKET INSTALL GUIDE with the bottom of TV and Screws and Wall Plugs are not supplied for attach to the position. mounting the unit. We recommend the Hilti (HUD-1 6 x 30) for the mounting. Please purchase it. Step 1 HLS26W-NB_DCANLLK_ENG_4760.indd 10 2011-03-03 5:32:34... - Page 11 Connecting 3. Remove the WALL BRACKET INSTALL GUIDE. 5. Hang the main unit onto the bracket as shown below. 4. Fix it with screws (not supplied) as shown in the illustration below. Step 5 Step 4 Note Detach the unit from the bracket as shown Note below. You can arrange power cord cable with the bracket as shown below. Power cord cable Power cord cable > Caution y Do not hang onto the installed unit and avoid any impact to the unit. y Secure the unit firmly to the wall so that it does not fall off. If the unit falls off, it may result in an injury or damage to the product. y When the unit is installed on a wall, please make sure that a child does not pull any of connecting cables, as it may cause it to fall. HLS26W-NB_DCANLLK_ENG_4760.indd 11 2011-03-03 5:32:34...
-
Page 12: Optional Equipment Connection
Speaker ez (easy) setup Listening to music from your Listens to sound from TV or DVD or Digital Device with 2.1 or 2ch mode. portable player 1. Connect the unit’s OPTICAL IN 1/ 2 jack to jack The unit can be used to play the music from many on optical out of your TV (or Digital Device etc.). types of portable player or external devices. 2. Select the OPTICAL 1/ 2 by using the OPTICAL. 1. Connect the portable player to the To select the OPTICAL 1/ 2 directly AUDIO (PORT. IN) IN connector of the unit. 3. Listen to sound with 2.1 or 2ch speaker. 2. Turn the power on by pressing 1 POWER. 4. Press OPTICAL to exit from OPTICAL 1/ 2. 3. Select the PORTABLE function by pressing Function is retuned to previous one. INPUT. 4. Turn on the portable player or external device and start playing it. HLS26W-NB_DCANLLK_ENG_4760.indd 12 2011-03-03 5:32:34... -
Page 13: Usb Playback
USB device requirement y Devices which require additional program installation connected to a computer, are not supported. y Do not extract the USB device while in operation. y For a large capacity USB, it may take longer than a few minutes to be searched. y To prevent data loss, back up all data. y If you use a USB extension cable or USB hub, the USB device is not recognized. Removing the USB Device from the unit. y Using NTFS file system is not supported. (Only 1. Choose a different function mode or press FAT(16/32) file system is supported.) I STOP twice in a row. y This unit is not supported when the total 2. Remove the USB device from the unit. number of files is 1 000 or more. y External HDD, Card readers, Locked devices, or hard type USB devices are not supported. y The unit’s USB Port cannot be connected to PC. The unit can not be used as a storage device. HLS26W-NB_DCANLLK_ENG_4760.indd 13 2011-03-03 5:32:35... -
Page 14: Operating
During playback, press C 2. Use C V to scroll up and down through or V to go to the next file the delay amount, which you can set at Skipping to the or to return to the beginning anything between 0 and 300m/sec. next/ previous of the current file. file Press C twice briefly to step back to the previous file. Press REPEAT on the remote Playing control repeatedly, the display repeatedly or change in the following order, randomly RPT 1 RPT D (DIRECTORY) RPT ALL RANDOM OFF. Press 0 to 9 numerical buttons on the remote Selecting files directly control to go to the desired file directly. HLS26W-NB_DCANLLK_ENG_4760.indd 14 2011-03-03 5:32:35... -
Page 15: Sleep Timer Setting
Displaying file and input source Press SLEEP one or more times to select delay time between 10 and 180 minutes, after the unit will You can display various information on the USB and turn off. OPTICAL IN 1/ 2 mode by pressing INFO.. To check the remaining time, press SLEEP. USB : MP3/ WMA containing file information To cancel the sleep function, press SLEEP repeatedly until “SLEEP 10” appears, and then press OPTICAL IN 1/ 2 : Audio format, Audio channel SLEEP once again while “SLEEP 10” is displayed. Note You can check the remaining time before the Unit turns off. Press SLEEP The remaining time appears in the display window. Dimmer Press SLEEP once. The display window will be darken by half. To cancel it, press SLEEP repeatedly until dim off. Turn off the sound temporarily Press MUTE to mute your unit. You can mute your unit in order, for example, to answer the telephone, appearing the in the display window. HLS26W-NB_DCANLLK_ENG_4760.indd 15 2011-03-03 5:32:35... -
Page 16: Sound Adjustment
BASS bass and surround sound effect. The CLRVOICE is Clear Voice. This program make voice sound clear, improving the CLRVOICE quality of voice sound. (We encourage to use this EQ when you watch the movie of 5.1 channel.) The VIRTUAL is VSM Plus. VIRTUAL You can enjoy more virtual surround sound. The GAME is Game Equalizer. You can enjoy more virtual GAME sound while playing video games. The NIGHT is Night Mode. This may be useful when you NIGHT want to watch movies at low volume late at night. The UPSCALER is MP3 Up- Scaling. When listening to MP3 files or other compressed UPSCALER music, you can enhance the sound. This mode is available only to 2 channel sources. Improves the bass and treble LOUDNESS sound. HLS26W-NB_DCANLLK_ENG_4760.indd 16 2011-03-03 5:32:35... -
Page 17: Using Bluetooth Technology
Bluetooth Profiles PIN code : 0000 In order to use Bluetooth wireless technology, 4. When this unit successfully paired with your devices must be able to interpret certain profiles. Bluetooth device, Bluetooth LED of this unit This unit is compatible with following profile. lights up and appears “PAIRED”. A2DP (Advanced Audio Distribution Profile) Note AVRCP (Audio/ Video Distribution Remote Control y Depending on the Bluetooth device type, Profile) some device have a different pairing way. y This function is recommended to use to listening to music. While using Bluetooth headset, sound and images may not be matched depending on the wireless environment or the connection conditions. 5. Listen to music. To play a music stored on your Bluetooth device, refer to your Bluetooth device’s user guide. Note y If you change the function of the unit, the Bluetooth function is disconnected, operate pairing again. (Bluetooth Function other than the Bluetooth) y AVRCP is not supported in this mode. HLS26W-NB_DCANLLK_ENG_4760.indd 17 2011-03-03 5:32:35... -
Page 18: Listening To Sound Through The Bluetooth Devices
3. Put the Bluetooth device in pairing mode. Bluetooth device. Refer to your Bluetooth device’s user guide. Appears in as below display window. 4. Press and hold BLUETOOTH. Appears “INQUIRY”. Connection : BT CONN If searched Bluetooth is only one, pairing the Disconnection : DISCONN unit. Refer the step 7. Note 5. Appears depending on type of Bluetooth If you change the function of the unit, the devices in display window . Bluetooth function is disconnected, press 6. Select a Bluetooth device you want to connect BLUETOOTH pairing again. by using WS FOLDER and press Z (STOP). (Bluetooth Function other than the Bluetooth) 7. Enter the PIN code by using numberical buttons. PIN code : 0000 8. Press Z (STOP) to confirm. When this unit successfully paired with your Bluetooth device, Bluetooth icon of this unit lights up and appears “BT SRC”. You can listen to music played on this unit using your Bluetooth device. Sound output from the speakers is stopped. HLS26W-NB_DCANLLK_ENG_4760.indd 18 2011-03-03 5:32:35... -
Page 19: Checking The Information Of Connected Bluetooth Device
Bluetooth and the set is less than 10m, there are obstacles between both, your Bluetooth device cannot be connected. y Depending on the type of the device, you may not be able to use the Bluetooth function. y You can enjoy wireless system using phone, MP3, Notebook, headset, etc.. y When not connected the Bluetooth, “BT READY” appears on the display window. y The Electrical malfunction due to devices using same frequency such as Medical equipment, Microwaves or wireless LAN devices, the connection will be disconnected. y When someone stands and interrupts communication between Bluetooth device and the player, the connection will be disconnected. y If the gotten away of the distance between Bluetooth and the unit, the sound quality is lower and lower the connection will disconnect when the space between the Bluetooth and the unit gets out of the operating range of Bluetooth. y The device with Bluetooth wireless technology is disconnected, if you turn off the main unit or put the device away from the main unit more than 10m. HLS26W-NB_DCANLLK_ENG_4760.indd 19 2011-03-03 5:32:35... -
Page 20: Controlling A Tv With The Supplied Remote Control
1, 3, 4 Button Operation GoldStar 1, 2 1 (TV POWER) Turn the TV on or off. Samsung 6, 7 Switch the TV’s input source AV/INPUT between the TV and other Sony 8, 9 input sources. Hitachi Adjust the volume of the VOL +/– 2. Release the 1 (TV POWER) button to complete setting. Scan up or down through PR/CH W/S Depending on your TV, some or all buttons may not memorized channels. function on the TV, even after entering the correct Note manufacturer code. When you replace the batteries of the remote, the code number you have set may Depending on the unit being connected, you be reset to the default setting. Set the appropriate may not be able to control your TV using some code number again. of the buttons. HLS26W-NB_DCANLLK_ENG_4760.indd 20 2011-03-03 5:32:35... -
Page 21: Troubleshooting
Troubleshooting Troubleshooting PROBLEM CORRECTION Plug in the power cord. No Power Check the condition by operating other electronic devices. Press FUNCTION and check the selected function. No sound The remote control is too far from the unit. Operate the remote control within about 23 ft (7m). The remote There is an obstacle in the path of the remote control and the unit. control does Remove the obstacle. not work properly. The battery in the remote control is exhausted. Replace the battery with new one. HLS26W-NB_DCANLLK_ENG_4760.indd 21 2011-03-03 5:32:35... -
Page 22: Appendix
Appendix Maintenance Handling the Unit When shipping the unit Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory. Keeping the exterior surfaces clean y Do not use volatile liquids such as insecticide spray near the unit. y Wiping with strong pressure may damage the surface. y Do not leave rubber or plastic products in contact with the unit for a long period of time. Cleaning the unit To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit. HLS26W-NB_DCANLLK_ENG_4760.indd 22 2011-03-03 5:32:35... -
Page 23: Trademarks And Licenses
Appendix Trademarks and Licenses Manufactured under license from Dolby Labo- ratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are registered trademarks & DTS Digital Surround and the DTS logos are trademarks of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved. Bluetooth® wireless technology is a system which allows radio contact between electronic devices within a max. range of 10 meters. Connecting individual devices under Bluetooth® wireless technology does not incur any charges. A mobile phone with Bluetooth® wireless tech- nology can be operated via the Cascade if the connection was made via Bluetooth® wireless technology. The Bluetooth® word mark and logos are owned by the Bluetooth® SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners. HLS26W-NB_DCANLLK_ENG_4760.indd 23 2011-03-03 5:32:35... -
Page 24: Specifications
Appendix Specifications General Power requirements Refer to main label. Power consumption Refer to main label. Dimensions (W x H x D) (39 x 3 x 2) inches without foot Net Weight (Approx.) 5.1 lbs Operating temperature 41 °F to 95 °F (5 °C to 35 °C) Operating humidity 5 % to 90 % Bus Power Supply (USB) DC 5 V 0 500 mA Inputs DIGITAL IN (OPTICAL IN) 3 V (p-p), Optical jack x 2 PORT. IN 0.5Vrms (3.5 mm stereo jack) Amplifier Stereo mode 70 W + 70 W (4 Ω at 1 kHz) Designs and specifications are subject to change without prior notice. HLS26W-NB_DCANLLK_ENG_4760.indd 24 2011-03-03 5:32:35... - Page 25 LG Customer Information Center 1-888-542-2623 CANADA Register your product Online! www.lg.com HLS26W-NB_DCANLLK_ENG_4760.indd 25 2011-03-03 5:32:35...
