SPLIT-TYPE AIR CONDITIONERS
OPERATING INSTRUCTIONS
INDOOR UNIT
MSC-07RV
MSC-09RV
MSC-12RV
MSC-C07TV
MSC-C09TV
MSC-C12TV
OPERATING INSTRUCTIONS
•
To use this unit correctly and safely, be sure to read this operating instructions
before use.
Bedienungsanleitung
•
Um diese Einheit richtig und sicher zu verwenden, unbedingt diese Bedienungs-
anleitung vor der Inbetriebnahme durchlesen.
NOTICE D'UTILISATION
•
Pour avoir la certitude d'utiliser cet appareil correctement et en toute sécurité, veuillez
lire attentivement cette notice d'instructions avant de mettre l'appareil en fonction.
GEBRUIKSAANWIJZING
•
Om dit apparaat op de juiste manier en veilig te gebruiken, dient u eerst deze
gebruiksaanwijzing aandachtig door te lezen.
MANUAL DE INSTRUCCIONES
•
Para emplear correctamente este aparato y por razones de seguridad debe leer
este manual de instrucciones de manejo antes de su utilización.
LIBRETTO D'ISTRUZIONI
•
Per utilizzare correttamente quest'unità, leggere questo libretto d'istruzioni atten-
tamente e per intero.
√¢∏°π∂™ §∂π∆√Àƒ°π∞™
•
°È· Ó· ¯ÚËÛÈÌÔÔÈ‹ÛÂÙ ·˘Ù‹ ÙËÓ ÌÔÓ¿‰· ÛˆÛÙ¿ Î·È Ì ·ÛÊ¿ÏÂÈ·, ‚‚·Èˆı›ÙÂ
fiÙÈ ¤¯ÂÙ ‰È·‚¿ÛÂÈ ·˘Ùfi ÙÔ ÂÁ¯ÂÈÚ›‰ÈÔ Ô‰ËÁÈÒÓ ÚÈÓ ·fi ÙËÓ ¯Ú‹ÛË.
INSTRUÇÕES DE OPERAÇÃO
•
Para utilizar esta unidade correctamente, certifique-se de que lê estas instruções
de operação antes da utilização.
BRUGSANVISNING
•
Læs denne brugsanvisning før brugen så korrekt og forsvarlig anvendelse af klima-
anlægget sikres.
BRUKSANVISNING
•
För att använda enheten på rätt och säkert sätt ska denna bruksanvisning läsas
innan enheten tas i bruk.
‹fiLETME TAL‹MATLARI
•
Bu birimi do¤ru ve güvenli olarak çal›flt›rmak için, kullanmadan önce bu iflletme
talimatlar›n› mutlaka okuyun.
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
•
Для обеспечения правильного и безопасного использования прибора следует
до начала его эксплуатации внимательно прочитать данное руководство.
ADVANCED AND EVER ADVANCING
For customers
Für Kunden
A l'attention des clients
Voor de klant
Para los clientes
Per gli utenti
°È· ÙÔÓ ÂÏ¿ÙË
Para os clientes
Til kunden
För kunder
Sat›n al›c›lar için
Для пользователей
English
Deutsch
Français
Nederlands
Español
Italiano
∂ÏÏËÓÈο
Português
Dansk
Svenska
Türkçe
Русский
Advertisement
Table of Contents
Related Manuals for Mitsubishi MSC-07RV
Summary of Contents for Mitsubishi MSC-07RV
- Page 1 Pour avoir la certitude d’utiliser cet appareil correctement et en toute sécurité, veuillez lire attentivement cette notice d’instructions avant de mettre l’appareil en fonction. INDOOR UNIT GEBRUIKSAANWIJZING Voor de klant MSC-07RV Nederlands • Om dit apparaat op de juiste manier en veilig te gebruiken, dient u eerst deze MSC-09RV gebruiksaanwijzing aandachtig door te lezen.
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS • SAFETY PRECAUTIONS ................2 Since rotating parts and parts which could cause an electric shock are used in this product, be sure to read these “Safety Precautions” before use. NAME OF EACH PART .................. 5 • Since the cautionary items shown here are important for safety, be sure to observe them. - Page 3 SAFETY PRECAUTIONS WARNING CAUTION • This air conditioner is NOT intended for use by children or infirm persons without supervisions. When the air filter is to Do not clean the air con- Ventilate well in using Do not use intermediate Do not turn the breaker Do not insert your finger be removed, do not...
- Page 4 SAFETY PRECAUTIONS CAUTION For installation WARNING When the unit is not going to Do not operate the unit Replace the 2 batteries be used for a long time, dis- for a long time in high with new ones of same •...
-
Page 5: Name Of Each Part
NAME OF EACH PART Outdoor unit Indoor unit Front panel Air cleaning filter Air inlet (back and side) (White bellows Air inlet type) Piping Deodorizing filter to Breaker (Gray sponge type) Drainage hose Power supply cord Air filter Remote control Air outlet receiving section Vertical vane... - Page 6 NAME OF EACH PART Remote controller Open the front lid. Signal transmitting section ˚C Operation display section CLOCK AMPM AMPM ON/OFF (operate/ stop) button ON/OFF WARM COOL AMPM Temperature buttons AMPM ON/OFF WARM COOL STOP Fan speed control button I FEEL COOL Off-timer button VANE START...
-
Page 7: Preparation Before Operation
PREPARATION BEFORE OPERATION Auto restart function Remote controller (How to set the batteries and the current time) Remove the front lid and insert bat- Press the CLOCK set button. These models are equipped with an auto restart function, but this function is OFF teries. - Page 8 PREPARATION BEFORE OPERATION When the remote controller cannot be used (emergency operation) Handling of the remote controller • The range that the signal can reach is about 6 m when the remote controller is pointed at the front of the When the batteries of the remote controller run out or the remote controller malfunctions, the emergency operation indoor unit.
-
Page 9: I Feel
I FEEL... AUTO OPERATION • To start operation: Description of “I FEEL...” mode ON/OFF Press the button. With the “ (I FEEL...)” auto operation mode, Details of operation the optimum room condition can be set automati- cally with a one-touch operation. When the “... -
Page 10: Manual Operation (Cool, Dry, Heat/Fan)
MANUAL OPERATION (COOL, DRY, HEAT/FAN) The details of the display on the indoor unit are explained on page 9. To select the COOL, DRY or HEAT/FAN mode NOTE ON/OFF Press the button. When the ambient temperature is too high, the room temperature may not reach the set temperature since the unit operates to cool under high load. -
Page 11: Air Flow Velocity And Direction Adjustment
AIR FLOW VELOCITY AND DIRECTION ADJUSTMENT To change the AIR FLOW velocity, press Auto air flow direction control operation AIR FLOW velocity and direction can be selected button. as required. VANE I When the AUTO mode is selected with the Each time the button is pressed, the fan speed is button, the position of the horizontal vane is automatically set changed in sequence: (Lo) →... -
Page 12: Econo Cool Operation
ECONO COOL OPERATION Perform the following operations while the Use this operation when you want to be com- unit is operating. fortable in COOL mode even with energy saved. ECONO COOL Press the button. When the (ECONO COOL) operation is selected in COOL mode, the air conditioner performs swing op- eration in various cycle according to the temperature of air conditioner. -
Page 13: Timer Operation (On/Off Timer)
WHEN THE AIR CONDITIONER IS NOT GOING TIMER OPERATION (ON/OFF TIMER) TO BE USED FOR A LONG TIME TIMER When it is not going to be used for a When the air conditioner is to be long time: used again: How to set the ON timer Perform the FAN operation for 3 or 4 hours Clean the air filter and install it in the in-... -
Page 14: Maintenance
CLEANING THE AIR FILTER AND MAINTENANCE THE DEODORIZING FILTER Do not open the front panel up past the level position in order to prevent it from being damaged. Before starting maintenance Cleaning the indoor unit Cleaning the air filter Cleaning the deodorizing filter Turn off the breaker and/or disconnect the Clean the unit using a soft dry cloth. -
Page 15: Replacement Of The Deodorizing Filter/Air Cleaning Filter
REPLACEMENT OF THE DEODORIZING FILTER/ BEFORE CONTACTING THE SERVICE REPRE- AIR CLEANING FILTER SENTATIVE, CHECK THE FOLLOWING AGAIN When the capacity is lowered because of dirt, etc., it is necessary to replace the deodorizing filter/air cleaning filter. The air conditioner Cannot be cooled Display of the remote con- cannot be operated. -
Page 16: When You Think That Trouble Has Occurred
WHEN YOU THINK THAT TROUBLE HAS OCCURRED Question Answer (not a malfunction) Question Answer (not a malfunction) I When a ventilation fan or a gas cooker is used in The air conditioner a room, the cooling load increases, resulting in I This protects the air conditioner according to in- cannot be operated The room cannot be... -
Page 17: Installation, Relocation And Inspection
INSTALLATION, RELOCATION AND INSPECTION Installation place Avoid installing the air conditioner in the following places. Keep the outdoor unit 3 m or I Where flammable gas could leak. more away from the antennas of TV sets or radios. CAUTION Inverter-type To prevent the effects fluorescent lamp of a fiuorescent lamp,... -
Page 18: Specifications
SPECIFICATIONS Set name MSH-07RV MSH-09RV MSH-12RV Set name MSH-C07TV MSH-C09TV MSH-C12TV Model Indoor MSC-07RV MSC-09RV MSC-12RV Model Indoor MSC-C07TV MSC-C09TV MSC-C12TV Outdoor MUH-07RV MUH-09RV MUH-12RV Outdoor MUH-C07TV MUH-C09TV MUH-C12TV Function Cooling Heating Cooling Heating Cooling Heating Function Cooling Heating Cooling... - Page 19 SPECIFICATIONS Note: 1. Rating condition 2. Guaranteed operating range ° ° Cooling — Indoor: C DB, 19 C WB Indoor Outdoor ° Outdoor: 35 C DB ° 32°C DB 43°C DB Heating — Indoor: C DB Upper limit ° ° 23°C WB —...
