Page 1 Wireless N/A 5GHz 200mW Outdoor AP Model: APO1200/APO1215 User’s Manual V.1.0...
Page 2: Table Of Contents
ETWORK REATION 3.2.1 Wireless General Setup ...20 3.2.2 Wireless Advanced Setup...22 3.2.3 Create Virtual AP (VAP) ...28 3.2.3.1 Virtual AP Overview ...28 3.2.3.2 Virtual AP Setup...29 3.2.4 Wireless MAC Filter Setup ...33 3.3 W IRELESS ETWORK XPANSION 3.4 S YSTEM ANAGEMENT ...35...
Page 3 5.1.3 Configure DDNS Setup ...83 5.1.4 Configure LAN Setup...84 5.2 A CCESS OINT SSOCIATION ...85 5.2.1 Configure Wireless General Setting ...85 5.2.2 Configure Wireless Advanced Setting ...87 5.2.3 Site Survey ...88 5.2.4 Create Wireless Profile...89 5.3 S YSTEM ANAGEMENT ...91 5.3.1 Configure Management...91...
Page 4 ONNECTION 7.1.1 Network Requirement...175 7.1.2 Configure LAN IP ...176 7.2 A CCESS OINT SSOCIATION ...178 7.2.1 Configure Wireless General Setting ...178 7.2.2 Wireless Advanced Setup...180 7.2.3 Site Survey ...186 7.2.4 Create Wireless Profile...187 7.3 W LAN N IRELESS ETWORK REATION 7.3.1 Repeater AP Setup ...189...
Page 5 8.7.4 Extra Info...260 8.7.5 QoS Plot...262 8.7.6 Event Log...263 APPENDIX A. WINDOWS TCP/IP SETTINGS...264 APPENDIX B. WEB GUI VALID CHARACTERS ...266 APPENDIX C. MCS DATA RATE ...269 APPENDIX D. SYSTEM MANAGER PRIVILEGES ...270 APPENDIX E. ENABLING UPNP IN WINDOWS XP...271 TECHNICAL SUPPORT ...273...
Page 6: Chapter 1. System Overview
Chapter 1. System Overview 1.1 Introduction Airlink101® Wireless N/A 5GHz 200mW Outdoor Access Point, APO1200 / Wireless N/A 5GHz 200mW Outdoor Access Point with 15dBi Patch Antenna, APO1215 is the point of connection to Wireless Outdoor Network for service provider deploying last mile services to business or residential broadband subscribers.
Page 7: System Concept
1.2 System Concept The APO1200/APO1215 is not only designed and used as traditional outdoor AP, but also with rich features tailored for WISP applications. The two-level management capability and access control ease WISP and owners to maintain and manage wireless network in a more controllable fashion. Main applications are listed as follows with illustration: Wireless CPE for Multi Dwelling Unit/Multi Tenant Unit(MDU/MTU) complexes including apartments, dormitories, and office complexes.
Page 8: Applications In Wireless Network
1.3 Applications in Wireless Network APO1200/APO1215 is a multiple mode system which can be configured either as a wireless gateway or an access point as desired. It also can be used as a WDS link for Ethernet network expansion. This section depicts different applications on Router AP Mode, AP Mode, WDS Mode, CPE Mode, Client Bridge + Universal Repeater Mode and CPE + AP Mode.
Page 9 Ethernet port. A relay base station relays data between main base stations and relay stations or remote base stations with clients. A remote base station is the end point to accept connections from wireless clients and pass data upwards to a network wirelessly.
Page 10 CPE mode, APO1200/APO1215 is a gateway enabled with NAT and DHCP Server functions. The wired clients connected to APO1200/APO1215 are in different subnet from those connected to Main Base Station, and, in CPE mode, it does not accept wireless association from wireless clients.
Page 11 WISPs deliver wireless broadband Internet service to new residential and business customers. In this mode, the APO1200/APO1215 is a gateway with NAT and DHCP Server functions. The wireless and wired clients of APO1200/APO1215 are on the different subnet from Main Base Station and it accepts wireless connections from client devices.
Page 12: Product Benefit
Integrated Power over Ethernet (PoE) Multiple Virtual AP & Capability of Client Isolation Business-class WLAN Security and Client Authentications Provide Advanced Wireless Setting Support Web Management and SNMP MIB II Over Load Current Protection Client Isolation Through Layer 2 VLAN Technology...
Page 13: Specification
Wireless Architecture Mode Router AP Mode Wire connection as WAN , in this mode , the device run as DHCP server to assign IP address to wireless clients out of a private IP address pool behind a NAT This enables the wireless interconnection of Access Point in an IEEE802.11 network .and accept wireless...
Page 14 Preamble setting : Short/ Long Setting for 802.11a/n mix or 802.11a only Setting for transmission speed Dynamic Wireless re-transmission IEEE802.11f IAPP (Inter Access Point Protocol), hand over users to another AP IEEE 802.11i Preauth (PMKSA Cache ) IEEE 802.11h - TPC(Transmission Power Control) and DFS(Dynamic Frequency Select) IEEE 802.11d -Multi country roaming...
Page 15 Authentication/ Encryption (Wireless Security) Layer 2 User Isolation and AP Isolation Blocks client to client discovery within a specified VLAN WEP 64/ 128 Bits EAP-TLS + Dynamic WEP EAP-TTLS + Dynamic WEP PEAP/ MS-PEAP+Dynamic WEP WPA (PSK +TKIP) WPA (802.1x certification + TKIP) 802.11i WPA2 (PSK + CCMP/ AES)
Page 16 System Administration Intuitive Web Management Interface Password Protected Access Firmware upgrade via Web Reset to Factory Defaults Profiles Configuration Backup and Restore One-button-click to reset factory default Two administrator accounts Remote Link Test – Display connect statistics Full Statistics and Status Reporting Real time QoS Flow Plot NTP Time Synchronization Even Log...
Page 17: Chapter 2. Basic Installation
Chapter 2. Basic Installation 2.1 Hardware Installation 2.1.1 Package Contents The standard package contents of APO1200/APO1215 : APO1200/APO1215 Quick Installation Guide CD-ROM (with User Manual and QIG) Power Adapter DC24V 0.5A PoE Injector Mounting Kit It is highly recommended to use all the supplies in the package instead of substituting any components by other suppliers to guarantee best performance.
Page 18 ► Press and hold the Reset button for more than 10 seconds to reset the system to default configurations. Power : Green LED ON indicates power on, and OFF indicates power off. WLAN : Green LED FLASH indicates Wireless Transmit. LAN : Green LED ON indicates connection, OFF indicates no connection, FLASH indicates packets transmit.
Page 19: Hardware Installation Steps
Connect PSE to the PoE connector on the front panel. Connect an Ethernet cable to the PSE and the other end to a computer or a subnet 192.168.2.x. Power on the PSE in order to supply power to APO1200. APO1215 Connect PSE to the PoE connector on the front panel.
Page 20: Web Management Interface Instructions
IP Segment Set-up for Administrator's PC/Laptop Set the IP segment of the administrator's computer to be in the same range as APO1200/APO1215 for accessing the system. Do not duplicate the IP Address used here with IP Address of APO1200/APO1215 or any other device within...
Page 21 System Login The system manager Login Page then appears. Enter “root” for user name and “default” for password, and then click OK to login to the system. Login Success System Overview page will appear after successful login.
Page 22: Chapter 3. Ap Mode Configuration
3.1 External Network Connection 3.1.1 Network Requirement Normally, APO1200/APO1215 connects to a wired LAN and provides a wireless connection point to associate with wireless client as shown in Figure 3-1. Then, Wireless clients could access to LAN or Internet by associating themselves with APO1200/APO1215 set in AP mode.
Page 23: Configure Lan Ip
IP Gateway : The default gateway of the LAN port; default Gateway is 192.168.2.1 Dynamic IP : This configuration type is applicable when the APO1200/APO1215 is connected to a network with the presence of a DHCP server; all related IP information will be provided by the DHCP server automatically.
Page 24 APO1200 APO1200 Click Save button to save your changes. Click Reboot button to activate your changes...
Page 25: Wireless Lan Network Creation
36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149, 153, 157, 161 Tx Power : You can adjust the output power of the system to get the appropriate coverage for your wireless network.
Page 26 HT TxStream/RxStream : By default, it's 2. Operating Mode : By default, it's Mixed Mode. Mixed Mode : In this mode packets are transmitted with a preamble compatible with the legacy 802.11a/g, the rest of the packet has a new format. In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.
Page 27: Wireless Advanced Setup
LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to re-transmit from collision because of hidden wireless clients or other causes.
Page 28 DTIM Interval : The DTIM interval is in the range of 1~255. The default is 1. DTIM is defined as Delivery Traffic Indication Message. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.
Page 29 52-140 is DFS channel. If turns on IEEE802.11H, AP Will have check, and will not send beacon and can not be connect. When APO1200/APO1215 detect radar(5GHz) signal, the AP will switch channel and stop beacon transmit between sec to do channel available...
Page 30 Voice High Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.
Page 31 When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates.
Page 32 Txop : Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM). This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.
Page 33: Create Virtual Ap (Vap)
3.2.3 Create Virtual AP (VAP) The APO1200/APO1215 support broadcasting multiple SSIDs, allowing the creation of Virtual Access Points, partitioning a single physical access point into Tag(ID) and network settings. Figure 3-2 shows multiple SSIDs with different security type and VLAN settings.
Page 34: Virtual Ap Setup
Maximum Clients : The default value is 32. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5, only 5 clients at most are allowed to connect to this VAP.
Page 35 This system supports tagged Virtual LAN(VLAN). A valid number of 1 to 4094 can be entered after it’s enabled. If your network utilize VLANs you could tie a VLAN Tag to a specific SSID, and packets from/to wireless clients belonging to that SSID will be tagged with that VLAN Tag. This enables security of wireless applications by applying VLAN Tag.
Page 36 WPA General Settings : • Cipher Suite : By default, it is AES. Select either AES or TKIP cipher suites • Group Key Update Period : By default, it’s 3600 seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required. •...
Page 37 WEP 802.1X : When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete configuration. Radius Server Settings : • IP Address : Enter the IP address of the Authentication RADIUS server. • Port : By default, it’s 1812.
Page 38: Wireless Mac Filter Setup
Add a station MAC : Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “Add” button, then the MAC address should display in the “Enable” List. There are a maximum of 20 clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the Add and Remove buttons.
Page 39: Wireless Network Expansion
The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links. A WDS link is bidirectional and both side must support WDS. Access points know each other by MAC Address. In other words, each access point needs to include MAC address of its peer.
Page 40: System Management
3.4 System Management 3.4.1 Configure Management Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods. Please click System -> Management and follow the below settings. System Information System Name : Enter a desired name or use the default one.
Page 41 RSA key. Ping Watchdog : The ping watchdog sets the APO1200/APO1215 Device to continuously ping a user defined IP address (it can be the internet gateway for example). If it is unable to ping under the user defined constraints, the APO1200/APO1215 device will automatically reboot.
Page 42 Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats system as an illegal website. Click “Continue to this website” to access the system's WMI. The system's Overview page will appear.
Page 43: Configure System Time
3.4.2 Configure System Time System time can be configured via this page, and manual setting or via a NTP server is supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current system time. NTP Client : To synchronize the system time with NTP server.
Page 44: Configure Snmp Setup
3.4.3 Configure SNMP Setup SNMP is an application-layer protocol that provides a message format for communication between SNMP manager and agent. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting. SNMP v2c Enable: Check to enable SNMP v2c.
Page 45 Community : Set a community string required by the remote host computer that will receive trap messages or notices send by the system. IP : Enter the IP addresses of the remote hosts to receive trap messages. Click Save button to save changes and click Reboot button to activate.
Page 46: Backup / Restore And Reset To Factory
3.4.4 Backup / Restore and Reset to Factory Backup current configuration, restore prior configuration or reset back to factory default configuration can be executed via this page. Please click on Utilities -> Profile Setting and follow the below setting. Save Settings To PC : Click Save button to save the current configuration to a local disk. Load Settings from PC : Click Browse button to locate a configuration file to restore, and then click Upload button to upload.
Page 47: Firmware Upgrade
To prevent data loss during firmware upgrade, please back up current settings before proceeding Do not interrupt during firmware upgrade including power on/off as this may damage system. Never perform firmware upgrade over wireless connection or via remote access connection.
Page 48: Network Utility
Count : By default, it’s 5 and the range is from 1 to 50. It indicates number of connectivity test. Traceroute : Allows tracing the hops from the APO1200/APO1215 device to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host. The test is...
Page 49: Reboot
3.4.7 Reboot This function allows user to restart system with existing or most current settings when changes are made. Click Reboot button to proceed and take around three minutes to complete. A reminder will be available for remaining time to complete. If power cycle is necessary, please wait till completion of the reboot process.
Page 50: System Status
This section breaks down into subsections of System Overview, Associated Clients Status, WDS Link Status, Extra Information and Event Log. 3.5.1 System Overview Display detailed information of System, Network, LAN and Wireless in the System Overview page. System : Display the information of the system. System Name : The name of the system.
Page 51 Transmit bytes : The total transmitted packets in bytes of the LAN port. Transmit packets : The total transmitted packets of the LAN port. Wireless Information : Display total received and transmitted statistics on available Virtual AP. MAC Address : The MAC address of the Wireless port.
Page 52: Associated Clients Status
3.5.2 Associated Clients Status It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with all Virtual AP. VAP Information : Highlights key VAP information. VAP : Available VAP from Primary AP to VAP6. ESSID : Display name of ESSID for each VAP.
Page 53: Show Wds Link Status
3.5.3 Show WDS Link Status Peers MAC Address, antenna 0/1 received signal strength, phy mode and channel bandwidth for each WDS are available. MAC Address : Display MAC address of WDS peer. Signal Strength ANT0/ANT1 : Indicate the signal strength of the respective WDS links. Phy Mode : Indicate the phy mode of the respective WDS linked.
Page 54: Extra Information
Route table information : Select “Route table information” on the drop-down list to display route table. APO1200/APO1215 could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces.
Page 55 Bridge STP Information : Select “Bridge STP Information” on the drop-down list to display a list of bridge STP information.
Page 56: Event Log
3.5.5 Event Log The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system. Time : The date and time when the event occurred. Facility : It helps users to identify source of events such “System”...
Page 57: Chapter 4. Wds Mode Configuration
4.1.1 Network Requirement You could expand your Ethernet network via WDS link. In this mode, the APO1200/APO1215 connects directly to a wired LAN, and wirelessly bridges to a remote access point via a WDS link as shown in Figure 4-1. In the mode, it can’t associate with any wireless clients.
Page 58: Configure Lan Ip
IP Gateway : The default gateway of the LAN port; default Gateway is 192.168.2.1 Dynamic IP : This configuration type is applicable when the APO1200/APO1215 is connected to a network with the presence of a DHCP server; all related IP information will be provided by the DHCP server automatically.
Page 59: Wireless Network Expansion
36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149, 153, 157, 161 Tx Power : You can adjust the output power of the system to get the appropriate coverage for your wireless network.
Page 60 HT TxStream/RxStream : By default, it's 2. Operating Mode : By default, it's Mixed mode Mixed Mode : In this mode packets are transmitted with a preamble compatible with the legacy 802.11a/g, the rest of the packet has a new format. In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.
Page 61: Wireless Advanced Setup
LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to re-transmit from collision because of hidden wireless clients or other causes.
Page 62 DTIM Interval : The DTIM interval is in the range of 1~255. The default is 1. DTIM is defined as Delivery Traffic Indication Message. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.
Page 63 The Channel 52-140 is DFS channel. If tuen on IEEE802.11H, AP Will have check, and will not send beacon and can not be connect. When APO1200/APO1215 detect radar(5GHz) signal, the AP will switch channel and stop beacon trasmit between WMM : By default, it's “Disable”.
Page 64 Voice High Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.
Page 65 When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates.
Page 66 Txop : Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM). This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.
Page 67: Wds Setup
The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links. A WDS link is bidirectional and both side must support WDS. Access points know each other by MAC Address. In other words, each access point needs to include MAC address of its peer.
Page 68: System Management
4.3 System Management 4.3.1 Configure Management Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods. Please click System -> Management and follow the below settings. System Information System Name : Enter a desired name or use the default one.
Page 69 RSA key. Ping Watchdog : The ping watchdog sets the APO1200/APO1215 Device to continuously ping a user defined IP address (it can be the internet gateway for example). If it is unable to ping under the user defined constraints, the APO1200/APO1215 device will automatically reboot.
Page 70 Click Save button to save your changes. Click Reboot button to activate your changes Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats system as an illegal website. Click “Continue to this website”...
Page 71: Configure System Time
4.3.2 Configure System Time System time can be configured via this page, and manual setting or via a NTP server is supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current system time. NTP Client : To synchronize the system time with NTP server.
Page 72: Configure Snmp Setup
4.3.3 Configure SNMP Setup SNMP is an application-layer protocol that provides a message format for communication between SNMP managers and agents. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting. SNMP v2c Enable : Check to enable SNMP v2c.
Page 73 Community : Set a community string required by the remote host computer that will receive trap messages or notices send by the system. IP : Enter the IP addresses of the remote hosts to receive trap messages. Click Save button to save changes and click Reboot button to activate.
Page 74: Backup / Restore And Reset To Factory
4.3.4 Backup / Restore and Reset to Factory Backup current configuration, restore prior configuration or reset back to factory default configuration can be executed via this page. Please click on Utilities -> Profile Setting and follow the below setting. Save Settings to PC : Click Save button to save the current configuration to a local disk. Load Settings from PC : Click Browse button to locate a configuration file to restore, and then click Upload button to upload.
Page 75: Firmware Upgrade
To prevent data loss during firmware upgrade, please back up current settings before proceeding. Do not interrupt during firmware upgrade including power on/off as this may damage system. Never perform firmware upgrade over wireless connection or via remote access connection.
Page 76: Network Utility
Count : By default, it’s 5 and the range is from 1 to 50. It indicates number of connectivity test. Traceroute : Allows tracing the hops from the APO1200/APO1215 device to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host. The test is...
Page 77: Reboot
4.3.7 Reboot This function allows user to restart system with existing or most current settings when changes are made. Click Reboot button to proceed and take around three minutes to complete. A reminder will be available for remaining time to complete. If power cycle is necessary, please wait till completion of the reboot process.
Page 78: System Status
This section breaks down into subsections of System Overview, WDS Link Status, Extra Information and Event Log. 4.4.1 System Overview Detailed information on System, Network, LAN Information and Wireless Information can be reviewed via this page. System : Display the information of the system.
Page 79 Transmit bytes : The total transmitted packets in bytes of the LAN port. Transmit packets : The total transmitted packets of the LAN port. Wireless Information : Display the detailed receive and transmit statistics of Wireless interface. MAC Address : The MAC address of the Wireless port.
Page 80: Wds List
4.4.2 WDS List Peers MAC Address, antenna 0/1 received signal strength, phy mode and channel bandwidth for each WDS are available. MAC Address : Display MAC address of WDS peer. Signal Strength ANT0/ANT1 : Indicate the signal strength of the respective WDS links. Phy Mode : Indicate the phy mode of the respective WDS linked.
Page 81: Extra Information
Route table information : Select “Route table information” on the drop-down list to display route table. APO1200/APO1215 could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces.
Page 82 Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table.
Page 83: Event Log
4.4.4 Event Log The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system. Time : The date and time when the event occurred. Facility : It helps users to identify source of events such “System”...
Page 84: Chapter 5. Cpe Mode Configuration
APO1200/APO1215 is a gateway enabled with NAT and DHCP Server functions. The wired clients connected to APO1200/APO1215 are in different subnet from those connected to Main Base Station, and, in CPE mode, it does not accept wireless association from wireless clients.
Page 85: Configure Wan Setup
IP Gateway : The default gateway of the WAN port; default Gateway is 192.168.1.1 Dynamic IP : Please consult with WISP for correct wireless settings to associate with WISP AP before a dynamic IP, along with related IP settings including DNS can be available from DHCP server. If IP Address is not assigned, please double check with your wireless settings and ensure successful association.
Page 86 User Name : Enter User Name for PPPoE connection Password : Enter Password for PPPoE connection Reconnect Mode : • Always on – A connection to Internet is always maintained. • On Demand – A connection to Internet is made as needed. When Time Server is enabled at the “On Demand”...
Page 87 When Time Server is enabled at the “On Demand” mode, the “Reconnect Mode” will turn out “Always on”. • Manual – Click the “Connect” button on “WAN Information” in the Overview page to connect to the Internet. Idle Time : Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes.
Page 88: Configure Ddns Setup
5.1.3 Configure DDNS Setup Dynamic DNS allows you to map domain name to dynamic IP address. Please click on System -> DDNS Setup and follow the below setting. Enabled: By default, it’s “Disable”. The mapping domain name won’t change when dynamic IP changes. The beauty of it is no need to remember the dynamic WAP IP while accessing to it.
Page 89: Configure Lan Setup
5.1.4 Configure LAN Setup Here are the instructions for how to setup the local IP Address and Netmask. Please click on System -> LAN and follow the below setting. LAN IP : The administrator can manually setup the LAN IP address. IP Address : The IP address of the LAN port;...
Page 90: Access Point Association
Country : Select the desired country code from the drop-down list; the options are US, ETSI, JP and NONE. Tx Power : You can adjust the output power of the system to get the appropriate coverage for your wireless network.
Page 91 MCS : This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to Appendix C. MCS Data Rate) MPDU Enable : Check Enable button to activate this function, and Disable to deactivate. A-MPDU : A-MPDU (Aggregated Mac Protocol Data Unit) allows the transmissions of multiple Ethernet frames to a single location as burst of up to 64kbytes This is performed on the hardware itself.
Page 92: Configure Wireless Advanced Setting
RTS Threshold : RTS Threshold is in the range of 1~2347 byte. The default is 2347 byte. The main purpose of enabling RTS by changing RTS threshold is to reduce possible collisions due to hidden wireless clients. RTS in AP will be enabled automatically if the packet size is larger than the Threshold value. By default, RTS is disabled in a normal environment supports non-jumbo frames.
Page 93: Site Survey
Use this tool to scan and locate WISP Access Points and select one to associate with. Please click on Wireless -> Site Survey. Below depicts an example for site survey. ESSID : Available Extend Service Set ID of surrounding Access Points.
Page 94: Create Wireless Profile
The administrator can configure station profiles via this page. Please click on Wireless -> Wireless Profile and follow the below setting. MAC Address : The MAC address of the Wireless Station is displayed here. Profile Name : Set different profiles for quick connection uses.
Page 95 Click “Delete” to remove profile. Click and Select a profile from list, then click the “Connect” button to connecting to the wireless network with the profile setting. After clicking “Connect” button, you can verify connecting status on Station Statistic Page...
Page 96: System Management
5.3 System Management 5.3.1 Configure Management Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods. Please click System -> Management and follow the below settings. System Information System Name : Enter a desired name or use the default one.
Page 97 RSA key. Ping Watchdog : The ping watchdog sets the APO1200/APO1215 Device to continuously ping a user defined IP address (it can be the internet gateway for example). If it is unable to ping under the user defined constraints, the APO1200/APO1215 device will automatically reboot.
Page 98 Click Save button to save your changes. Click Reboot button to activate your changes Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats system as an illegal website. Click “Continue to this website”...
Page 99: Configure System Time
5.3.2 Configure System Time System time can be configured via this page, and manual setting or via a NTP server is supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current system time. NTP Client : To synchronize the system time with NTP server.
Page 100: Configure Upnp
Click Save button to save changes and click Reboot button to activate changes For UPnP to work in Windows XP, the “APO1200/APO1215” must be available in “My Network Places”. If these devices are not available, you should verify that the correct components and services are loaded in Windows XP.
Page 101: Configure Snmp Setup
5.3.4 Configure SNMP Setup SNMP is an application-layer protocol that provides a message format for communication between SNMP managers and agents. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting. SNMP v2c Enable: Check to enable SNMP v2c.
Page 102 Community : Set a community string required by the remote host computer that will receive trap messages or notices send by the system. IP : Enter the IP addresses of the remote hosts to receive trap messages. Click Save button to save changes and click Reboot button to activate.
Page 103: Backup / Restore And Reset To Factory
5.3.5 Backup / Restore and Reset to Factory Backup current configuration, restore prior configuration or reset back to factory default configuration can be executed via this page. Please click on Utilities -> Profile Setting and follow the below setting. Save Settings to PC : Click Save button to save the current configuration to a local disk. Load Settings from PC : Click Browse button to locate a configuration file to restore, and then click Upload button to upload.
Page 104: Firmware Upgrade
To prevent data loss during firmware upgrade, please back up current settings before proceeding. Do not interrupt during firmware upgrade including power on/off as this may damage system. Never perform firmware upgrade over wireless connection or via remote access connection.
Page 105: Network Utility
Count : By default, it’s 5 and the range is from 1 to 50. It indicates number of connectivity test. Traceroute : Allows tracing the hops from the APO1200/APO1215 device to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host.
Page 106: Reboot
5.3.8 Reboot This function allows user to restart system with existing or most current settings when changes are made. Click Reboot button to proceed and take around three minutes to complete. A reminder will be available for remaining time to complete. If power cycle is necessary, please wait till completion of the reboot process.
Page 107: Access Control List
Allows to create deny or allow rules to filter ingress or egress packets from specific source and/or to destination IP address on wired (LAN) or Wireless (WAN) ports. Filter rules could be used to filter unicast or multicast packets on different protocols as shown in the IP Filter Setup.
Page 108 Example 1 : Create a higher priority rule to allow IP address 192.168.2.2 Telnet access from LAN port first, and deny Telnet access from remaining IP addresses in the same subnet. Source Rule IP/Mask Port 192.168.2.2/32 192.168.2.254/32 192.168.2.0/24 192.168.2.254/32 Example 2 : All Telnet access to the system from the IP addresses of subnet 192.168.2.x works with the rule 1 of Example 2.
Page 109: Mac Filter Setup
MAC Filter List. There are a maximum of 20 clients allowed in this MAC Filter List. The MAC addresses of the wireless clients can be added and removed to the list using the Add and Delete buttons.
Page 110: Parental Control Setup
IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254. Protocol : Select Any or specify protocol(TCP, UDP, ICMP, URL Blocking and Application) from drop-down list. When you select ICMP or Layer 7 Application , the Local(LAN)/ Destination Port can not used. APO1200...
Page 111 If you want to block websites with specific URL address or using specific keywords, enter each URL or keywords in the “URL Blocking” field and click “Add” button to add in the URL Blocking list of each rule. Click “Remove” button can remove URL or keywords.
Page 112: Qos Setup
For example, you can configure a classifier to select traffic from the same protocol port (such as FTP) to form a flow. APO1200 APO1200 Please click on Advance -> QoS and follow the below setting.
Page 113 Rules : Use the rules to define the classifiers. After you define the rules, you can specify action to act upon the traffic that matches the rules Comment : Enter a descriptive name for this rule for identifying purposes. MAC Address : Enter MAC address in valid MAC address format(xx:xx:xx:xx:xx:xx) and click “Add” button to add in the MAC group of each rule.
Page 114 DROP Precedence Low Drop Medium Drop High Drop Protocol : Select Any or specify protocol(TCP, UDP, ICMP, Application) from drop-down list. When you select ICMP or Layer 7 Application, the Local/ Destination Port can not used. Local Port : Specify local port(LAN port) range required for this rule Destination Port : Specify destination port range required for this rule Action : After configuring rule, a policy rule ensures that a traffic flow gets the requested treatment in the network.
Page 115: Resource Sharing
DMZ : By default, it’s “Disable”. Check Enable radial button to enable DMZ. IP Address : Enter IP address of DMZ host and only one DMZ host is supported. Click Save button to save your changes. Click Reboot button to activate your changes. APO1200...
Page 116: Virtual Server (Port Forwarding)
Example : Public Port is 11 to 20 and the Private Port can be a 10 ports range. Click “Add” button to add Virtual Server rule to List. Total of maximum 20 rules are allowed in this List. All rules can be edited or removed from the List. Click Reboot button to activate your changes. APO1200...
Page 117 While creating multiple Virtual Server rules, the prior rules have higher priority. The Virtual server rules have precedence over the DMZ one while both rules exist. Example 1 and 2 demonstrate proper usage of DMZ and Virtual Server rules. Example 1 : All connections should be redirected to 192.168.2.12 while DMZ is enabled. Since Virtual Server rules have precedence over the DMZ rule all connections to TCP port 22 will be directed to TCP port 22 of 192.168.2.10 and remaining connections to port TCP 20~80 will be redirected to port TCP 20~80 of 192.168.2.11 DMZ Enabled : 192.168.2.12...
Page 118: System Status
5.6 System Status This section breaks down into subsections of System Overview, Station Statistics, Extra Information and Event Log. 5.6.1 Overview Detailed information on System, WAN Information, LAN Information and DHCP Server Status can be reviewed via this page. System : Display the information of the system. System Name : The name of the system.
Page 119 The WAN port specified PPPoE or PPTP, and the Connect and DisConnect button will be show up. Click “Connect” button to assigned IP address from PPPoE or PPTP server, “DisConnect” button to release IP address of WAN port. Mode : Supports Static, Dynamic, PPPoE and PPTP modes. Reconnect Mode : The current reconnect mode of the PPPoE or PPTP.
Page 120 IP Address : IP addresses to LAN devices by DHCP server. MAC Address : MAC addresses of LAN devices. Expired In : Shows how long the leased IP address will expire.
Page 121: Station Statistics
Link Status : Status : Shows the current link status. It should be “Connected” or “Disconnected”. ESSID : Shows the current SSID, which must be the same on the wireless client and AP in order for communication to be established.
Page 122 RTS Frames Successfully Receive CTS: The number of successful received CTS (Clear To Send) response after this APO1200/APO1215 sends out the RTS (Request To Send) message. RTS Frames Fail To Receive CTS: The number of unsuccessful received CTS response after this APO1200/APO1215 sends out the RTS message.
Page 123: Extra Info
Route table information : Select “Route table information” on the drop-down list to display route table. APO1200/APO1215 could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces.
Page 124 Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table.
Page 125: Qos Plot
5.6.4 QoS Plot The QoS Plot show graphs, which continuously represents the current data traffic on each QoS rule. The chart scale and throughput dimension (bps, Kbps, Mbps) changes dynamically according to the mean throughput value. The statistics is updated automatically every 5 seconds. The throughput statistics of QoS can be updated manually using the Refresh button.
Page 126: Event Log
5.6.5 Event Log The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system. Time : The date and time when the event occurred. Facility : It helps users to identify source of events such “System”...
Page 127: Chapter 6. Cpe + Ap Mode Configuration
WISPs deliver wireless broadband Internet service to residents and business customers. In the CPE+AP mode, APO1200/APO1215 is a gateway enabled with NAT and DHCP Server functions. The wired and wireless clients connected to APO1200/APO1215 are in different subnet from those connected to Main Base Station, and, in CPE+AP mode, it accepts wireless connections from wireless client devices.
Page 128: Configure Wan Setup
IP Gateway : The default gateway of the WAN port; default Gateway is 192.168.1.1 Dynamic IP : Please consult with WISP for correct wireless settings to associate with WISP AP before a dynamic IP, along with related IP settings including DNS can be available from DHCP server. If IP Address is not assigned, please double check with your wireless settings and ensure successful association.
Page 129 User Name : Enter User Name for PPPoE connection Password : Enter Password for PPPoE connection Reconnect Mode : • Always on – A connection to Internet is always maintained. • On Demand – A connection to Internet is made as needed. When Time Server is enabled at the “On Demand”...
Page 130 When Time Server is enabled at the “On Demand” mode, the “Reconnect Mode” will turn out “Always on”. • Manual – Click the “Connect” button on “WAN Information” in the Overview page to connect to the Internet. Idle Time : Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes.
Page 131: Configure Ddns Setup
6.1.3 Configure DDNS Setup Dynamic DNS allows you to map domain name to dynamic IP address. Please click on System -> DDNS Setup and follow the below setting. Enabled: By default, it’s “Disable”. The mapping domain name won’t change when dynamic IP changes. The beauty of it is no need to remember the dynamic WAP IP while accessing to it.
Page 132: Configure Lan Setup
6.1.4 Configure LAN Setup Here are the instructions for how to setup the local IP Address and Netmask. Please click on System -> LAN and follow the below setting. LAN IP : The administrator can manually setup the LAN IP address. IP Address : The IP address of the LAN port;...
Page 133: Access Point Association
Country : Select the desired country code from the drop-down list; the options are US, ETSI, JP and NONE. Tx Power : You can adjust the output power of the system to get the appropriate coverage for your wireless network.
Page 134 MCS : This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to Appendix C. MCS Data Rate) MPDU Enable : Check Enable button to activate this function, and Disable to deactivate. A-MPDU : A-MPDU (Aggregated Mac Protocol Data Unit) allows the transmissions of multiple Ethernet frames to a single location as burst of up to 64kbytes This is performed on the hardware itself.
Page 135: Wireless Advanced Setup
LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to re-transmit from collision because of hidden wireless clients or other causes.
Page 136 DTIM Interval : The DTIM interval is in the range of 1~255. The default is 1. DTIM is defined as Delivery Traffic Indication Message. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.
Page 137 The Channel 52-140 is DFS channel. If turns on IEEE802.11H, AP Will have check, and will not send beacon and can not be connect. When APO1200/APO1215 detect radar(5GHz) signal, the AP will switch channel and stop beacon transmit between WMM : By default, it's “Disable”.
Page 138 Voice High Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.
Page 139 When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates.
Page 140 Txop : Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM). This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.
Page 141: Site Survey
Use this tool to scan and locate WISP Access Points and select one to associate with. Please click on Wireless -> Site Survey. Below depicts an example for site survey. ESSID : Available Extend Service Set ID of surrounding Access Points.
Page 142: Create Wireless Profile
The administrator can configure station profiles via this page. Please click on Wireless -> Wireless Profile and follow the below setting. MAC Address : The MAC address of the Wireless Station is displayed here. Profile Name : Set different profiles for quick connection uses.
Page 143 Click “Delete” to remove profile. Click and Select a profile from list, then click the “Connect” button to connecting to the wireless network with the profile setting. After clicking “Connect” button, you can verify connecting status on Remote AP Page If turns on IEEE802.11H and APO1200/APO1215 connect AP with DFS channel 52-150, APO1200/APO1215...
Page 144: Wireless Lan Network Creation
Maximum Clients : The default value is 32. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5, only 5 clients at most are allowed to connect to this Repeater Security Type : Select the desired security type from the drop-down list;...
Page 145 Authentication Method : Enable the desire option among OPEN, SHARED or WEPAUTO. Key Index : key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only one is chosen. WEP Key # : Enter HEX or ASCII format WEP key value;...
Page 146 WPA General Settings : • Cipher Suite : By default, it is AES. Select either AES or TKIP cipher suites • Group Key Update Period : By default, it’s 3600 seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required. •...
Page 147 WEP 802.1X : When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete configuration. Radius Server Settings : • IP Address : Enter the IP address of the Authentication RADIUS server. • Port : By default, it’s 1812.
Page 148: Wireless Mac Filter Setup
Add a station MAC : Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “Add” button, then the MAC address should display in the “Enable” List. There are a maximum of 20 clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the Add and Remove buttons.
Page 149: System Management
6.4 System Management 6.4.1 Configure Management Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods. Please click System -> Management and follow the below settings. System Information System Name : Enter a desired name or use the default one.
Page 150 RSA key. Ping Watchdog : The ping watchdog sets the APO1200/APO1215 Device to continuously ping a user defined IP address (it can be the internet gateway for example). If it is unable to ping under the user defined constraints, the APO1200/APO1215 device will automatically reboot.
Page 151 Click Save button to save your changes. Click Reboot button to activate your changes Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats system as an illegal website. Click “Continue to this website”...
Page 152: Configure System Time
6.4.2 Configure System Time System time can be configured via this page, and manual setting or via a NTP server is supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current system time. NTP Client : To synchronize the system time with NTP server.
Page 153: Configure Upnp
Click Save button to save changes and click Reboot button to activate changes For UPnP to work in Windows XP, the “APO1200/APO1215” must be available in “My Network Places”. If these devices are not available, you should verify that the correct components and services are loaded in Windows XP.
Page 154: Configure Snmp Setup
6.4.4 Configure SNMP Setup SNMP is an application-layer protocol that provides a message format for communication between SNMP managers and agents. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting. SNMP v2c Enable: Check to enable SNMP v2c.
Page 155 Community : Set a community string required by the remote host computer that will receive trap messages or notices send by the system. IP : Enter the IP addresses of the remote hosts to receive trap messages. Click Save button to save changes and click Reboot button to activate.
Page 156: Backup / Restore And Reset To Factory
6.4.5 Backup / Restore and Reset to Factory Backup current configuration, restore prior configuration or reset back to factory default configuration can be executed via this page. Please click on Utilities -> Profile Setting and follow the below setting. Save Settings to PC : Click Save button to save the current configuration to a local disk. Load Settings from PC : Click Browse button to locate a configuration file to restore, and then click Upload button to upload.
Page 157: Firmware Upgrade
1. To prevent data loss during firmware upgrade, please back up current settings before proceeding. 2. Do not interrupt during firmware upgrade including power on/off as this may damage system. 3. Never perform firmware upgrade over wireless connection or via remote access connection.
Page 158: Network Utility
Count : By default, it’s 5 and the range is from 1 to 50. It indicates number of connectivity test. Traceroute : Allows tracing the hops from the APO1200/APO1215 device to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host.
Page 159: Reboot
6.4.8 Reboot This function allows user to restart system with existing or most current settings when changes are made. Click Reboot button to proceed and take around three minutes to complete. A reminder will be available for remaining time to complete. If power cycle is necessary, please wait till completion of the reboot process.
Page 160: Access Control List
Allows to create deny or allow rules to filter ingress or egress packets from specific source and/or to destination IP address on wired (LAN) or Wireless (WAN) ports. Filter rules could be used to filter unicast or multicast packets on different protocols as shown in the IP Filter Setup.
Page 161 Example 1 : Create a higher priority rule to allow IP address 192.168.2.2 Telnet access from LAN port first, and deny Telnet access from remaining IP addresses in the same subnet. Source Rule IP/Mask Port 192.168.2.2/32 192.168.2.254/32 192.168.2.0/24 192.168.2.254/32 Example 2 : All Telnet access to the system from the IP addresses of subnet 192.168.2.x works with the rule 1 of Example 2.
Page 162: Mac Filter Setup
MAC Filter List. There are a maximum of 20 clients allowed in this MAC Filter List. The MAC addresses of the wireless clients can be added and removed to the list using the Add and Delete buttons.
Page 163: Parental Control Setup
Local / Destination IP : Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254. APO1200...
Page 164 Protocol : Select Any or specify protocol(TCP, UDP, ICMP, URL Blocking and Application) from drop-down list. When you select ICMP or Layer 7 Application , the Local(LAN)/ Destination Port can not used. If you want to block websites with specific URL address or using specific keywords, enter each URL or keyworks in the “URL Blocking”...
Page 165: Qos Setup
For example, you can configure a classifier to select traffic from the same protocol port (such as FTP) to form a flow. APO1200 APO1200 Please click on Advance -> QoS and follow the below setting.
Page 166 Rules : Use the rules to define the classifiers. After you define the rules, you can specify action to act upon the traffic that matches the rules Comment : Enter a descriptive name for this rule for identifying purposes. MAC Address : Enter MAC address in valid MAC address format(xx:xx:xx:xx:xx:xx) and click “Add” button to add in the MAC group of each rule.
Page 167 DROP Precedence Low Drop Medium Drop High Drop Protocol : Select Any or specify protocol from drop-down list. When you select ICMP or Layer 7 Application , the Source/ Destination Port can not used. Local Port : Specify local port(LAN port) range required for this rule Destination Port : Specify destination port range required for this rule Action : After configuring rule, a policy rule ensures that a traffic flow gets the requested treatment in the network.
Page 168: Resource Sharing
DMZ : By default, it’s “Disable”. Check Enable radial button to enable DMZ. IP Address : Enter IP address of DMZ host and only one DMZ host is supported. Click Save button to save your changes. Click Reboot button to activate your changes. APO1200...
Page 169: Virtual Server (Port Forwarding)
Public Port : A port or a range of ports may be specified as start:end; i.e. port 20:80 The Private Port and Public Port can be different. However, total number of ports need to be the same. Example : Public Port is 11 to 20 and the Private Port can be a 10 ports range. APO1200...
Page 170 Click “Add” button to add Virtual Server rule to List. Total of maximum 20 rules are allowed in this List. All rules can be edited or removed from the List. Click Reboot button to activate your changes. While creating multiple Virtual Server rules, the prior rules have higher priority. The Virtual server rules have precedence over the DMZ one while both rules exist.
Page 171: System Status
This section breaks down into subsections of System Overview, Associated Clients Status, Remote AP, Extra Information and Event Log. 6.7.1 Overview Detailed information on System, WAN Information, LAN Information, Wireless Information and DHCP Server Status can be reviewed via this page. System : Display the information of the system.
Page 172 The WAN port specified PPPoE or PPTP, and the Connect and DisConnect button will be show up. Click “Connect” button to assigned IP address from PPPoE or PPTP server, “DisConnect” button to release IP address of WAN port. Mode : Supports Static, Dynamic, PPPoE and PPTP modes. Reconnect Mode : The current reconnect mode of the PPPoE or PPTP.
Page 173 Wireless Information : Display the detailed receive and transmit statistics of Wireless interface. AP MAC Address : The MAC address of the Repeater AP. Station MAC Address : The MAC address of the Wireless Client Station. Channel : The current channel on the Wireless port.
Page 174: Associated Clients Status
6.7.2 Associated Clients Status It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with Repeater AP. AP Information : Highlights key Repeater AP information. AP : Available Repeater AP. ESSID : Display name of ESSID for Repeater AP.
Page 175: Remote Ap
SSID, MAC address, antenna 0/1 received signal strength and channel bandwidth for associated AP are available. ESSID : Shows the current ESSID, which must be the same on the wireless client and AP in order for communication to be established.
Page 176: Extra Info
Route table information : Select “Route table information” on the drop-down list to display route table. APO1200/APO1215 could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces.
Page 177 Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table.
Page 178: Qos Plot
6.7.5 QoS Plot The QoS Plot show graphs which continuously represents the current data traffic on each QoS rule. The chart scale and throughput dimension (bps, Kbps, Mbps) changes dynamically according to the mean throughput value. The statistics is updated automatically every 5 seconds. The throughput statistics of QoS can be updated manually using the Refresh button.
Page 179: Event Log
6.7.6 Event Log The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system. Time : The date and time when the event occurred. Facility : It helps users to identify source of events such “System”...
Page 180: Chapter 7. Client Bridge + Universal Repeater Configuration
General and Advanced Setup also used simultaneously. But the Security Type can be different. In the other word, the channel or other settings will be the same between APO1200/APO1215 to Main Base Station and wireless client to APO1200/APO1215, but security type can be different.
Page 181: Configure Lan Ip
IP Gateway : The default gateway of the LAN port; default Gateway is 192.168.2.1 Dynamic IP : This configuration type is applicable when the APO1200/APO1215 is connected to a network with the presence of a DHCP server; all related IP information will be provided by the DHCP server automatically.
Page 182 DHCP : Check Enable button to activate this function or Disable to deactivate this service. Start IP / End IP: Specify the range of IP addresses to be used by the DHCP server when assigning IP address to clients. The default range IP address is 192.168.2.10 to 192.168.2.70, the netmask is 255.255.255.0 DNS1 IP : Enter IP address of the first DNS server;...
Page 183: Access Point Association
Country : Select the desired country code from the drop-down list; the options are US, ETSI, JP and NONE. Tx Power : You can adjust the output power of the system to get the appropriate coverage for your wireless network.
Page 184 MCS : This parameter represents transmission rate. By default (Auto) the fastest possible transmission rate will be selected. You have the option of selecting the speed if necessary. (Refer to Appendix C. MCS Data Rate) MPDU Enable : Check Enable button to activate this function, and Disable to deactivate. A-MPDU : A-MPDU (Aggregated Mac Protocol Data Unit) allows the transmissions of multiple Ethernet frames to a single location as burst of up to 64kbytes This is performed on the hardware itself.
Page 185: Wireless Advanced Setup
LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to re-transmit from collision because of hidden wireless clients or other causes.
Page 186 DTIM Interval : The DTIM interval is in the range of 1~255. The default is 1. DTIM is defined as Delivery Traffic Indication Message. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.
Page 187 The Channel 52-140 is DFS channel. If turns on IEEE802.11H, AP Will have check, and will not send beacon and can not be connect. When APO1200/APO1215 detect radar(5GHz) signal, the AP will switch channel and stop beacon transmit between WMM : By default, it's “Disable”.
Page 188 Voice High Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.
Page 189 When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates.
Page 190 Txop : Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM). This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.
Page 191: Site Survey
Use this tool to scan and locate WISP Access Points and select one to associate with. Please click on Wireless -> Site Survey. Below depicts an example for site survey. ESSID : Available Extend Service Set ID of surrounding Access Points.
Page 192: Create Wireless Profile
The administrator can configure station profiles via this page. Please click on Wireless -> Wireless Profile and follow the below setting. MAC Address : The MAC address of the Wireless Station is displayed here. Profile Name : Set different profiles for quick connection uses.
Page 193 Click “Delete” to remove profile. Click and Select a profile from list, then click the “Connect” button to connecting to the wireless network with the profile setting. After clicking “Connect” button, you can verify connecting status on Remote AP Page If turns on IEEE802.11H and APO1200/APO1215 connect AP with DFS channel 52-150, APO1200/APO1215...
Page 194: Wireless Lan Network Creation
Maximum Clients : The default value is 32. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5, only 5 clients at most are allowed to connect to this Repeater Security Type : Select the desired security type from the drop-down list;...
Page 195 Authentication Method : Enable the desire option among OPEN, SHARED or WEPAUTO. Key Index : key index is used to designate the WEP key during data transmission. 4 different WEP keys can be entered at the same time, but only one is chosen. WEP Key # : Enter HEX or ASCII format WEP key value;...
Page 196 WPA General Settings : • Cipher Suite : By default, it is AES. Select either AES or TKIP cipher suites • Group Key Update Period : By default, it’s 3600 seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds. Entering the time-length is required. •...
Page 197 WEP 802.1X : When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete configuration. Radius Server Settings : • IP Address : Enter the IP address of the Authentication RADIUS server. • Port : By default, it’s 1812.
Page 198: Wireless Mac Filter Setup
Add a station MAC : Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “Add” button, then the MAC address should display in the “Enable” List. There are a maximum of 20 clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the Add and Remove buttons.
Page 199: System Management
7.4 System Management 7.4.1 Configure Management Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods. Please click System -> Management and follow the below settings. System Information System Name : Enter a desired name or use the default one.
Page 200 RSA key. Ping Watchdog : The ping watchdog sets the APO1200/APO1215 Device to continuously ping a user defined IP address (it can be the internet gateway for example). If it is unable to ping under the user defined constraints, the APO1200/APO1215 device will automatically reboot.
Page 201 Click Save button to save your changes. Click Reboot button to activate your changes Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats system as an illegal website. Click “Continue to this website”...
Page 202: Configure System Time
7.4.2 Configure System Time System time can be configured via this page, and manual setting or via a NTP server is supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current system time. NTP Client : To synchronize the system time with NTP server.
Page 203: Configure Snmp Setup
7.4.3 Configure SNMP Setup SNMP is an application-layer protocol that provides a message format for communication between SNMP manager and agent. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting. SNMP v2c Enable: Check to enable SNMP v2c.
Page 204 Community : Set a community string required by the remote host computer that will receive trap messages or notices send by the system. IP : Enter the IP addresses of the remote hosts to receive trap messages. Click Save button to save changes and click Reboot button to activate.
Page 205: Backup / Restore And Reset To Factory
7.4.4 Backup / Restore and Reset to Factory Backup current configuration, restore prior configuration or reset back to factory default configuration can be executed via this page. Please click on Utilities -> Profile Setting and follow the below setting. Save Settings To PC : Click Save button to save the current configuration to a local disk. Load Settings from PC : Click Browse button to locate a configuration file to restore, and then click Upload button to upload.
Page 206: Firmware Upgrade
To prevent data loss during firmware upgrade, please back up current settings before proceeding Do not interrupt during firmware upgrade including power on/off as this may damage system. Never perform firmware upgrade over wireless connection or via remote access connection.
Page 207: Network Utility
Count : By default, it’s 5 and the range is from 1 to 50. It indicates number of connectivity test. Traceroute : Allows tracing the hops from the APO1200/APO1215 device to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host. The test is...
Page 208: Reboot
7.4.7 Reboot This function allows user to restart system with existing or most current settings when changes are made. Click Reboot button to proceed and take around three minutes to complete. A reminder will be available for remaining time to complete. If power cycle is necessary, please wait till completion of the reboot process.
Page 209: System Status
This section breaks down into subsections of System Overview, Associated Clients Status, Remote AP, Extra Information and Event Log. 7.5.1 System Overview Display detailed information of System, Network, LAN and Wireless in the System Overview page. System : Display the information of the system. System Name : The name of the system.
Page 210 Transmit bytes : The total transmitted packets in bytes of the LAN port. Transmit packets : The total transmitted packets of the LAN port. Wireless Information : Display the detailed receive and transmit statistics of Wireless interface. AP MAC Address : The MAC address of the repeater AP.
Page 211 DHCP Server Status : Users could retrieve DHCP server and DHCP clients’ IP/MAC address via this field. IP Address : IP addresses to LAN devices by DHCP server. MAC Address : MAC addresses of LAN devices. Expired In : Shows how long the leased IP address will expire.
Page 212: Associated Clients Status
7.5.2 Associated Clients Status It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with Repeater AP. AP Information : Highlights key Repeater AP information. AP : Available Repeater AP. ESSID : Display name of ESSID for Repeater AP.
Page 213: Remote Ap
SSID, MAC address, antenna 0/1 received signal strength and channel bandwidth for associated AP are available. ESSID : Shows the current ESSID, which must be the same on the wireless client and AP in order for communication to be established.
Page 214: Extra Information
Route table information : Select “Route table information” on the drop-down list to display route table. APO1200/APO1215 could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces.
Page 215 pruned from the table. In that situation, switching packet to that particular MAC address will be discontinued. Bridge STP Information : Select “Bridge STP Information” on the drop-down list to display a list of bridge STP information.
Page 216: Event Log
7.5.5 Event Log The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system. Time : The date and time when the event occurred. Facility : It helps users to identify source of events such “System”...
Page 217: Chapter 8. Router Ap Mode Configuration
8.1.1 Network Requirement It can be used as an Router AP with WDS function. In this mode, APO1200/APO1215 is a gateway enabled with NAT and DHCP Server functions. The wireless clients connected to APO1200/APO1215 are in different subnet from those connected to Internet.
Page 218: Configure Wan Setup
IP Gateway : The default gateway of the WAN port; default Gateway is 192.168.1.1 Dynamic IP : Please consult with WISP for correct wireless settings to associate with WISP AP before a dynamic IP, along with related IP settings including DNS can be available from DHCP server. If IP Address is not assigned, please double check with your wireless settings and ensure successful association.
Page 219 User Name : Enter User Name for PPPoE connection Password : Enter Password for PPPoE connection Reconnect Mode : • Always on – A connection to Internet is always maintained. • On Demand – A connection to Internet is made as needed. When Time Server is enabled at the “On Demand”...
Page 220 When Time Server is enabled at the “On Demand” mode, the “Reconnect Mode” will turn out “Always on”. • Manual – Click the “Connect” button on “WAN Information” in the Overview page to connect to the Internet. Idle Time : Time to last before disconnecting PPPoE session when it is idle. Enter preferred Idle Time in minutes.
Page 221: Configure Ddns Setup
8.1.3 Configure DDNS Setup Dynamic DNS allows you to map domain name to dynamic IP address. Please click on System -> DDNS Setup and follow the below setting. Enabled: By default, it’s “Disable”. The mapping domain name won’t change when dynamic IP changes. The beauty of it is no need to remember the dynamic WAP IP while accessing to it.
Page 222: Configure Lan Setup
8.1.4 Configure LAN Setup Here are the instructions for how to setup the local IP Address and Netmask. Please click on System -> LAN and follow the below setting. LAN IP : The administrator can manually setup the LAN IP address. IP Address : The IP address of the LAN port;...
Page 223: Wireless Lan Network Creation
36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108, 112, 116, 120, 124, 128, 132, 136, 140, 149, 153, 157, 161 Tx Power : You can adjust the output power of the system to get the appropriate coverage for your wireless network.
Page 224 HT TxStream/RxStream : By default, it's 2. Operating Mode : By default, it's Mixed Mode. Mixed Mode : In this mode packets are transmitted with a preamble compatible with the legacy 802.11a/g, the rest of the packet has a new format. In this mode the receiver shall be able to decode both the Mixed Mode packets and legacy packets.
Page 225: Wireless Advanced Setup
LAN. For a sender and receiver own right of the channel the shorter slot time help manage shorter wait time to re-transmit from collision because of hidden wireless clients or other causes.
Page 226 DTIM Interval : The DTIM interval is in the range of 1~255. The default is 1. DTIM is defined as Delivery Traffic Indication Message. It is used to notify the wireless stations, which support power saving mode, when to wake up to receive multicast frame. DTIM is necessary and critical in wireless environment as a mechanism to fulfill power-saving synchronization.
Page 227 The Channel 52-140 is DFS channel. If turn on IEEE802.11H, AP Will have check, and will not send beacon and can not be connect. When APO1200/APO1215 detect radar(5GHz) signal, the AP will switch channel and stop beacon transmit between WMM : By default, it's “Disable”.
Page 228 Voice High Configuring QoS options consists of setting parameters on existing queues for different types of wireless traffic. You can configure different minimum and maximum wait times for the transmission of packets in each queue based on the requirements of the media being sent. Queues automatically provide minimum transmission delay for Voice, Video, multimedia, and mission critical applications, and rely on best-effort parameters for traditional IP data.
Page 229 When the no acknowledgment (No ACK) policy is used, the recipient does not acknowledge received packets during wireless packet exchange. This policy is suitable in the environment where communication quality is fine and interference is weak. While the No ACK policy helps improve transmission efficiency, it can cause increased packet loss when communication quality deteriorates.
Page 230 Txop : Transmission Opportunity is an interval of time when a WME AP has the right to initiate transmissions onto the wireless medium (WM). This value specifies (in milliseconds) the Transmission Opportunity (Txop) for AP; that is, the interval of time when the WMM AP has the right to initiate transmissions on the wireless network.
Page 231: Create Virtual Ap (Vap)
8.2.3 Create Virtual AP (VAP) The APO1200/APO1215 support broadcasting multiple SSIDs, allowing the creation of Virtual Access Points, partitioning a single physical access point into settings. Figure 8-2 shows multiple SSIDs with security type settings. Figure 8-2 Multiple SSIDs with different Security Type 8.2.3.1 Virtual AP Overview...
Page 232: Virtual Ap Setup
Maximum Clients : The default value is 32. You can enter the number of wireless clients that can associate to a particular SSID. When the number of client is set to 5, only 5 clients at most are allowed to connect to this VAP.
Page 233 In this mode, the system does not support VLAN Tag(ID) function. Security Type : Select the desired security type from the drop-down list; the options are Disable, WEP, WPA-PSK, WPA2-PSK, WPA-Enterprise, WPA2-Enterprise and WEP 802.1X. Disable : Data are unencrypted during transmission when this option is selected. WEP : Wired Equivalent Privacy(WEP) is a data encryption mechanism based on a 64-bit or 128-bit shared key.
Page 234 WPA-Enterprise (or WPA2-Enterprise): The RADIUS authentication and encryption will be both enabled if this is selected. WPA General Settings : • Cipher Suite : By default, it is AES. Select either AES or TKIP cipher suites • Group Key Update Period : By default, it’s 3600 seconds. This time interval for rekeying GTK, broadcast/multicast encryption keys, in seconds.
Page 235 WEP 802.1X : When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP and RADIUS settings to complete configuration. Radius Server Settings : • IP Address : Enter the IP address of the Authentication RADIUS server. • Port : By default, it’s 1812.
Page 236: Wireless Mac Filter Setup
Add a station MAC : Enter MAC address (e.g. aa:bb:cc:00:00:0a) and click “Add” button, then the MAC address should display in the “Enable” List. There are a maximum of 20 clients allowed in this “Enable” List. The MAC addresses of the wireless clients can be added and removed to the list using the Add and Remove buttons.
Page 237: Wireless Network Expansion
The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links. A WDS link is bidirectional and both side must support WDS. Access points know each other by MAC Address. In other words, each access point needs to include MAC address of its peer.
Page 238: System Management
8.4 System Management 8.4.1 Configure Management Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods. Please click System -> Management and follow the below settings. System Information System Name : Enter a desired name or use the default one.
Page 239 RSA key. Ping Watchdog : The ping watchdog sets the APO1200/APO1215 Device to continuously ping a user defined IP address (it can be the internet gateway for example). If it is unable to ping under the user defined constraints, the APO1200/APO1215 device will automatically reboot.
Page 240 Click Save button to save your changes. Click Reboot button to activate your changes Without a valid certificate, users may encounter the following problem in IE7 when they try to access system's WMI (https://192.168.2.254). There will be a “Certificate Error”, because the browser treats system as an illegal website. Click “Continue to this website”...
Page 241: Configure System Time
8.4.2 Configure System Time System time can be configured via this page, and manual setting or via a NTP server is supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current system time. NTP Client : To synchronize the system time with NTP server.
Page 242: Configure Upnp
Click Save button to save changes and click Reboot button to activate changes For UPnP to work in Windows XP, the “APO1200/APO1215” must be available in “My Network Places”. If these devices are not available, you should verify that the correct components and services are loaded in Windows XP.
Page 243: Configure Snmp Setup
8.4.4 Configure SNMP Setup SNMP is an application-layer protocol that provides a message format for communication between SNMP managers and agents. By enabling SNMP function, the administrator can obtain the system information remotely. Please click on System -> SNMP Setup and follow the below setting. SNMP v2c Enable: Check to enable SNMP v2c.
Page 244 Community : Set a community string required by the remote host computer that will receive trap messages or notices send by the system. IP : Enter the IP addresses of the remote hosts to receive trap messages. Click Save button to save changes and click Reboot button to activate.
Page 245: Backup / Restore And Reset To Factory
8.4.5 Backup / Restore and Reset to Factory Backup current configuration, restore prior configuration or reset back to factory default configuration can be executed via this page. Please click on Utilities -> Profile Setting and follow the below setting. Save Settings to PC : Click Save button to save the current configuration to a local disk. Load Settings from PC : Click Browse button to locate a configuration file to restore, and then click Upload button to upload.
Page 246: Firmware Upgrade
1. To prevent data loss during firmware upgrade, please back up current settings before proceeding. 2. Do not interrupt during firmware upgrade including power on/off as this may damage system. 3. Never perform firmware upgrade over wireless connection or via remote access connection.
Page 247: Network Utility
Count : By default, it’s 5 and the range is from 1 to 50. It indicates number of connectivity test. Traceroute : Allows tracing the hops from the APO1200/APO1215 device to a selected outgoing IP address. It should be used for the finding the route taken by ICMP packets across the network to the destination host.
Page 248: Reboot
8.4.8 Reboot This function allows user to restart system with existing or most current settings when changes are made. Click Reboot button to proceed and take around three minutes to complete. A reminder will be available for remaining time to complete. If power cycle is necessary, please wait till completion of the reboot process.
Page 249: Access Control List
Allows to create deny or allow rules to filter ingress or egress packets from specific source and/or to destination IP address on wired (LAN) or Wireless (WAN) ports. Filter rules could be used to filter unicast or multicast packets on different protocols as shown in the IP Filter Setup.
Page 250 Example 1 : Create a higher priority rule to allow IP address 192.168.2.2 Telnet access from LAN port first, and deny Telnet access from remaining IP addresses in the same subnet. Source Rule IP/Mask Port 192.168.2.2/32 192.168.2.254/32 192.168.2.0/24 192.168.2.254/32 Example 2 : All Telnet access to the system from the IP addresses of subnet 192.168.2.x works with the rule 1 of Example 2.
Page 251: Mac Filter Setup
MAC Filter List. There are a maximum of 20 clients allowed in this MAC Filter List. The MAC addresses of the wireless clients can be added and removed to the list using the Add and Delete buttons.
Page 252: Parental Control Setup
Local / Destination IP : Specify local(LAN)/ destination IP addresses range required for this rule. If you specify local IP addresses range from 192.168.1.1 to 192.168.2.254. The matches a range of local IP addresses include every single IP address from the first to the last, so the example above includes everything from 192.168.1.1 to 192.168.2.254. APO1200...
Page 253 Protocol : Select Any or specify protocol(TCP, UDP, ICMP, URL Blocking and Application) from drop-down list. When you select ICMP or Layer 7 Application , the Local(LAN)/ Destination Port can not used. If you want to block websites with specific URL address or using specific keywords, enter each URL or keywords in the “URL Blocking”...
Page 254: Qos Setup
For example, you can configure a classifier to select traffic from the same protocol port (such as FTP) to form a flow. APO1200 APO1200 Please click on Advance -> QoS and follow the below setting.
Page 255 Rules : Use the rules to define the classifiers. After you define the rules, you can specify action to act upon the traffic that matches the rules Comment : Enter a descriptive name for this rule for identifying purposes. MAC Address : Enter MAC address in valid MAC address format(xx:xx:xx:xx:xx:xx) and click “Add” button to add in the MAC group of each rule.
Page 256 DROP Precedence Low Drop Medium Drop High Drop Protocol : Select Any or specify protocol from drop-down list. When you select ICMP or Layer 7 Application , the Source/ Destination Port can not used. Local Port : Specify local port(LAN port) range required for this rule Destination Port : Specify destination port range required for this rule Action : After configuring rule, a policy rule ensures that a traffic flow gets the requested treatment in the network.
Page 257: Resource Sharing
DMZ : By default, it’s “Disable”. Check Enable radial button to enable DMZ. IP Address : Enter IP address of DMZ host and only one DMZ host is supported. Click Save button to save your changes. Click Reboot button to activate your changes. APO1200...
Page 258: Virtual Server (Port Forwarding)
Public Port : A port or a range of ports may be specified as start:end; i.e. port 20:80 The Private Port and Public Port can be different. However, total number of ports need to be the same. Example : Public Port is 11 to 20 and the Private Port can be a 10 ports range. APO1200...
Page 259 Click “Add” button to add Virtual Server rule to List. Total of maximum 20 rules are allowed in this List. All rules can be edited or removed from the List. Click Reboot button to activate your changes. While creating multiple Virtual Server rules, the prior rules have higher priority. The Virtual server rules have precedence over the DMZ one while both rules exist.
Page 260: System Status
This section breaks down into subsections of System Overview, Associated Clients Status, WDS Link Status, Extra Information and Event Log. 8.7.1 Overview Detailed information on System, WAN Information, LAN Information, Wireless Information and DHCP Server Status can be reviewed via this page. System : Display the information of the system.
Page 261 The WAN port specified PPPoE or PPTP, and the Connect and DisConnect button will be show up. Click “Connect” button to assigned IP address from PPPoE or PPTP server, “DisConnect” button to release IP address of WAN port. Mode : Supports Static, Dynamic, PPPoE and PPTP modes. Reconnect Mode : The current reconnect mode of the PPPoE or PPTP.
Page 262 Wireless Information : Display the detailed receive and transmit statistics of Wireless interface. MAC Address : The MAC address of the Wireless Port. Channel : The current channel on the Wireless port. Rate : The current Bit Rate on the Wireless port.
Page 263: Associated Clients Status
8.7.2 Associated Clients Status It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with all Virtual AP. VAP Information : Highlights key VAP information. VAP : Available VAP from Primary AP to VAP6. ESSID : Display name of ESSID for each VAP.
Page 264: Show Wds Link Status
8.7.3 Show WDS Link Status Peers MAC Address, antenna 0/1 received signal strength, phy mode and channel bandwidth for each WDS are available. MAC Address : Display MAC address of WDS peer. Signal Strength ANT0/ANT1 : Indicate the signal strength of the respective WDS links. Phy Mode : Indicate the phy mode of the respective WDS linked.
Page 265: Extra Info
Route table information : Select “Route table information” on the drop-down list to display route table. APO1200/APO1215 could be used as a L2 or L3 device. It doesn’t support dynamic routing protocols such as RIP or OSPF. Static routes to specific hosts, networks or default gateway are set up automatically according to the IP configuration of system's interfaces.
Page 266 Ageing timers will be reset when existing MAC addresses in table are learned again or added when new MAC addresses are seen from wired or wireless interfaces as well. When time runs out for a particular entry, it will be pruned from the table.
Page 267: Qos Plot
8.7.5 QoS Plot The QoS Plot show graphs which continuously represents the current data traffic on each QoS rule. The chart scale and throughput dimension (bps, Kbps, Mbps) changes dynamically according to the mean throughput value. The statistics is updated automatically every 5 seconds. The throughput statistics of QoS can be updated manually using the Refresh button.
Page 268: Event Log
8.7.6 Event Log The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system. Time : The date and time when the event occurred. Facility : It helps users to identify source of events such “System”...
Page 269: Appendix A. Windows Tcp/Ip Settings
Appendix A. Windows TCP/IP Settings Windows XP 1. Click Start -> Settings -> Control Panel, and then “Control Panel” window appears. Click on “Network Connections”, and then “Network Connections” window appears. 2. Click right on “Local Area Connection”, and select Properties.
Page 270 3. In “Local Area Connection Properties” window, select “Internet Protocol (TCP/IP)” and click on Properties button. 4. Select “Use the following IP address”, and type in IP address : 192.168.2.100 Subnet mask : 255.255.255.0...
Page 271: Appendix B. Web Gui Valid Characters
Appendix B. WEB GUI Valid Characters Table B WEB GUI Valid Characters Block Field IP Address IP Netmask IP Gateway Primary DNS Secondary DNS Hostname Manual MAC Address IP Address IP Netmask IP Gateway Hostname User name Password Idle Time Primary DNS Secondary DNS Hostname...
Page 272 HTTP/ HTTPS Port Telnet/ SSH Port RO/RW community SNMP RO/RW user RO/RW password Community Tx Power General Setup Profile Name Wireless Profile ESSID WEP Key Pre-shared Key Beacon Interval Advanced Setup Date Beacon Rate Fragment Threshold RTS Threshold Valid Characters...
Page 273 Table B WEB GUI Valid Characters (continued) Block Field ESSID Virtual AP Setup Maximum Clients VLAN ID WEP Key Group Key Update Period PMK Cache Period Pre-Shared Key Radius Server IP Radius Port Shared Secret Session Timeout WEP Key WDS Setup TKIP Key AES Key Peer's MAC Address...
Page 274: Appendix C. Mcs Data Rate
Appendix C. MCS Data Rate The table below shows the relationships between the variables that allow for the maximum data rate Table C MCS Data Rate MCS Index Modulation Long Guard Interval BPSK QPSK QPSK 16-QAM 16-QAM 64-QAM 64-QAM 64-QAM BPSK QPSK QPSK...
Page 275: Appendix D. System Manager Privileges
The root manager account is empowered with full privilege to Read & Write while the admin manager account is Read only. The following table display CPE admin account’s privileges. Main Menu Sub Menu Operating Mode System Time Server General Wireless Advanced Site Survey IP Filter MAC Filter Advance Virtual Server Parental Control Management...
Page 276: Appendix E. Enabling Upnp In Windows Xp
Appendix E. Enabling UPnP in Windows XP Open the “Add/Remove Programs” control panel, and then click on “Add/Remove Windows Components” in the sidebar. Scroll down and find “Networking Services”, highlight it, and then click Details. In the “Networking Services” window, ensure that the “Internet Gateway Device” and “UPnP User Interface” options are checked.
Page 277 Discovery Services, and choose Start from the pop-up menu. The SSDP Discovery Service will then be running and start each time you boot. After enabling UPnP and starting the SSDP Discovery Service, it may take few minutes for the “Air Force One 5” to be discovered and appear in your “My Network Places”.
Page 278: Technical Support
*Theoretical maximum wireless signal rate derived from IEEE standard 802.11 specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, mix of wireless products used, radio frequency interference (e.g., cordless telephones and microwaves) as well as network overhead lower actual data throughput rate.

This manual is also suitable for:

Apo1215

Airlink101 APO1200 User Manual

Chapter 1. System Overview

Chapter 2. Basic Installation

Chapter 3. Ap Mode Configuration

Chapter 4. Wds Mode Configuration

Chapter 5. Cpe Mode Configuration

Chapter 6. Cpe + Ap Mode Configuration

Chapter 7. Client Bridge + Universal Repeater Configuration

Chapter 8. Router Ap Mode Configuration

Appendix A. Windows Tcp/Ip Settings

Appendix B. Web Gui Valid Characters

Appendix C. Mcs Data Rate

Appendix D. System Manager Privileges

Appendix E. Enabling Upnp in Windows Xp

Technical Support

Quick Links

Related Manuals for Airlink101 APO1200

Summary of Contents for Airlink101 APO1200
