Page 26
ENGLISH Introduction Congratulations on your purchase and welcome to Philips! To fully benefi t from the support that Philips offers, register your product at www.philips. com/welcome. General description (Fig. 1) Trimming head Regular trimming side (32 mm) Precision trimming side (15 mm)
Page 27
ENGLISH - The adapter contains a transformer. Do not cut off the adapter to replace it with another plug, as this causes a hazardous situation. - This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use...
Page 28
Compliance with standards - The appliance complies with the internationally approved IEC safety regulations and can be safely used in the bath or shower. - This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fi elds. Charging Charging normally takes approx.
Page 29
ENGLISH Insert the small plug into the charging stand. Note: The small plug is easiest to insert when the charging stand is folded. Unfold the charging stand (‘click’). Put the adapter in the wall socket. Put the appliance in the charging stand. , The battery status indicator starts to fl...
Page 30
ENGLISH Trimming with comb The trimming combs allow you to trim to different lengths. Start at the highest setting to acquire practice with this appliance. See the table below for an overview of the hair length settings and the corresponding hair lengths. Setting Hair length after trimming 1 mm - 3/64 inch...
Page 31
ENGLISH Hold the appliance in the trimming position, with the trimming head pointing upwards and the shaving head pointing downwards. Slide the comb into guiding groove of the appliance (‘click’). Press the hair length setting selector and then move it from left to right or right to left to select a setting.
Page 32
ENGLISH To trim the hair, move the trimming comb through the hair slowly. Tips - Always make sure that the tips of the trimming comb points in the direction in which you move the appliance. - Make sure that the fl at part of the trimming comb is always in full contact with the skin to obtain an even hair length result.
Page 33
ENGLISH Press the trimming head on/off button to switch on the trimming head. Hold the appliance with the trimming head pointing upwards and make downward strokes with the regular side of the trimming head. Using the precision side of the trimming head The precision trimming head is only half as wide as the regular trimming head.
Page 34
If you do this, the trimming head is switched off immediately. - Your skin may need 2 or 3 weeks to get accustomed to the Philips shaving system. Wet shaving Apply some water to your skin.
Page 35
ENGLISH Press the shaving head on/off button once to switch on the shaving head. , The on/off button lights up to indicate that the shaving head is operating. Place the shaving head on the skin and move the appliance against the direction of hair growth while you press it lightly.
Page 36
ENGLISH Press the shaving head on/off button once to switch on the shaving head. , The on/off button lights up to indicate that the shaving head is operating. Place the shaving head on the skin and move the appliance against the direction of hair growth while you press it lightly.
Page 37
ENGLISH Only clean the appliance and the adapter with the cleaning brush supplied. Note: The trimming head and shaving head do not need any lubrication. Cleaning the trimming head Switch off the appliance. Pull the comb off the trimming head. Clean the trimming head under the tap.
Page 38
ENGLISH Clean the inside of the trimming head with the cleaning brush. After cleaning, put the trimming head back onto the appliance. Quick cleaning of the shaving head after wet shaving or shaving with shaving foam Cup your hand under a running tap and fi ll it with water.
Page 39
ENGLISH Pull the shaving head off the appliance. Note: The shaving head is fragile. Handle it carefully. Replace the shaving head if it is damaged. Rinse the shaving head with lukewarm water. Do not clean the shaving head with the cleaning brush, as this may cause damage.
Page 40
ENGLISH Snap the new shaving foil into the shaving head (‘click’). Cutters Pull the shaving head off the appliance. Remove the cutters. Snap the new cutters onto the appliance (‘click’). Storage You can fold the charging stand for easy travelling or storage.
Page 41
If you have trouble removing the battery, you can also take the appliance to a Philips service centre. The staff of this centre will remove the battery for you and will dispose of it in an environmentally safe way.
, Now you see a printed-circuit board. Break the battery from the printed-circuit board. Be careful, the battery strips are very sharp. Guarantee and support If you need information or support, please visit www.philips.com/support or read the separate worldwide guarantee leafl et.
