POWER
TALLY
INTERCOM / TALLY OUTPUT
CASCADE OUT
FREQUENCY RESPONSE
THD
S/N
OPERATING RANGE
OPERATING TEMP. RANGE
DIMENSIONS
Ground Terminal
When connecting this unit to any other component, make sure
that it is properly grounded by connecting this terminal to an
appropriate point. When connecting, use the socket and be sure
to use wire with a cross-sectional area of at least 1.0 mm
Dimensions
Specifications
12V 22W
2 x 15 Pin Sub female Sockets for Tally A and Tally B
CH1-8, 5 PIN XLR Female connector
Yes
550-3.6KHz, < +/-3dB
< 3%
> 50dB
Up to 200m between Base Station and Slave
5 ~ 45°C
(1U height 19" rack) W: 440mm x D: 130mm x H: 40mm
7
2
.
