Outdoor Unit For IT Cooling Application
OUTDOOR UNIT
m-MOCU-G02-050
INSTALLATION MANUAL
For safe and correct use, please read this installation manual thoroughly before installing the air-conditioner unit.
INSTALLATIONSHANDBUCH
Zum sicheren und ordnungsgemäßen Gebrauch der Klimageräte das Installationshandbuch gründlich durchlesen.
MANUEL D'INSTALLATION
Veuillez lire le manuel d'installation en entier avant d'installer ce climatiseur pour éviter tout accident et vous assurer d'une utilisation correcte.
INSTALLATIEHANDLEIDING
Voor een veilig en juist gebruik moet u deze installatiehandleiding grondig doorlezen voordat u de airconditioner installeert.
MANUAL DE INSTALACIÓN
Para un uso seguro y correcto, lea detalladamente este manual de instalación antes de montar la unidad de aire acondicionado.
MANUALE DI INSTALLAZIONE
Per un uso sicuro e corretto, leggere attentamente questo manuale di installazione prima di installare il condizionatore d'aria.
ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ ΕΓΚΑΤΑΣΤΑΣΗΣ
Για ασφάλεια και σωστή χρήση, παρακαλείστε διαβάσετε προσεχτικά αυτό το εγχειρίδιο εγκατάστασης πριν αρχίσετε την εγκατάσταση της μονάδας κλιματισμού.
MANUAL DE INSTALAÇÃO
Para segurança e utilização correctas, leia atentamente este manual de instalação antes de instalar a unidade de ar condicionado.
INSTALLATIONSMANUAL
Læs venligst denne installationsmanual grundigt, før De installerer airconditionanlægget, af hensyn til sikker og korrekt anvendelse.
INSTALLATIONSHANDBOK
Läs den här installationshandboken noga innan luftkonditioneringsenheten installeras, för säker och korrekt användning.
MONTAJ ELKİTABI
Emniyetli ve doğru biçimde nasıl kullanılacağını öğrenmek için lütfen klima cihazını monte etmeden önce bu elkitabını dikkatle okuyunuz.
PODRĘCZNIK INSTALACJI
W celu bezpiecznego i poprawnego korzystania należy przed zainstalowaniem klimatyzatora dokładnie zapoznać się z niniejszym podręcznikiem instalacji.
INSTALLASJONSHÅNDBOK
For sikker og riktig bruk, skal du lese denne installasjonshåndboken nøye før du installerer klimaanlegget.
РУКОВОДСТВО ПО УСТАНОВКЕ
Для осторожного и правильного использования прибора необходимо тщательно ознакомиться с данным руководством по установке до выполнения установки кондиционера.
For use with R410A
<ORIGINAL>
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric m-MOCU-G02-050
Summary of Contents for Mitsubishi Electric m-MOCU-G02-050
- Page 1 <ORIGINAL> Outdoor Unit For IT Cooling Application OUTDOOR UNIT m-MOCU-G02-050 For use with R410A INSTALLATION MANUAL For safe and correct use, please read this installation manual thoroughly before installing the air-conditioner unit. INSTALLATIONSHANDBUCH Zum sicheren und ordnungsgemäßen Gebrauch der Klimageräte das Installationshandbuch gründlich durchlesen.
-
Page 3: Table Of Contents
CONTENTS 1. Safety precautions ················································································ 2 1-1. General precautions....................... 2 1-2. Precautions for transporting the unit ..................3 1-3. Precautions for unit installation ....................4 1-4. Precautions for piping work....................4 1-5. Precautions for electrical wiring ..................... 5 1-6. Precautions for relocating or repairing the unit ..............5 1-7. -
Page 4: Safety Precautions
- Operating the unit with a safety device whose settings have been changed may result in bursting, fire, or explosion. - Using safety devices other than those specified by MITSUBISHI ELECTRIC HYDRONICS & IT COOLING SYSTEMS S.p.A. may result in bursting, fire, or explosion. -
Page 5: Precautions For Transporting The Unit
Do not touch the refrigerant pipes and refrigerant line components with bare hands during and immediately after operation. - The refrigerant in the pipes will be very hot or very cold, resulting in frostbite or burns. Do not touch the electrical parts with bare hands during and immediately after operation. - Doing so may result in burns. -
Page 6: Precautions For Unit Installation
1-3. Precautions for unit installation Do not install the unit where combustible gas may leak. - If combustible gas accumulates around the unit, fire or explosion may result. Do not allow children to play with the packing materials. - Suffocation or serious injury may result. Cut up the packing materials before disposal. -
Page 7: Precautions For Electrical Wiring
1-5. Precautions for electrical wiring Include some slack in the power cables. - Failure to do so may break or overheat the cables, resulting in smoke or fire. Connections must be made securely and without tension on the terminals. - Improperly connected cables may break, overheat, or cause smoke or fire. Tighten all terminal screws to the specified torque. -
Page 8: Additional Precautions
1-7. Additional precautions Do not turn off the power immediately after stopping operation. - Wait for at least five minutes after the unit has stopped before turning off the power. Failure to do so may result in drain water leakage or the mechanical failure of sensitive parts. The unit must be periodically inspected by a dealer or qualified personnel. - Page 9 Use refrigerant piping made of phosphorus deoxidized copper (copper and copper alloy seamless pipes) that meets local requirements. Pipe joints should also meet local requirements. Keep the inner and outer surfaces of the pipes clean and free of sulphur, oxides, dust/dirt, shaving particles, oils, moisture, or any other contaminants. - Contaminants on the inside of the refrigerant piping will cause the refrigerant oil to deteriorate and cause the compressor to malfunction.
-
Page 10: About The Product
IT equipment. ・This unit uses R410A refrigerant. 3. Combination of outdoor units Configuration Combination of outdoor units Single-outdoor-unit system m-MOCU-G02-050 Two-outdoor-unit system m-MOCU-G02-050 m-MOCU-G02-050 * "Twinning Kit" is required to connect combination units on site. 4. Specifications... -
Page 11: Transporting The Unit
6. Transporting the unit When lifting the unit, pass the slings through the four designated sling holes. - Improper lifting will cause the unit to topple or fall, resulting in serious injury. ・Always use two slings to lift up the unit. Each sling must be at least 8 m (26 ft) long and must be able to support the weight of the unit. -
Page 12: Installation Location
7. Installation location Do not install the unit where combustible gas may leak. - If combustible gas accumulates around the unit, fire or explosion may result. ・Provide sufficient space around the unit for effective operation, efficient air movement, and ease of access for maintenance. -
Page 13: Multiple Unit Installation
(3) When there are overhead obstacles ≥ 1000 (39-3/8) ≥ 240 (9-1/2) ≥ 45° Air outlet guide (not supplied) ≥ 50 (2) 7-2. Multiple unit installation ・When installing multiple units, make sure to take into consideration factors such as providing enough space for people to pass through, ample space between blocks of units, and sufficient space for airflow. - Page 14 (3) Combination of face-to-face and side-by-side installations When there are walls in the front and rear of the When there are two walls in an L-shape block of units Ⓐ Unit height (19-11/16) (19-11/16) h2’ Ⓐ 500 (19-11/16) L2’ Ⓐ Ⓐ...
-
Page 15: Foundation Work
8. Foundation work Install the unit in accordance with the instructions to minimize the risk of damage from earthquakes and strong winds. - Improper installation will cause the unit to topple, resulting in serious injury. The unit must be securely installed on a structure that can sustain its weight. - Failure to do so will cause the unit to fall, resulting in serious injury. - Page 16 ・In abnormally harsh environments such as cold and/or windy areas, sufficient countermeasures to guard against excessive wind and snow should be taken to ensure the unit’s correct operation. When the unit is expected to operate in cooling mode in conditions under 10°C (50°F), in snowy areas, in environments subject to strong winds or rain, install snow hoods of the following specifications (not supplied).
-
Page 17: Refrigerant Piping Work
- It may also be in violation of applicable laws. - MITSUBISHI ELECTRIC HYDRONICS & IT COOLING SYSTEMS S.p.A. cannot be held responsible for malfunctions or accidents resulting from the use of the wrong type of refrigerant. - Page 18 ・The pipe from multiple outdoor units must be installed so that oil will not accumulate in the pipe under certain conditions. Refer to the figures below for details. * Small dots in the figures indicate branching points. To indoor units Ⓐ...
-
Page 19: Pipe Selection
・If the length of the pipe between the branching point and the outdoor unit exceeds 2 m (6 ft), provide a trap within 2 m (6 ft) from the branching point. The trap must be at least 200 mm (7-7/8 in) in height. (gas pipe only) If there is no trap, oil can accumulate inside the pipe, causing a shortage of oil and may damage the compressor. -
Page 20: Twinning Kit Selection
9-3. Twinning kit selection 9-3-1. Indoor unit twinning kit Refer to the manual for the connected indoor unit. 9-3-2. Outdoor unit twinning kit Select a proper outdoor unit twinning kit (sold separately) based on the outdoor unit configuration, using the table below as a reference. - Page 21 Pipes A, A [mm (in)] Combination unit Pipe A Pipe A Pipe A Configuration Unit 1 Unit 2 Liquid Liquid Liquid ø15.88 ø28.58 Single-outdoor-unit system m-MOCU-G02-050 (ø5/8) (ø1-1/8) ø15.88* ø28.58* ø15.88 ø28.58 ø15.88 ø28.58 Two-outdoor-unit system m-MOCU-G02-050 m-MOCU-G02-050 (ø5/8) (ø1-1/8) (ø5/8) (ø1-1/8)
-
Page 22: Piping Connections And Valve Operations
9-5. Piping connections and valve operations Before heating the brazed sections, remove the gas and oil that are trapped in the pipes. - Failure to do so may generate fire, resulting in serious injury. Ventilate the room while servicing the unit. - If the refrigerant leaks, oxygen deficiency may result. - Page 23 ・Reduce the number of bending portions as much as possible, and make the bending radius as big as possible. ・Do not use any commercially available anti-oxidizing agents since they may cause pipe corrosion and degrading of the refrigerant oil. Please contact MITSUBISHI ELECTRIC HYDRONICS & IT COOLING SYSTEMS S.p.A. for more details.
-
Page 24: Air-Tightness Test
・When expanding the on-site piping, satisfy the minimum insertion depth requirement as follows. Pipe size [mm (in)] Minimum insertion depth [mm (in)] ø5 (ø1/4) or more, less than ø8 (ø3/8) 6 (1/4) ø8 (ø3/8) or more, less than ø12 (ø1/2) 7 (5/16) ø12 (ø1/2) or more, less than ø16 (ø11/16) 8 (3/8) -
Page 25: Thermal Insulation For Pipes
9-7. Thermal insulation for pipes Insulate pipes to prevent condensation. - Condensation may collect and drip from the unit onto the ceiling or floor. Insulate the liquid and gas pipes separately with polyethylene foam insulation materials. Inadequate insulation may cause condensation to drip. Pipes in the ceiling are especially vulnerable to condensation and require adequate insulation. - Page 26 9-7-2. Insulation for the section of the pipe that goes through a wall (1) Inner wall (concealed) (2) Outer wall (3) Outer wall (exposed) Ⓓ Ⓔ Ⓐ Ⓑ Ⓒ Ⓑ Ⓐ Ⓑ Ⓗ (4) Floor (waterproof) (5) Rooftop pipe shaft (6) Protecting the penetrating parts in a fire limit zone or through a parting wall Ⓓ...
-
Page 27: Evacuation Of The System
9-8. Evacuation of the system Do not purge the air using refrigerant. Use a vacuum pump to evacuate the system. - Residual gas in the refrigerant lines will cause bursting of the pipes or an explosion. Use a vacuum pump with a check valve. - If the vacuum pump oil flows back into the refrigerant lines, the refrigerant oil may deteriorate and the compressor may malfunction. -
Page 28: Additional Refrigerant Charge
Unit model Factory-charged amount [kg] m-MOCU-G02-050 11.8 The amount of refrigerant that is shown in the table below is the maximum amount to be added on site. - Page 29 <Example> Outdoor unit model: m-MOCU-G02-050 × 2 Total capacity of connected indoor units: 44 kW < Total capacity ≤ 54 kW * Refer to the pipe connection examples in section 9-4 for the pipes marked with the letters below. A: ø15.88; 40 m B: ø19.05;...
-
Page 30: Electrical Work
10. Electrical work Electrical work must be performed by qualified personnel in accordance with local regulations and the instructions provided in this manual. Only use the specified cables and dedicated circuits. - Inadequate power source capacity or improper electrical work will result in electric shock, malfunction, or fire. - Page 31 ・Be sure to use the appropriate type of overcurrent breaker. Note that generated overcurrent may include some amount of direct current. ・Select the type of breaker for an inverter circuit as an earth leakage breaker. (Mitsubishi Electric NV-S series or its equivalent) ・The earth leakage breaker should be used in combination with a local switch.
-
Page 32: Control Cable Specifications
10-3. Control cable specifications ・Transmission cable Type 2-core shielded cable CVVS, CPEVS, or MVVS Size 1.25 mm (AWG 16), or ø1.2 mm or above Length Max. 200 m (656 ft) The maximum allowable length of transmission cables via outdoor units (indoor-outdoor transmission cables) is 500 m Remarks (1640 ft). -
Page 33: Wiring Connections In The Control Box
10-5. Wiring connections in the control box Connections must be made securely and without tension on the terminals. - Improperly connected cables may break, overheat, or cause smoke or fire. 10-5-1. Threading power cable through the knockout hole ・Punch out the knockout holes at the bottom of the front panel with a hammer. Ⓐ... - Page 34 10-5-2. Fixing the cables in place Power supply terminal block Cable strap M-NET board Transmission terminal block Rubber bushing Cable strap Tie band (Supplied) Tie band (Supplied) Rubber bushing Power cable Transmission cable Unit wiring (sensor wiring) (not supplied) (not supplied) ①...
-
Page 35: Address Setting
10-5-3. Connecting the cables Control box Ⓐ Ⓒ Ⓑ Power supply terminal block (TB1) Ⓒ Connect the outdoor transmission cable. Ⓓ Ⓑ Ⓐ Ⓓ Terminal block for indoor-outdoor transmission cable L1 L2 L3 N (TB3) Terminal block with loose screws Ⓐ... -
Page 36: Test Run
11. Test run 11-1. Before a test run After the wiring work has been completed, measure the insulation resistance, and make sure that it reads at least 1 MΩ. - Failure to do so may result in electric leakage, malfunction, or fire. Turn on the power at least 12 hours before starting operation. -
Page 37: Function Setting
11-2. Function setting Make function settings by setting the dipswitches SW4, SW6, and SWP1 on the main board. Write down the switch settings on the electrical wiring diagram label on the control box front panel for future reference when the control box needs to be replaced. ・Take the following steps to make settings. -
Page 38: Inspection And Maintenance
12. Inspection and maintenance Only qualified personnel must relocate or repair the unit. Do not attempt to disassemble or alter the unit. - Failure to do so will result in refrigerant leakage, water leakage, serious injury, electric shock, or fire. ・While the unit is turned on, the compressor will remain energized even when it is stopped. -
Page 39: Rating Plate Information
13. Rating plate information Configuration Single-outdoor-unit system Unit model m-MOCU-G02-050 Refrigerant (R410A) 11.8 kg Allowable pressure (Ps) HP: 4.15 MPa, LP: 2.21 MPa Net weight 304 kg Configuration Two-outdoor-unit system Unit model m-MOCU-G02-050 m-MOCU-G02-050 Refrigerant (R410A) 11.8 kg 11.8 kg Allowable pressure (Ps) HP: 4.15 MPa, LP: 2.21 MPa... - Page 40 OUTDOOR 45°CDB) RATED CONDITION INDOOR 35 / 21 DB / WB °C OUTDOOR 35 / - Contains fluorinated greenhouse gases. MANUFACTURER: MITSUBISHI ELECTRIC HYDRONICS & IT COOLING SYSTEMS S.p.A. M11-VIA CADUTI DI CEFALONIA, 1-36061 BASSANO DEL GRAPPA (VI)-ITALY MADE IN THAILAND...
- Page 44 This product is designed and intended for use in the residential, commercial and light-industrial environment. The product at hand is based on the following EU regulations: • Low Voltage Directive 2014/35/EU • Electromagnetic Compatibility Directive 2014/30/EU • Pressure Equipment Directive 2014/68/EU •...
