  • Page 2 AVH-G210BT AVH-G110DVD DVD RDS AV RECEIVER Operation Manual Autogoods “130”...

  • Page 3: Table Of Contents

    Contents ■ Favourite menu ....38 Thank you for buying this Pioneer ■ product. Other functions ....39 Please read through these instructions ■ Appendix ......41 so you will know how to operate your model properly. After you have finished...

  • Page 4: Precaution

    Precaution Certain country and government laws may prohibit or restrict the placement and use of this product in your vehicle. Please comply with all applicable laws and regulations regarding the use, installation and operation of this product. If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used electronic products in accordance with legislation that requires proper treatment, recovery and recycling.
  • Page 5 • If you notice smoke, a strange noise or odour from this product, or any other abnormal signs on the LCD screen, turn off the power immediately and consult your dealer or the nearest authorised Pioneer Service Station. Using this product in this condition may result in permanent damage to the system.
  • Page 6 To ensure safe driving WARNING • LIGHT GREEN LEAD AT POWER CONNECTOR IS DESIGNED TO DETECT PARKED STATUS AND MUST BE CONNECTED TO THE POWER SUPPLY SIDE OF THE HANDBRAKE SWITCH. IMPROPER CONNECTION OR USE OF THIS LEAD MAY VIOLATE APPLICABLE LAW AND MAY RESULT IN SERIOUS INJURY OR DAMAGE.
  • Page 7 • To prevent data loss and damage to the storage device, never remove it from this product while data is being transferred. • Pioneer cannot guarantee compatibility with all USB mass storage devices and assumes no responsibility for any loss of data on media players, iPhone, smartphone, or other devices while using this product.

  • Page 8: Parts And Controls

    Notes on internal memory • The information will be erased by disconnecting the yellow lead from the battery (or removing the battery itself ). • Some of the settings and recorded contents will not be reset. About this manual This manual uses diagrams of actual screens to describe operations. However, the screens on some units may not match those shown in this manual depending on the model used.

  • Page 9: Basic Operation

    (HOME) Press to display the top menu screen. Press and hold to power off. To power back on, press any button. (MUTE) Press and hold to display off. USB port RESET Press to reset the microprocessor (page 8). Microphone The Bluetooth microphone is built in the grill of the product. Speak towards the microphone when you make a call.
  • Page 10 Starting up the unit Start the engine to boot up the system. The [Select Program Language] screen appears. NOTE From the second time on, the screen shown will differ depending on the previous conditions. Touch the language. Touch The top menu screen appears. Using the touch panel You can operate this product by touching the keys on the screen directly with your fingers.
  • Page 11 Returns to the previous screen. Close the screen. Operating list screens Touching an item on the list allows you to narrow down the options and proceed to the next operation. Appears when all characters are not displayed on the display area. If you touch the key, the rests are scrolled for display.

  • Page 12: Bluetooth

    Setting the time and date (page 39) Settings (page 29) and Favourite menu (page 38) Hands-free phoning (page 13) (AVH-G210BT) AV source off If you select , you can turn off almost all functions. The unit turns on by operating following functions: •...
  • Page 13 • If your device supports SSP (Secure Simple Pairing), a six-digit number appears on the display of this product. Touch [Yes] to pair the device. • is invalid when the device is already connected, during connection or disconnected. • Before connecting from the Bluetooth device, make sure that the connection of this product and other Bluetooth device is disconnected.
  • Page 14 Menu Item Description [PIN Code Input] Change the PIN code for Bluetooth connection. The default PIN code is “0000”. Touch [0] to [9] to input the pin code (up to 8 digits). Touch [Device Information] Displaying the device name and address of this product. [BT Version Info.] Displaying the Bluetooth version.
  • Page 15 Using preset dial list (page 14) Using phone book Select a contact from the phone book. Touch the desired name on the list then select the phone number. TIPS • The contacts on your phone will be automatically transferred to this product. •...
  • Page 16 Receiving a phone call Touch to answer the call. Touch to end the call. TIPS • Touch while getting a call waiting, switch to the talking person. • Touch while getting a call waiting to reject the call. Phone settings Press , then touch Menu Item...
  • Page 17 ▶Registration and connection • Mobile phone operations vary depending on the type of mobile phone. Refer to the instruction manual that came with your mobile phone for detailed instructions. • When phone book transfer does not work, disconnect your phone and then perform pairing again from your phone to this product.

  • Page 18: Av Source

    • While you are listening to songs on your Bluetooth device, refrain from operating the phone function as much as possible. If you try operating, the signal may cause noise for song playback. • When you are talking on the Bluetooth device connected to this product via Bluetooth, it may pause playback.

  • Page 19: Smartphone Connection For Av Source

    • USB The following sources can be played back or used by connecting an auxiliary device. • Bluetooth® audio* • AUX * AVH-G210BT Selecting a source Source on the AV source selection screen Press Touch the source icon. When you select , the AV source is turned off.

  • Page 20: Radio

    * AVH-G210BT Compatible smartphones Compatibility with all smartphones is not guaranteed. For details about smartphone compatibility with this product, refer to the information on our website. Connecting via Bluetooth G210BT The following sources are available when a smartphone is connected to the unit via Bluetooth.
  • Page 21 Recalls the preset channel stored to a key from memory. Stores the current broadcast frequency to a key. Displays the preset channel list. Select an item on the list ([1] to [6]) to switch to the preset channel. Selects the FM1, FM2, FM3, MW, or LW band. Performs BSM (best stations memory) function (page 20).
  • Page 22 Touch [AV Source Settings]. Touch [Radio settings]. The menu items vary according to the source. Menu Item Description [Local] Local seek tuning allows you to only tune into [Off] radio stations with sufficiently strong signals. FM: [Level1] [Level2] [Level3] [Level4] NOTE MW/LW: [Level1] [Level2] [Level4] for FM and [Level2] for MW/LW are available...

  • Page 23: Disc

    Disc Inserting and ejecting a disc You can play a normal music CD, Video-CD, or DVD-Video using the built-in drive of this product. CAUTION Do not insert anything other than a disc into the disc-loading slot. Inserting a disc Insert a disc into the disc-loading slot. The source changes and then playback will start.
  • Page 24 Selects a track from the list. Touch a track on the list to play back. Video source CAUTION For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the handbrake. Description of Video source screen Touch anywhere on the screen, the touch panel keys appear.

  • Page 25: Compressed Files

    Selects the audio output from [L+R], [Left], [Right], [Mix]. This function is available for Video-CDs and DVDs recorded with LPCM audio. Changes the viewing angle (Multi-angle). This function is available for DVDs featuring multi-angle recordings. Resumes playback (Bookmark). This function is available for DVD-Video. You can memorise one point as a Bookmark for a disc (up to five discs).
  • Page 26 Plug in the USB device/smartphone (Android device) using an appropriate cable. NOTES • This product may not achieve optimum performance with some USB storage devices. • Connection via a USB hub is not possible. CAUTION Use a USB cable (sold separately) to connect the USB device as any device connected directly to the unit will protrude out from the unit, which could be dangerous.
  • Page 27 Audio source Description of Audio source screen (Example: USB) When you touch text information, all information is displayed by scrolling only when the handbrake is applied. Sets a repeat play range for all files/the current folder/the current file. NOTE The types of repeat play range depend on the source. Plays files or does not play in random order.
  • Page 28 Touch anywhere on the screen, the touch panel keys appear. Performs frame-by-frame playback. Performs slow-motion playback. Sets a repeat play range for all files/the current folder/the current file. NOTE The types of repeat play range depend on the source. Switches the audio/subtitle language. Switches the following media file types.

  • Page 29: Aux

    Switches the following media file types. [Music]: Compressed audio files [Video]: Compressed video files [Photo]: Image files Selects a file from the list. Touch a file on the list to playback. Touching a folder on the list shows its contents. You can play a file on the list by touching it.

  • Page 30: Settings

    Switches between the video input and audio input. Settings You can adjust various settings in the main menu. Displaying the setting screen Press Touch Touch one of the following categories, then select the options. System settings (page 29) Theme settings (page 34) Audio settings (page 34) Video settings (page 36) Bluetooth settings (page 12)
  • Page 31 To set the rear view camera as the camera for Camera View mode, set [Back Camera Input] to [On] (page 30). CAUTION Pioneer recommends the use of a camera which outputs mirror reversed images, otherwise the screen image may appear reversed. • Immediately verify whether the display changes to the rear view camera image when the gearstick is moved to REVERSE (R) from another position.
  • Page 32 [Safe Mode] Menu Item Description [Safe Mode] Set the safe mode that regulate operating some functions [On] [Off] only when you stop your vehicle in a safe place and apply the handbrake. [System Language] Menu Item Description [System Language] Select the system language. NOTES •...
  • Page 33 NOTES • Do not use sharp pointed tools such as ballpoint or mechanical pens. They may damage the screen. • Do not turn off the engine while saving the adjusted position data. • This setting is available only when you stop your vehicle in a safe place and apply the handbrake. Menu Item Description [Touch panel calibration]...
  • Page 34 Menu Item Description [Dimmer Duration] Adjust the time that the dimmer is turned on or off by dragging the cursors or touching You can use this function when [Dimmer Trigger] is set to [Time]. TIPS • Each touch of moves the cursor backwards or forwards in the 15 minute width.

  • Page 35: Theme Settings

    * With some pictures, you cannot adjust [Hue] and [Colour]. NOTES • The adjustments of [Brightness], [Contrast], and [Dimmer] are stored separately when your vehicle's headlights are off (daytime) and on (nighttime). • [Brightness] and [Contrast] are switched automatically depending on the setting of [Dimmer Settings].
  • Page 36 Menu Item Description [Fader/Balance] Touch to adjust the front/rear speaker balance. Set [Front] and [Rear] to [0] when using a dual speaker system. Touch to adjust the left/right speaker balance. You can also set the value by dragging the point on the displayed table. NOTE Only the fader can be adjusted when [Rear] is selected as the speaker mode.

  • Page 37: Video Settings

    Menu Item Description [Loudness] Compensates for deficiencies in the low-frequency and [Off] [Low] [Mid] [High] high-frequency ranges at low volume. NOTE This function is not available while you make or receive a call using the hands-free function. (AVH-G210BT) Adjusting the LPF cutoff frequency value You can adjust the LPF cutoff frequency value for subwoofer.
  • Page 38 Menu Item Description [Parental] Set restrictions so that children cannot watch violent or adult-oriented scenes. You can set the parental lock level in steps as desired. Touch [0] to [9] to input a four-digit code number. Touch Registers the code number, and you can now set the level.

  • Page 39: Thank You For Buying This Pioneer Favourite Menu

    [Video Signal Setting] Menu Item Description [AUX] Select the suitable video signal setting when you connect [Auto] [PAL] [NTSC] [PAL- this product to an AUX equipment. M] [PAL-N] [SECAM] [Camera] Select the suitable video signal setting when you connect [Auto] [PAL] [NTSC] [PAL- this product to a rear view camera.

  • Page 40: Other Functions

    Other functions Setting the time and date Touch the current time on the screen. Touch to set the correct time and date. You can operate the following items: Year, month, date, hour, minute. TIPS • You can change the time display format to [12hour] or [24hour]. •...
  • Page 41 TIPS • Different settings can be stored for each video source. • When a video is viewed in wide screen mode that does not match its original aspect ratio, it may appear different. • The video image will appear coarser when viewed in [Zoom] mode. NOTE Image files can be set to either [Normal] or [Trimming] in wide screen mode.

  • Page 42: So You Will Know How To Operate Your Appendix

    → The system is performing still, slow here, contact your dealer or the nearest authorised Pioneer service facility. motion, or frame-by-frame playback with DVD-Video. – There is no sound during still, slow...
  • Page 43 If the error persists, USB storage device record the error message and contact your dealer or your nearest Pioneer service Error-02-9X/-DX centre. → Communication failed. – Turn the ignition switch OFF and back Common –...
  • Page 44 If the error message is still displayed after performing the above action, please disc contact your dealer or an authorised Pioneer Service Station. • At extremely high temperatures, a temperature cutout protects this product by switching it off automatically. Handling and care of •...
  • Page 45 • It is not possible to play DVD Audio discs. • Manufactured under license from Dolby This DVD drive may not be able to play all Laboratories. Dolby, Dolby Audio and the discs bearing the marks shown above. double-D symbol are trademarks of Dolby Laboratories.
  • Page 46 • DVD-R DL (Dual Layer) discs which have • It may not be possible to play some music been recorded with Layer Jump files from USB because of file recording cannot be played back. characteristics, file format, recorded • For detailed information about recording application, playback environment, mode, please contact the manufacturer storage conditions, and so on.
  • Page 47 • This product corresponds to a DivX file • If multiple subtitles are programmed to display of up to 1 590 minutes 43 display within a very short time frame, seconds. Search operations beyond this such as 0.1 seconds, the subtitles may not time limit are prohibited.
  • Page 48 CD-R/-RW, DVD-R/-R SL/-R DL/DVD-RW Sampling frequency: 16, 22.05, 24, 32, 44.1, 48 kHz File extension: .mp3 Bit rate: 8, 16, 24, 32, 40, 48, 56, 64, 80, 96, AAC compatibility 112, 128, 144, 160, 192, 224, 256, 320 kbps • This product plays back only LC-AAC files (CBR), VBR encoded by iTunes.
  • Page 49 Bluetooth the file. SIG, Inc. and any use of such marks by PIONEER • This product is not compatible with CORPORATION is under license. Other packet write data transfer.
  • Page 50 Notice regarding video Using the LCD screen viewing correctly Remember that use of this system for commercial or public viewing purposes Handling the LCD screen may constitute an infringement on the author’s rights as protected by the • When the LCD screen is subjected to Copyright Law.
  • Page 51 • 50 W × 4 ch/4 Ω visible. In that case, please consult your Continuous power output: dealer or the nearest authorised Pioneer 22 W × 4 (50 Hz to 15 kHz, 5 %THD, 4 Ω Service Station. LOAD, Both Channels Driven) Load impedance: 4 Ω...
  • Page 52 Equaliser (7-Band Graphic Equaliser): MPEG video decoding format: Frequency: MPEG1 (Low Level), MPEG2 (Main 50 Hz/125 Hz/315 Hz/800 Hz/2 kHz/5 Level), MPEG4 (part2) (Main Level) kHz/12.5 kHz Gain: ±12 dB (2 dB/step) USB 1.1, USB 2.0 full speed, USB 2.0 high Subwoofer/LPF: speed Frequency:...
  • Page 53 Bluetooth (AVH-G210BT) Version: Bluetooth 4.1 certified Output power: 3.0 dBm (-6 dB/+2 dB) (Power class 2) Frequency band: 2 400 MHz to 2 483.5 MHz FM tuner Frequency range: 87.5 MHz to 108 MHz Usable sensitivity: 12 dBf (1.1 μV/75 Ω, mono, S/N: 30 dB) Signal-to-noise ratio: 72 dB (IEC-A network) MW tuner...
  • Page 54 © 2018 PIONEER CORPORATION. All rights reserved. <QRI3048-A> EU Autogoods “130”...
