- Page 1 17” WOOD BANDSAW KC-1702FXR SEE PAGE 9 MODEL: KC-1702C & KC-1702FXR INSTRUCTION MANUAL COPYRIGHT © 2002 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC.
-
Page 2: Replacement Parts
IMPORTANT INFORMATION & SPECIFICATIONS 2-YEAR KING CANADA TOOLS LIMITED WARRANTY OFFERS A 2-YEAR LIMITED WARRANTY FOR THIS 17” WOOD BANDSAW FOR INDUSTRIAL USE. PROOF OF PURCHASE Please keep your dated proof of purchase for warranty and servicing purposes. REPLACEMENT PARTS Replacement parts for this tool are available at our authorized KING CANADA service centers across Canada. -
Page 3: General Safety Instructions For Power Tools
GENERAL SAFETY INSTRUCTIONS FOR POWER TOOLS 1. KNOW YOUR TOOL 12. ALWAYS WEAR SAFETY GLASSES. Read and understand the owners manual and labels affixed to Always wear safety glasses (ANSI Z87.1). Everyday the tool. Learn its application and limitations as well as its eyeglasses only have impact resistant lenses, they are NOT specific potential hazards. -
Page 4: Rear Of Band Saw
GETTING TO KNOW YOUR 17” WOOD BANDSAW FRONT OF BAND SAW UPPER DRIVE WHEEL UPPER WHEEL COVER HAND DRIVE BLADE TENSION ADJUSTMENT KNOB BLADE TENSION WINDOW UPPER BALL BEARING GUIDE SYSTEM SWITCH MITER SLOT TABLE RIP FENCE 4” DUST PORT LOWER WHEEL COVER POSITIVE KNOB... -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! ALL ELECTRICAL CONNECTIONS MUST BE DONE BY A QUALIFIED ELECTRICIAN. FAILURE TO COMPLY MAY RESULT IN SERIOUS INJURY! ALL ADJUSTMENTS OR REPAIRS MUST BE DONE WITH THE BANDSAW DISCONNECTED FROM THE POWER SOURCE. FAILURE TO COMPLY MAY RESULT IN SERIOUS INJURY! POWER SUPPLY box in Fig.B. - Page 6 ASSEMBLY & OPERATIONS MOVING YOUR BANDSAW a. Use a 2000kg. chain hoist connected to the top mounted hook (A, Fig.1) to move the Bandsaw to the desired location. b. To ensure sufficient stability and security, bolt the base of the Bandsaw to the floor using the 4 mounting holes.
-
Page 7: Changing Blades
ADJUSTMENTS & OPERATIONS CHANGING BLADES 1. Unplug power cord. 2. Remove the table insert and table pin from the table. 3. Open upper and lower wheel covers. 4. Loosen the upper and lower ball bearing blade guide systems. 5. Loosen the rod lever knob (quick change saw blade system) on rear of bandsaw. -
Page 8: Dust Collection
ADJUSTMENTS & OPERATIONS ADJUSTING THE TENSION OF THE BLADE Blade tension is set by a spring loaded tension mechanism on the upper drive wheel. The tension window allows you to see and adjust the tension of the blade, the adjustment depends on the width of the blade used. - Page 9 17” WOOD BANDSAW WITH RESAW GUIDE AND CAST IRON BLADE WHEELS INSTRUCTIONS FOR KC-1702FXR 2-YEAR LIMITED WARRANTY FOR KING INDUSTRIAL MACHINERY PROOF OF PURCHASE Please keep your dated proof of purchase for warranty and servicing purposes. REPLACEMENT PARTS Replacement parts for this improved product are available at our authorized King Canada service centers across Canada.
