This Operator's Manual is an
integral part of the safe operation
of this machine and must be
maintained with the unit at all
times. READ, UNDERSTAND, and
FOLLOW
Operation Instructions contained
in this manual before operating
the equipment. C01-Cover_R
®
RHINO
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: parts@servis-rhino.com
OPERATOR'S MANUAL
the
Safety
©2013 Alamo Group Inc.
FX17/FX21
FLEX FLAIL
Important
Operating
and Safety Instructions
are found in the Mower
Safety Video that can
and
be instantly accessed
on
the
internet
www.algqr.com/rve
Part NO. 00776900C
at:
