IMPORTANT MANUAL
OPERATOR'S MANUAL
MODEL:
PP175A42
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulanpro.com
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
115 90 91-49
Do Not Throw Away
03032
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so can
re sult in serious in ju ry.
05.18.17 BD
Printed in the U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Poulan Pro PP175A42

Summary of Contents for Poulan Pro PP175A42

  • Page 1 Read this Man u al and follow all Warnings MODEL: and Safety Instructions. Fail ure to do so can re sult in serious in ju ry. PP175A42 LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulanpro.com Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.

  • Page 2: Safety Rules

    SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Be alert and turn machine off if a child enters the area. WARNING: In order to prevent ac ci den tal •...
  • Page 3 SAFETY RULES Safe Operation Practices for Ride-On Mowers III. SLOPE OPERATION • Never remove gas cap or add fuel with the engine running. • Allow engine to cool before refueling. WARNING! When loading or unloading • Never fuel the machine indoors. this machine, do not exceed the maximum •...

  • Page 4: Table Of Contents

    PRODUCT SPECIFICATIONS CONGRATULATIONS on your purchase of a new tractor. It has been designed, engineered and manu fac tured to give you the best possible dependability and performance. Gasoline Capacity 1.5 Gallons/5,67 L and type: Regular Unleaded Should you experience any problem you cannot easily remedy, please contact your nearest authorized service Oil Type: SAE 30 (above 32°F/0°C)
  • Page 5 UNASSEMBLED PARTS Steering Wheel (1) Lock Washer Steering (1) Large Wheel Insert Flat Washer Steering Wheel (1) Hex Bolt Steering Steering Wheel Extension Adapter Steering Boot Shaft Seat (1) Washer (1) Knob (1) Seat Battery Keys Oil Drain Extension Slope Sheet (2) Hex Bolts Key(s) (2) Nut Keps...

  • Page 6: Assembly

    ASSEMBLY Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to ensure proper tightness.
  • Page 7 ASSEMBLY NOTE: You may now roll your tractor off the skid. Continue INSTALL SEAT (See Fig. 3) using the instructions that follow to remove the tractor from Adjust seat before tightening adjustment knob. the skid. • Remove adjustment knob and flat washer securing WARNING: Before start ing, read, un der stand and fol- seat to cardboard packing and set aside for assembly low all in struc tions in the Op er a tion section of this man u al.
  • Page 8 ASSEMBLY ✓ CHECKLIST BEFORE YOU OPERATE YOUR NEW TRAC TOR, WE WISH TO ENSURE THAT YOU RECEIVE THE BEST PERFORMANCE AND SATISFACTION FROM THIS QUALITY PRODUCT. PLEASE REVIEW THE FOLLOWING CHECKLIST: ✓ All assembly instructions have been com plet ed. ✓...

  • Page 9: Operation

    OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE NEUTRAL HIGH CHOKE FAST SLOW IGNITION SWITCH ENGINE ENGINE ENGINE DIFFERENTIAL CLUTCH/ PARKING MOWER MOWER START LOCK BRAKE PEDAL BRAKE HEIGHT LIFT...
  • Page 10 OPERATION KNOW YOUR TRACTOR READ THIS OPERATOR'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Fig.
  • Page 11 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any adjustments or repairs. We rec om mend a wide vision safety mask over spectacles or stan dard safety glasses.
  • Page 12 OPERATION TO ADJUST MOWER CUTTING HEIGHT TO OPERATE MOWER (See Fig. 9) Your tractor is equipped with an operator presence sensing switch. Any attempt by the operator to leave the seat with The position of the attachment lift lever (A) determines the the engine running and the attachment clutch engaged will cutting height.
  • Page 13 OPERATION WARNING: Backing up with the attachment clutch en- TOWING CARTS & OTHER AT TACH MENTS gaged while mowing is strongly discouraged. Turning the Tow only the attachments that are recommended by and ROS "ON", to allow reverse operation with the attachment comply with specifications of the manufacturer of your trac- clutch engaged, should only be done when the operator tor.
  • Page 14 OPERATION MOWING TIPS TO START ENGINE (See Fig. 3) When starting the engine for the first time or if the engine • DO NOT use tire chains when the mower hous ing is has run out of fuel, it will take extra cranking time to move attached to tractor.

  • Page 15: Maintenance Schedule

    MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE SCHEDULE EACH SEASON STORAGE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence and ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Clean Debris off Steering Plate Check Mower Levelness...

  • Page 16: Maintenance

    MAINTENANCE TRACTOR BLADE CARE For best results mower blades must be kept sharp. Re place Always observe safety rules when per form ing any bent or damaged blades. main te nance. BRAKE OPERATION CAUTION: Use only a replacement blade ap- proved by the manufacturer of your tractor.
  • Page 17 MAINTENANCE V-BELTS OIL DRAIN HOLE Check V-belts for deterioration and wear after 100 hours of operation and replace if necessary. The belts are not ad just able. Re place belts if they begin to slip from wear. OIL DRAIN PLUG TRANSAXLE MAINTENANCE OIL DRAIN EXTENSION...
  • Page 18 MAINTENANCE ENGINE COOLING SYSTEM (See Fig. 19) CLEANING Debris may clog the engine's air cooling system. Remove • Clean engine, battery, seat, finish, etc. of all foreign blower housing and clean the area shown to prevent over- matter. heating and engine damage. •...

  • Page 19: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •...
  • Page 20 SERVICE AND ADJUSTMENTS • ATTACH MOWER SIDE SUSPENSION ARMS (A) TO • Insert end of link (E) into hole in front mower bracket CHASSIS - Position hole in arm over pin (B) on outside and secure with washer and retainer spring (J). of tractor chassis and secure with retainer spring.
  • Page 21 SERVICE AND ADJUSTMENTS TO LEVEL MOWER FRONT-TO-BACK ADJUSTMENT (See Figs. 30 & 31) IMPORTANT: Deck must be level side-to-side. Ensure tires are properly inflated to the PSI shown on tires. If tires are over or under inflated, it may affect the appear- To obtain the best cutting re sults, the mower blades should ance of your lawn and lead you to think the mower is not be adjusted so the front tip is 1/8"...
  • Page 22 SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE DRIVE BELT TO REPLACE MOTION DRIVE BELT (See Fig. 32) (See Fig. 33) The mower blade drive belt may be replaced without tools. Park the tractor on level surface. En gage parking brake. For as sis tance, there is a belt installation guide decal on Park the tractor on level surface.
  • Page 23 SERVICE AND ADJUSTMENTS TO REMOVE WHEEL (See Fig. 34) TO START ENGINE WITH A WEAK BATTERY (See Fig. 35) • Block up axle securely. • Remove axle cover, retaining ring and washers to allow WARNING: Lead-acid batteries gen er ate wheel removal (rear wheel contains a square key - Do ex plo sive gases.
  • Page 24 SERVICE AND ADJUSTMENTS REPLACING BATTERY (See Fig. 36) TO REMOVE HOOD AND GRILL ASSEMBLY (See Fig. 37) WARNING: Do not short battery ter mi- • Raise hood. nals by allowing a wrench or any other • Unsnap headlight wire connector. object to contact both terminals at the •...

  • Page 25: Storage

    STORAGE ENGINE Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK...

  • Page 26: Troubleshooting

    TROUBLESHOOTING PROBLEM CAUSE CORRECTION 1. Out of fuel. 1. Fill fuel tank. Will not start 2. Engine not “CHOKED” properly. 2. See “TO START ENGINE” in Operation section. 3. Engine flooded. 3. Wait several minutes before attempting to start. 4. Bad spark plug. 4.
  • Page 27 TROUBLESHOOTING PROBLEM CAUSE CORRECTION Engine continues to 1. Faulty operator-safety presence control 1. Check wiring, switches and connections. If not system. corrected, contact an authorized service center/ run when operator department. leaves seat with attachment clutch CAUTION: DO NOT operate machine until engaged problem is corrected.
  • Page 29 SERVICE NOTES...
