REPAIR PARTS MANUAL
MODEL:
PP155A42
LAWN TRACTOR
ALWAYS WEAR EYE PROTECTION DURING OPERATION
Visit our website: www.poulanpro.com
589 88 63-01
DO NOT THROW AWAY
WARNING:
Read this Man u al and follow all Warnings
and Safety Instructions. Fail ure to do so
can re sult in serious in ju ry.
10.31.16 BD
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Poulan Pro PP155A42
Summary of Contents for Poulan Pro PP155A42
- Page 1 Read this Man u al and follow all Warnings MODEL: and Safety Instructions. Fail ure to do so can re sult in serious in ju ry. PP155A42 LAWN TRACTOR ALWAYS WEAR EYE PROTECTION DURING OPERATION Visit our website: www.poulanpro.com 10.31.16 BD 589 88 63-01 Printed in the U.S.A.
-
Page 2: Table Of Contents
The model number for your tractor can be found on the fender under the seat. When ordering parts, always give the following information: • Product - “TRACTOR” • MODEL NUMBER - “PP155A42 (274430)” • Part Number • Part Description TABLE OF CONTENTS SCHEMATIC ........................ -
Page 3: Schematic
TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 SCHEMATIC SCH11 BATTERY SOLENOID STARTER FUSE AMMETER BLACK (OPTIONAL) WHITE WHITE ATTACHMENT CLUTCH (CLUTCH OFF) BLACK CLUTCH/BRAKE GRAY (PEDAL UP) REVERSE SWITCH BLACK (NOT IN REVERSE) BLACK BLACK BLACK BLACK SEAT SWITCH... -
Page 4: Electrical
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 ELECTRICAL TR02K Service Minder (If Equipped) -
Page 5: Electrical
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 ELECTRICAL KEY PART DESCRIPTION 532 16 34-65 Battery 874 76 04-12 Bolt Hex Hd 1/4-20 unc x 3/4 532 19 32-28 Box Battery 532 17 61-38 Switch Interlock 532 00 41-52... -
Page 6: Chassis
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 CHASSIS Chassis-tex_elite basic_5_r2... -
Page 7: Chassis
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 CHASSIS KEY PART DESCRIPTION 532 41 17-64 Dash 532 18 65-80 Hood 532 42 67-92 Grille 580 91 08-01 Plate Engine 817 06 05-12 Screw 5/16-18 x 3/4 532 42 07-96... -
Page 8: Drive
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 DRIVE drive-tex_VATR_PEDAL_43... - Page 9 REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 DRIVE KEY PART KEY PART DESCRIPTION DESCRIPTION – – – – – – Transaxle, Variator SD Pedal 532 19 43-21 Spacer Retainer (587884401) (Order parts from 819 13 32-10 Washer 13/32 x 2 x 10 ga transaxle manufacturer.)
-
Page 10: Engine
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-tex_BS_128... -
Page 11: Engine
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 ENGINE KEY PART DESCRIPTION – – – – – – Engine, B&S 31R707-0001-G1 (585926001) (Order parts from engine manufacturer.) 532 13 73-52 Muffler Exhaust B&S 582 54 03-02 Keeper Belt Engine... -
Page 12: Steering
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 STEERING steering-tex_STDHRS_21... - Page 13 REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 STEERING KEY PART DESCRIPTION 532 42 45-43 Wheel, Steering 532 41 81-68 Axle Asm., Front 532 40 30-87 Spindle Asm., LH 532 40 30-88 Spindle Asm., RH 532 12 49-31 Washer Thrust 0.75 x 1.23...
-
Page 14: Mower Deck
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 MOWER DECK 42_D_man-tex_LT_55_r4... -
Page 15: Mower Deck
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 MOWER DECK KEY PART KEY PART DESCRIPTION DESCRIPTION 532 19 99-11 Mower Housing 532 43 71-10 Arm, Idler 532 19 51-86 Arm Suspension 532 19 90-92 Spacer, Retainer 532 41 63-58 Screw #10 x 0.750 BOS Thread... -
Page 16: Mower Lift
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 MOWER LIFT 101* lift-tex_37 *Key 91 may be substituted for Key 101 KEY PART KEY PART DESCRIPTION DESCRIPTION 532 42 20-27 Shaft Asm., Cross Lift 532 19 79-84 Link Lift Susp Mower Rear 532 19 52-31 Lever Asm., Lift RH... -
Page 17: Seat
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 SEAT seat-tex_knob_6 KEY PART KEY PART DESCRIPTION DESCRIPTION 532 19 75-14 Seat 532 12 39-76 Nut Lock 1/4 532 18 01-66 Bracket Pivot Fender 532 19 93-72 Knob Seat 873 80 06-00 Nut, Lock w/Ins. -
Page 18: Decals
REPAIR PARTS TRACTOR - MODEL NUMBER PP155A42 (274430), PRODUCT NO. 274430 DECALS KEY PART KEY PART DESCRIPTION DESCRIPTION 501 52 13-01 Decal, Replacement 582 67 74-01 Decal, Hood RH/LH 585 55 48-01 Decal, Engine HP 532 14 50-05 Decal, Caution, Battery 584 90 46-01 Decal, Deflect. -
Page 19: Transaxle Breakdown
TRACTOR - - MODEL NUMBER PP155A42 (274430) GENTRANS TRANSAXLE - MODEL NUMBER (RS800 SD-P) 587884401 RS800 SD-P PART PART DESCRIPTION DESCRIPTION 587291101 Inversion Security System 587291601 Cover 587086701 Driven Kit 590100301 Output Seals 587291301 Brake Kit 587884401 RS800 SD-P 587086702... -
Page 20: Engine Breakdown
TRACTOR - - MODEL NUMBER 274430 BRIGGS & STRATTON ENGINE-MODEL NUMBER 31R707, TYPE NUMBER 0001-G1 1329 REPLACEMENT ENGINE 1330 REPAIR MANUAL 1036 EMISSIONS LABLE 48 SHORT BLOCK 1058 OPERATOR’S MANUAL 121 CARBURETOR OVERHAUL KIT 1059 1051 1266 1266A 358 ENGINE GASKET SET 1090 1119 1022... - Page 21 TRACTOR - - MODEL NUMBER 274430 BRIGGS & STRATTON ENGINE-MODEL NUMBER 31R707, TYPE NUMBER 0001-G1 1023 1022 1026 1026A 1022 1034 1029 1266 1044 1127 1270 1264 1263...
- Page 22 TRACTOR - - MODEL NUMBER 274430 BRIGGS & STRATTON ENGINE-MODEL NUMBER 31R707, TYPE NUMBER 0001-G1 PART PART DESCRIPTION DESCRIPTION 695415 Jet-Main (High Altitude) 796010 Cylinder Assembly 796184 Kit-Carburetor Overhaul 797673 Bushing/Seal Kit (Magneto Side) 391086s Seal-Oil (Magneto Side) 591731 Carburetor 690727 Plug-Welch 697106...
- Page 23 TRACTOR - - MODEL NUMBER 274430 BRIGGS & STRATTON ENGINE-MODEL NUMBER 31R707, TYPE NUMBER 0001-G1 PART PART DESCRIPTION DESCRIPTION 797901 Elbow-Intake 691108 Screw (Rocker Cover) 591334 Filter-Air Cleaner Cartridge 699915 Solenoid-Fuel 691261 Washer (Starter Cable) 799159 Cap-Connector 592831 Alternator 591647 Cover-Air Cleaner 691532 Strap-Starter...
-
Page 24: Parts And Service
PARTS AND SERVICE This product has been expertly en gi neered and carefully manu fac tured to rigid quality stan dards. As with all mechanical products, some adjustments or part replacement may be necessary during the life of your unit. Support / Help If you require assistance or have questions concerning the application, operation, maintenance or parts for your product:...
