Page 1: Microwave Oven
CE107V imagine the possibilities Microwave Oven Thank you for purchasing this Samsung product. Please register your product at www.samsung.com/global/register Owner’s Instructions & Cooking Guide CE107V_XEU-03714L_EN.indd 1 2010-02-18 3:10:15... -
Page 2: Table Of Contents
contents “Quick” look-up guide ...2 Control panel ...3 Oven ...4 Accessories ...4 Using this instruction booklet ...5 Safety information ...5 Installing your microwave oven ...12 Setting the time ...13 Checking that your oven is operating correctly ...13 How a microwave oven works ...14 What to do if you are in doubt or have a problem...14 Cooking/reheating ...15 Power levels and time variations ...15... -
Page 3: Control Panel
3. Select the weight by pressing the ( ) and ( ) buttons as required. 4. Press Start ( ) button. Result: Defrosting starts. • When cooking has finished, the oven will beep and flash “0” four times. The oven will then beep one time per minute. CE107V_XEU-03714L_EN.indd 3 coNtRoL paNEL 1. -
Page 4: Oven
ovEN 1. DOOR HANDLE 7. TURNTABLE 2. VENTILATION HOLES 8. COUPLER 3. HEATING ELEMENT 9. ROLLER RING 4. VENTILATION HOLES 10. SAFETY INTERLOCK HOLES 5. DOOR LATCHES 11. CONTROL PANEL 6. DOOR CE107V_XEU-03714L_EN.indd 4 accESSoRIES Depending on the model that you have purchased, you are supplied with several accessories that can be used in a variety of ways. -
Page 5: Using This Instruction Booklet
INStRuctIoN bookLEt You have just purchased a SAMSUNG microwave oven. Your Owner’s Instructions contain much valuable information on cooking with your microwave oven: • Safety precautions • Accessories and cookware • Useful cooking tips Inside the cover you will find a quick look-up guide explaining three basic cooking operations: • Cooking (microwave mode) - Page 6 Severe warning signs for installation WARnInG The installation of this appliance must be performed by a qualified microwave service technician trained by the manufacturer. Please see the section “Installing your Microwave Oven”. Plug the power cord into the proper wall socket or higher and use the socket for this appliance only.
- Page 7 Do not pull or excessively bend the power cord. Do not twist or tie the power cord. Do not hook the power cord over a metal object, place a heavy object on the power cord, insert the power cord between objects, or push the power cord into the space behind the appliance.
- Page 8 Appliance is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. WaRNING : Accessible parts may become hot during use. To avoid burns young children should be kept away.
- Page 9 Do not immerse the power cable or plug in water and keep the power cable away from heated surfaces. Do not operate this appliance if it has a damaged power cable or plug. DO NOT operate the microwave oven when it is empty. The power will be cut off automatically for safety.
- Page 10 Do not hold food or any part there of during or immediately after cooking. - Use cooking gloves because it may be very hot and you could burn yourself. - If you pull the ceramic dish or well-being multi-purpose pan forwards, food may spill and this may result in burns.
- Page 11 Severe warning signs for cleaning WARnInG Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner or alcohol to clean the appliance. - This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, unplug the appliance from the wall socket and remove food waste from the door and cooking compartment.
-
Page 12: Installing Your Microwave Oven
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY Failure to observe the following safety precautions may result in harmful exposure to microwave energy. (a) Under no circumstances should any attempt be made to operate the oven with the door open or to tamper with the safety interlocks (door latches) or to insert anything into the safety interlock holes. -
Page 13: Setting The Time
SEttING tHE tIME Your microwave oven has an inbuilt clock. When power is supplied, “12:00” is automatically displayed on the display. Please set the current time. The time can be displayed in either the 24- hour or 12-hour notation. You must set the clock: • When you first install your microwave oven • After a power failure Do not forget to reset the clock when you switch to and from summer... -
Page 14: How A Microwave Oven Works
Please have the following information read; • The model and serial numbers, normally printed on the rear of the oven • Your warranty details • A clear description of the problem Then contact your local dealer or SAMSUNG aftersales service. 2010-02-18 3:10:23... -
Page 15: Cooking/Reheating
cookING/REHEatING The following procedure explains how to cook or reheat food. ALWAYS check your cooking settings before leaving the oven unattended. Open the door. Place the food in the centre of the turntable. Close the door. Never switch the microwave oven on when it is empty. 1. -
Page 16: Stopping The Cooking
StoppING tHE cookING You can stop cooking at any time so that you can: • Check the food • Turn the food over or stir it • Leave it to stand to stop the cooking... then... Temporarily Open the door. Result: To resume cooking, close the door again and press the Start ( ) button. - Page 17 The following table presents the various Auto Cook Programmes, quantities, standing times and appropriate recommendations. Programmes no 1 and 2 are running with microwave energy only. Programmes no 3 and 4 are running with a combination of microwaves and grill. Programme no 5 is running with a combination of microwaves and convection.
-
Page 18: Using The Auto Reheat Feature
uSING tHE auto REHEat fEatuRE The four Auto Reheat ( ) features provide four pre-programmed cooking times. You do not need to set either the cooking times or the power level. You can adjust the size of the serving by pressing the ( ) and ( ) buttons. Use only recipients that are microwave-safe. -
Page 19: Using The Power Defrost Feature
uSING tHE poWER dEfRoSt fEatuRE The Power Defrost ( ) feature enables you to defrost meat, poultry, fish, bread , cake and fruit. The defrost time and power level are set automatically. You simply select the programme and the weight. Use only containers that are microwave-safe. -
Page 20: Using The Cafeteria Feature
code food Serving Standing Size time Bread / 125-1000 g 10-60 min. Put bread horizontally on a cake Fruit 100-600 g 5-20 min. CE107V_XEU-03714L_EN.indd 20 uSING tHE cafEtERIa fEatuRE Recommendations With the Cafeteria ( ) feature, the cooking time is set automatically. First, place the food in the centre of the turntable and close the door. -
Page 21: Multistage Cooking
The following table presents Auto Programmes for Reheat of drinks and defrosting & warming frozen cake. It contains its quantities, standing times and appropriate recommendations. Programme no. 1 use the microwave only mode. Programme no. 2 uses a combination of microwaves and convection mode. code food Serving Standing... -
Page 22: Fast Preheating The Oven
7. Press the Grill ( ) button. 8. Set the cooking time by pressing the ( ) and ( ) buttons (15 minutes in the example). 9. Press Start ( ) button. Result: Cooking starts: • When cooking has finished, the oven will beep and flash “0”... -
Page 23: Cooking By Convection
cookING by coNvEctIoN The convection mode enables you to cook food in the same way as in a traditional oven. The microwave mode is not used. You can set the temperature, as required, in a range varying from 40 °C to 220 °C in eight preset levels. -
Page 24: Grilling
GRILLING The grill enables you to heat and brown food quickly, without using microwaves. • Always use oven gloves when touching the recipients in the oven, as they will be very hot. • You can get better cooking and grilling results, if you use the high rack. -
Page 25: Combining Microwaves And The Grill
coMbINING MIcRoWavES aNd tHE GRILL You can also combine microwave cooking with the grill, to cook quickly and brown at the same time. ALWAYS use microwave-safe and oven-proof cookware. Glass or ceramic dishes are ideal as they allow the microwaves to penetrate the food evenly. -
Page 26: Using The Memory Cook Feature
5. Press the Start ( ) button. Result: • Combination cooking starts. • The oven is heated to the required temperature and then microwave cooking continues until the cooking time is over. • The display times are 8 seconds for the preset cooking time and 2 seconds for the preset temperature in sequence. -
Page 27: Using The Deodorize Feature
uSING tHE dEodoRIzE fEatuRE Use this feature after cooking odorous food or when there is a lot of smoke in the oven interior. First clean the oven interior. Press the deodorize button after you have finished cleaning. You will hear four beeps. The deodorization time has been specified as 5 minutes. -
Page 28: Cookware Guide
cookWaRE GuIdE To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken when choosing the cookware. If the cookware is marked microwave-safe, you do not need to worry. The following table lists various types of cookware and indicates whether and how they should be used in a microwave oven. -
Page 29: Cooking Guide
cookING GuIdE MICROWAVES Microwave energy actually penetrates food, attracted and absorbed by its water, fat and sugar content. The microwaves cause the molecules in the food to move rapidly. The rapid movement of these molecules creates friction and the resulting heat cooks the food. - Page 30 cooking Guide for rice and pasta Rice: Use a large glass pyrex bowl with lid - rice doubles in volume during cooking. Cook covered. After the cooking time is over, stir before standing time and salt or add herbs and butter. Remark: the rice may not have absorbed all water after the cooking time is finished.
- Page 31 food portion time Standing (min.) time (min.) Onions 250 g 5-5½ Pepper 250 g 4½-5 Potatoes 250 g 500 g Turnip 250 g 5½-6 Cabbage CE107V_XEU-03714L_EN.indd 31 REHEATING Instructions Your microwave oven will reheat food in a fraction of the time that conventional ovens hobs normally take.
-
Page 32: Baby Food
REHEATING LIQUIDS Always allow a standing time of at least 20 seconds after the oven has been switched off to allow the temperature to even out. Stir during heating, if necessary, and ALWAYS stir after heating. To prevent eruptive boiling and possible scalding, you should put a spoon or glass stick into the beverages and stir before, during and after heating. - Page 33 Reheating Liquids and Food Use the power levels and times in this table as a guide lines for reheating. food portion power time (min.) Drinks 150 ml 900 W 1-1½ (coffee, tea (1 cup) and water) 250 ml 2-2½ (2 cups) 450 ml 3-3½...
- Page 34 DEFROSTING Microwaves are an excellent way of defrosting frozen food. Microwaves gently defrost frozen food in a short period of time. This can be of great advantage, if unexpected guests suddenly show up. Frozen poultry must be thoroughly thawed before cooking. Remove any metal ties and take it out of any wrapping to allow thawed liquid to drain away.
- Page 35 GRILL The grill-heating element is located underneath the ceiling of the cavity. They operate while the door is closed and the turntable is rotating. The turntable’s rotation makes the food brown more evenly. Preheating the grill for 4 minutes will make the food brown more quickly. cookware for grilling: Should be flameproof and may include metal.
- Page 36 Grill Guide for Fresh Food Preheat the grill with the grill-function for 2-3 minutes. Use the power levels and times in this table as guide lines for grilling. Use oven gloves when taking out. fresh portion power 1. Side 2. Side food time time...
- Page 37 CONVECTION Cooking with convection is the traditional and well known method of cooking food in a traditional oven with hot air. The heating element and the fan position is at the back-wall, so that the hot air is circulating. cookware for convection cooking: All conventional ovenproof cookware, baking tins and sheets –...
- Page 38 fresh portion power 1. Side food time (min) bREad Fresh 6 pcs (350 g) 100 W + 8-10 Bread 180 °C Rolls Garlic 200 g (1 pc) 180 W + 8-10 Bread 220 °C (chilled, prebaked) cakE Apple 500 g Only 38-43 Cake...
-
Page 39: Cleaning Your Microwave Oven
cLEaNING youR MIcRoWavE ovEN The following parts of your microwave oven should be cleaned regularly to prevent grease and food particles from building up: • Inside and outside surfaces • Door and door seals • Turntable and Roller rings aLWayS ensure that the door seals are clean and the door closes properly. -
Page 40: Wiring Instructions
WIRING INStRuctIoNS WARNING THIS APPLIANCE MUST BE EARTHED. This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock providing an escape wire for the electric current. The appliance is equipped with a mains lead which includes an earth wire for connecting to the earth terminal of your mains plug. -
Page 41: Cooking Instructions
CE107V_XEU-03714L_EN.indd 41 tEcHNIcaL SpEcIfIcatIoNS SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are thus subject to change without notice. - Page 42 NotE NotE CE107V_XEU-03714L_EN.indd 42 2010-02-18 3:10:37...
- Page 43 NotE NotE CE107V_XEU-03714L_EN.indd 43 2010-02-18 3:10:37...
- Page 44 CE107V_XEU-03714L_EN.indd 44 0810-SAMSUNG (7267864,€ 0.07/Min) AUSTRIA www.samsung.com/be (Dutch) 02-201-24-18 BELGIUM www.samsung.com/be_fr(French) 70-70-19-70 DENMARK 030-6227 515 FINLAND 01-48-63-00-00 FRANCE 01805-SAMSUNG (726-7864 € 0,14/Min) GERMANY 800-SAMSUNG (726-7864) ITALIA 261-03-710 LUXEMBURG 0900-SAMSUNG (0900-7267864) NETHERLANDS (€ 0.10/Min) 815-56-480 NORWAY 80820-SAMSUNG (726-7864) PORTUGAL 902-1-SAMSUNG (902 172 678)
