STEP 5 INSTALL ANTI-TIP BRACKET
(Standard/Stainless
Installation only) (cont.)
Remove Grilles for Access to Anti-Tip Locking Hooks
Fresh Food Unit
• Open the access door.
• Remove the 4 screws from the grille.
• Pull the bottom of the grille forward, down and out
to remove.
Freezer Unit
• Open the access door.
• Remove the 4 screws from the grille.
• Pull the bottom of the grille forward, down and out
to remove.
Installation Instructions
18
Power Cord
Locate the power cord inside the left cavity. If it has not
been adjusted so the plug is easily accessible,
do so now.
Move Unit into Final Position
• Move appliance toward its final installed location.
Align the tabs on the wall bracket with the openings
in the back of the unit.
• The unit has "L" bolts in the upper left and right
corners inside of the access compartment. These
bolts will interlock with the wall bracket and secure
the unit using the washers and hair pin cotters
in the hardware kit once the unit has been leveled
and is in the final position.
