THE WOODWORKERS
•
CHOICE FOR
PRECISION
TOOLS
HEAVY-DUTY B3NCH
10" SINGLE BEVEL COMPOUND
MITER SAW
our new 10" compound miter saw from Jet
B3ncH is the right saw at home or on the job. this
versatile saw comes standard with our innovative
Green Xacta Laser
, a high performance laser
™
system exclusively from Jet
accurate, high-visibility guide line for precision cuts,
even outdoors. add to that the powerful 15 amp,
4800 RpM motor, comfortable rubber grip handles,
and up front controls and you have a saw that is as
powerful as it is precise.
B
C
a.
Large aluminum extruded fence
c.
Features
b.
Sheet metal outfeed table with
d.
height adjustment
PORTABLE
Dual rubber-grip carrying handles allow for convenient portability
•
■
Features
Lightweight die cast aluminum design for easy transport
•
■
Versatile base can mount to a stand or workbench
•
■
PORTABLE
Combination benchtop jointer & planer provides a 2 in 1 machine to maximize workspace
•
POWERFUL
■
Compact benchtop design fits conveniently in smallshop environments
Heavy-Duty 15 Amp motor for various cutting applications
•
•
■
■
Integrated cord wrap makes transporting easy and ensures workshop safety
Die cast aluminum table for long-lasting durability
•
•
■
■
Holddown clamp tightens securely to the workpiece to ensure an accurate cut
•
■
Oversized, ergonomic knobs provide ease of use and maximum control
POWERFUL
•
■
Heavy-Duty 13 Amp motor for various cutting applications
•
■
PRECISE
Two high speed steel knives for precise, smooth cuts
•
■
Innovative Green XACTA Laser™ provides high visibility for precision cutting
•
■
Oversized, ergonomic knobs provide ease of use andmaximum control
•
■
Up-front controls for safety and ease of use
•
■
Ergonomic, D-shaped, over-molded handle for maximum control during cutting applications
•
■
PRECISE
Quick cam miter lock conveniently adjusts and stops at 9 detents:
•
■
0°, 15°, 22.5°, 31.6°, and 45° left and right
Large aluminum extruded fence makes joining stable and precise
•
■
Sheet metal extension wings provide added workpiece support
Sheet metal outfeed table with height adjustment supports long workpieces and helps
•
•
■
■
reduce snipe
Easy-slide fence extends further to support the workpiece
•
Planing and joining tables lock to ensure precision cutting
•
■
Precision machined table top ensures a smooth, straight cut
•
■
™
®
that projects an
®
F
Planing and joining tables lock
e.
Oversized, ergonomic knobs
Precision ground table top
f.
Integrated cord wrap
a.
Innovative Green XACTA Laser™
Up front controls
b.
c.
Ergonomic, D-shaped, over-molded
handle
d.
Quick cam miter lock conveniently adjusts
and stops at 9 detents
A
SpecificationS
SpecificationS
Stock number
Stock number
Model number
Model number
Motor
Motor
Knife Size (in.)
Miter Stops (deg.)
number of Knives (RpM)
Bevel Stops (deg.)
Miter capacity (deg.)
cutting Speed
Blade Speed (RpM)
cuts per Minute cpM
arbor Size (in.)
feed Speed fpM
cut capacity @ cross (LxW/in.)
Max. cutting Width (in.)
cut capacity @ 45° Miter (LxW/in.)
Jointer Max. cut Depth (in.)
cut capacity @ 45° Bevel (LxW/in.)
planer Max. cut Depth (in.)
cut capacity @ 45° compound (LxW/in.)
cutting thickness (in.)
Blade type (in.)
Jointer table Size (LxW/in.)
net Wt / Gross Wt (lbs.)
planer table Size (LxW/in.)
planer table with out feed (LxW/in.)
fence Size (LxW/in.)
fence tilt (deg.)
Gross Wt. / net Wt. (lbs.)
jettools.com/b3nch
C
B
D
707400
707100
JJP-8BT
JMS-10CMS
120V, 60Hz, 13Amp
120 V, 15 Amp.
8.25 x .65 x .06
9 stops, -45 to 45
2
3 at 0, 45 and 90 left
0 – 45 left and right
9,000
4,800
18,000
5/8
19.5
2-5/8 x 5-1/2
8
2-5/8 x 3-1/2
1/8
1-1/2 x 5-1/2
.08
1-1/2 x 3-1/2
.20 - 4.92
10 –40T carbide tipped
29 x 8-1/4
35.5 / 42.2
10-5/8 x 8-1/2
17-3/4 x 8-1/2
4-1/8 x 21
0-45
68.3 / 58.4
