Model
Ｖ－ＦＡ２７２ＦＴ
Language
Ｅｎｇｌｉｓｈ／Ａｒａｂｉｃ
４０
Page
Material
１００ｇ
Date
２００７／１０／２５
Part No.
３８２８ＦＩ３８７７Ｊ
Chage Record
Change content
No.
1
2
3
4
5
6
7
8
9
Color(cover/body)
Size(W*H)
Designer
Description
Date
ECO No.
２／１
１４５＊２１５
ＹＡＮＧＺＨＩＨＵＡ
ＭＡＮＵＡＬ，ＯＷＮＥＲＳ
Designer Confirm

Advertisement

Table of Contents
loading

Related Manuals for LG V-FA272FT

Summary of Contents for LG V-FA272FT

  • Page 1 Model Ｖ－ＦＡ２７２ＦＴ Language Ｅｎｇｌｉｓｈ／Ａｒａｂｉｃ ４０ Page ２／１ Color(cover/body) １４５＊２１５ Material Size(W*H) １００ｇ ＹＡＮＧＺＨＩＨＵＡ Date ２００７／１０／２５ Designer Part No. ３８２８ＦＩ３８７７Ｊ Description ＭＡＮＵＡＬ，ＯＷＮＥＲＳ Chage Record Change content Designer Confirm Date ECO No.
  • Page 2 Upright Vacuum Cleaner Owner's Manual MODEL: V-FA272FT PLEASE READ THIS MANUAL THOROUGHLY AND CAREFULLY BEFORE OPERATING THE VACUUM CLEANER P/No.: 3828FI3877J...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INFORMATION FOR YOUR SAFETY.............3 PARTS AND FEATURES ................4 TELESCOPIC HANDLE RELEASE............5 CORD RELEASE ..................5 SWITCH OPERATION ................6 BODY RELEASE AND POSITIONS ............6 RECOMMENDED PILE HEIGHT SETTINGS .........6 ATTACHMENT USE CHART..............7 VACUUMING TIPS ..................7 ATTACHMENTS ..................7 PERFORMANCE FEATURES ..............9 VACUUM CLEANER CARE..............10 Vacuum Storage......................10 Dust bin assembly .....................10...

  • Page 4: Information For Your Safety

    ❏ Do not use the vacuum cleaner If the power cord is damaged or faulty. ❏ If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard. ❏ Do not unplug by pulling on cord.

  • Page 5: Parts And Features

    PARTS AND FEATURES It is important to know your vacuum cleaner’s parts and features to assure its proper and safe use. Review these before using your cleaner. Telescopic handle Switch Carry handle Mini nozzle Supporter filter case Dust bin release lever Dust bin Nozzle hose Height adjustment...

  • Page 6: Telescopic Handle Release

    TELESCOPIC HANDLE RELEASE Release the telescopic handle by pulling telescopic release lever up with fingers and pulling up the telescopic handle. Telescopic release lever To lower the telescopic handle pull the telescopic release lever up with fingers and push down on Telescopic handle the telescopic handle.

  • Page 7: Switch Operation

    SWITCH OPERATION Switch operation • Off • Floor: Hard floors (Agitator off) • Carpet: Agitator on WARNING Personal injury hazard To avoid personal injury, do not turn switch On/Off if the vacuum or your hand is wet. BODY RELEASE AND POSITIONS Release the vacuum body by pressing down on the body release pedal with your foot and pulling back and down.

  • Page 8: Attachment Use Chart

    ATTACHMENT USE CHART CLEANING AREA ATTACHMENT Between Furniture* Drapes* Stairs Walls Cushions* DUSTING BRUSH CREVICE TOOL MINI NOZZLE * Always clean attachments before using on fabrics. VACUUMING TIPS Carpet edges WARNING Use attachments such as crevice tool, dusting brush, Mini-nozzle on carpet edges. Personal Injury Hazard See page 7, 8 Use care if vacuum cleaner is placed on...
  • Page 9 Dusting brush: Mini-nozzle Functions as a dusting brush,also an upholstery Mini-nozzle is attached as shown and used for nozzle which is useful for furniture, shelves etc. stairs and other hard to reach places. Attach as shown. To remove Mini-nozzle cover: Remove 2 screws on the bottom and take Mini- nozzle cover off as shown.

  • Page 10: Performance Features

    PERFORMANCE FEATURES Motor protector Thermal protector This vacuum has a motor protector bypass This vacuum has a thermal protector which valve which automatically opens to provide automatically trips to protect the vacuum from cooling air to the motor when a clog prevents overheating.

  • Page 11: Vacuum Cleaner Care

    VACUUM CLEANER CARE Always follow all safety precautions when cleaning and servicing the vacuum cleaner. WARNING Electrical shock and personal injury hazard. Disconnect electrical supply before servicing or cleaning the unit. Failure to do so could result in electrical shock or personal injury from cleaner suddenly starting. VACUUM STORAGE To store the vacuum cleaner when it is not used, assemble its cord and return its...

  • Page 12: Dust Bin Cleaning

    DUST BIN CLEANING For best performance always empty the dust TO CLEAN DUST BIN remove 3 catches on bin when the dirt level reaches the "MAX" line. dust cap and separate dust bin lid from dust bin and blade as shown. Dust bin lid WARNING Lock...

  • Page 13: Filters Cleaning / Changing

    FILTERS CLEANING / CHANGING Close Open Supporter filter case Exhaust filter Allow exhaust filter to dry 24 hours in the shade before putting it back. Make sure that the filters dry completely. FOR OPTIONAL PERFORMANCE, CHECK FILTERS FREQUENTLY AND CLEAN WHEN Remove supporter filter case and clean the filter DIRTY.

  • Page 14: Belt Changing And Agitator Cleaning

    BELT CHANGING AND AGITATOR CLEANING Check and remove hair, string, ad lint build-up in the agitator brush area. To replace nozzle WARNING bottom plate, should regulation be placed in its place and reinstall things you removed. Electrical shock and personal injury hazard.
  • Page 15 Remove string or hair that may be wrapped To seat agitator right end, pull both end of around the agitator. agitator forward and seat it into nozzle base. WARNING To seat agitator left end, put left end of Be careful when removing the agitator into slot in nozzle base as shown.

  • Page 16: Cleaning Exterior

    CLEANING EXTERIOR Unplug power cord from wall outlet. Clean DO NOT drip water in the cleaner. exterior using a clean, soft cloth that has been DO NOT clean tools in dishwasher or clothes dipped in a solution of mild liquid detergent and washer.

  • Page 17: Troubleshooting

    Review this chart to find do-it-yourself solutions for a minor performance problems. Additional service needed, other than those described in this owner's manual, should be performed at an authorized LG Electronics Service agency. WARNING Electrical shock and personal injury hazard.
  • Page 18 Note -17-...
  • Page 19 Note -18-...
  • Page 20 Note -19-...
  • Page 22 ‰ ‰ L L U U ∑ ∑ F F ß ß « « ô ô œ œ ∞ ∞ V-FA272FT ¥ ¥ u u œ œ « « ∞ ∞ º º J J M M « « ∞ ∞...
  • Page 24 • • • • • 3 3 1 1 2 2 6 6...
  • Page 27 • • •...
  • Page 29 ” “...
  • Page 31 ” . “ Unlock Unlock Unlock Unlock Unlock Lock Lock Lock Lock Lock Lock...
  • Page 32 — — • — — •...
  • Page 34 To seat agitator right end, pull both end of agitator forward and seat it into nozzle base.
  • Page 35 Pull...
