- Page 1 Model ＶＦＡ２８２ＦＴＷ Language Ｅｎｇｌｉｓｈ ２０ Page Material １００ｇ Date ２００７／０５／１７ Part No. ３８２８ＦＩ３８７７Ｅ Chage Record Change content ２／１ Color(cover/body) １４５＊２１５ Size(W*H) ＹＡＮＧＺＨＩＨＵＡ Designer Description ＭＡＮＵＡＬ，ＯＷＮＥＲＳ Designer Confirm Date ECO No.
-
Page 2: Upright Vacuum Cleaner
Upright Vacuum Cleaner Owner's Manual MODEL: VFA282FTW PLEASE READ THIS MANUAL THOROUGHLY AND CAREFULLY BEFORE OPERATING THE VACUUM CLEANER P/No.: 3828FI3877E... -
Page 3: Table Of Contents
INFORMATION FOR YOUR SAFETY...3 PARTS AND FEATURES ...4 TELESCOPIC HANDLE RELEASE...5 CORD RELEASE ...5 SWITCH OPERATION ...6 BODY RELEASE AND POSITIONS ...6 RECOMMENDED PILE HEIGHT SETTINGS ...6 ATTACHMENT USE CHART...7 VACUUMING TIPS ...7 ATTACHMENTS ...7 PERFORMANCE FEATURES ...9 VACUUM CLEANER CARE...10 Vacuum Storage...10 Dust bin assembly ...10 Dust bin cleaning...11... -
Page 4: Information For Your Safety
❏ Do not use the vacuum cleaner If the power cord is damaged or faulty. ❏ If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard. ❏ Do not unplug by pulling on cord. -
Page 5: Parts And Features
It is important to know your vacuum cleaner’s parts and features to assure its proper and safe use. Review these before using your cleaner. Telescopic release lever Quick release cord hanger Crevice tool Body release pedal Cord hook Motor protector PARTS AND FEATURES Telescopic handle Switch... -
Page 6: Telescopic Handle Release
TELESCOPIC HANDLE RELEASE Release the telescopic handle by pulling telescopic release lever up with fingers and pulling up the telescopic handle. To lower the telescopic handle pull the telescopic release lever up with fingers and push down on the telescopic handle. Note : For your convenience, adjust telescopic handle height properly to your height. -
Page 7: Switch Operation
Switch operation • Off • Floor: Hard floors (Agitator off) • Carpet: Agitator on WARNING Personal injury hazard To avoid personal injury, do not turn switch On/Off if the vacuum or your hand is wet. BODY RELEASE AND POSITIONS Release the vacuum body by pressing down on the body release pedal with your foot and pulling back and down. -
Page 8: Attachment Use Chart
ATTACHMENT USE CHART ATTACHMENT DUSTING BRUSH CREVICE TOOL MINI NOZZLE * Always clean attachments before using on fabrics. Carpet edges Use attachments such as crevice tool, dusting brush, Mini-nozzle on carpet edges. See page 7, 8 To use attachments 1) Place the cleaner on a flat surface. Remove the wand off the body by grasping and rotating while pulling up. - Page 9 Dusting brush: Functions as a dusting brush,also an upholstery nozzle which is useful for furniture, shelves etc. Attach as shown. Crevice tool: Crevice tool is attached as shown and used for corners, between cushions etc. Note : For added reach the dusting brush can be used with crevice tool as shown.
-
Page 10: Performance Features
PERFORMANCE FEATURES Motor protector This vacuum has a motor protector bypass valve which automatically opens to provide cooling air to the motor when a clog prevents the normal flow of air to the motor. If the by- pass valve opens to prevent motor overheating and possible damage to the vacuum, you will notice a change of sound as air rushes through the valve opening. -
Page 11: Vacuum Cleaner Care
VACUUM CLEANER CARE Always follow all safety precautions when cleaning and servicing the vacuum cleaner. WARNING Electrical shock and personal injury hazard. Disconnect electrical supply before servicing or cleaning the unit. Failure to do so could result in electrical shock or personal injury from cleaner suddenly starting. To store the vacuum cleaner when it is not used, assemble its cord and return its telescopic handle to its lower space saving... -
Page 12: Dust Bin Cleaning
For best performance always empty the dust bin when the dirt level reaches the "MAX" line. WARNING Electrical shock and personal injury hazard. Always unplug power cord from electrical outlet before performing any service on vacuum. TO REMOVE DUST BIN, press the dust bin release lever until it snaps, and slide the bin out of cleaner. -
Page 13: Filters Cleaning / Changing
FILTERS CLEANING / CHANGING Close Open Supporter filter case Remove supporter filter case and clean the filter and case in cold water only. DO NOT USE DETERGENT OR SOAP. Let filter dry for 24 hours in the shade before putting it back. TO CLEAN EXHAUST FILTER Remove exhaust filter from vacuum and clean the filter and case in cold water only. -
Page 14: Belt Changing And Agitator Cleaning
BELT CHANGING AND AGITATOR CLEANING WARNING Electrical shock and personal injury hazard. Disconnect electrical supply before servicing or cleaning the unit. Failure to do so could result in electrical shock or personal injury from cleaner suddenly starting. Frequently check and remove hair, string, and lint build-up in the agitator brush area. -
Page 15: To Replace Belt
Remove string or hair that may be wrapped around the agitator. WARNING Be careful when removing the agitator as the belt tension is high. Failure to do so could result in personal injury from the agitator releasing quickly and snapping away. TO REPLACE BELT Seat the right end of agitator into nozzle base. -
Page 16: Cleaning Exterior
Unplug power cord from wall outlet. Clean exterior using a clean, soft cloth that has been dipped in a solution of mild liquid detergent and water and wrung dry. The hose located on the vacuum cleaner carries the dirt from the nozzle up to the dust bin. -
Page 17: Troubleshooting
Review this chart to find do-it-yourself solutions for a minor performance problems. Additional service needed, other than those described in this owner's manual, should be performed at an authorized LG Electronics Service agency. WARNING Electrical shock and personal injury hazard. - Page 18 Note -17-...
- Page 19 Note -18-...
- Page 20 Note -19-...
