The DSX-CHA-5-IX-S is a set of two adapters for use with Fluke Networks
DSX CableAnalyzer
Industrial links and patch cords to the IEEE 802.3 specifications often used
for industrial Ethernet applications.
DSX Firmware Requirements
Your DSX CableAnalyzer will show a message if it needs a firmware update
to operate with these adapters. Firmware updates are available at no
charge on the Fluke Networks website. To install an update, use the latest
version of LinkWare PC or LinkWare Live. For details, see the Versiv Series
Users Manual.
PN 5082049 March 2019
©2019 Fluke Corporation
All product names are trademarks of their respective companies.
DSX-CHA-5-IX-S
testers. The adapters let you test and certify ix
™
ix Industrial
for Industrial Ethernet
Users Guide
™
Adapters
Advertisement
Table of Contents
Related Manuals for Fluke DSX-CHA-5-IX-S
Summary of Contents for Fluke DSX-CHA-5-IX-S
- Page 1 ™ Adapters for Industrial Ethernet Users Guide The DSX-CHA-5-IX-S is a set of two adapters for use with Fluke Networks DSX CableAnalyzer testers. The adapters let you test and certify ix ™ Industrial links and patch cords to the IEEE 802.3 specifications often used for industrial Ethernet applications.
-
Page 2: Safety Information
Symbols Warning or Caution: Risk of damage or destruction to equipment or software. See explanations in the manuals. Warning: Risk of fire, electric shock, or personal injury. » Consult the user documentation. 40 year Environment Friendly Use Period (EFUP) under China ‡... -
Page 3: Set The Reference
Set the Reference Before you use the ix Industrial adapters to test and certify links, set the reference. Repeat the reference procedure every thirty days at minimum. To set the reference Turn on the tester and the remote a minimum of 1 minute before you set the reference. - Page 4 Test and Certify a Channel On the home screen, tap the test setup panel. On the CHANGE TEST screen, tap NEW TEST. On the TEST SETUP screen, tap the panels to select settings: • Cable Type: If the correct type is not in the LAST USED list, tap MORE, tap Manufacturers, tap the correct manufacturer, then tap a cable type.
- Page 5 Variable frequency drive Channel 90 m maximum (295 ft) Switch ix Industrial connectors Main and remote testers with DSX-CHA-5-IX adapters CY05.EPS Figure 2. Connections for Channel Tests with Two ix Industrial Connectors...
- Page 6 Variable frequency drive Channel 90 m maximum (295 ft) Switch RJ45 cable ix Industrial from switch connector Main tester with Remote DSX-CHA004 tester with channel adapter* DSX-CHA-5-IX adapter * Channel adapters are included with the DSX-5000 and DSX-8000 kits. CY04.EPS Figure 3.
- Page 7 Test and Certify an ix Industrial Patch Cord Patch cord tests include results for the ix Industrial connectors on the ends of cord. Use this procedure to do tests on ix Industrial cords you make to connect the components in your system. On the home screen, tap the test setup panel.
-
Page 8: Maintenance And Service
1-800-283-5853, +1-425-446-5500 Fluke Networks 6920 Seaway Boulevard, MS 143F Everett WA 98203 USA Fluke Networks operates in more than 50 countries worldwide. For more contact information, visit our website. Specifications The DSX-CHA-5-IX adapters meet all measurement accuracy specifications for Level IIe test equipment. For more information, visit the Fluke Networks website. -
Page 9: Limited Warranty And Limitation Of Liability
LIMITED WARRANTY AND LIMITATION OF LIABILITY Fluke Networks mainframe products will be free from defects in material and workmanship for one year from the date of purchase, unless stated otherwise herein. Parts, accessories, product repairs and services are warranted for 90 days, unless otherwise stated.
