- Page 1 START Click the button and follow the in- structions. CATEYE V2c/V3 CC-TR200DW/300TW Quick Start...
- Page 2 Thank you for purchasing our cyclocomputer CATEYE V2c/V3. This Quick Start Manual explains how to set up the computer, how to install the unit to your bicycle, and how to wear the heart rate sensor. Please set up the unit according to the specified procedure, then it will be ready for use as a cyclocomputer.
- Page 3 This PDF contains a movie file. When you click on the movie screen, a message regarding security appears. Click the “Trust in the text” or “Play” button to close the message. Click the screen again to play the movie. Next...
- Page 4 CATEYE V2c / V3 Return to a Cover Quick Start Manual Contents Click the item you wish to view. Setting up the computer How to install the bracket (movie) How to install the speed sensor (movie) How to wear the heart rate sensor (movie)
- Page 5 Operation of buttons Set up the computer by operating the buttons as follows. Check the button position before you start setting up. Front Press the SSE button, the M1/+ but- ton, and the M2/- button on the front of the computer. M1/ + M2/- Press the MENU button on the back of...
- Page 6 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Close Restarting operation Setting the date display Open Setting the year Setting the month Setting the day Setting the clock display Setting the hour Setting the minute Setting the wheel...
- Page 7 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Setting the hour Setting the minute Setting the wheel Setting the speed unit...
- Page 8 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Date display Setting the hour Setting the minute Setting the wheel...
- Page 9 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Setting the hour Setting the minute Setting the wheel Setting the speed unit...
- Page 10 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Month Setting the hour Setting the minute Setting the wheel...
- Page 11 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Setting the hour Setting the minute Setting the wheel Setting the speed unit...
- Page 12 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Clock display Setting the hour Setting the minute Setting the wheel...
- Page 13 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Setting the hour Setting the minute Setting the wheel Setting the speed unit...
- Page 14 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Minute Setting the hour Setting the minute Setting the wheel...
- Page 15 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Setting the wheel Restarting operation Press the MENU button to change to the FILE VIEW screen. Press the M2/- button twice to change to the WHEEL setting screen, and press Setting the date display the SSE button to proceed to “Setting the wheel (1/3)”.
- Page 16 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Tire circumference A Setting the hour Setting the minute Setting the wheel (2/3)
- Page 17 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Entering the tire circumference Setting the hour Tire circum- Setting the minute...
- Page 18 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Setting the speed unit Restarting operation Press the M2/- button twice to change to the UNIT setting screen, and press the SSE button to proceed to “Setting the measurement unit”.
- Page 19 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Setting the speed unit Setting the hour Setting the minute...
- Page 20 CATEYE V2c / V3 Quick Start Manual Preparation for setting up Restarting operation Setting the date display Setting the year Setting the month Setting the day Setting the clock display Measuring screen Setting the hour Setting the minute Setting the wheel...
- Page 21 CATEYE V2c / V3 Return to Contents Quick Start Manual How to install the bracket...
- Page 22 CATEYE V2c / V3 Return to Contents Quick Start Manual How to install the speed sensor...
- Page 23 CATEYE V2c / V3 Return to Contents Quick Start Manual How to wear the heart rate sensor...
- Page 24 CATEYE V2c / V3 Quick Start Manual Tire circumference reference table ETRTO L (mm) ETRTO Tire size Tire size 47-203 12x1.75 40-406 20x1.50 54-203 12x1.95 47-406 20X1.75 40-254 14x1.50 1020 50-406 20x1.95 47-254 14x1.75 1055 28-451 20x1-1/8 40-305 16x1.50 1185 37-451 20x1-3/8 47-305 16x1.75...
