Monitoring System Activity and Performance
•
Type ESC + R to return to the H2TU-C logon screen.
Monitor Performance
------------------------------------------------------------------------------
# Date and Time
1 10/21/99 12:25:00
2 10/21/99 12:25:00
3 10/21/99 12:25:00
4 10/21/99 12:25:00
5 10/21/99 00:13:32
6 09/16/99 00:13:27
7 09/16/99 00:13:27
8 09/16/99 00:11:16
9 09/16/99 00:10:43
10 09/16/99 00:10:30
11 09/16/99 00:04:11
12 09/16/99 00:00:40
13 09/16/99 00:00:02
14 - Empty -
15 - Empty -
Press: (N)ext Page, (P)revious Page, (T)op of Log, C(l)ear Log
ID: xxxx--xxxx--xxxx--xxxx
Sectionalized events use the following status definitions:
38
Event Log Config
Sectionalized Event Log (Page 1 of 7)
NET-TX
OK
Alarm
Alarm
Alarm
Alarm
OK
ES
OK
RAI
RAI
OK
OK
OK
02/15/00 12:30:01
Figure 24. H2TU-R Sectionalized Event Log Screen
Table 17. Sectionalized Event Descriptions
Screen Section Events
OK Signal is clean
ES Errored Seconds condition
SES Severely Errored Seconds
condition
ALARM LOS
AIS Alarm Indicator Signal condition
RAI Remote Alarm Indicator condition
AIS-CI Customer AIS
RAI-CI Customer RAI
NOT SECT No Sectionalized Data Available
OOF Out-of-frame condition
