HOW TO USE THIS MANUAL This manual is designed to provide the customer with a means to identify the parts on his/her tractor when ordering repair parts. The illustrations may or may not represent the actual assemblies; therefore, it is not recommended to use this manual as a guide to assemble or disassemble the tractor. Some hardware and parts are drawn larger in order to more readily identify them.
REPAIR PARTS TRACTOR - - MODEL NUMBER 164891 (96016001500) PRODUCT NO. 960 16 00-15 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.1cyl_49 PART PART DESCRIPTION DESCRIPTION 170551 Control Th/ch Flag 17000612 Screw Hex Wsh Thdrol 3/8-16 17720408 Screw Hex Thd Cut 1/4-20 x 1/2 19091416 Washer 9/32 x 7/8 x 16 Ga.
REPAIR PARTS TRACTOR - - MODEL NUMBER 164891 (96016001500) PRODUCT NO. 960 16 00-15 DECALS PART PART DESCRIPTION DESCRIPTION 181251 Decal, Clutch Brake 145005 Decal, Caution, Battery 404122 Decal, Replacement 193863 Decal, Oper Sdl P/L Gear Dr Eng 184769 Decal, Engine HP 160396 Decal, V-Belt Sch.
Page 18
Murray Pro Series 4 Year Warranty The Home Depot Canada is doubling the warranty period of the manufacturer’s warranty and those of the companies that manufacture engines, accessories, transmissions, batteries, transaxles and other sourced components To make claim under this warranty does not change. Return the unit or if authorized in advance, the defective part, along with your proof of purchase to The Home Depot Canada store where purchased or closest to you, or, to an authorized Service Dealer.
