THIS MANUAL MUST BE READ IN ITS
ENTIRETY BEFORE OPERATING HEATER
FS35ETRBN/US FS35ETRSN/US
FS35ETRBL/US FS35ETRSL/US
Owners Operation and Installation Manual
WARNING: If the information in these instructions are not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in
your building.
• Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
This heater has been designed to code ANSI Z 21.88a-2000
effective 7-1-2002
This appliance is only for use with the type of gas indicated on
the rating plate.
This appliance is not convertible for use with other gases.
INSTALLER: MUST LEAVE THIS MANUAL WITH THE UNIT AFTER INSTALLATION
OWNER: RETAIN THIS MANUAL SAFELY, FOR FUTURE REFERENCE
HOME OWNER / INSTALLER
FOR YOUR SAFETY
Gas Radiant Space Heater
WHAT TO DO IF YOU SMELL GAS
Advertisement
Table of Contents
Related Manuals for Rinnai FS35ETRBL/US
Summary of Contents for Rinnai FS35ETRBL/US
- Page 1 HOME OWNER / INSTALLER THIS MANUAL MUST BE READ IN ITS ENTIRETY BEFORE OPERATING HEATER FS35ETRBN/US FS35ETRSN/US FS35ETRBL/US FS35ETRSL/US Gas Radiant Space Heater Owners Operation and Installation Manual WARNING: If the information in these instructions are not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
