- Page 1 Operation and Maintenance Documentation AIR CURTAINS Type : ACR 100W ACR 100E ACR 100C ACR 150W ACR 150E ACR 150C ACR 200W ACR 200E ACR 200C www.pakole.com...
-
Page 2: Table Of Contents
ACR air curtains Contents Contents 1. GENERAL AND SAFETY PRINCIPLES ..........................3 2. PURPOSE OF THE DEVICE ..............................4 3. BASIC TECHNICAL PARAMETERS ............................4 4. HEAT OUTPUT RANGES ................................5 ACR 100-150-200 W Air curtains with water heater .......................5 ACR 100-150-200 E Air curtains with electric heater ......................5 5. -
Page 3: General And Safety Principles
ACR air curtains Operation and Maintenance Documentation GENERAL AND SAFETY PRINCIPLES The ACR air curtains are manufactured in compliance with the rules and standards concerning quality, ecology, utility and work comfort . Before starting the device be sure to read the Manual carefully. The ACR air curtains are delivered ready-to-use in a cardboard package that is to protect from any mechanical damages. -
Page 4: Purpose Of The Device
• sports and show halls, • exhibition surfaces BASIC TECHNICAL PARAMETERS ACR 200E ACR 150W ACR 200W ACR 100E ACR 150E ACR 100W ACR 200C ACR 100C ACR 150C * Noise level measured in distance of 3 m in open space building... -
Page 5: Heat Output Ranges
ACR air curtains Operation and Maintenance Documentation HEAT OUTPUT RANGES acr 100-150-200 W Air curtains with water heater ACR 100W ACR 150W ACR 200W acr 100-150-200 E Air curtains with electric heater ACR 100E ACR 150E ACR 200E ACR E series (with electric heater) are based on a new type of PTC electric coils J It is a modern and safe solution, additional advan- tages of PTC heaters •... -
Page 6: Installation
ACR air curtains Operation and Maintenance Documentation INSTALLATION When deciding on the air curtain position you should take into account such factors as: • Ease of access for servicing, • Access to water and electricity supplies It is recommended to install the air curtain in position above the entrance opening, on the wall or under the ceiling, on support pins or horizontal mounting brackets. - Page 7 ACR air curtains Operation and Maintenance Documentation It is important to note that the minimum distance between the device and the ceiling is not less than 150 mm. This will ensure easy access to the water exchanger spigots, cable entries as well as free air flow to the inlet grille. Wall installation by means of a horizontal brackets The curtain can be mounted to the wall in a horizontal position using 2 mounting brackets to the horizontal system.
-
Page 8: Installation Using Brackets For Vertical Mounting
ACR air curtains Operation and Maintenance Documentation Installation using brackets for vertical mounting It is also possible to install the unit vertically with the engine downwards and upwards. Two vertical mounts are used for this purpose. In the brackets there are Ø9mm holes for M8 screws. In the EPP housing, drill holes Ø 12-13mm in front of existing holes in the steel in- take grille. -
Page 9: Connection Of Heating Medium
ACR air curtains Operation and Maintenance Documentation It is important to note that the minimum distance between the unit and the floor for installation with engine at the bottom is not less than 100mm. This allows access to the electrical terminal strip and to the water exchanger vent. Connection of heating medium The connection of the heating medium to the heat curtain, using G 1/2”... -
Page 10: Control Panel
ACR air curtains Operation and Maintenance Documentation CONTROL PANEL The curtain control is done by using the COMFORT control panel, which allows to adjust the flow and air temperature. The control panel should be located outside the curtain airflow zone. Up to 2 ACR curtains can be connected to one COMFORT panel. •... -
Page 11: Diagrams Of Electrical Connections
• Power supply 230V/50Hz; protection of the C10 system; cross section of power supply cables min. 3 x 1.5 mm • COMFORT control panel - 3-speed fan control with thermostat (OMY 5x 1.0mm) • Actuator valve - control 230V / 50Hz (OMY 2 x 0.75mm - TS Lite PAKOLE TRADE Kft.),... -
Page 12: Diagram Of Connection Of One Acr 100-150-200 E Curtain (Electric Heater) To The Comfort Panel
ACR air curtains Operation and Maintenance Documentation Diagram of connection of one ACR 100-150-200 E curtain (electric heater) to the COM- FORT panel • 400V/50Hz power supply; wire cross section; current protection circuit • min. 5 x 2,5 mm˛ for G100E ; (B16) •... -
Page 13: Diagram Of Connection Of One Acr 100-150-200 E Curtain (Electric Heater) To The Comfort Panel
• switches the curtain on/off from the master BMS system. • With the use of digital signals 0/1 (potential free contact), the BMS PAKOLE TRADE Kft. can work with any BMS master protocol • without need to convert the signal... -
Page 14: Connection Diagram Of Acr 100-150-200 W And C With Bms Module
ACR air curtains Operation and Maintenance Documentation Connection diagram of ACR 100-150-200 W and C with BMS module SIGNALS FROM BMS PZ „READY FOR OPERATION” • Digital signal “1” from the master BMS (potential-free contact) - Curtain ready for operation •... -
Page 15: Diagram Of Connection Of Acr 100-150-200 E Curtain With Bms Module
ACR air curtains Operation and Maintenance Documentation Diagram of connection of ACR 100-150-200 E curtain with BMS module ATTENTION ! While using BMS commuincation module for ACR electic series remove factory in- stalled jumper between COM-1 SIGNALS FROM BMS PZ „READY FOR OPERATION” •... -
Page 16: Dimensions Of The Acr 100-150-200 W, E, C Curtains
ACR air curtains Operation and Maintenance Documentation DIMENSIONS OF THE ACR 100-150-200 W, E, C CURTAINS... -
Page 17: Operation And Maintenance
– in case of any problems contact the installer of the device or the • PAKOLE TRADE Kft. Authorized Service immediately. TROUBLESHOOTING AND TECHNICAL PROBLEMS Possible problems and solutions are shown below. To eliminate a problem encountered contact the PAKOLE TRADE Kft. Authorized Service. Fault, symptoms Potential causes Solutions... - Page 18 If you would like to contact us the type and serial number of device always be at hand. In case of other needed information write to the following address: PAKOLE TRADE Kft. H-8000 Székesfehérvár, Börgöndi út 8-10. Tel.: +36 22 316 484...
- Page 20 PAKOLE TRADE Kft. H-8000 Székesfehérvár, Börgöndi út 8-10. www: https://www.pakole.com E-mail: mail@pakole.hu Tel.: +36 22 316 484 Fax.: +36 22 316 074...
