  • Page 1 Star Trac ® 8-RDE Rear Drive Elliptical OWNER’S MANUAL...

  • Page 2: Table Of Contents

    INTRODUCTION .................................. 01 Product Speci cations ..........................01 Warning ..........................02 ARABIC SAFETY INSTRUCTIONS .................................. 04 SAFETY INSTRUCTIONS .................................. 05 English ..........................06 Dutch ..........................07 French ..........................08 Italian ..........................09 Portuguese ..........................10 Spanish ..........................11 Swedish ..........................12 Chinese ..........................

  • Page 3: Product Speci Cations

    PRODUCT SPECIFICATIONS MANUFACTURER: 8-RDE CORE HEALTH & FITNESS Dimensions: 35”W x 86”L x 73”H 4400 NE 77th Avenue, Suite 300 91cm x 219cm x 186cm Vancouver, WA 98662 Weight: 395 lbs/179 kg Telephone: (888) 678-2476 http://www.corehealthand tness.com CUSTOMER SUPPORT: CORE HEALTH & FITNESS Contact your local distributor, or Core Health &...
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS DANGER - to reduce the risk of electrical shock: and under the personal supervision concerning use of the machine by a person responsible for their 1. Always unplug the machine from the electrical outlet safety. Do not leave children unsupervised around before cleaning or servicing.
  • Page 5 10. Do not operate the machine if the motor shroud is removed or if the power cord is damaged in any manner. Keep all air openings free from dirt or any material that would block the ow of air to the motor.

  • Page 6: Arabic

    SAFETY INSTRUCTIONS This chapter includes precautions and tness safeguards for the installation and use of the product. Please read this chapter carefully before installing or using your equipment. Safety instructions are provided in the following languages (in the order shown): •...

  • Page 7: Safety Instructions

    PRECAUTIONS CAUTION: READ THE OWNER’S CAUTION: MOVING PARTS, KEEP MANUAL COMPLETELY BEFORE HANDS AND FEET FROM UNDER OPERATING THIS MACHINE. THE TREADMILL WHEN OPERATING. CAUTION: BEFORE CLEANING OR SERVICING, DISCONNECT POWER STOP (OF ACTIVITY) SUPPLY. These safety notes are directed to you as the owner of the equipment. For safety purposes, it is your responsibility to train all your members and tness sta to follow these safety instructions.
  • Page 8 VOORZORGSMAATREGELEN WAARSCHUWING: LEES DE WAARSCHUWING: BEWEGENDE GEBRUIKERSHANDLEIDING ONDERDELEN, HOUD HANDEN VOLLEDIG VOORDAT UDIT TOESTEL EN VOETEN NIET ONDER HET IN GEBRUIKT NEEMT. TOESTEL TIJDENS GEBRUIK. WAARSCHUWING: HAAL DE STEKKER UIT HET STOPCONTACT STOP (ACTIVITEIT) VOORDAT U HET TOESTEL REINIGT OF ONDERHOUDT. Deze veiligheidsmaatregelen zijn aan u als eigenaar van de apparatuur gericht.
  • Page 9 PRÉCAUTIONS MISE EN GARDE : PRENDRE MISE EN GARDE : PIÈCES MOBILES MARCHE CONNAISSANCE DU MODE ; NE PAS METTRE LES MAINS NI D’EMPLOI AVANT DE SE SERVIR LES PIEDS EN DESSOUS DE ARRÊT DE L’APPAREIL. L’APPAREIL LORSQU’EN FONCTIONNEMENT. MISE EN GARDE : DÉBRANCHER L’APPAREIL DU SECTEUR AVANT ARRÊT (DE L’ACTIVITÉ) TOUTE PROCÉDURE DE...
  • Page 10 PRECAUZIONI ATTENZIONE: PRIMA DI UTILIZ- ATTENZIONE: PRESENZA DI PARTI ZARE LA MACCHINA LEGGERE IL IN MOVIMENTO, TENERE MANI MANUALE DI ISTRUZIONI. E PIEDI LONTANI DALLA PARTE INFERIORE DELLA MACCHINA MENTRE QUESTA È IN FUNZIONE. ATTENZIONE: PRIMA DI EFFETTUARE LA PULIZIA O INTERVENTI DI ARRESTO (DELL’ATTIVITÀ) MANUTENZIONE, TOGLIERE TENSIONE ALLA MACCHINA.
  • Page 11 PRECAUÇÕES CUIDADO: LEIA POR COMPLETO CUIDADO: PARTES MÓVEIS, LIGA O MANUAL DO PROPRIETÁRIO MANTENHA AS MÃOS E OS PÉS ANTES DE OPERAR ESTA AFASTADOS DA PARTE SOB A DESLIGA MÁQUINA. MÁQUINA DURANTE A OPERAÇÃO. CUIDADO: ANTES DA LIMPEZA OU MANUTENÇÃO, DESCONECTE A PARADA (DA ATIVIDADE) ALIMENTAÇÃO.
  • Page 12 PRECAUCIONES CUIDADO: LEA COMPLETAMENTE CUIDADO: CUENTA CON PARTES ENCENDIDA EL MANUAL DEL PROPIETARIO MÓVILES, AL OPERARLA ANTES DE OPERAR ESTA MANTENGA LAS MANOS Y PIES APAGADA MÁQUINA. ALEJADOS DE DEBAJO DE LA MÁQUINA. CUIDADO: ANTES DE LIMPIAR O DAR SERVICIO, DESCONECTE EL DETENER (EL FUNCIONAMIENTO) SUMINISTRO DE ENERGÍA.
  • Page 13 FÖRSIKTIGHETSÅTGÄRDER VARNING: LÄS HELA VARNING: DET FINNS RÖRLIGA PÅ ÄGARHANDBOKEN INNAN DU DELAR. HA INTE HÄNDER ELLER ANVÄNDER DEN HÄR MASKINEN. FÖTTER UNDER MASKINEN NÄR DEN ANVÄNDS. VARNING: kOPPLA UR ELKABELN FÖRE RENGÖRING OCH STOPPA (AKTIVITETEN) UNDERHÅLL. Dessa säkerhetsföreskrifter är riktade till dig som är ägare av utrustningen. Av säkerhetsskäl är det ditt ansvar att utbilda alla medlemmar och träningspersonal så...
  • Page 14 • • • • • • • • • • • • • • • • • • • • • • • • • • Page 12...
  • Page 15 • • • • • • • • • • • • • • • • • • • • • • • • • • • Page 13...
  • Page 16 • • • (350 • • • • • • • • • • • • • • • • • • • • • • • • Page 14...
  • Page 17 ARABIC SAFETY INSTRUCTIONS Page 15...

  • Page 18: Important Label Locations

    IMPORTANT LABEL LOCATIONS READ THE OWNERS MANUAL AND FOLLOW ALL PROPER INSTRUCTIONS PRIOR TO USE. IMPROPER USE OF THIS MACHINE CAN RESULT IN SERIOUS INJURY. 1. As with all exercise equipment or programs, consult a physician prior to use and stop if you feel faint, dizzy or exhausted.

  • Page 19: Operation - Openhub Lcd Console

    OPERATION - OPENHUB LCD CONSOLE DISPLAY MEASUREMENTS (RPM) Displays the current RPM (LEVEL) Displays the current level (KCAL) Displays accumulated calories burned (WATTS/ METS) Alternates display of current user Watts and METS WORKOUT PROFILE Displays pro le of past and upcoming speed levels relative to one another SEGMENT TIMER Below the Workout Pro le area is a segment timer that counts down the time remaining in the current segment.

  • Page 20: Console Key Functions

    CONSOLE KEY FUNCTIONS Bluetooth Device Pairing with Bluetooth Button: Pushing the button puts the console into discover mode. The console will be available for pairing for up to 60 seconds to pair with a compatible App. The button will ash while searching for pairing, and the display will show the unique console code.

  • Page 21: Workout Selection Keys

    WORKOUT SELECTION KEYS AND PROGRAM DEFINITIONS Manual: Similar to Quick Start, but allows user to enter weight for more accurate Calorie measurement Auto Pilot: Increase resistance by pedaling faster, no key to press Warm up program: Seven minute program with three resistance level settings designed to properly warm up the muscles prior to a workout Random Hill: Climbing interval style workout Alpine Pass: Climbing interval style workout with a progressive, high level of intensity...

  • Page 22: Openhub Touch Screen Consoles

    OPERATION - OPENHUB TOUCHSCREEN CONSOLES DISPLAY MEASUREMENTS Time Current total workout time Level Current level, from 1-20 Current RPM Distance Current total distance Calories Accumulated calories burned Cal/Hour Current rate of calorie burn WATTS Current user Watts METS Current user METS Heart Rate Current HR in beats per minute, if available...
  • Page 23 WORKOUT SELECTION KEYS AND PROGRAM DEFINITIONS On the main screen are several choices: Select a Workout User selects from a variety of pre-loaded workout options: Warm Up Burn Fat Improve Cardio Capacity (HR Control Programs) Train (Speed, Strength, Endurance, 5K Time Trial, Constant Watts, Interval Watts) Evaluate Fitness Level (Fitness Test) Create a Workout...

  • Page 24: Maintenance

    MAINTENANCE TOOLS Working on this product will require basic and/or sometimes specialty tools based on the type of service that will be performed at any time. To assist, we recommend having the tools listed (Fig. 7) available when performing maintenance. Tool Multi-meter Screwdriver Set, Phillips...

  • Page 25: Maintenance Schedule

    With durable, high performance components, this equipment is designed for heavy usage with minimal maintenance required. To keep it in top condition, perform regular daily, weekly and monthly preventive maintenance routines outlined below. The safety and integrity of this machine can only be maintained when the equipment is regularly examined for damage and wear and repaired.

  • Page 26: Maintenance Mode

    MAINTENANCE MODE - LCD Maintenance Mode allows access to service and diagnostic information, as well as provides the ability to adjust certain program default parameters. To enter Maintenance Mode: 1. Press and hold the keys together. 2. A beep will sound and “MAINTENANCE MODE” will display momentarily in the Information Window. 3.
  • Page 27 Default Weight (to user). Typical weight in lb 1 (lb) 500 (lb) 155 (lb) (UNx = UNE) or kg (UNx = UNM). 1 (kg) 226 (kg) 70 (kg) Language. Display language; either LEN (English), LGE (German), LSP (Spanish), LDU LANG (Dutch), LPO (Portuguese), LFR (French), LIT (Italian), LSW (Swedish), LKA (Katakana) or RUS (Russian).
  • Page 28 Random Program. Number of times the RNDM PROG Random program was run since last reset. Interval Watts Program. Number of times IW PROG the Interval Watts program was run since last reset. Continuous Watts Program. Number of CW PROG times the Continuous Watts program was run since last reset.

  • Page 29: Regulatory Information

    REGULATORY INFORMATION This section provides regulatory and safety information CSA C22.2 No 0-M91 General Requirements • pertaining to the product • CSA C22.2 No. 68-92 Motor Operated Appliances FCC AND OTHER DOMESTIC REGULATIONS EUROPEAN APPLICATIONS This product has been tested and found to comply This product has been tested to the following with the limits for a Class A digital device, pursuant to standards:...
  • Page 30 © 2018 CORE HEALTH & FITNESS, LLC PART NUMBER 620-8437, REV D...
