FP03-60E
Propeller
Operator's manual
REV. A00
26
January 2018
th
This is an original document issued by Pipistrel.
Should third-party translations to other languages contain any inconsistencies,
Pipistrel denies all responsibility.
WARNING!
This leaflet MUST be present inside the cockpit at all times when required by law.
If the aircraft ownership changes, this manual must be handed over to the new owner.
Advertisement
Related Manuals for Pipistrel FP03-60E
Summary of Contents for Pipistrel FP03-60E
- Page 1 Propeller Operator’s manual REV. A00 January 2018 This is an original document issued by Pipistrel. Should third-party translations to other languages contain any inconsistencies, Pipistrel denies all responsibility. WARNING! This leaflet MUST be present inside the cockpit at all times when required by law.
- Page 2 FP03-60E Propeller pipistrel.si Operator's manual Index of revisions Enter and sign the list of revised pages in the manual into the spaces provided below. All revised pages should be clearly designated in the upper right corner of the page, also, any changes in page content should be clearly visible (e.g.
- Page 3 FP03-60E Propeller Operator's manual List of valid pages This manual contains original and revised pages listed below. Pages State: Cover Original Page numbering Original Index of revised pages Original List of valid pages Original Table of contents Original General...
- Page 4 FP03-60E Propeller pipistrel.si Operator's manual This page is intentionally left blank.
- Page 5 FP03-60E Propeller Operator's manual Table of contents General Handling and maintenance...
- Page 6 FP03-60E Propeller pipistrel.si Operator's manual This page is intentionally left blank.
- Page 7 FP03-60E Propeller Operator's manual General General Introduction Notes and remarks Propeller markings Shipping list Propeller description Manufacturing method Technical data and operational limitations...
- Page 8 In case of aircraft damage or people injury resulting form disobeying instructions in the manual PIPISTREL d.o.o. denies any responsibility. All text, design, layout and graphics are owned by PIPISTREL d.o.o. Therefore this manual and any of its contents may not be copied or distributed in any manner (electronic, web or printed) without the prior consent of PIPISTREL d.o.o.
- Page 9 Spinner, spinner backplate and screws Installation material (p/n 1153194), includes: Propeller plate adapter Mounting bolts (6x M8) and washers Propeller description Pipistrel FP03-60E propeller is a fixed pitch propeller for ultralight and experimental aircraft in pull configuration. Propeller and spinner assembly...
- Page 10 WARNING! Pipistrel FP03-60E propeller does not comply with ICAO rules and regulations and is therefore used at one’s own responsibility. Manufacturing method The FP03-60E propeller’s outer skin and inside parts are made of composite materials, namely fibre reinforced plastic. The blade’s base is made of aluminium and stainless steel tube, which lies within to ensure the blade’s safe attachment to the propeller base (hub).
- Page 11 FP03-60E Propeller Operator's manual Handling and maintenance Handling and maintenance Introduction Upon delivery Propeller installation Propeller removal Scheduled maintenance Daily check-up Overhauls Overspeed Repairs Paint jobs Ground handling...
- Page 12 Operator's manual Handling and maintenance Introduction This chapter provides information on handling and maintenance of Pipistrel FP03-60E propeller. CAUTION! Prior to servicing the propeller the area around the aircraft must be cleared and barricade tape put up, to warn passers by of the possible hazard.
- Page 13 FP03-60E Propeller Operator's manual Handling and maintenance Scheduled maintenance Every 100 flight hours perform a check to the following components: • Spinner and spinner backplate • Blades • The check has to be performed as follows: • Visual inspection to the spinner: no cracks, no paint and/or edge separations •...
- Page 14 Overhauls must be done by the manufacturer once every 1000 flight hours. Maximum life span of the propeller Until present time, no boundaries of FP03-60E propeller’s life span are known. Several Pipistrel FP03- 60E propellers have been in operations without showing any structural abnormalities.
- Page 15 FP03-60E Propeller Operator's manual Handling and maintenance Ground handling Use pure water and a soft piece of cloth to clean the blades. If you are unable to remove certain spots, consider using mild detergents. Afterwards, rinse the entire surface thoroughly.
- Page 16 FP03-60E Propeller pipistrel.si Operator's manual This page is intentionally left blank.
- Page 17 34070 Savogna d’Isonzo (GO) Italia - EU t +39 0481 522000 f +39 0481 522110 pipistrel@legalmail.it www.pipistrel.eu Pipistrel Vertical Solutions d.o.o. Vipavska cesta 2 SI-5270 Ajdovščina Slovenia- EU t +386 5 366 38 73 f +386 5 366 12 63 info@pipistrel.si...
