Pipistrel Sinus 503 Flight And Maintenance Manual

Hide thumbs Also See for Sinus 503:
Table of Contents

Advertisement

Quick Links

See also: Service & Repair Manual
Flight manual and

Maintenance manual

applies to Sinus 503, Sinus 582 in Sinus 912
equipped with Rotax 503, Rotax 582
and Rotax 912 engines
Sinus NW (nose-wheel edition) owners please regard to the
Supplemental sheet at the back of this manual
REV. 0
(15 April, 2006)
This is the original manual of Pipistrel d.o.o. Ajdovscina
Should third-party translations to other languages contain any inconsistencies,
Pipistrel d.o.o. denies all responsibility.
WARNING!
As this manual applies to all models of Sinus ultralight motorglider it is mandatory to designate
those specific parts of this manual that regard the aircraft you own.
This booklet MUST be present inside the cockpit at all times!
Should you be selling the aircraft make sure this manual is handed over to the new owner.
