Goodman GM9S92 Manual

Heating Input: 40,000-120,000 BTU/h
Standard Features
• Heavy-duty aluminized-steel tubular heat exchanger
• Stainless-steel secondary heat exchanger
• Single-stage gas valve
• Durable Silicon Nitride igniter
• Multi-speed ECM blower motor
• Quiet single-speed induced draft blower
• Self-diagnostic control board
• All models comply with California 40 ng/J
Low NOx emissions standard
• Can no longer be installed in California's South Coast
Air Quality Management District (SCAQMD)
on or after October 1, 2019.
• AHRI Certified; ETL Listed
SS-GM9S92
Downloaded from ManualsNet.com
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To receive the Lifetime Heat Exchanger Limited Warranty
(good for as long as you own your home), 2-Year Unit Replacement Limited Warranty and 10-Year Parts Limited Warranty, online registration must
be completed within 60 days of installation. Online registration is not required in California or Quebec.
search engine
Cabinet Features
• Designed for multi-position installation -
GM9S92: upflow, horizontal left or right
• Certified for direct vent (2-pipe)
or non-direct vent (1-pipe)
• Easy-to-install top venting with optional side venting -
GM9S92/upflow models only
• Convenient left or right connection
for gas and electrical service
• Cabinet air leakage (Q
• Heavy-gauge steel cabinet with durable finish
• Foil-faced insulated heat exchanger cabinet
• Airtight solid bottom or side return with
easy-cut tabs for effortless removal in
bottom air-inlet applications
www.goodmanmfg.com
GM9S92
Single-Stage, Multi-Speed
ECM Gas Furnace
Up to 92% AFUE
Contents
Nomenclature ............................................2
Product Specifications ............................... 3
Dimensions ................................................4
Airflow Specifications ................................5
Wiring Diagram ........................................13
Accessories ..............................................14
) ≤ 2%
Leak
2/22
Supersedes 8/21
