Pentax R-315(N) Instruction Manual

R-300 series electronic total station
Hide thumbs
Table of Contents

Advertisement

Quick Links

PENTAX R-300 (p01-19)
10/30/02
11:20 AM
Page c
R
Instruction Manual
Electronic Total Station
R-300
SERIES
R-315(N)/R-325(N)/R-335(N)
R-322(N)/R-323(N)/R-326

Advertisement

Table of Contents
loading

Related Manuals for Pentax R-315(N)

Summary of Contents for Pentax R-315(N)

  • Page 1 PENTAX R-300 (p01-19) 10/30/02 11:20 AM Page c Instruction Manual Electronic Total Station R-300 SERIES R-315(N)/R-325(N)/R-335(N) R-322(N)/R-323(N)/R-326...
  • Page 2 PENTAX R-300 (p01-19) 10/30/02 PRECAUTIONS REGARDING SAFETY Safety Precautions (Must be followed) The following items are intended to prevent possible injury to the user or other people and/or damage to the instrument before it occurs. These safety precautions are important to the safe operation of this product and should be observed at all times.

  • Page 3: Precautions Regarding Safety Safety Precautions

    Do not look into the laser radiation aperture directly as this may result in damage to your eyes. Never use the telescope to view intense light such as direct sunlight or sunlight reflected through a prism as this may result in loss of sight.
  • Page 4 PENTAX R-300 (p01-19) 10/30/02 PRECAUTIONS REGARDING SAFETY CAUTION For security, please do the opening inspection and inspection every a fixed period and adjustment. When the laser beam enters eyes, an unexpected accident might be caused by the blink of eyes. Establish the laser product to avoid the height of eyes of a driving person and walker.

  • Page 5: Usage Precautions

    [Solar Observation] WARNING Never view the sun directly using the telescope as this may result in loss of sight. Never point the objective lens directly at the sun as this may damage internal components. When using the instrument for solar observation, be sure to attach the special solar filter (MU64) designed for this product to the objective lens.
  • Page 6 PENTAX R-300 (p01-19) 10/30/02 PRECAUTIONS REGARDING SAFETY e There is a possibility that synthesized values are calculated and the distance may become longer or shorter than the actual one when the operator measure the target of slope or sphere or rugged shape.
  • Page 7 [Checks and Repairs] Always check the instrument before beginning work and check that the instrument is maintaining the proper level of precision. Pentax bears absolutely no responsibility for damages due to survey results obtained from surveys conducted without an initial instrument check.

  • Page 8: Table Of Contents

    PENTAX R-300 (p01-19) 10/30/02 CONTENTS PRECAUTIONS REGARDING SAFETY Safety Precautions ... 1 Usage Precautions ... 3 BEFORE USING THE INSTRUMENT Names of Parts ... 9 Unpacking and Packing ... 11 Standard equipment ... 11 Attaching and Charging the Battery ... 12 DISPLAY AND KEYBOARD Display and Keyboard ...
  • Page 9 PENTAX R-300 (p01-19) 10/30/02 DISTANCE MEASUREMENT Target Setting ... 42 Distance Measurement ... 44 CORRECTION MODE Changing the Target Constant ... 46 Changing the Temperature ... 48 Changing the Atmospheric Pressure ... 50 Changing the ppm Value ... 52 INITIAL SETTING Overview ...
  • Page 10 PENTAX R-300 (p01-19) 10/30/02 CONTENTS APPENDIX 13-1 Error Messages ... 79 13-2 Atmospheric Correction ... 80 13-3 hPa and mmHg Conversion Tables ... 81 13-4 Error when no Atmospheric Correction is made ... 82 13-5 Atmospheric Refraction and Earth Curvature Correction ... 83 13-6 Distance Range ...

  • Page 11: Before Using The Instrument

    PENTAX R-300 (p01-19) 10/30/02 1 BEFORE USING THE INSTRUMENT 1-1 Names of Parts Collimator Power focus key Eyepiece Circular vial Display panel Key board Circular vial Leveling screw R-325(N)/R-322(N)/R-323(N): Detachable type 11:21 AM Page 9 1 BEFORE USING THE INSTRUMENT...
  • Page 12 PENTAX R-300 (p01-19) 10/30/02 11:21 AM Page 10 1 BEFORE USING THE INSTRUMENT Top handle Objective lens Centering knob Dual display panel is an optional accessory. R-335 (N): Shift type...

  • Page 13: Unpacking And Packing

    Remove the instrument from the case. Packing the Instrument in the case q Make sure the telescope is fairly level and lightly tighten the telescope clamp screw. w Line up the housing marks (round yellow marks on the instrument) and tighten the upper and lower clamp screws.

  • Page 14: Attaching And Charging The Battery

    PENTAX R-300 (p01-19) 10/30/02 1 BEFORE USING THE INSTRUMENT 1-4 Attaching and Charging the Battery Removing the Battery q Turn the lock lever anticlockwise and remove the Battery. w Lift up the battery pack and remove it from the instrument.
  • Page 15 PENTAX R-300 (p01-19) 10/30/02 Remaining Battery Charge When the instrument’s power is turned on, a battery mark “ displayed on the right of the display screen. This mark can be used to check the charge status of the battery. Low battery: Please change. Replace with the spare battery or charge.
  • Page 16 1 BEFORE USING THE INSTRUMENT Lock lever [Detaching the battery] q Press the lock lever and slide the battery to the lock lever direction. w Detach the battery packing from the battery pocket. [Display panel] q Power supply lamp (red) : Turns on when the power supply is turned on. w Charge lamp (green) : Turns on while charging and turns off when the e Discharge lamp (yellow) : Turns on when you push the discharge button.
  • Page 17 PENTAX R-300 (p01-19) 10/30/02 11:21 AM Page 15 1 BEFORE USING THE INSTRUMENT [How to charge] q It begins charging automatically when you set the battery packing in the charger which beams the power supply lamp. w Leave just as it is until the charge is completed.

  • Page 18: Display And Keyboard

    ON/OFF of power supply Returns to previous screen or cancels an operation. Turns the illumination of the LCD display and telescope reticle on and off. Accepts the selected (highlighted) choice or the displayed screen value. Displays the laser plummet *1, electronic vial function, and the LD point screen when you push the laser plummet/electronic vial key.

  • Page 19: Function Key

    PENTAX R-300 (p01-19) 10/30/02 2-3 Function Key Display F. Key Mode A [MEAS] [TARGET] [0 SET] [DISP] [MODE] Mode B [S.FUNC] [ANG SET] [HOLD] [CORR] [MODE] Other functions [RETICLE] [LCD] [ILLU] [CLEAR] [SELECT] 11:21 AM Page 17 2 DISPLAY AND KEYBOARD...
  • Page 20 PENTAX R-300 (p01-19) 10/30/02 2 DISPLAY AND KEYBOARD [How to move the menu number] Example: The cursor is located at Menu 1. Press the numeric key 0 and 2 to move to Menu 2 or press [F4] [ 11:21 AM...

  • Page 21: Alphanumeric Input

    The beam of the sun is strong and visual confirmation is difficult in daytime when outdoors. The laser beam is designed not to be able to observe through the telescope. Please visually align the laser beam to the target and mark the center.

  • Page 22: Preparation For Surveying

    PENTAX R-300 (p20-52) 10/30/02 3 PREPARATION FOR SURVEYING 3 PREPARATION FOR SURVEYING 3-1 Centering and Leveling of the Instrument Setting up the instrument and the tripod q Adjust the tripod legs so that a height suitable for observation is obtained when the instrument is set on the tripod.
  • Page 23 PENTAX R-300 (p20-52) 10/30/02 [For the Shift type laser plummet equipment model] Turn on the laser plummet function by pushing the Laser key. Match the position by the tripod so that the laser mark coincides with the ground mark. The centering knob is loosened, and the upper plate is pushed by the tip of a finger, and a center mark is matched to the ground mark.

  • Page 24: Optical Plummet (Option)

    PENTAX R-300 (p20-52) 10/30/02 3 PREPARATION FOR SURVEYING The brightness adjustment step of the laser is 10 steps. The laser plummet spot can become difficult to see in bright sunlight which makes it difficult to perform the occasional check. In this case, use your foot or the carrying case to make a shadow over the laser position.

  • Page 25: Leveling With Circular Vial

    3-4 Leveling with Circular vial Tripod is adjusted according to the following points by extending or contracting the legs so that the bubble of the Circular vial goes to the center of the circle. Shorten the leg at the side of the bubble or extend the leg opposite of the bubble to position the bubble in the center of the vial circle.
  • Page 26 PENTAX R-300 (p20-52) 10/30/02 3 PREPARATION FOR SURVEYING [Leveling] q Rotate instrument horizontally and make two Leveling screws arbitrarily chosen parallel to the display. w Turn on the Electronic vial function by pushing the Laser key. Put the bubble of the Circular vial in the center of the circle when the display shows “TILT OVER”.

  • Page 27: Eyepiece Adjustment

    The eyepiece adjustment is performed before target sighting. q Remove the telescope lens cap. w Point the telescope at a bright object, and rotate the eyepiece ring full counter-clockwise. e Look through the eyepiece, and rotate the eyepiece ring clockwise until the reticle appears as its maximum sharpness.

  • Page 28: Target Sighting

    PENTAX R-300 (p20-52) 10/30/02 11:08 AM Page 26 3 PREPARATION FOR SURVEYING 3-7 Target Sighting [Auto focus] The Auto focus mechanism is very precise but will not function under every condition. There is a slight possibility of focusing failure owing to brightness, contrast, the shape and size of the target.
  • Page 29 PENTAX R-300 (p20-52) 10/30/02 [Target sighting by Auto focus] The Auto focus of R-300 series has following two modes. 1. Normal mode 2. Continuous mode : Pressing AF buttons for two seconds beeps, and releasing 11:08 AM Page 27 3 PREPARATION FOR SURVEYING : Pressing AF button focuses on the target.
  • Page 30 Tighten the above two screws. r Adjust the eyepiece. t Look through the telescope and press the AF button. Move your eye vertically and horizontally to see if the target image moves in relation to reticle. y Align the reticle accurately on the target using telescope and horizontal tangent screws.
  • Page 31 Tighten the above two screws. r Adjust the eyepiece. t Look through the telescope and then press the AF button for two seconds to beep, and release the key to enter into the Continuous mode. y Align the reticle accurately on the target using telescope and horizontal tangent screws.
  • Page 32 Point the telescope at the target using a collimator. e Tighten the above two screws. r Adjust the eyepiece. t Look through the telescope, and then operate the Power focus key and focus on the target. y Align the reticle accurately on the target using telescope and horizontal tangent screws.
  • Page 33 Tighten the above two screws. r Adjust the eyepiece. t Look through the telescope and then rotate the AF ring and stop it where the target can be seen clearly and the target image does not move in relation to reticle even if your eye is vertically and horizontally moved.

  • Page 34: Attachment And Detachment Of Tribrach

    PENTAX R-300 (p20-52) 10/30/02 11:08 AM Page 32 3 PREPARATION FOR SURVEYING 3-8 Attachment and Detachment of Tribrach The tribrach of R-322, 323, 325, 322N, 323N, 325N, and 326 are detachable from the instrument if required when replacing the instrument with a target or unit prism for example.

  • Page 35: Turning The Power On

    PENTAX R-300 (p20-52) 10/30/02 4 TURNING THE POWER ON 4-1 Turning the Power On and Off Pressing the [POWER] key shows the initial screen. (The [POWER] key is also used to turn the power off.) After a few seconds, it turns to Electronic vial screen.

  • Page 36: Adjusting Lcd Contrast

    PENTAX R-300 (p20-52) 10/30/02 4 TURNING THE POWER ON 4-2 Adjusting LCD Contrast Press [F4] while holding down the Illumination key to access the screen for adjusting LCD contrast. Pressing [F1] [ ] will lighten the contrast,while pressing the [F2] [ ] will darken the contrast.

  • Page 37: Adjusting Illumination Brightness

    Pressing the Illumination key views the F3-RETICLE, F4-LCD and F5-ILLU. Illumination brightness of the LCD screen and telescope reticle may be adjusted as necessary at any time. Illumination brightness may be adjusted to any one of 10 levels.

  • Page 38: Angle Measurement

    PENTAX R-300 (p20-52) 10/30/02 5 ANGLE MEASUREMENT 5 ANGLE MEASUREMENT 5-1 Measuring an Angle Aim at the first target, then press [F3] [0 SET] twice in succession to reset the horizontal angle to 0. Aim at the second target, then read the horizontal angle.

  • Page 39: Resetting The Horizontal Angle To 0

    PENTAX R-300 (p20-52) 10/30/02 5-2 Resetting the Horizontal Angle to 0 Pressing [F3] [0 SET] twice in succession resets the horizontal angle to 0° 0' 0". The [F3] [0 SET] cannot reset the vertical angle to 0. Pressing the [F3] [0 SET] accidentally during measurement does not reset the horizontal angle to 0 unless you press it again.

  • Page 40: Inputting An Arbitrary Horizontal Angle

    PENTAX R-300 (p20-52) 10/30/02 5 ANGLE MEASUREMENT 5-4 Inputting an Arbitrary Horizontal Angle In case of Horizontal angle 123° 45' 20" input Press [F5] [MODE] to enter mode B. Press [F2] [ANG SET] to display the angle setting screen, then press [F4] [ the cursor to “2.
  • Page 41 PENTAX R-300 (p20-52) 10/30/02 Press the numeric key as 123.4520. Press the [ENT] key to accept the horizontal angle set to 123° 45' 20" and change the screen to mode A. The former data is called by pressing the [CLEAR] key again.

  • Page 42: Displaying The % Slope Of The Vertical Angle

    If the slope (%) exceeds [+/-]1000%, “Out of grade range” is displayed, indicating that the current vertical angle cannot be measured. When the telescope returns to a slope within slope [+/-] 1000%, the slope (%) display returns automatically from the “Out of grade range” message to the numeric value.

  • Page 43: Changing The Horizontal Angle From Clockwise To Counterclockwise

    PENTAX R-300 (p20-52) 10/30/02 5-6 Changing the Horizontal Angle from Clockwise to Counterclockwise Press [F5] [MODE] to enter mode B. Press [F2] [ANG SET] to display the Angle setting screen. Press [F4] [ ] to move the cursor to “3. R/L REVERSE”.

  • Page 44: Distance Measurement

    PENTAX R-300 (p20-52) 10/30/02 6 DISTANCE MEASUREMENT 6 DISTANCE MEASUREMENT 6-1 Target Setting The target mode and its Constant of current setting are shown at the left of the battery mark. For example in case of each Constant 0, Reflector sheet; S 0, Reflectorless(Non-Prism); N 0, Prism; P 0 Pressing [F2][TARGET] changes the target mode.
  • Page 45 PENTAX R-300 (p20-52) 10/30/02 q There is a possibility that correct distance measurement may be impossible by dispersion or reduction of laser beam when the laser beam comes into the target from diagonal angle. w There is a possibility that the instrument cannot calculate correctly when receiving reflected laser beam from forth and back directions in case of measuring the target on the road.

  • Page 46: Distance Measurement

    If the instrument is in mode B, press the [F5][MODE] to switch to mode A and press [F1] [MEAS]. Pressing the [F1][MEAS] after collimating the telescope at the prism starts Shot distance measurement with the “MEAS” text blinking. Distance measurement is completed and the “MEAS” text stops blinking the moment the distance measured by Shot measurement is displayed.
  • Page 47 If the instrument is in mode B, press [F5] [MODE] to switch to mode A and press [F1] [ MEAS ] twice. Pressing [F1] [MEAS] twice after collimating the telescope at the Target starts Continuous distance measurement at fast speed with the “MEAS” text blinking.

  • Page 48: Correction Mode

    PENTAX R-300 (p20-52) 10/30/02 7 CORRECTION MODE 7 CORRECTION MODE 7-1 Changing the Target Constant Changing the Target Constant can be performed only when the Reflector sheet and Prism Constant settings are “INPUT” in Initial Setting 1. Example: Prism Constant - 25mm setting Press [F4] [CORR] in mode B.
  • Page 49 PENTAX R-300 (p20-52) 10/30/02 Press the [ENT] key to accept the Prism Constant to -25 mm. Pressing the [ENT] key returns the instrument to mode A. To set the Reflector sheet constant to “0” select “0” for “Prism Constant” in “Initial Setting 1”.

  • Page 50: Changing The Temperature

    PENTAX R-300 (p20-52) 10/30/02 7 CORRECTION MODE 7-2 Changing the Temperature The temperature setting can be changed only when “Atmospheric Correction” has been set to “ATM INPUT” in “Initial Setting 1”. Example: Setting the temperature to +22°C Press [F4] [CORR] in mode B.
  • Page 51 PENTAX R-300 (p20-52) 10/30/02 Press the [ENT] key to accept the Temperature to +22°C. Pressing the [ENT] key returns the instrument to mode A. The valid range of Temperatue input is from -30°C to +60°C. When “Atmospheric Correction” in “Initial Setting 1” has been set to “1 . AUTO”...

  • Page 52: Changing The Atmospheric Pressure

    PENTAX R-300 (p20-52) 10/30/02 7 CORRECTION MODE 7-3 Changing the Atmospheric Pressure The atmospheric pressure setting can be changed only when “Atmospheric Correction” has been set to “ATM INPUT” in “Initial Setting 1”. Example: Setting the pressure to 900 hPa Press [F4] [CORR] in mode B.
  • Page 53 PENTAX R-300 (p20-52) 10/30/02 Press the [ENT] key to accept the PRESS to 900 hPa. Pressing the [ENT] key returns the instrument to mode A. The valid range of Pressure input is from 600 to 1120 hPa. (420 - 840 mmHg) When “Atmospheric Correction”...

  • Page 54: Changing The Ppm Value

    PENTAX R-300 (p20-52) 10/30/02 7 CORRECTION MODE 7-4 Changing the ppm Value The ppm value can be changed only when “Atmospheric Correction” has been set to “ppm INPUT” in “Initial Setting 1”. “TEMP” and “PRESS” are not displayed. Example: Setting the ppm value to 31 ppm Press [F4] [CORR] in mode B.

  • Page 55: Initial Setting

    PENTAX R-300 (p53-64) 10/30/02 8-1 Overview For the R-300 series, you can select and save the desired setting for a variety of prescribed instrument conditions, called Initial Setting. The Initial Setting is saved in four modes, “Initial Setting 1”, “Initial Setting 2”, “Initial Setting 4”, and “Initial Setting 5”, in which you can select and save the...

  • Page 56: Entering The Mode For Initial Setting 4

    PENTAX R-300 (p53-64) 10/30/02 8 INITIAL SETTING 8-4 Entering the Mode for Initial Setting 4 Press the [POWER] key while holding [F4] key down to access the screen for Initial setting 4. Select the item of interest in the same way as in the mode for Initial setting 1.

  • Page 57: Example Of Changing An Initial Setting Content

    8-6 Example of Changing an Initial Setting Content (Selection of Atmospheric Correction) This section describes the operating procedures for selecting “1.ATM CORR” in Initial Setting 1 as an example of changing an Initial Setting content. Use this example as a reference when changing other items because it is also applicable to the operating procedures for changing them.

  • Page 58: Initial Setting 1

    PENTAX R-300 (p53-64) 10/30/02 8 INITIAL SETTING 8-7 Initial Setting 1 1. Selection of Atmospheric Correction : [ATM CORR] Select whether Atmospheric Correction is to be performed by using the automatic measurement correction function with a atmospheric sensor, by entering the atmospheric temperature and pressure...

  • Page 59: Initial Setting 2

    PENTAX R-300 (p53-64) 10/30/02 8-8 Initial Setting 2 1. Selection of Minimum Distance measurement unit : [MEAS. MIN DISP] COARSE or FINE: 2. Selection of the Shot count : [SHOT COUNT] Select whether the shot count for Shot distance measurement is to be 1,3, 5, or an arbitrary count to be entered.
  • Page 60 PENTAX R-300 (p53-64) 10/30/02 8 INITIAL SETTING 10.Selection of primary MEAS setting : [PRIM. MEAS KEY] Select whether the primary distance measurement is MEAS SHOT or MEAS CONT or TRACK SHOT or TRACK CONT. 11.Selection of second MEAS setting : [SEC. MEAS KEY]...
  • Page 61 PENTAX R-300 (p53-64) 10/30/02 16.Selection for Automatic illumination power-off function : [ILLU. OFF] Select the time interval (3, 5, or 10 minutes) for activating the automatic illumination power-off function, or select NIL, disabling the function. 17.Selection for Distance measurement buzzer : [DIST.

  • Page 62: Initial Setting 4

    PENTAX R-300 (p53-64) 10/30/02 8 INITIAL SETTING 8-9 Initial Setting 4 1. Selection of Temperature unit setting : [TEMP. UNIT] Select °C or °F as the unit for Temperature. 2. Selection of Pressure unit setting : [PRESS UNIT] Select hPa (hectopascal) , mmHg, inchHg as the unit for pressure to be input.

  • Page 63: Initial Setting 5

    PENTAX R-300 (p53-64) 10/30/02 8-10 Initial Setting 5 1. Selection of Transfer rate (baud rate) : [BAUD UNIT] Select a baud rate of 1200, 2400, 4800, or 9600. 2. Selection of Data bits : [DATA LENGTH] Select a data length of 8 bits or 7 bits.

  • Page 64: Accsessing The Functions

    PENTAX R-300 (p53-64) 10/30/02 9 ACCESSING THE FUNCTIONS 9 ACCESSING THE FUNCTIONS 9-1 Accessing by Help key You can use the [HELP] key to display specific Initial Setting (such as the Prism Constant and Priority mode). Press the [lLLU]+[ESC] key in mode A or B.

  • Page 65: Accessing By 007

    PENTAX R-300 (p53-64) 10/30/02 9-2 Accessing by 007 The R-300 allows you to enter a special code of 007 with the Alphanumeric keys to display Specific Initial Setting. (such as the Prism Constant and Priority mode) Press the numeric keys [0] [0] [7] in mode A or B.
  • Page 66 9 ACCESSING THE FUNCTIONS [Instrument setting items] 007 code HELP menu list TARGET CONST PRISM CONST SHEET CONST ATM CORR MEAS. MIN DISP SHOT COUNT SHOT CONT SHOT INPUT CRV/REF CORR MIN UNIT ANG. V. ANG. STYLE DIST.BUZ QUAD BUZ AUTO OFF EDM OFF ILLU.OFF...

  • Page 67: Checks And Adjustments

    PENTAX R-300 (p65-88) 10/30/02 10 CHECKS AND ADJUSTMENTS Checks and Adjustments should be performed before and during measurement. The instrument should be checked after long storage and transportation. The checks should be performed in the following order. [Cautions on CHECKS AND ADJUSTMENTS] When adjustment is completed, be sure that adjusting screws are completely tightened.
  • Page 68 PENTAX R-300 (p65-88) 10/30/02 10 CHECKS AND ADJUSTMENTS Please check the electronic vial in a steady environment that has no vibration or rapid temperature change. When the electronic vial is checked outdoors and on a tripod, avoid sunlight influence by using a sunshade. Please wait for a while until the instrument and tripod are at the same temperature as the surrounding air.

  • Page 69: Circular Vial

    PENTAX R-300 (p65-88) 10/30/02 10-2 Circular Vial Checks q Adjust by the electronic vial beforehand. w Confirm the position of the bubble of the Circular vial. At this time, it is not necessary to adjust if the bubble is at the center of the circle.

  • Page 70: Vertical Reticle

    Set the instrument up the tripod and carefully level it. w Sight the target Point A with telescope. e Using the telescope fine adjustment screws, move Point A to the edge of the field of view by screw (point A’).

  • Page 71: Perpendicularity Of Line Of Sight To Horizontal Axis

    Position a target Point A at a distance 30m - 50m away from the instrument, and sight it with the telescope. w Loosen the telescope lock screw and turn the telescope until a point is sighted at a distance roughly equal to that of Point A. This is Point B.

  • Page 72: Vertical 0 Point Error

    Sight the telescope at any reference target A at Normale state. Read the vertical angle ( ). e Turn the telescope and rotate the alidade. Sight the same target A again at Back state and read the vertical angle R.

  • Page 73: Laser Plummet

    When a center part where a cross intersection and the laser mark look the brightest shifts by 0.8mm or more (at the instrument height 1.5m), it is necessary to adjust it. A repair engineer does this adjustment. Please contact the PENTAX dealer.

  • Page 74: Optical Plummet

    PENTAX R-300 (p65-88) 10/30/02 10 CHECKS AND ADJUSTMENTS 10-7 Optical Plummet Checks q Set the instrument on the tripod, and place a piece of white paper with a cross drawn on it right under the instrument. w Look through the optical plummet, and move the paper so that the intersecting point of the cross comes to the center of the field of view.

  • Page 75: Offset Constant

    PENTAX R-300 (p65-88) 10/30/02 10-8 Offset Constant The offset constant rarely changes. It is recommended, however, that check be done once or twice a year. The check of the offset constant can be done on a certified base line. It can also be obtained in a simple way as described below.

  • Page 76: Beam Axis And Line Of Sight

    10-10 The EDM beam axis The distance measurement (EDM) beam axis is adjusted to be aligned to the sighting axis of the telescope, but it can be changed a little in case of rapid temperature change, shock or aging. Check your instrument by following procedures.
  • Page 77 PENTAX R-300 (p65-88) 10/30/02 11:11 AM Page 75 10 CHECKS AND ADJUSTMENTS Target Plate approx. 50 m 10mm 10mm Internal circle 20mm 20mm Laser spot “Center” [Example: Adjustment is necessary] [Example: Adjustment is unnecessary] Adjustments At the procedure 4. above, if the “Center” of laser spot is not within the internal circle (10mm) of the target plate, the adjustment is necessary.

  • Page 78: Specifications

    PENTAX R-300 (p65-88) 10/30/02 11 SPECIFICATIONS 11 SPECIFICATIONS Reflectorless items are applicable to “N” models only. Telescope Image Optical aperture EDM aperture Reticle illumination Auto & Power focus Method Power Pointer Magnification Resolving power Field of view Minimum focus Auto-Focus...
  • Page 79 Weight Internal Memory Coordinates data Note: Reflector sheet: By PENTAX genuine Reflector sheet (5cm x 5 cm) Normal conditions: 20km visibility with slight shimmer (Good conditions): 40km visibility, overcast, no heat no shimmer and moderate wind Reflectorless The measurement range and accuracy are determined by the white side of the Kodak Gray Card.

  • Page 80: Data Collector

    PENTAX R-300 (p65-88) 10/30/02 12 DATA COLLECTOR 12 DATA COLLECTOR The instrument can communicate directly with a computer through the RS232C interface. By use of a data collector you can automate data entry from the collection of survey data to the transfer of the data to a computer. This is useful in saving time and protecting data integrity.

  • Page 81: Appendix

    PENTAX R-300 (p65-88) 10/30/02 13-1 Error Messages Message Out of tilt range Displayed when the instrument is tilted beyond the vertical compensation range (±3') in case 1 axis or 2 axis automatic compensation is selected. This message may be temporarily displayed if the instrument is turned too fast.

  • Page 82: Atmospheric Correction

    PENTAX R-300 (p65-88) 10/30/02 11:11 AM Page 80 13 APPENDIX 13-2 Atmospheric Correction The speed at which light travels through the air varies depending on the temperature and atmospheric pressure. The R-100 series is designed to measure distances at the speed of light in order to measure accurately, Atmospheric Correction needs to be used.

  • Page 83: Hpa And Mmhg Conversion Tables

    PENTAX R-300 (p65-88) 10/30/02 13-3 hPa and mmHg Conversion Table Converting from hPa to mmHg mmHg 1000 1100 1200 Converting from mmHg to hPa mmHg 1067 1080 1200 1213 11:11 AM Page 81 mmHg mmHg mmHg mmHg mmHg 1000 1013...

  • Page 84: Error When No Atmospheric Correction Is Made

    PENTAX R-300 (p65-88) 10/30/02 13 APPENDIX 13-4 Error when no Atmospheric Correction is made When measurement is carried out with no Atmospheric Correction (with the settings fixed at a temperature of 15°C and an atmospheric pressure of 1013 hPa or 760 mmHg), the Error per 100 meters in temperature and pressure will be shown in the tables below.

  • Page 85: Atmospheric Refraction And Earth Curvature Correction

    PENTAX R-300 (p65-88) 10/30/02 13-5 Atmospheric Refraction and Earth Curvature Correction Atmospheric refraction and earth curvature correction refers to correcting both the bending of the light beam caused by atmospheric refraction and the effect on the height differential and horizontal distance caused by the earth curvature.

  • Page 86: Distance Range

    PENTAX R-300 (p65-88) 10/30/02 13 APPENDIX 13-6 Distance Range Generally speaking, the maximum range which can be measured varies considerably depending on the atmospheric conditions. For this reason, the Specifications illustrate the values for both Good and Normal weather conditions.

  • Page 87: Notice To The User Of This Product

    1) Specifications of Laser Radiation A) The EDM module of the R-300 produces a visible light beam, which is emitted from the telescope objective lens and the center hole of the instrument base plate. The R-300 is designed and built to have a laser diode radiating at 620-690 nm.
  • Page 88 PENTAX R-300 (p65-88) 10/30/02 14 NOTICE TO THE USER OF THIS PRODUCT Aperture label Aperture label 11:11 AM Page 86 Warning label Laser beam is transmitted from this aperture. Warning logotype Warning logotype For R-300N model For R-300N model For R-300 model For R-300 model Laser beam is transmitted from this aperture.
  • Page 89 PENTAX R-300 (p65-88) 10/30/02 11:11 AM Page 87 14 NOTICE TO THE USER OF THIS PRODUCT [TARGET PLATE]...
  • Page 90 PENTAX R-300 (p65-88) 10/30/02 11:11 AM Page 88...
  • Page 91 PENTAX R-300 (p01-19) 10/30/02 Member symbol of the Japan Surveying Instruments Manufacturers’ Association representing the high quality surveying products. 11:20 AM Page b ® 2-5-2, Higashi-Oizumi, Nerima-ku, Tokyo, 178-8555, Japan Tel: +81-3-5905-1222 Fax:+81-3-5905-1225 10.2002 First Edition TS01101E...
