Installation Manual
Silver Plus Freestanding
1

Advertisement

loading

Summary of Contents for palmiye SILVER PLUS

  • Page 1 Installation Manual Silver Plus Freestanding...
  • Page 2 Dear Customer, Installation manual contains suggestions and rules for fast and exact installation of our product. We recommend you to read our instruction carefully. During installation, all necessary actions have to be carried out by authorized and specialized technicians. All unauthorized interventions during warranty period will invalidate the warranty.
  • Page 3 INDEX 1. Symbols, Precautions and Warnings 2. Terminology 3. Packaging 4. Installation Steps 5. Programming / Resetting of Panels and Lights 6. Sensors and Automation 7. Hardware 8. Tools 9. Frequently Asked Questions 10. Risk Table 11. Motorization...
  • Page 4 In case of anomalies, immediately stop the work and contact with hospital. Palmiye will not be responsible on use of non-original parts or unauthorized interventions and modifications for damage caused to people or animals or property.
  • Page 5 2. TERMINOLOGY BOM ID Description Back Beam - 100x150mm Front Pillar - 100x100mm - Full Drainage Front Pillar - 100x100mm - Half Drainage Front Pillar - 100x100 w/o Drainage Side Beam Pillar - 100x100mm Cross Beam - 40x120mm Side Beam Pillar (Until Rail) -50x100mm Back Pillar - 100x100mm Side Beam - 50x150mm Special Side Beam - 100x150mm...
  • Page 6 In case of anomalies, immediately stop the work and contact with hospital. Fixing elements such as screws, plugs etc. are included in the box. If not please contact service department of Palmiye. Do not use a knife to avoid the risk of ruining the paint or other materials.
  • Page 7 3.2.2. Rail BOM ID Description 4 Wheel Carriage M4, 8x25mm self-drilling screw Back roll bearing set Fixed area Square nut Front roll bearing set M8x16 hexagonal hed bolt Rail - 120x150x3mm Al. Rail Gasket GS294 Rail Profile Cast Aluminium End Cap - Roundec Rail Rear Connection Apparatus Left Rail Rear Connection Apparatus Right...
  • Page 8 3.2.3. Front Beam BOM ID Description BOM ID Description 100X150 Profile Attachment Alu 20 cm 100X150 Profile Attachment Alu 40 cm 100x150 Profile Attachment Alu 20 cm 4,8X25 Self Tapping Screw Front Beam - 100x150x3mm Al. 100x150 Profile Attachment Alu 40 cm Front Beam Cast Aluminium Cap - Rounded 100x150 mm 2 Front Beam Rail Connecting Apparatus - PLUS 4,8x25 Self-drilling Screw...
  • Page 9 3.2.5. Side Beam (Standard) BOM ID Description 50x150mm Aluminum Profile 1 BOM ID Description 50x150mm Aluminium Profile 3.2.6. Side Beam (Special) BOM ID Description 1-2 (Welded) Aluminum Profile 50x150-50x100 1 BOM ID Description 1-2 (Welded) Aluminium Profile 50x150-50x100...
  • Page 10 3.2.7. Boxes 1. Electrical Box Electrical Equipments - Lighting box, Synchronized control box, Remote Controls, Sensors - are inside Electric box. It has a red label on the box. ELECTRIC 2. Metal Box U Brackets, Mounting brackets, Gutter caps, Front beam and Rail connecting bracket caps, Hexagonal motor shaft drives, M12x185mm countersunk dacromented bolt, M10x160mm hexagonal dacromented bolt, M4,8x25mm self-drilling screws, M5,5x25mm self-drilling with sealant washer screws, drainage elbow, Stainless steel anchorages, (If you have a decorative...

  • Page 11: Installation Steps

    4. INSTALLATION STEPS 4.1. Structure Installation • 4.1.1. Back beam and Back Pillar Installation Back beam and back pillar should be connected by M12x185mm dacromented rod on ground.
  • Page 12 4.1.2. Front Beam and Front Pillar Connection In order to prevent water leakage, you should apply a sealant to the connection points between the drainage-able elbow and front pillar. Place elbow to the pillar. The drainage elbow should face inward. Aluminium Front Pillar Full Cutted Aluminium Front Pillar Full Cutted Aluminium Drainage Elbow Plus - Full...
  • Page 13 Front beam and front pillar connection bolts should be fastened on the ground after lifted as shown image below. M12x185 Countersunk Bolt M12x185 Countersunk Bolt In this situation you may need some people since you must hold pillars carefully. In this stage of installation , front pillars do not need to be their exact points. Exact points of front pillars is determined after 4.1.6.
  • Page 14 4.1.3. Hidden Side Beam Fixing If you have preferred a hidden side beam connection, follow the steps below. Skip this section if you have selected a standard side beam connection. There are two options on hidden side beam. 4.1.3.1. 50x150mm Aluminium Fix the apparatus to the profile with 3 Pass the profile into the fixed apparatus.
  • Page 15 Fix it with 3 pieces of 4.8x25 mm self-tapping screws from the right and left sides and the assembly is completed. 4.1.3.2. 100x150mm Aluminium Fix the apparatus to the wall/pillar with 6 5.5x50mm self-tapping screws and chemical dowel. Pass the profile into the fixed apparatus. Fix the profile to the bracket with 3 4.8x25mm The profile is aligned on the front beam as self-tapping screws from both sides.
  • Page 16 On the other side; if there is a drainage point, Fix the apparatus to the front beam with 6 the U apparatus comes in as a ridge and in pieces of 4.8x25 mm self-tapping screws. half drainage. Attach the profile so that it passes over the Fix it with 3 pieces of 4.8x25 mm self-tapping fixed apparatus.
  • Page 17 4.1.4. Rail Placing There are two type rails. One of them without gasket and another one with gasket which located bottom of the rail and according to rail position. When you looking in front of the product the gasket must be inside of the product as you see at below picture. gasket gasket During rail bolts fastening to back beam and front beam you will need someone else...
  • Page 18 The rails are mounted to the rail brackets on the back beam with the help of 4 M8X20 bolts. M8 Washer Stainless Steel M8 Washer Stainless Steel M8 Nut M8 Nut M8x20 Socket head Allen Stainless Steel M8x20 Socket head Allen Stainless Steel Shaft holes must overlap one to one.
  • Page 19 M4,8x25mm Self-Tapping Screw M4,8x25mm Self-Tapping Screw At first, just fasten one screw. The rest shall be fixed after cross check. Lastly, put the rail caps.
  • Page 20 4.1.5. Cross Check and Level Control...
  • Page 21 4.1.6. Pillar Fixing Freestanding products have base plates on front and back pillars. The pillars are 100x100mm Aluminium or 100x100mm Steel, according to the product dimensions. Unless otherwise stated, the flange directions shall be produced as shown in the diagram below.
  • Page 22 4.1.7. Gutter Fixing Place the cap and fasten by screws. If there is water outlet on the corner pillar, make sure the gutter profile fits on the elbow properly. Place as temporary gutter profile to front beam in order to define the drainage hole and adjust according to the drainage elbow position and mark with pen on bottom of the gutter.
  • Page 23 Using a punch, make a hole of Ø80mm for full drainage / Ø40mm for half drainage, inside of the marked position for drainage. Create a drip edge with Palmiye’s Gutter Hole Bending Apparatus (DMR.APR.P1066.ELGV). Apply the sealant behind the gutter profile before installing it.
  • Page 24 Carry out to self-drilling screw related line on gutter. There are 6 types of gutter rubber size (Defined on your production document). • SP130 = 30mm (1 3/16”) only gutter gasket • GS451 = 50mm (2”) only gutter gasket • 30 mm gutter gasket with 30 mm gutter gasket extension profile •...
  • Page 25 Fix gutter connector by M5,5x25mm self-drilling screw with washer. Apply a sealant around gutter connector. Place the gutter side cap to end of gutter.
  • Page 26 Rain Gutter Rain Gutter Gutter Gasket Gutter Gasket Aluminium Gasket Strip Profile Aluminium Gasket Strip Profile Gutter Side Cap Right Gutter Side Cap Right Applying type at below; Place gasket to the gutter channel. Secondly, apply the adhesive glue as approximately 10cm (4”) to gasket channel where is end of the gutter then the adhesive glue will dry.
  • Page 27 Pull gasket and apply a glue Pull gasket and apply a glue If a strainer is preferred, place the strainer on the water outlet in the gutter profile and apply silicone. Silicon Water Outlet...
  • Page 28 4.2. Motor Box Installation 4.2.1. Motor Box Fixing Motor box should be centered in between two rails. Motor box should be centered in between two rails. All carriers must be on the rear.
  • Page 29 4.2.2. Motor Shaft Driver Installation Place a Hexagonal shaft spindle to transmission tube. On edge sides 40cm (1’ - 3 ¾”) shaft spindle is used while on middle 70cm (2’ – 4”) shaft spindle is used. Shaft Transmitter Plastic Shaft Transmitter Plastic Shaft Spindle Shaft Spindle Transmission Tube...
  • Page 30 Insert a shaft transmitter plastic to transmission tube. Shaft Transmitter Plastic Shaft Transmitter Plastic Shaft Spindle Shaft Spindle Place a shaft spindle and insert shaft transmitter plastic to there.
  • Page 31 There must be at least 1cm (1/2”) of gap between the rail bracket and the transmitter plastic. Also, on edge side there are 2 shaft transmitter plastic. Fasten bolts on shaft transmitter plastic. There is only 1 shaft transmitter plastic on each side on middle rail location.
  • Page 32 4.3. Fabric Installation If the product width is bigger than 800cm (26’ – 3”), the fabric support profile is not installed on the fabric in factory production. In this situation you must install the fabric support profiles to the fabric on site. Double channeled fabric support profile’s gasket goes to the end without any separation.
  • Page 33 Double channeled fabric support profile Double channeled fabric support profile Double channeled side plastic Double channeled side plastic...
  • Page 34 However, Single channeled fabric support profiles have designed a gap according to the rail position. Single channeled fabric support profile Single channeled fabric support profile Single channeled side plastic Single channeled side plastic...
  • Page 35 Note that if you have a lighting system, the fabric will be sent with wired harness. Therefore, profile with LED must be placed to related gasked which you can define with wire output at the side channel of fabric. Single channeled middle plastic Single channeled middle plastic In order to cabling, exiting hole can be used in the side plastic.
  • Page 36 First you need to fix one side of fabric support profile. The fabric should be stretch properly. In order to this, PALMIYE designed a special tool called Fabric Stretching Equipment . When fabric is pulled to the end of the fabric support profile it means fabric has stretched.
  • Page 37 After stretching you need to fix it. M3,5x18mm philips head screw M3,5x18mm philips head screw In order to install to the retractable pergola carriers there must be a hole. You should make a hole carefully by Palmiye special fabric hole cutter. Part Code: HRD.TKM.G1039.BRUT...
  • Page 38 When you stretched to whole fabric support profile the fabric will be ready to integrate to retractable pergola. In this operation you should use to lift or our special fabric elevator. Thus, you are able to lift up without any damage to the fabric. Fabric support profile connection points needs to be lifted aligned and at same time.
  • Page 39 If you have a decorative fabric, you must follow the same operations. In addition, you should slide the deco fabric then fasten from one side then stretch other side. At the end the valance fabric shall be installed to the back-fabric support profile. Firstly, there must be fix valance strip profile to bottom of the back beam.
  • Page 40 Now, you can use Velcro on the valance profile and valance fabric, you can stick fabric using Velcro. 4.4. Cross Beam Installation In order to fix the cross beam, you should define an exact U Bracket position. It means, firstly you have to check fabric cover sheet length, after that you can place to U bracket according to that dimension.
  • Page 41 The fabric cover sheet must be extended from the cross beam at least 1cm (1/2”). Cross beam gasket Cross beam gasket There are 2 different cross beam which is 40x120mm it’s located on back and frontier is 42x150mm with gasket. The gasket ensures that air does not leak.
  • Page 42 4.4.1. Control Box Installation Synchronized motor control box and / or lighting control box can fix to the cross beams. In this case, the control box shouldn’t touch the fabric cover sheet on top. 4.4.2. Exact Covering If there is a gap between front fabric profile and gutter.
  • Page 43 Secondly, adjust proper position and tighten the nut. And place the back-fabric support profile. All fixed carriers should move at equal distance from the end of rail profile. 4.4.3. Module Connection If there are two products where is located side by side, you must apply a sealant. Place T profile.
  • Page 44 4.5. Fabric Cover Sheet Installation 4.5.1. Side Covering Before fabric cover sheet fixing, you can place the side cover profile; 4.5.2. Fabric Cover Sheet Place the fabric cover sheets. Fabric Cover - Al. 63x100mm Fabric Cover - Al. 63x100mm Fabric Cover - Al. 63x100mm Fabric Cover - Al.
  • Page 45 4.5.3. Back Finish 100x100mm angle is used for back finish. 4.6. Side Beam There are two options on side beam. 50x150mm Aluminium It cannot be applied with full drainage on corner pillar. 100x150mm Aluminium special It is produced by welded 50x100mm and 50x150mm profiles. It cannot applied with full drainage.
  • Page 46 4.6.1. Fixing L Bracket to Front beam L Bracket must be fix 6mm (2 ½”) outside of the corner pillar alignment. The red zone is 6mm (2 ½”). 4.6.2. Fixing U Bracket to Wall/Side Beam Back Pillar Side Beam - 50x150mm Al. Side Beam - 50x150mm Al.
  • Page 47 If there is a triangle glass product, a sealant must be applied on top of the side beam profile. Place side beam to U bracket on back and align with L bracket on front then fasten screws. In addition, the side beam can be fix same align with gutter/front beam.
  • Page 48 4.7. Side Beam Pillar There are two options on side beam pillar. 4.7.1. Until to Side Beam For 50x100mm side beam pillar; You must choose 50x150mm side beam. For 100x100mm side beam pillar; You must choose 100x150mm special side beam. Define the side beam pillar top U bracket and fasten screws to side beam as you see at below.
  • Page 49 4.8. External Square Downpipe Installation If there is a steel pillar or you want to have additional downpipe, you may use External Square Downpipe. It’s 100x100x3mm Aluminium, you can integrate water elbow which is drain from gutter to below of the pillar. Sealant Sealant For more information related to Gutter Drilling, please refer to 4.1.7...
  • Page 50 Use only SOMFY RTS radio controls. The receiver (433,42 MHz) must be programmed with transmitters. 5.2. Remote Control Button Configurations Silver Plus Freestanding is integrated with linear tube motor with radio control for opening, closing or stopping the fabric support profiles use the respective buttons (see figure). There are 4 different remote-control models.
  • Page 51 5.3. Remote Types Situo 1 RTS Situo 5 RTS TELIS 16 Channels Battery Type 2430 Lithium LR03AAA Battery Voltage 1,5 V Thickness Width Height Colour Silver Silver & Pure Compatibility Compatible with a range of Somfy RTS enabled products Radio Frequence For indoor use Radio Range 433,42 MHz...
  • Page 53 5.4. Replacing The Battery Using a small screwdriver loosen the screws on the reverse side of the remote control and remove the back cover. Replace the battery with one 2430 Lithium 3V Battery. 5.5. Programming 5.5.1. Single Motor (OREA RTS) for 230VAC / 50Hz Step 1: There isn’t any control unit box at single motor products.
  • Page 54 Step 7: Press “MY” button CONSTANTLY until motor jogs to confirm the settings (5 seconds). Step 8: Finally, press the “PROGRAMING BUTTON” on the back of the transmitter until the motor jogs (to leave the installation mode). *Front limit doesn’t need to be set for Single Motor (OREA RTS) product as the motor will stop automatically when fabric is stretch.
  • Page 55 Step 10: Finally, press the “PROGRAMING BUTTON” on the back of the transmitter until the motor jogs (to leave the installation mode). *Front and Back limit needs to be set for Single Motor (ALTUS 50 RTS) product. 5.5.3. Double Motor Step 1: Please have a look at the schedule of below diagram.
  • Page 56 Step 3: Move from “Auto” to ”0” button on the control unit box, motor will jog briefly. Step 4: Choose your desired channel on the Remote control. Step 5: Remove the cap of the Somfy control unit (Centralis UNO RTS) on the control unit box and press the “PROG”...
  • Page 57 Step 6: Press and hold the PROG button back of the remote control, until motor will jog briefly. Step 7: Move from “0” to “Auto” button on the control unit box, motor will jog briefly. Now, you can control to motor by your remote control. Step 8: Right and Left Motor has a switch (Yellow and White).
  • Page 58 Step 10: Press the down button on remote control until the same align Cross beam reaches the required back position, then stop it. Step 11: Check the back-limit position. If the motors don’t stop automatically Yellow button isn’t true. You must return the last position to Yellow Button. Correct button is White button. Motor head by pressing and releasing it.
  • Page 59 Step 13: Check the front limit position. If the motors don’t stop automatically White button isn’t true. You must return the last position to White Button. Correct button is Yellow button. Motor head by pressing and releasing it. The front limit is now set. 5.5.4.
  • Page 60 5.6. Resetting 5.6.1. Single Motor Step 1: While provided power to OREA motor unplug for 2 seconds Step 2: Plug in 10 seconds Step 3: Unplug 2 seconds Step 4: Plug in 10 seconds, the OREA motor will jog briefly Step 5: Press and hold the PROG button on the back of Remote Control for more than 7 seconds until the OREA motor jog briefly 2 times.
  • Page 61 6. SENSORS & AUTOMATION 6.1. Sensors 6.1.1. Single Motor Connection to EOLIS RTS (Wind Sensor) 6.1.1.1. Cabling 6.1.1.2. Programming The motor must be in its learning mode to record an EOLIS RTS Sensor. Up to three EOLIS RTS Sensors can be memorized in a motor and one EOLIS RTS Sensor can be memorized in several motors.
  • Page 62 • Erase all the sensors and record a new one; • Press more than 7 sec. on the “prog” button of the new EOLIS RTS sensor. • The pergola moves shortly (DOWN/UP) 6.1.1.3. Functioning The WIND threshold can be adjusted by a potentiometer accommodate wind speed between 10 to 50km/h (6 to 31mph) •...

  • Page 63: Setting Instructions

    6.1.2.2 Operation The SOLIRIS RTS Sensor controls and provides a measure of protection for a retractable pergola according to the sun and wind conditions. The WIND and SUN thresholds can be adjusted by two potentiometers, one for wind speed and the other for daylight intensity. The adjustment range is between 10 –...

  • Page 64: User Mode

    THRESHOLD USER MODE DEMO MODE Under sun level: RED LED Continues light during 5 sec. Blinking light during 30 sec. Over sun level: GREEN LED Continues light during 5 sec. Blinking light during 30 sec. By pressing MODE button > 2 sec. > the light will start blinking for 30 sec.
  • Page 65 READJUSTING ADJUST THE SUN LEVEL WITH THE POTENTIOMETER ACCORDING TO YOUR WISHES 1 turn to left (-) 2 Turn to right (+) LESS sun is needed to lower the blind MORE sun is needed to lower the blind 6.1.3. Single Motor Connection to ONDEIS (Rain) Sensor Rain sensor requires a dry contact input.
  • Page 66 6.1.4.1. Universal Receiver RTS Inside Description Prog. LED Prog button Test button Sensor live (brown) Sensor neutral (blue) Power supply live (brown) Power supply neutral (blue) Motor common Motor DOWN Motor UP Power supply earth (yellow/green) Motor earth (yellow/green) 6.1.4.2. Programming •...
  • Page 67 • Enter Programming Mode; • Press the programming button of the Universal Receiver -> 2sec until the motor feedback and LED lights. • Record/Delete the transmitter; • Press briefly prog button of the sensor -> motor feedback / LED of receiver blinks.
  • Page 68 When you plug all cables now you can program to rain sensor. • Select the RTS address on the channel selector corresponding to dry contact connectors. • Press to PROG button on your remote control. • Then press PROG button on RS485 or Dry Contact Transmitter. If you supplied any time (after order or installation) you can change it.
  • Page 69 Neutral: Blue cable no:4 • Phase: Red cable no:5 If you have ONDEIS Rain sensor you must inform before the order. Then Palmiye will send Universal Receiver RTS instead of Centralis UNO RTS on during the production. 6.2. Automation 6.2.1. Adaptable to Somfy Systems Our Retractable Pergola Systems can be controlled by Somfy Home Automation Smart System which is CONNEXOON®...
  • Page 70 • Only RTS motors can be controlled by RS485 RTS Transmitter or Dry Contact Transmitter. • RS485 have a 5 dry contact input and Dry Contact Transmitter have only one input. • Select the RTS address on the Channel selector corresponding to dry contact connectors. •...
  • Page 71 7. HARDWARE 7.1. Back Beam - Back Pillar Connection M12x185mm countersunk head bolt M12x185mm countersunk bolt M12x185mm countersunk bolt Back beam profile Back beam profile Back pillar profile Back pillar profile 7.2. Rail - Back Beam Connection M8x20mm countersunk head bolt M8 stainless steel washer M8 stainless steel nut M8 Washer Stainless Steel...
  • Page 72 7.3. Rail – Front Beam Connection M4.8x25mm self-drilling screw M4,8x25mm Self-Tapping Screw M4,8x25mm Self-Tapping Screw 7.4. Pillar – Front Beam Connection M12x185mm hexagonal head dacromented bolt M12x185mm Countersunk Bolt M12x185mm Countersunk Bolt...
  • Page 73 7.5. Pillar – Ground Connection M12x200mm Galvanized Rod M12 Stainless Steel Washer M12 Stainless Steel Nut M12 Nut Stainless Steel M12 Nut Stainless Steel M12 Washer Stainless Steel M12 Washer Stainless Steel M12 Galvanized Rod M12 Galvanized Rod 7.6. Motor – Back Beam Connection M5.5x25mm self-drilling screw with washer M5,5x25mm Self-Tapping Screw M5,5x25mm Self-Tapping Screw...
  • Page 74 7.7. Fabric – Carrier Connection M8 nut with sealant. M8 nut with sealant M8 nut with sealant 7.8. Gutter – Front Beam Connection M5.5x25mm self-tapping screw with washer. M5,5x25mm Self-tapping Screw M5,5x25mm Self-tapping Screw...
  • Page 75 7.9. Side Beam – Front Beam Connection M4.8x25mm self-drilling screw. M4,8x25mm Self-Tapping Screw M4,8x25mm Self-Tapping Screw 7.10. Side Beam – Wall Connection M4.8x25mm self-drilling screw. M4,8x25mm Self-Tapping screw M4,8x25mm Self-Tapping screw...
  • Page 76 7.11. Side Beam – Side Beam Pillar Connection M4.8x25mm self-drilling screw. M4,8x25mm Self-Tapping Screw M4,8x25mm Self-Tapping Screw 7.12. Cross Beam – Rail Connection M4.8x25mm self-tapping screw. M4,8x25mm Self-Tapping Screw M4,8x25mm Self-Tapping Screw...
  • Page 77 M4.8x25mm self-tapping screw. M4.8x25mm self-tapping screw M4.8x25mm self-tapping screw 7.13. Fabric Cover Sheet – Cross Beam Connection M5.5x25mm self-drilling screw with washer.

  • Page 78: Product Code

    Gutter Drainage Hole to bend the drainage Bending Apparatus hole on gutter which is DMR.APR.P1067.ELGV (ø50mm) making on site Palmiye T-Shirt for Installation teams HZM.ISG.G1009BRUT Palmiye Trousers for Installation teams HZM.ISG.G1014.BRUT Palmiye Waistcoat for Installation teams HZM.ISG.1013.BRUT...
  • Page 79 Image Product Description Product Code to anchor rods to Epoxy HRD.KMY.G1027.BRUT concrete to fix and stabilaze M12 Rod products to ground/ HRD.CVT.G0100.ZINC wall/ceiling to fix and stabilaze M30 - Rod Galvanized products to ground/ HRD.CVT.G0105.ZINC wall/ceiling part to to fix and M12 Rondela Washer stabilaze products to HRD.CVT.G1062.PSMZ...

  • Page 80: Installation Tool List

    INSTALLATION TOOL LIST Tool box with wheel 1 pc Spiral grinder 1 pc Batery driller. 1 pc Electric impact drill 1 pc Lighting 2 pc Extansion lead 2 pc Ladder 2 pc Tape measure 5m 1 pc Tape measure 10m 1 pc Water gauge 2 pc...
  • Page 81 Allen wrench set 2 Set Socket wrench 1 pc Screw driver 1 Set Plastic hammer 1 pc Iron hammer 2 pc Electrical screw driver 2 pc Cutter 1 pc Slicon gun 2 pc Bits 2 Set PH2X100 Bits 2 pc APEX 493 A Bits 2 pc Insulating Tape (Black)

  • Page 82: Frequently Asked Questions

    Open the control panel and Broken fuse change the fuse Possibly broken belts, or The motor starts but the disconnection from drive Contact Palmiye pergola won’t move shaft. Clean the rails. Follow The pergola moves errati- Dirty rails, rails not properly...
  • Page 83 10. RISK TABLE...
  • Page 84 11. MOTORIZATION According to retractable pergola size; single and double motors are used. 11.1. Single Motor Somfy Orea 60 RTS motors are used on 230VAC/50Hz using electricity countries. Somfy LT60 Altus RTS motors are able to uses on 120VAC/60Hz using electricity countries. They are controlling by remote control device Nominal Nominal...
  • Page 85 11.2. Double Motor Somfy LT60 WT motors are used in countries using 230VAC/50Hz electricity. Somfy LT60 STANDARD WT motors are used in countries using 120VAC/60Hz electricity. Systems are controlled by remote control devices over control box. Nominal Nominal Rated Rated Thermal Noise Torque...
  • Page 86 www.palmiye.eu...
