- Page 1 SD Multi AV Device Operating Instructions SV-AV10E/B/EN Model No. Before use, please read these instructions completely. VQT9775...
-
Page 2: Table Of Contents
Contents Information for Your Safety ... 3 Caution for AC mains lead (SV-AV10B only) ... 3 Introduction... 4 Power supply frequency... 4 Preparation Standard Accessories ... 4 Optional Accessories... 4 Controls and Components... 5 Attaching the Neck Strap... 5 Power Supply ... 6 Using AC Adaptor ... -
Page 3: Information For Your Safety
Dear Customer, We would like to take this opportunity to thank you for purchasing this Panasonic SD Multi AV Device. Please read these Operating Instructions carefully and keep them handy for future reference. Information for Your Safety WARNING TO REDUCE THE RISK OF FIRE OR SHOCK... -
Page 4: Introduction
Home Edition/XP Professional) (VFF0143) Panasonic Media Manager (real jukebox (VFF0148) ≥For the installation and the operation of the Panasonic Media Manager, refer to the additional instructions supplied in the same package. ≥For using the SD-MovieStage software, refer to the PDF manual. -
Page 5: Controls And Components
2) 3) DC IN 4.8V Ë Controls and Components 1) LCD Monitor (l 7) 2) Recording Start/Stop Button (l 14, 16, 18) 3) Card Slot Cover (l 7) 4) Card Slot (l7) 5) Card Access Lamp (l 7) 6) Power ON/OFF Button [ ] (l 8) Menu Button [MENU] (l 9) 7) Power Lamp (l 8) -
Page 6: Power Supply
DC IN 4.8V Using the Battery DC IN 4.8V Removing the Battery Power Supply ª Using AC Adaptor Connect the AC Mains Lead to the AC Adaptor and the AC mains socket. ≥The AC Mains Lead does not fit entirely into the AC Adaptor socket. -
Page 7: Inserting A Card
Inserting a Card Removing the Card Inserting a Card Slide the Card Slot Cover , and flip it to open. ≥Turn off the SD Multi AV Device, when inserting a Card. Hold the Memory Card placing the cut off corner left and showing the label frontward, and then insert it fully until it clicks. -
Page 8: Turning The Power On
PLAY VOICE MPEG4 PICTURE Turning the Power ON Install the battery or plug in the AC adaptor. (l 6) Hold down the [ ≥The SD Multi AV Device is turned on. ≥The message [PLEASE WAIT] is displayed for a while and then the mode selection screen will be displayed. -
Page 9: Using The Menu Screen
3,4,5 PICTURE RECORD RECORDING SETUP OTHER FUNCTIONS PRESS MENU TO RETURN RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY PRESS MENU TO RETURN ª REC MODE MPEG4 RECORD RECORDING SETUP OTHER FUNCTION PICTURE RECORD " RECORDING SETUP OTHER FUNCTIONS VOICE RECORD FUNCTIONS Using the Menu Screen Allows the functions useable in the selected mode to be set from the... -
Page 10: Playback Mode
Sub-Menu for REC MODE RECORDING SETUP MPEG4 MODE FINE NORMAL ECONOMY1 ECONOMY2 OTHER FUNCTIONS DATE/TIME TIME DISPLAY LCD SET LCD MONITOR NORMAL UPSIDE-DOWN AC MAINS 50HZ 60HZ CLOCK SET PRESS MENU TO RETURN RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY OTHER FUNCTIONS DATE/TIME... - Page 11 Sub-Menu for PLAYBACK CARD EDITING ERASE ALL FILES FILE PROTECTION CARD FORMAT OTHER FUNCTIONS DATE/TIME TIME DISPLAY LCD SET DISPLAY SIZE FULL NORMAL LCD MONITOR NORMAL UPSIDE-DOWN CLOCK SET PRESS MENU TO RETURN CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT...
-
Page 12: Setting The Power Supply Frequency
1,2,3 PLAY VOICE MPEG4 PICTURE MPEG4 RECORD RECORDING SETUP OTHER FUNCTIONS PRESS MENU TO RETURN OTHER FUNCTIONS DATE/TIME TIME DISPLAY LCD SET LCD MONITOR NORMAL UPSIDE-DOWN AC MAINS 50HZ 60HZ CLOCK SET PRESS MENU TO RETURN 1/100 1/120 Setting the power supply frequency Set the power supply frequency before using the SD Multi AV Device. -
Page 13: Adjusting Brightness And Colour Level
1,2,3,4 MPEG4 RECORD RECORDING SETUP OTHER FUNCTIONS PRESS MENU TO RETURN OTHER FUNCTIONS DATE/TIME TIME DISPLAY LCD SET LCD MONITOR NORMAL UPSIDE-DOWN AC MAINS 50HZ 60HZ CLOCK SET PRESS MENU TO RETURN LCD SET BRIGHTNESS COLOUR LEVEL PRESS MENU TO RETURN 1,2,3 OTHER FUNCTION DATE/TIME... -
Page 14: Basic Functions
≥The MPEG4 moving pictures can be recorded in any mode, but moving pictures recorded in the [FINE], [NORMAL] or [ECONOMY 1] mode may not be played on other Panasonic digital video cameras. The message [Press RESET button.] may be displayed in such case. This is not a fault of the camera. -
Page 15: Playing The Moving Picture (Mpeg4)
1,2,3 PLAY MPEG4 VOICE PICTURE MUSIC MPEG4 . ASF . ASF . ASF . ASF . ASF . ASF OTHER FUNCTIONS DATE/TIME TIME DISPLAY LCD SET DISPLAY SIZE FULL NORMAL LCD MONITOR NORMAL UPSIDE-DOWN CLOCK SET PRESS MENU TO RETURN Playing the Moving Picture (MPEG4) Plays back moving pictures recorded on the card. -
Page 16: Recording Still Pictures
1,2,3,4 PLAY MPEG4 VOICE PICTURE PICTURE RECORD RECORDING SETUP OTHER FUNCTION PRESS MENU TO RETURN RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY PRESS MENU TO RETURN RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY PRESS MENU TO RETURN PICTURE R 15 Recording Still Pictures Records still pictures. -
Page 17: Playing Back Still Pictures
1,2,3 PLAY MPEG4 VOICE PICTURE MUSIC PICTURE 100 - 0001 100 - 0002 100 - 0003 100 - 0004 100 - 0005 100 - 0006 Playing back Still Pictures Plays back still pictures recorded on the card. Set the Operation Mode to [PLAY>>PICTURE] ≥Still picture files recorded on the card are displayed in the form of a list (six files per page) 2. -
Page 18: Recording Voice (Voice Recording Function)
PLAY MPEG4 VOICE PICTURE VOICE 0h10m14s R0h10m Recording Voice (Voice Recording Function) You can record voice data on the card. Set the Operation Mode to [RECORD>>VOICE] Press the Recording Start/Stop Button. ≥Recording starts. Speak into the built-in microphone Device. ª To stop recording While recording Voice, press the Recording Start/Stop Button. -
Page 19: Hearing The Voice Recorded (Playback Sound)
Ë 2,3,4 PLAY MPEG4 VOICE PICTURE MUSIC VOICE . VM1 . VM1 . VM1 . VM1 . VM1 . VM1 Hearing the Voice Recorded (Playback Sound) Plays back the voice files recorded by this SD Multi AV Device. Plays back the voice files recorded by this SD Multi AV Device. Wear the Earphone (supplied) to listen to the sound. -
Page 20: Listening To Music (Music Play)
While playing back, move the Jog Lever up or down. ≥Only the MPEG2-AAC formatted file and MP3 (data recorded using Panasonic Media Manager) is applicable to play on your SD Multi AV Device. ≥Music playback is not possible with a MultiMediaCard. -
Page 21: Using The Earphone
≥Normal MP3 files cannot be played back. Use the data created with Panasonic Media Manager. ≥Some MP3 or MPEG2-AAC files which were written with Panasonic Media Manager may not be played back. ≥The bit rates (recommended) supported are 64 kbps, 96 kpbs or 128 kbps for both the MPEG2-AAC and MP3 files. -
Page 22: Advanced Functions
PLAY MPEG4 VOICE PICTURE PLAY MPEG4 VOICE PICTURE Advanced Functions Backlight Compensation Function This prevents a recording subject from being recorded darker in backlight. (Backlight is the light that shines from behind a recording subject.) Set the Operation Mode to [REC>>MPEG4] or [REC>>PICTURE] Move the Jog Lever up for about 1 second. -
Page 23: Erasing The Files Recorded On A Card
ERASE CARD FILE FILE PROTECTION DPOF SETTING CHECK EXIT ERASE FILE RETURN CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT PRESS MENU TO RETURN Erasing the Files Recorded on a Card Using SD Multi AV Device, you can erase the files recorded on a Card. After the file is erased, it cannot be restored. -
Page 24: Protecting The File (Lock Setting)
ERASE CARD FILE FILE PROTECTION DPOF SETTING CHECK EXIT 100-0011 100-0012 100-0013 CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT PRESS MENU TO RETURN FILE PROTECTION LOCK ALL FILES UNLOCK ALL FILES PRESS MENU TO RETURN Protecting the file (Lock Setting) Precious files recorded on a Card can be locked (to prevent accidental erasure). -
Page 25: Writing Printing Data On A Card (Dpof Setting)25
ERASE CARD FILE FILE PROTECTION DPOF SETTING CHECK EXIT DPOF SETTING 100-0011 100-0012 100-0013 CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT PRESS MENU TO RETURN DPOF SETUP ALL 1 ALL 0 CHECK PRESS MENU TO RETURN Writing Printing Data on a Card (DPOF Setting) DPOF Setting Printing data (DPOF Setting), such as the number of... -
Page 26: Playing Back Still Pictures One By One (Slide Show)
≥By formatting, all data stored in the Card (e.g., still pictures, MPEG4 moving pictures, voice data, music data) is erased. ≥Format the Card on the SD Multi AV Device or on Panasonic Media Manager (supplied). A Card formatted on a machine other than the SD Multi AV Device may not be used. -
Page 27: For Using Sd-Moviestage
For using SD-MovieStage • For using the SD-MovieStage software, refer to the PDF manual. This manual describes installation only. Operating environment SD-MovieStage can be installed in a PC/AT compatible personal ® computer which can run Microsoft Windows Professional/XP. Compatible machines: PC/AT compatible PC with Microsoft Windows XP/2000 Professional pre-installed.(Intel higher CPU recommended) -
Page 28: Installing Sd-Moviestage
Installing SD-MovieStage Insert the supplied CD-ROM into the personal computer’s CD-ROM drive. Double-click [My Computer], double-click CD-ROM icon, double-click [SD-MovieStage Ver.1.0E], and double-click [SETUP.EXE]. Select the Language to be installed and click the [OK] Button. Click the [Next] Button. ≥The next screen will be displayed. Read License Agreement carefully, and click [Yes] Button, if you accept the terms of the agreement. -
Page 29: Cautions For Windows Xp/2000 Professional
Instructions for using the SD-MovieStage. Select [Programs] >> [Panasonic] >> [SD-MovieStage] >> [SD-MovieStage] from the Windows start menu. ≥SD-MovieStage will start. ≥If you use Windows 98SE, install Panasonic Media Manager (supplied accessory) before using the SD-MovieStage. Others Notes & Precautions ª... -
Page 30: Using A Card In A Personal Computer
Macintosh is required.) ≥When formatting a Card, format it on the SD Multi AV Device or on Panasonic Media Manager. ≥When a moving picture is played back on a personal computer, a black belt may be present along the top and bottom of the picture. -
Page 31: Indications
MPEG4 PLEASE WAIT 0h10m14s APR 10 2002 R 0h10m Indications 1) Remaining Battery Power [ When the battery power becomes low, the indication changes. When the battery level indicator indicates ], the battery will run out in a few minutes. Recharge the battery. -
Page 32: Cautions For Use
8) Displayed by the text [LOW BATTERY]: The battery may be exhausted. Replace it with fully charged battery. [NO CARD]: The Memory Card is not inserted. Otherwise, the Card may not be inserted correctly. [CARD FULL]: The memory capacity is fully utilized. Erase any unneccessaly files or replace it with a new card. -
Page 33: About The Lens
Do not use benzine, thinner or alcohol for cleaning the SD Multi AV Device. ≥The camera body may be deformed and the surface finish may peel off. ≥Before cleaning, detach the Battery or pull out the AC Mains Lead from the AC Mains socket. ≥Wipe the SD Multi AV Device with a soft dry cloth. -
Page 34: Notes On The Sd Memory Card Write-Protect Switch
The flashing speed suggests the following states. Flashing approx. every 0.5 seconds: ≥The SD Multi AV Device, battery or AC adaptor may be defective. Contact your nearest Panasonic dealer. Flashing approx. every six seconds: ≥The ambient temperature or that of the battery itself is too high or too low. -
Page 35: Before Requesting Service
Before Requesting Service If the trouble persists even when the action suggested below has been taken, press the the [ off the power and disconnect and re-connect the Power Cable. Consult your dealer. Power The SD Multi AV Device power cannot be turned Is the power source connected correctly? The SD Multi AV Device power shuts off automatically. -
Page 36: Specifications
Specifications SD Multi AV Device Power Source: Power Source: Power Consumption: Image Sensor: Lens: Monitor: Microphone: Standard Illumination: Minimum Required Illumination: Recording Media: Image Compression: Video Compression: Voice Compression: Music Expansion Dimensions: Weight: Operating Temperature: Operating Humidity: AC Adaptor Power Source: Power Consumption: DC Output: Dimensions:... - Page 39 ИНФОРМАЦИЯ О СЕРТИФИКАЦИИ ПРОДУКЦИИ BZ02 Информация для покупателя VQT9775 F0202Mk0( 0000 A) Matsushita Electric Industrial Co., Ltd. Web site: http://www.panasonic.co.jp/global/...
