SD Multi AV Device

Operating Instructions

SV-AV10U
Model No.
Before use, please read these instructions completely.
For USA assistance. please call:1-800-211-PANA(7262) or send e-mail to:consumerproducts@panasonic.com
For Canadian assistance. please call:1-800-561-5505 or visit us at www.panasonic.ca
VQT9629

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SV-AV10

Summary of Contents for Panasonic SV-AV10

  • Page 1: Operating Instructions

    SD Multi AV Device Operating Instructions SV-AV10U Model No. Before use, please read these instructions completely. For USA assistance. please call:1-800-211-PANA(7262) or send e-mail to:consumerproducts@panasonic.com For Canadian assistance. please call:1-800-561-5505 or visit us at www.panasonic.ca VQT9629...

  • Page 2: Table Of Contents

    Contents Information for Your Safety ... 3 Introduction... 4 Power supply frequency... 4 Preparation Standard Accessories ... 4 Optional Accessory ... 4 Controls and Components... 5 Attaching the Neck Strap... 5 Power Supply ... 6 Using AC Adaptor ... 6 Using the Battery ...

  • Page 3: Information For Your Safety

    Dear Customer, We would like to take this opportunity to thank you for purchasing this Panasonic SD Multi AV Device. Please read these Operating Instructions carefully and keep them handy for future reference. Information for Your Safety WARNING TO REDUCE THE RISK OF FIRE OR SHOCK...

  • Page 4: Introduction

    Home Edition/XP Professional), Adobe (VFF0139) Panasonic Media Manager (Real Jukebox (VFF0149) ≥For the installation and the operation of the Panasonic Media Manager, refer to the additional instructions supplied in the same package. ≥For using the SD-MovieStage software, refer to the PDF manual.

  • Page 5: Controls And Components

    2) 3) DC IN 4.8V Ë Controls and Components 1) LCD Monitor (l 7) 2) Recording Start/Stop Button (l 14, 16, 18) 3) Card Slot Cover (l 7) 4) Card Slot (l7) 5) Card Access Lamp (l 7) 6) Power ON/OFF Button [ ] (l 8) Menu Button [MENU] (l 9) 7) Power Lamp (l 8)

  • Page 6: Power Supply

    DC IN 4.8V Using the Battery DC IN 4.8V Removing the Battery Power Supply ª Using AC Adaptor Connect the AC Main Lead to the AC Adaptor and the AC main socket. Connect the DC Input Lead to the [DC IN 4.8V] socket on the SD Multi AV Device.

  • Page 7: Inserting A Card

    Inserting a Card Removing the Card Inserting a Card Slide the Card Slot Cover , and flip it to open. ≥Turn off the SD Multi AV Device before inserting a Card. Hold the Memory Card placing the cut off corner left and showing the label frontward, and then insert it fully until it clicks.

  • Page 8: Turning The Power On

    PLAY VOICE MPEG4 PICTURE Turning the Power ON Install the battery or plug in the AC adaptor. (l 6) Hold down the [ ≥The SD Multi AV Device is turned on. ≥The message [PLEASE WAIT] is displayed for a while and then the mode selection screen will be displayed.

  • Page 9: Using The Menu Screen

    3,4,5 PICTURE RECORD RECORDING SETUP OTHER FUNCTIONS PRESS MENU TO EXIT RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY PRESS MENU TO RETURN ª REC MODE MPEG4 RECORD RECORDING SETUP OTHER FUNCTIONS PICTURE RECORD " RECORDING SETUP OTHER FUNCTIONS VOICE RECORD FUNCTIONS Using the Menu Screen Allows the functions useable in the selected mode to be set from the...

  • Page 10: Playback Mode

    Sub-Menu for REC MODE RECORDING SETUP MPEG4 MODE FINE NORMAL ECONOMY1 ECONOMY2 OTHER FUNCTIONS DATE/TIME DATE DISPLAY LCD SET LCD MONITOR NORMAL UPSIDE-DOWN AC MAINS 50HZ 60HZ CLOCK SET PRESS MENU TO RETURN RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY OTHER FUNCTIONS DATE/TIME...
  • Page 11 Sub-Menu for PLAYBACK CARD EDITING ERASE ALL FILES FILE PROTECTION CARD FORMAT OTHER FUNCTIONS DATE/TIME DATE DISPLAY LCD SET DISPLAY SIZE FULL NORMAL LCD MONITOR NORMAL UPSIDE-DOWN CLOCK SET PRESS MENU TO RETURN CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT...

  • Page 12: Setting The Power Supply Frequency

    1,2,3 PLAY MPEG4 VOICE PICTURE MPEG4 RECORD RECORDING SETUP OTHER FUNCTIONS PRESS MENU TO EXIT OTHER FUNCTIONS DATE/TIME TIME DISPLAY LCD SET LCD MONITOR NORMAL UPSIDE-DOWN AC MAINS 50HZ 60HZ CLOCK SET PRESS MENU TO RETURN 1/100 1/120 Setting the power supply frequency Set the power supply frequency before using the SD Multi AV Device.

  • Page 13: Adjusting Brightness And Color Level

    1,2,3,4 MPEG4 RECORD RECORDING SETUP OTHER FUNCTIONS PRESS MENU TO EXIT OTHER FUNCTIONS DATE/TIME DATE DISPLAY LCD SET LCD MONITOR NORMAL UPSIDE-DOWN AC MAINS 50HZ 60HZ CLOCK SET PRESS MENU TO RETURN LCD SET BRIGHTNESS COLOR LEVEL PRESS MENU TO RETURN 1,2,3,4 OTHER FUNCTION DATE/TIME...

  • Page 14: Basic Functions

    ≥The MPEG4 moving pictures can be recorded in any mode, but moving pictures recorded in the [FINE], [NORMAL] or [ECONOMY1] mode may not be played on other Panasonic digital video cameras. The message [PUSH THE RESET SWITCH] may be displayed in such case.

  • Page 15: Playing Moving Pictures (Mpeg4)

    1,2,3 PLAY MPEG4 VOICE PICTURE MUSIC MPEG4 . ASF . ASF . ASF . ASF . ASF . ASF OTHER FUNCTIONS DATE/TIME TIME DISPLAY LCD SET DISPLAY SIZE FULL NORMAL LCD MONITOR NORMAL UPSIDE-DOWN CLOCK SET PRESS MENU TO RETURN Playing Moving Pictures (MPEG4) Plays back moving pictures recorded on the card.

  • Page 16: Recording Still Pictures

    1,2,3,4 PLAY VOICE MPEG4 PICTURE PICTURE RECORD RECORDING SETUP OTHER FUNCTIONS PRESS MENU TO EXIT RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY PRESS MENU TO RETURN RECORDING SETUP FLASH PICTURE QUALITY FINE NORMAL ECONOMY PRESS MENU TO RETURN PICTURE R 15 Recording Still Pictures Records still pictures.

  • Page 17: Playing Back Still Pictures

    1,2,3 PLAY MPEG4 VOICE PICTURE MUSIC PICTURE 100 - 0001 100 - 0002 100 - 0003 100 - 0004 100 - 0005 100 - 0006 Playing back Still Pictures Plays back still pictures recorded on the card. Set the Operation Mode to [PLAY>>PICTURE] ≥Still picture files recorded on the card are displayed in the form of a list (six files per page) 2.

  • Page 18: Recording Voice (Voice Recording Function)

    PLAY MPEG4 VOICE PICTURE VOICE 0h10m14s R 0h10m Recording Voice (Voice Recording Function) You can record voice data on the card. Set the Operation Mode to [REC>>VOICE] Press the Recording Start/Stop Button. ≥Recording starts. Speak into the built-in microphone Device. ª...

  • Page 19: Hearing The Voice Recorded (Playback Sound)

    Ë 2,3,4 PLAY MPEG4 VOICE PICTURE MUSIC VOICE . VM1 . VM1 . VM1 . VM1 . VM1 . VM1 Hearing the Voice Recorded (Playback Sound) Plays back the voice files recorded by this SD Multi AV Device. Wear the earphones (supplied) to listen to the sound.

  • Page 20: Listening To Music (Music Play)

    While playing back, move the Jog Lever up or down. ≥Only the MPEG2-AAC formatted file and MP3 (data recorded using Panasonic Media Manager) is applicable to play on your SD Multi AV Device. ≥Music playback is not possible with a MultiMediaCard.

  • Page 21: Using The Earphones

    ≥Normal MP3 files cannot be played back. Use the data created with Panasonic Media Manager. ≥Some MP3 or MPEG2-AAC files which were written with Panasonic Media Manager may not be played back. ≥The bit rates (recommended) supported are 64 kbps, 96 kpbs or 128 kbps for both the MPEG2-AAC and MP3 files.

  • Page 22: Advanced Functions

    PLAY MPEG4 VOICE PICTURE PLAY MPEG4 VOICE PICTURE Advanced Functions Backlight Compensation Function This prevents a recording subject from being recorded too dark in backlight. (Backlight is the light that shines from behind a recording subject.) Set the Operation Mode to [REC>>MPEG4] or [REC>>PICTURE] Move the Jog Lever up for about 1 second.

  • Page 23: Erasing The Files Recorded On A Card

    ERASE CARD FILE FILE PROTECTION DPOF SETTING CHECK EXIT ERASE FILE RETURN CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT PRESS MENU TO RETURN Erasing the Files Recorded on a Card Using SD Multi AV Device, you can erase the files recorded on a Card. After the file is erased, it cannot be restored.

  • Page 24: Protecting Files (File Protection)

    ERASE CARD FILE FILE PROTECTION DPOF SETTING CHECK EXIT 100-0011 100-0012 100-0013 CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT PRESS MENU TO RETURN FILE PROTECTION LOCK ALL FILES UNLOCK ALL FILES PRESS MENU TO RETURN Protecting files (File Protection) Precious files recorded on a Card can be locked (to prevent accidental erasure).

  • Page 25: Writing Printing Data On A Card (Dpof Setting)

    ERASE CARD FILE FILE PROTECTION DPOF SETTING CHECK EXIT DPOF SETTING 100-0011 100-0012 100-0013 CARD EDITING ERASE ALL FILES FILE PROTECTION DPOF SETTING SLIDE SHOW CARD FORMAT PRESS MENU TO RETURN DPOF SETUP ALL 1 ALL 0 CHECK PRESS MENU TO RETURN Writing Printing Data on a Card (DPOF Setting) DPOF Setting Printing data (DPOF Setting), such as the number of...

  • Page 26: Playing Back Still Pictures One By One (Slide Show)

    ≥By formatting, all data stored in the Card (e.g., still pictures, MPEG4 moving pictures, voice data, music data) is erased. ≥Format the Card on the SD Multi AV Device or on Panasonic Media Manager (supplied). A card formatted on a machine other than the SD Multi AV Device may not be used.

  • Page 27: For Using Sd-Moviestage

    For using SD-MovieStage SD-MovieStage The SD-MovieStage (supplied accessory) functions as follows. ≥MPEG4 moving pictures (ASF-format files) and still pictures (JPEG pictures) recorded on the SD Multi AV Device are displayed in thumbnail form and can be easily played back on a personal computer. ≥MPEG4 moving pictures (ASF-format files) can be Cut-edited.

  • Page 28: Installing Sd-Moviestage

    Installing SD-MovieStage Insert the supplied CD-ROM into the personal computer’s CD-ROM drive. Double-click [My Computer], double-click CD-ROM icon, double-click [SD-MovieStage Ver.1.0U], and double-click [SETUP.EXE]. Click the [Next] Button. ≥The next screen will be displayed. Read License Agreement carefully, and click [Yes] Button, if you accept the terms of the agreement.

  • Page 29: Cautions For Windows Xp/2000 Professional

    Connect the USB Reader/Writer to the computer’s USB port. ≥The driver for the USB Reader/Writer is enabled automatically. ≥If you use Windows 98SE, install Panasonic Media Manager (supplied accessory) before using the SD-MovieStage. Taking care that the card is facing the right way, insert the SD memory card into the USB Reader/Writer.

  • Page 30: Others

    DC IN 4.8V Others Notes & Precautions ª Charge the built-in battery for maintaining the date information This built-in battery is used for the memory of date and time. If [0] is displayed when the power is on, the built-in battery may be exhausted. Charge using the following procedure: Take the battery out and plug in the AC adapter (l 6).

  • Page 31: Using A Card In A Personal Computer

    ≥When formatting a Card, format it on the SD Multi AV Device or on Panasonic Media Manager. ≥When a moving picture is played back on a personal computer, a black belt may be present along the top and bottom of the picture.

  • Page 32: Indications

    MPEG4 CARD LOCKED 12:30:10PM 0h10m14s APR 10 2002 R 0h10m Indications 1) Remaining Battery Power [ When the battery power becomes low, the indication changes. When the battery level indicator indicates ], the battery will run out in a few minutes. Recharge the battery.

  • Page 33: Cautions For Use

    9) Displayed by the text [LOW BATTERY]: The battery may be exhausted. Replace it with a fully charged battery or recharge the supplied battery. [NO CARD]: The Memory Card is not inserted, or the Card may not be inserted correctly. [CARD FULL]: The memory capacity is fully utilized.

  • Page 34: About The Lens

    Do not use benzine, thinner or alcohol for cleaning the SD Multi AV Device. ≥The camera body may be deformed and the surface finish may peel off. ≥Before cleaning, detach the Battery or pull out the AC Main Lead from the AC Main socket. ≥Wipe the SD Multi AV Device with a soft dry cloth.

  • Page 35: Notes On The Sd Memory Card Write-Protect Switch

    The flashing speed suggests the following states. Flashing approx. every 0.5 seconds: ≥The SD Multi AV Device, battery or AC adaptor may be defective. Contact your nearest Panasonic dealer. Flashing approx. every six seconds: ≥The ambient temperature or that of the battery itself is too high or too low.

  • Page 36: Before Requesting Service

    Before Requesting Service Power The SD Multi AV Device power cannot be turned Is the power source connected correctly? The SD Multi AV Device power shuts off automatically. If you do not use the SD Multi AV Device for more than 10 minutes, the power shuts off automatically to save the Battery power.

  • Page 37: Specifications

    Specifications SD Multi AV Device (Panasonic SV-AV10U) Power Source: Power Consumption: Image Sensor: Lens: Monitor: Microphone: Standard Illumination: Minimum Required Illumination: Recording Media: Image Compression: Video Compression: Voice Compression: Music Expansion Dimensions: Weight: Operating Temperature: Operating Humidity: AC Adaptor (Panasonic VSK0620)

  • Page 38: Limited Warranty (For U.s.a. Only)

    One Panasonic Way Secaucus, New Jersey 07094 Limited Warranty Coverage If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as “the warrantor”) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (“warranty period”), at its option either (a)

  • Page 39: Customer Services Directory (For U.s.a. Only)

    Customer’s in Puerto Rico, please ship or carry in to location below (“Service in Puerto Rico”). Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/ Factory Servicenter: Ave. 65 de Infantería, Km. 9.5 San Gabriel Industrial Park, Carolina, Puerto Rico 00985 Phone (787) 750-4300 Fax (787) 768-2910 Monday-Friday 9am-9pm Saturday-Sunday 9am-7pm, EST.

  • Page 40: Spanish Quick Use Guide/Guía Española Para El Uso Rápido

    DC IN 4.8V DC IN 4.8V Spanish Quick Use Guide/Guía española para el uso rápido Spanish Quick Use Guide/Guía española para el uso rápido Alimentación eléctrica ª Utilización del adaptador AC Conectar el cable principal AC al adaptador AC y a la toma de corriente principal AC.
  • Page 41 PLAY MPEG4 VOICE PICTURE 3,4,5,6 PLAY MPEG4 VOICE PICTURE MUSIC MPEG4 . ASF . ASF . ASF . ASF . ASF . ASF Grabacion de imágenes dinámicas (MPEG4)/ imágenes estáticas/la voz Pulsar el botón [MODE]. ≥Aparece la pantalla de selección de modo 1 . ≥La pantalla de selección de modo aparece también cuando se enciende el dispositivo.
  • Page 44 Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America One Panasonic Way, Secaucus, NJ 07094 Panasonic Sales Company ("PSC") Division of Matsushita Electric of Puerto Rico, Inc. Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park, Carolina, Puerto Rico 00985 Panasonic Canada Inc.
