Operation manual Daikin room air conditioner FTXJ20A2V1BW FTXJ25A2V1BW FTXJ35A2V1BW FTXJ42A2V1BW FTXJ50A2V1BW FTXJ20A2V1BS FTXJ25A2V1BS FTXJ35A2V1BS FTXJ42A2V1BS FTXJ50A2V1BS FTXJ20A2V1BB FTXJ25A2V1BB FTXJ35A2V1BB Operation manual FTXJ42A2V1BB English Daikin room air conditioner FTXJ50A2V1BB... -
Page 2: Table Of Contents
To start/stop Powerful operation ......... 12 Latest revisions of the supplied documentation may be available on Econo operation ................ 12 the regional Daikin website or via your installer. 5.7.1 To start/stop Econo operation........12 The original documentation is written in English. All other languages Outdoor unit quiet operation............ - Page 3 Chemicals could collect in the unit, and endanger the health of and fitting for damage. If damaged, the people who are hypersensitive to unit may fall and result in injury. chemicals. FTXJ-A(W)(S)(B) Operation manual Daikin room air conditioner 3P485919-15W – 2021.12...
-
Page 4: About The System
10 seconds, it returns to the colour of the operation works of art. mode for 3 minutes. Example: When the timer is set during cooling operation, the Daikin eye will periodically light orange for 10 seconds, and then switch to blue for 3 minutes. Operation manual... -
Page 5: About The User Interface
OFF the operation, all timer functions are OFF. Replace the batteries as soon as possible. ▪ ALWAYS replace both batteries together. FTXJ-A(W)(S)(B) Operation manual Daikin room air conditioner 3P485919-15W – 2021.12... -
Page 6: To Mount The Wireless Remote Control Magnetic Holder
1 Make sure the operation is OFF. If not, turn it OFF using 3 Follow the directions on the screen to install. 2 In the indoor unit setting menu, navigate to the open the front panel screen using Operation manual FTXJ-A(W)(S)(B) Daikin room air conditioner 3P485919-15W – 2021.12... - Page 7 1 Navigate to WPS screen by . Press to confirm selection. INFORMATION Result: The Daikin eye colour alternates between orange and partly Make sure operation is stopped before setting the wireless green. connection. Connection CANNOT be made when the unit WPS setting is in operation.
-
Page 8: Vertical Airflow Function
. Press to confirm your return to “indoor unit setting menu”. selection. To confirm the wireless LAN connection status Result: The Daikin eye alternates between green and white. Communication is OFF. 1 Navigate to the status screen using . Press confirm. -
Page 9: Operation Mode And Temperature Setpoint
2 Press to start operation. When. Adjust the system operation mode and set the temperature 3 The home screen changes as follows and the Daikin eye when you want to: indication lamp goes ON. ▪ Heat up or cool down a room Home screen when unit is ON during…... -
Page 10: To Adjust The Airflow Rate
The unit will automatically change the direction of the airflow to heat up or cool down the room more effectively. Direct airflow from the unit will be less noticeable. Operation manual FTXJ-A(W)(S)(B) Daikin room air conditioner 3P485919-15W – 2021.12... -
Page 11: To Adjust Vertical Airflow Direction
1 Set the vertical and the horizontal airflow to ON. appears on the bottom of the home screen. The flaps (horizontal blades) and louvers (vertical blades) will begin to swing. FTXJ-A(W)(S)(B) Operation manual Daikin room air conditioner 3P485919-15W – 2021.12... -
Page 12: Powerful Operation
Econo operation will NOT further reduce power Note: remains on the home screen, even if you turn off the unit consumption. using the wireless remote control or indoor unit ON/OFF switch. Operation manual FTXJ-A(W)(S)(B) Daikin room air conditioner 3P485919-15W – 2021.12... -
Page 13: Flash Streamer (Air Cleaning) Operation
To set the clock 1 In the clock and timer setting menu, navigate to the clock setting screen using . Enter the setting using 2 Press to enter the OFF timer setting menu. FTXJ-A(W)(S)(B) Operation manual Daikin room air conditioner 3P485919-15W – 2021.12... -
Page 14: Weekly Timer Operation
The set time is displayed on the ON timer screen in the main menu. The setting using in 10-minute intervals. Daikin eye lights orange. The unit will turn ON after the set time. Change CANCEL to Set hours Set minutes... -
Page 15: Energy Saving And Optimum Operation
1 To delete individual entries, change the setting to DEL and your selection. confirm using Result: The Daikin eye lights orange. Settings for the first day of the week will display (4 entries for each day). Result: The day of the week with 4 day entries is displayed. -
Page 16: To Clean The Indoor Unit And Wireless Remote Control
After a long use, check the unit stand and fitting for 5 Open the front panel until the support fits into the fixing tab. damage. If damaged, the unit may fall and result in injury. Operation manual FTXJ-A(W)(S)(B) Daikin room air conditioner 3P485919-15W – 2021.12... -
Page 17: To Clean The Air Filters
1 Remove the filter from the tabs of the filter frame and replace the filter with a new one. 5 Soak in lukewarm water for about 10 to 15 minutes. FTXJ-A(W)(S)(B) Operation manual Daikin room air conditioner 3P485919-15W – 2021.12... -
Page 18: To Close The Front Panel
2 Lift the front panel slightly and remove the support from the well. supply. fixing tab. The Daikin eye flashes and you can Notify your installer and check the error code by the wireless report the error code. remote control. To display the error code see the user reference guide of the indoor unit. - Page 20 3P485919-15W 2021.12 Verantwortung für Energie und Umwelt...
