Page 1: Operation Manual
DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL MODELS FTXJ25PVMAW FTXJ35PVMAW FTXJ50PVMAW FTXJ25PVMAS FTXJ35PVMAS FTXJ50PVMAS... -
Page 2: Intelligent Eye
Features Enhanced comfort and energy Enhanced comfort and energy savings savings INTELLIGENT EYE The INTELLIGENT EYE sensor detects human movement in a room. If no one is in the room for more than 20 minutes, the operation automatically changes to energy saving operation. Page 15 WEEKLY TIMER Up to 4 timer settings can be saved for each day of the week... -
Page 3: Table Of Contents
Contents Read Before Operatio n Safety Precautions ......... Names of Parts ..........Preparation Before Operation ......Operatio n AUTO · DRY · COOL · HEAT · FAN Operation ........... Adjusting the Airfl ow Direction and Rate ..........COMFORT AIRFLOW / INTELLIGENT EYE Operation ... -
Page 4: Safety Precautions
Safety Precautions Read the precautions in this manual carefully This appliance is fi lled with R32. before operating the unit. • Keep this manual where the user can easily fi nd it. • The precautions described herein are classifi ed as WARNING and CAUTION. They both contain important information regarding safety. - Page 5 CAUTION • Do not sit on the outdoor unit, put things on the unit, or pull the unit. Doing so may cause accidents, such as falling or toppling down, thus resulting in injury, product malfunctioning, or product damage. • Do not place objects that are susceptible to moisture directly beneath the indoor or outdoor units. Under certain conditions, condensation on the main unit or refrigerant pipes, air fi...
-
Page 6: Names Of Parts
Names of Parts Indoor Unit INTELLIGENT EYE sensor • Appearance of the indoor unit may differ. Air inlet • Detects the movements of people and automatically switches between normal operation and energy saving operation. Page 15-17 Upper front panel Indoor temperature sensor Air outlet •... - Page 7 Open the upper front panel Back of the upper front panel Panel support plate Lower front panel Air fi lter Titanium apatite photocatalytic air-purifying fi lter Outdoor Unit • The appearance of the outdoor unit may differ between different models. Outdoor temperature Air inlet sensor (back)
-
Page 8: Front Cover
Names of Parts Remote Controller Signal transmitter Receiver 50cm or more Display (LCD) • Displays the current settings. • To use the remote controller, aim the (In this illustration, each section is transmitter at the indoor unit. If there shown with its displays on for the is anything blocking the signals purpose of explanation.) between the unit and the remote... -
Page 9: Night Set Mode
Open the front cover MODE selector button • Selects the operation mode. (AUTO/DRY/COOL/HEAT/ FAN) Page 11 ECONO/QUIET button • ECONO/OUTDOOR UNIT Lamp brightness QUIET operation. Page 19 setting button Page 9 SWING button • Adjusts the airfl ow direction COMFORT/SENSOR Page 13 button •... -
Page 10: Preparation Before Operation
Preparation Before Operation To insert the batteries Position Slide the front cover to take it off. – correctly! Insert 2 dry batteries AAA.LR03 (alkaline). Replace the front cover. To fi x the remote controller holder to a wall Choose a place from where the signals Remote controller reach the unit. - Page 11 Turn on the circuit breaker • After the power is turned on, the fl aps of the indoor unit open and close once to set the reference position. To set the clock Press • “ ” is displayed on the LCD. •...
-
Page 12: Operation
AUTO · DRY · COOL · HEAT · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. To start operation Press and select an operation mode. - Page 13 To change the temperature setting Press • The displayed items on the LCD will change whenever either one of the buttons is pressed. COOL operation HEAT operation AUTO operation DRY or FAN operation 18-32°C 10-30°C 18-30°C The temperature setting Press to raise the temperature and press to lower the cannot be changed.
-
Page 14: Adjusting The Airfl Ow Direction And Rate
Adjusting the Airfl ow Direction and Rate You can adjust the airfl ow direction to increase your comfort. To start auto swing Up and down airfl ow direction Press • “ ” is displayed on the LCD. • The fl aps (horizontal blades) will begin to swing. Right and left airfl... - Page 15 To adjust the airfl ow rate setting Press • Each pressing of advances the airfl ow rate setting in sequence. AUTO Indoor unit quiet Middle low High Middle high Middle • When the airfl ow is set to “ ”, quiet operation starts and noise from the indoor unit will become quieter.
-
Page 16: Comfort Airflow / Intelligent Eye Operation
COMFORT AIRFLOW / INTELLIGENT EYE Operation COMFORT AIRFLOW operation The airfl ow direction is upward while in COOL operation, and downward while in HEAT operation. This function prevents cold or warm air from blowing directly on the occupants in the room. COOL operation HEAT operation INTELLIGENT EYE operation... -
Page 17: Intelligent Eye Operation
To start operation Press and select the desired mode. • Each time is pressed, a different setting option is displayed on the LCD. • The INTELLIGENT EYE lamp lights green. Display • By selecting “ ” from the following icons, the air conditioner will switch to COMFORT AIRFLOW operation combined with INTELLIGENT EYE operation. - Page 18 COMFORT AIRFLOW / INTELLIGENT EYE Operation NOTE Notes on COMFORT AIRFLOW operation • The position of the fl aps will change, preventing air from blowing directly on the occupants of the room. • POWERFUL operation and COMFORT AIRFLOW operation cannot be used at the same time. Priority is given to the function of whichever button is pressed last.
-
Page 19: Powerful Operation
POWERFUL Operation POWERFUL operation quickly maximizes the cooling (heating) effect in any operation mode. In this mode, the air conditioner operates at maximum capacity. To start POWERFUL operation Press during operation. • “ ” is displayed on the LCD. • POWERFUL operation ends in 20 minutes. -
Page 20: Econo / Outdoor Unit Quiet Operation
ECONO / OUTDOOR UNIT QUIET Operation ECONO operation ECONO operation is a function which enables effi cient operation by limiting the maximum power consumption value. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit. - Page 21 To start operation Press and select the desired mode. • Each time is pressed, a different setting option is displayed on the LCD. blank ECONO OUTDOOR UNIT Combination No Setting QUIET To cancel operation Press until no icon is displayed. NOTE Notes on ECONO operation •...
-
Page 22: Off Timer Operation
OFF TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off at night or in the morning. You can also use OFF TIMER and ON TIMER together. To use OFF TIMER operation • Check that the clock is correct. If not, set the clock to the present time. -
Page 23: On Timer Operation
ON TIMER Operation To use ON TIMER operation • Check that the clock is correct. If not, set the clock to the present time. Page 10 Press • “ ” is displayed on the LCD. • “ ” blinks. • “... -
Page 24: Weekly Timer Operation
WEEKLY TIMER Operation Up to 4 timer settings can be saved for each day of the week. This is convenient to adapt the WEEKLY TIMER to your family’s life style. Setting example of the WEEKLY TIMER The same timer settings are used from Monday through Friday, while different timer settings are used for the weekend. Make timer settings for programmes 1-4. - Page 25 To use WEEKLY TIMER operation Setting mode • Make sure the day of the week and time are set. If not, set the day of the week and time. Page 10 Programme 1 Programme 2 Programme 3 Programme 4 [Monday] 25°C 27°C 6:00...
- Page 26 WEEKLY TIMER Operation Press to select the desired time. • The time can be set between 0:00 and 23:50 in 10-minute intervals. • To return to the ON/OFF TIMER mode setting, press • Proceed to step when setting the OFF TIMER. Press •...
- Page 27 Copy mode • A reservation made once can be copied to another day of the week. The whole reservation of the selected day of the week will be copied. Programme 1 Programme 2 Programme 3 Programme 4 [Monday] 25°C 27°C 6:00 8:30 17:30...
- Page 28 WEEKLY TIMER Operation Confi rming a reservation • The reservation can be confi rmed. Setting Displays Normal Confi rmation Press • The day of the week and the reservation number of the current day will be displayed. Press to select the day of the week and the reservation number to be confi...
- Page 29 To delete reservations An individual reservation Press • The day of the week and the reservation number will be displayed. Press to select the day of the week and the reservation number to be deleted. Press • “ ” and “ ”...
-
Page 30: Care And Cleaning
Care and Cleaning Quick reference How to open the upper front panel How to close the upper front panel • Hold the upper front panel by the sides and open it. • Return the panel support plate to its previous position. •... - Page 31 Air fi lter Pull out the air fi lters. If the dust does not come off easily • Open the upper front panel. • Wash the air fi lters with neutral detergent thinned with • Set the panel support plate between the ribs on lukewarm water, then let them dry in the shade.
- Page 32 Care and Cleaning Titanium apatite photocatalytic air-purifying fi lter Take off the titanium Set the fi lters as they were and apatite photocatalytic air- close the upper front panel. purifying fi lters. • Return the panel support plate to its previous position. •...
-
Page 33: Air Conditioner
Check the units Check that the base, stand and other fi ttings of the outdoor unit are not decayed or corroded. Check that nothing blocks the air inlets and the outlets of the indoor unit and the outdoor unit. Check that the drain comes smoothly out of the drain hose during COOL or DRY operation. •... -
Page 34: Troubleshooting
Troubleshooting These cases are not troubles. • The following cases are not air conditioner troubles but have some reasons. You may just continue using it. Indoor unit The fl aps do not start swinging immediately. • The air conditioner is adjusting the position of the fl... - Page 35 • Before making an inquiry or a request for repair, please Operation stopped suddenly. check the following. If the problem persists, consult your dealer. (Multi-monitor lamp is blinking.) Not trouble • Are the air fi lters dirty? Clean the air fi lters. •...
- Page 36 Troubleshooting Hot air does not fl ow out soon after The outdoor fan rotates while the the start of HEAT operation. air conditioner is not in operation. Immediately after the air conditioner is • The air conditioner is warming up. Wait for about 1 to 4 stopped minutes.
-
Page 37: Disposal Requirements
Call your dealer immediately WARNING When an abnormality (such as a burning smell) occurs, stop operation and turn off the circuit breaker. • Continued operation in an abnormal condition may result in troubles, electric shocks or fi re. • Consult the dealer where you bought the air conditioner. Do not attempt to repair or modify the air conditioner by yourself. - Page 38 Troubleshooting Fault diagnosis by remote controller • The remote controller can receive relevant error codes from the indoor unit. When is held down for about 5 seconds, “ ” blinks in the temperature display section. Press repeatedly until a continuous beep is produced.
- Page 39 Memo...
- Page 40 Quick Reference The two-dimensional bar code is a manufacturing code. 3P369488-1 M13B312 (1406) HT...
